Green roofs to Mitigate the Urban Heat Island Adewunmi Fareo, Tim Myers, Neville Fowkes, Graeme Hocking Hermane Mambili, Narenee Mewalal, Sicelo Goqo, Tresia Holtzhausen MISG2020 January 17, 2020 1 / 19

Introduction Urban Heat Island 2 / 19

Introduction 3 / 19

Mathematical Model The use of green roofs to reduce Urban heat Island AIM: How much energy is absorbed over one day? 4 / 19

Model Consider the heat equation ∂ t = k ∂ 2 T ρ c ∂ T ∂ x 2 subject to the following BC’s → T av , as T − x − → ∞ and − k ∂ T ∂ x = (1 − γ ) Q sun + H ( T − T a ) + ǫσ ( T 4 − T 4 a ) − ρ w L e ˙ m Heat flux = heat from sun + convective heat transfer from surface to air + radiative heat transfer to air + evaporative energy 5 / 19

Model Nobody likes T 4 so we linearise − k ∂ T (1 − γ ) Q sun + ( H + 4 ǫσ T 3 = a )( T − T a ) − ρ w L e ˙ m ∂ x (1 − γ ) Q sun − ( H + 4 ǫσ T 3 � � = a ) T a − ρ w L e ˙ m ( H + 4 ǫσ T 3 � � + a ) T 6 / 19

Model Non-dimensionalise T = T − T av x = x t = t ˆ ˆ ˆ ∆ T L τ We choose to work over a time-scale τ = 3600s ∂ 2 T ρ c ∂ T ∂ t = k L 2 ∂ x 2 τ � Hence L = k τ/ρ c ≈ 4cm 7 / 19

Model − k ∆ T ∂ T (1 − γ ) Q sun − ( H + 4 ǫσ T 3 � � = a )( T av − T a ) − ρ w L e ˙ m ∂ x L ( H + 4 ǫσ T 3 � � + a ) ∆ T . T Here we may choose ∆ T as the whole of the first square bracket or (1 − γ ) Q sun . Find ∆ T ≈ 10K. With whole of first bracket − ∂ T = 1 + β T ∂ x where � L ( H + 4 ǫσ T 3 � β = a ) k 8 / 19

Approximate Solution A fundamental solution using Green’s functions is given by: x 2 − � t 4 k ′ ( t − t ′ ) 1 q ( t ′ ) e dt ′ T ( x , t ) = √ √ t − t ′ ρ c π k 0 where q represents the heat flux. Then on the surface we have: � t q ( t ′ ) 1 t − t ′ dt ′ T (0 , t ) = T s ( t ) = √ √ ρ c π k 0 9 / 19

Approximate solution We get : � t 1 + β T s ( t ′ ) dt ′ , T s ( t ) = √ t − t ′ 0 An approximate solution is found by setting β = 0. T s = 2 √ t , putting this expression back in the equation above and integrating for τ s gives √ √ √ T s ( t ) = 2 t − 2 2 β 1 − t , 10 / 19

Approximate solution 11 / 19

Laplace Transform An exact solution may be found to the system using Laplace transforms � x � x � � �� T = 1 √ e β ( β ( t − x )) erfc 2 √ t − β t − erfc 2 √ t β From this we see the exact behaviour of the temperature with space and time The solution apears to be controlled only by β , but the temperature scale depends on values we wish to change (1 − γ ) Q sun − ( H + 4 ǫσ T 3 � � ∆ T = a )( T av − T a ) − ρ w L e ˙ m L / k ( H + 4 ǫσ T 3 � � β = a ) L / k β ≈ 0 . 03 12 / 19

Laplace Transform Can compare with surface solution by first setting β → 0 � x � � t T = 2 e − x 2 / (4 t ) π − x erfc + O ( β ) 2 √ t At x = 0 � t π + β t + O ( β 2 ) T = 2 Leading order ∝ √ t as with previous. Easy to carry on the series 13 / 19

Solution Temperature variation with air at 25C, average temperature 20C after 2 and 10 hours. Also shown is 10 hour curve with evaporation rate of 2mm/12 hours. 14 / 19

So, how can we use this? The energy absorbed/unit area is � ∞ E = ρ c ( T − T av ) dx 0 We may plot this over time, to see the increase during the day or ... Calculate E for different scenarios, changing albedo, adding evaporation etc This will then tell us how much we may change the energy storage in a city under different scenarios. 15 / 19

Solution Effect of changing albedo 16 / 19

Solution Fixed albedo γ = 0 . 15, with evaporation 17 / 19

Conclusion Can find exact solution for temperature in a semi-infinite concrete slab (could also do finite). Green roofs/cool roofs do not have a noticeable effect in the street (if roof above 10m). Actual temperature profile in a city way beyond our skills but ... Exact solution allows us to find differences in absorbed energy and shows effect of albedo and evaporation. Most important terms in (1 − γ ) Q sun − ( H + 4 ǫσ T 3 � � � a )( T av − T a ) − ρ w L e ˙ τ/ρ ck m Green roofs can reduce heat (soil layer will absorb much less heat). Evaporation also helps. High reflective/cool roofs may reflect more heat away. However, green roofs as well as reducing heat absorption also reduce CO2 and provide habitat for birds and insects. 18 / 19

The End 19 / 19
