Graphical Perception Nam Wook Kim Mini-Courses January @ GSAS 2018 What is graphical perception? The visual decoding of information encoded on graphs Why important? Graphical excellence is that which gives to the viewer the greatest

slide-1

SLIDE 1

Graphical Perception

Nam Wook Kim Mini-Courses — January @ GSAS 2018

slide-2

SLIDE 2

The visual decoding of information encoded on graphs

What is graphical perception?

slide-3

SLIDE 3

Why important?

slide-4

SLIDE 4

“Graphical excellence is that which gives to the viewer the greatest number of ideas in the shortest time with the least ink in the smallest space” — Edward Tufte

slide-5

SLIDE 5

Goal

Understand the role of perception in visualization design

slide-6

SLIDE 6

Topics

Signal Detection
Magnitude Estimation
Pre-Attentive Processing
Using Multiple Visual Encodings
Gestalt Grouping
Change Blindness

slide-7

SLIDE 7

Signal Detection

slide-8

SLIDE 8

Detecting Brightness

Which is brighter? A B

slide-9

SLIDE 9

(128,128,128) (144,144,144)

A B

Detecting Brightness

slide-10

SLIDE 10

Detecting Brightness

Which is brighter? A B

slide-11

SLIDE 11

(138,138,138) (134,134,134)

Detecting Brightness

A B

slide-12

SLIDE 12

Weber’s Law

Just Noticeable Difference (JND)

dp = k dS S

slide-13

SLIDE 13

Weber’s Law

Just Noticeable Difference (JND)

dp = k dS S

Physical Intensity Change of Intensity

slide-14

SLIDE 14

Weber’s Law

Just Noticeable Difference (JND)

dp = k dS S

Physical Intensity Change of Intensity Perceived Change

slide-15

SLIDE 15

Weber’s Law

Just Noticeable Difference (JND)

dp = k dS S

Physical Intensity Change of Intensity Perceived Change

Most continuous variation in stimuli are perceived in discrete steps

slide-16

SLIDE 16

Ranking correlation visualizations

[Harrison et al 2014]

slide-17

SLIDE 17

slide-18

SLIDE 18

[Harrison et al 2014]

Which of the two appeared to be more highly correlated?

Ranking correlation visualizations

A B

slide-19

SLIDE 19

r = 0.7 r = 0.6

Which of the two appeared to be more highly correlated?

Ranking correlation visualizations

slide-20

SLIDE 20

Which of the two appeared to be more highly correlated?

Ranking correlation visualizations

A B

slide-21

SLIDE 21

Which of the two appeared to be more highly correlated?

Ranking correlation visualizations

r = 0.7 r = 0.65

slide-22

SLIDE 22

Ranking visualizations for depicting correlation

[Harrison et al 2014] Overall, scatterplots are the best for both positive and negative correlations. Parallel coordinates are only good for negative correlations .

slide-23

SLIDE 23

Magnitude Estimation

slide-24

SLIDE 24

A Quick Experiment…

slide-25

SLIDE 25

A B

slide-26

SLIDE 26

A B

slide-27

SLIDE 27

A B Area

slide-28

SLIDE 28

A B

Length

slide-29

SLIDE 29

Steven’s Power Law

[Graph from T. Munzner 2014]

S = I p

Physical Intensity Perceived Sensation Exponent (Empirically Determined) Predicts bias, not necessarily accuracy! Models the relationship between the magnitude of a physical stimulus and its perceived intensity.

slide-30

SLIDE 30

[Graph from T. Munzner 2014]

Overestimate Underestimate Unbiased

Steven’s Power Law

slide-31

SLIDE 31

Apparent Magnitude Scaling

To compensate for human error in interpreting scale because people tend to underestimate area

× 1 0.7

Cartography: Thematic Map Design, Figure 8.6, p. 170, Dent, 96

slide-32

SLIDE 32

Graphical Perception [Cleveland & McGill 84]

What percentage of the smaller was of the larger?

slide-33

SLIDE 33

Graphical Perception [Cleveland & McGill 84]

What percentage of the smaller was of the larger?

Compare positions   (along common scale) Compare lengths

slide-34

SLIDE 34

slide-35

SLIDE 35

https://ig.ft.com/science-of-charts/

slide-36

SLIDE 36

slide-37

SLIDE 37

[T. Munzer 2014]

Effectiveness Ranking of Visual Encoding Variables

for comparing numerical quantities

slide-38

SLIDE 38

Pre-Attentive Processing

slide-39

SLIDE 39

How Many 3’s?

1281768756138976546984506985604982826762 9809858458224509856458945098450980943585 9091030209905959595772564675050678904567 8845789809821677654876364908560912949686

[based on a slide from J. Stasko]

slide-40

SLIDE 40

1281768756138976546984506985604982826762 9809858458224509856458945098450980943585 9091030209905959595772564675050678904567 8845789809821677654876364908560912949686

How Many 3’s?

[based on a slide from J. Stasko]

slide-41

SLIDE 41

The ability of the low-level human visual system to effortlessly identify certain basic visual properties.

Pre-attentive processing

slide-42

SLIDE 42

Visual Pop-Out: Color

Christopher Healey, https://www.csc.ncsu.edu/faculty/healey/PP/index.html

slide-43

SLIDE 43

Visual Pop-Out: Shape

Christopher Healey, https://www.csc.ncsu.edu/faculty/healey/PP/index.html

slide-44

SLIDE 44

and many more…

Christopher Healey, https://www.csc.ncsu.edu/faculty/healey/PP/index.html

slide-45

SLIDE 45

No unique visual property of the target

Feature Conjunctions

Consistent Inconsistent

Christopher Healey, https://www.csc.ncsu.edu/faculty/healey/PP/index.html

slide-46

SLIDE 46

Pre-attentive Conjunctions

Most conjunctions are not pre-attentive. Some spatial conjunctions are pre-attentive.

Motion and color
Motion and shape
Motion and 3D disparity
3D disparity and color
3D disparity and shape

slide-47

SLIDE 47

Multiple Attributes

slide-48

SLIDE 48

One-Dimensional: Lightness

White Black White Black White White White Black Black White

r

Classify objects based on lightness

slide-49

SLIDE 49

Square Circle Circle Circle Square Circle Circle Circle Square Circle

r

One-Dimensional: Shape

Classify objects based on shape

slide-50

SLIDE 50

Redundant: Shape & Lightness

Circle Square Square Square Circle Circle Circle Square Square Square

r

Classify objects based on shape. Easier?

slide-51

SLIDE 51

Orthogonal: Shape & Lightness

Circle Circle Square Square Circle Classify objects based on shape. Difficult?

slide-52

SLIDE 52

Orthogonal: Shape & Lightness

Circle Circle Square Square Circle Classify objects based on lightness. Difficult?

slide-53

SLIDE 53

Speeded Classification

Redundancy Gain Facilitation in reading one dimension when the other provides redundant information. Filtering Interference Difficulty in ignoring one dimension while attending to the

ther.

slide-54

SLIDE 54

Speeded Classification

R: Redundant Encoding 1: One-dimensional O: Orthogonal Encoding

Stable

White White Black White Black

slide-55

SLIDE 55

Speeded Classification

R: Redundant Encoding 1: One-dimensional O: Orthogonal Encoding

Interference Gain

Circle Square Square Square Circle

slide-56

SLIDE 56

Types of Perceptual Dimensions

Integral Filtering interference and redundancy gain Separable No interference or gain Asymmetric One dimension separable from other, not vice versa e.g., Lightness was not really influenced by shape

slide-57

SLIDE 57

Separability vs. Integrality

2 groups each

[Tamara Munzner 14]

What we perceive:

Position Hue (Color) Fully separable

slide-58

SLIDE 58

Separability vs. Integrality

2 groups each

[Tamara Munzner 14]

What we perceive:

Position Hue (Color) Fully separable Position Hue (Color) Size Hue (Color) Fully separable Some interference

2 groups each

slide-59

SLIDE 59

Separability vs. Integrality

2 groups each

[Tamara Munzner 14]

What we perceive:

Position Hue (Color) Fully separable Position Hue (Color) Size Hue (Color) Fully separable Some interference Position Hue (Color) Size Hue (Color) Width Height Fully separable Some interference Some/signifjcant interference

2 groups each 3 groups total: integral area

slide-60

SLIDE 60

Separability vs. Integrality

2 groups each 2 groups each 3 groups total: integral area 4 groups total: integral hue

Position Hue (Color) Size Hue (Color) Width Height Red Green Fully separable Some interference Some/signifjcant interference Major interference

[Tamara Munzner 14]

What we perceive:

slide-61

SLIDE 61

Not about good or bad

Match the characteristics of the channels to the information that is encoded. For a single data attribute with three categories, this may work just fine: small, flattened, and large.

[Tamara Munzner 14]

slide-62

SLIDE 62

Gestalt Grouping

slide-63

SLIDE 63

Principles of Perceptual Organization

Similarity Proximity Uniformed Connectedness Connection Enclosure Continuity Symmetry and there are more not covered here…

slide-64

SLIDE 64

Proximity

Columns Rows

slide-65

SLIDE 65

Similarity

Rows stand out due to similarity.

slide-66

SLIDE 66

Scatter Plot Matrix Clusters and outliers

slide-67

SLIDE 67

Uniformed Connectedness: Connection

Connectedness dominates proximity and similarity

Proximity (column) vs connection (row) Similarity (row) vs connection (column)

slide-68

SLIDE 68

Uniformed Connectedness: Enclosure

slide-69

SLIDE 69

Chart Annotations

[ https://chartaccent.github.io/ ]

Enclosure Connection

slide-70

SLIDE 70

Visualizing Sets

[ Slides from A. Lex ]

Bubble Sets Line Sets Kelp Diagrams

slide-71

SLIDE 71

TreeMap and Circle Packing

https://bl.ocks.org/mbostock/4063530 https://bl.ocks.org/mbostock/4063582

Proximity, Similarity, Enclosure

slide-72

SLIDE 72

Continuity

We prefer smooth not abrupt changes Connections are clearer with smooth contours

[from Ware 04]

slide-73

SLIDE 73

Hierarchical Edge Bundling

[ Holten 06 ]

slide-74

SLIDE 74

Symmetry

Elements that are symmetrical to each other tend to be grouped together.

https://www.populationpyramid.net/united-states-of-america/2017/

slide-75

SLIDE 75

Population Pyramid (or tornado chart?)

https://www.populationpyramid.net/united-states-of-america/2017/

Korean War?

slide-76

SLIDE 76

Change Blindness

slide-77

SLIDE 77

The phenomenon where even very large changes are not noticed if we are attending to something else.

slide-78

SLIDE 78

http://www.psych.ubc.ca/~rensink/flicker/download/

Change Detection Test

slide-79

SLIDE 79 https://www.youtube.com/watch?v=ubNF9QNEQLA

Change Detection Test

slide-80

SLIDE 80

“To see an object change, it is necessary to attend to it.” — Ronald A. Rensink

slide-81

SLIDE 81

Reducing change blindness in visualization

Provide attentional guidance by leveraging pre-attentive features, Gestalt principles, etc.

https://bl.ocks.org/mbostock/3885705

Example: Ease tracking objects through motion

slide-82

SLIDE 82

Topics

Signal Detection
Magnitude Estimation
Pre-Attentive Processing
Using Multiple Visual Encodings
Gestalt Grouping
Change Blindness

slide-83

SLIDE 83

Take away

1. Human don’t perceive changes and magnitude at face value. 2. Use pre-attentive visual features for faster target detection. 3. Be aware of interference and redundancy of multiple features. 4. Leverage gestalt principles for high-level grouping. 5. Change blindness in visualization is the failure of design, not because of our vision system.

Knowledge of perception can benefit visualization design

slide-84

SLIDE 84

1. Value of visualization
2. Design principles
3. Graphical perception

Today

Fundamental

slide-85

SLIDE 85

1. Data model and visual encoding
2. Exploratory data analysis
3. Storytelling with data
4. Advanced visualizations

Practical

Tomorrow

slide-86

SLIDE 86

Data model and visual encoding

Next

Rankings of visual variables for quantitative, ordinal, and normal data

slide-87

SLIDE 87

See you tomorrow!
