GPU Multisplit

Saman Ashkiani, Andrew Davidson, Ulrich Meyer, John D. Owens

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 1 / 16

Motivating Simple Example: Compaction

Compaction (i.e., binary split)

Traditional approach: Flags → Scan → Shuffle

e.g., splitter: 10

input keys 25 12 4 76 7 17 6 1 compacted 4 7 6 1

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 2 / 16

Motivating Simple Example: Compaction

Compaction (i.e., binary split)

Traditional approach: Flags → Scan → Shuffle

e.g., splitter: 10

Other option: split input into two buckets

input keys 25 12 4 76 7 17 6 1 buckets 1 1 1 1

• utput keys

4 7 6 1 25 12 76 17 buckets 1 1 1 1

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 2 / 16

Motivating Simple Example: Compaction

Compaction (i.e., binary split)

Traditional approach: Flags → Scan → Shuffle

e.g., splitter: 10

Other option: split input into two buckets Can also be solved by sorting keys

Not always possible Loses “stability”, i.e., initial order within buckets not preserved

input keys 25 12 4 76 7 17 6 1 buckets 1 1 1 1

• utput keys

4 7 6 1 25 12 76 17 buckets 1 1 1 1 sorted keys 1 4 6 7 12 17 25 76

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 2 / 16

What is Multisplit?

Multisplit (generalization of binary split)

Let’s try multiple buckets

e.g., splitters: 10 and 20

input keys 25 17 4 76 7 12 6 1 buckets 2 1 2 1

• utput keys

4 7 6 1 17 12 25 76 buckets 1 1 2 2

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 3 / 16

What is Multisplit?

Multisplit (generalization of binary split)

Let’s try multiple buckets

e.g., splitters: 10 and 20

Can also be solved by sorting keys

input keys 25 17 4 76 7 12 6 1 buckets 2 1 2 1

• utput keys

4 7 6 1 17 12 25 76 buckets 1 1 2 2 sorted keys 1 4 6 7 12 17 25 76 buckets 1 1 2 2

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 3 / 16

Mutlisplit primitive

Input:

unordered set of keys (or key-value pairs) m, number of buckets a user specified function to identify buckets for each key

Output:

keys (or key-value pairs) separated into m buckets

B0 B1 B2 B3

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 4 / 16

A Fast and Flexible Data-Organization Primitive

characterizing key-value pairs into buckets

General load balancing Priority queues

Single Source Shortest Path (SSSP)

Serial (Dijkstra): processing the vertex with the lowest weight Bellman-Ford-Moore → all vertices in parallel delta-stepping formulation of SSSP [Davidson et al., 2014]

classifying vertices into buckets by their weights processing the lowest weights in parallel But no multisplit primitive → used radix-sort instead By using our own multisplit → 2.1x faster

• ther applications

colored prefix-sum reorganizing into 8 direction-based buckets in GPU based ray tracers [Yang et al., 2013] first step in building GPU hash tables [Alcantara et al., 2009] in the shallow stages of k-d tree construction [Wu et al., 2011]

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 5 / 16

Common Approaches:

1 Recursive scan-based split

⌈log(m)⌉ rounds of binary splits

31 24 3 17 82 59 46 6 B0 = {i ≤ 40} B1 = {i > 40} Initial Keys

1 2 4 6 3 7 5 1 1 1 1 1 1 2 3 3 4

31 24 3 17 82 59 46 6 31

1 2 4 6 3 7 5 1 1 1 1 1 1 1 2

B0 B1

Exclusive scan right to left exclusive scan

Buckets

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 6 / 16

Common Approaches:

1 Recursive scan-based split

⌈log(m)⌉ rounds of binary splits

2 Radix sort

sorting keys

• verkill (sorted within buckets)

initial order is not preserved

31 24 3 17 82 59 46 6

1 2 4 6 3 7 5

0000011 0010001 1010010 0011000 0000110 0011111 0101110 0111011

31 24 3 17 82 59 46 6 31

1 2 4 6 3 7 5

Initial Keys

binary representation ≤ 7 splits

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 6 / 16

Common Approaches:

1 Recursive scan-based split

⌈log(m)⌉ rounds of binary splits

2 Radix sort

sorting keys

• verkill (sorted within buckets)

initial order is not preserved

3 Reduced bit sort

sort (bucket ID, keys) ⌈log m⌉-bit bucket IDs

31 24 3 17 82 59 46 6

1 2 4 6 3 7 5

Initial Keys 31 24 3 17 82 59 46 6

1 1 1 1 New values New keys key-value sort

31 24 3 17 82 59 46 6 31

1 2 4 6 3 7 5

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 6 / 16

Common Approaches:

1 Recursive scan-based split

⌈log(m)⌉ rounds of binary splits

2 Radix sort

sorting keys

• verkill (sorted within buckets)

initial order is not preserved

3 Reduced bit sort

sort (bucket ID, keys) ⌈log m⌉-bit bucket IDs

4 Randomized insertions

a PRAM algorithm large buffers for buckets random insertions initial order is not preserved

31 24 3 17 82 59 46 6

1 2 4 6 3 7 5

Initial Keys 31 24 6 3 17 46 59 82

buffer B0 buffer B1 compaction

31 24 3 17 82 59 46 6 31

1 2 4 6 3 7 5

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 6 / 16

Designing an Efficient Approach

Stable Multisplit → unique permutation + data movement

1 Deriving all permutations → global computations

histogram (h0, . . . , hm−1) key order per bucket

ui ∈ Bj ⇒ p(i) =

j−1

• k=0

hk

Number of keys in previous buckets

+ |{ur : ur ∈ Bj, r < i}|

• Number of keys

before me in my own bucket

B0 B1 B2 B3

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 7 / 16

Designing an Efficient Approach

Stable Multisplit → unique permutation + data movement

1 Deriving all permutations → global computations

histogram (h0, . . . , hm−1) key order per bucket

2 Final data movements → global random scatters B0 B1 B2 B3

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 7 / 16

Our high level ideas

1 Global computations

Localize computations

several large enough local subproblems − → local histograms a single small enough global computation − → global histogram several large enough local subproblems − → permutations + scatters Avoid shared memory and synchronization: utilize intrinsics

Global Local Local Pre scan Scan Post scan

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 8 / 16

Our high level ideas

1 Global computations

Localize computations

several large enough local subproblems − → local histograms a single small enough global computation − → global histogram several large enough local subproblems − → permutations + scatters Avoid shared memory and synchronization: utilize intrinsics

2 Global random scatters

Reordering keys locally in the last stage → local multisplits

more computational cost but better memory access pattern (coalesced writes)

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 8 / 16

Granularity Tradeoffs

We experimented with a couple different subproblem granularities

1

warp

warp synchronous model with minimal warp divergence fast communication via warp-wide ballot/shuffles

2

block

more expensive communication via shared memory cheaper global computation (scan over m × Nblocks) more locality to extract after reordering

Property Direct MS Warp-level MS Block-level MS Subproblem warp warp block reordering – warp-wide reordering block-wide reordering computational load low medium high Coalesced memory access low medium high

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 9 / 16

Implementation details & Optimizations

Warp-level MS

1 Pre-scan (Local):

read keys warp histogram

1

bit-by-bit balloting

2

⌈log m⌉ rounds store warp histogram · · · · · · · · · · · ·

· · · · · · · · · · · ·

an an an · · ·

h0,0 h1,0 hm−1,0 h0,1 h1,1 hm−1,1

· · ·

h0,L−1 h1,L−1 hm−1,L−1

· · · · · · Pre scan

1: procedure warp histogram(bucket id[0:31])

Input: bucket id[0:31] Output: histo[0:m-1]

2:

for each thread i = 0:31 parallel warp do

3:

histo bmp[i] = 0xFFFFFFFF;

4:

for (int k = 0; k < ceil(log2(m)); k++) do

5:

temp buffer = ballot(bucket id[i] & 0x01);

6:

if ((i >> k) & 0x01) then

7:

histo bmp[i] &= temp buffer;

8:

else

9:

histo bmp[i] &= XOR(0xFFFFFFFF, temp buffer);

10:

end if

11:

bucket id[i] >>= 1;

12:

end for

13:

histo[i] = popc(histo bmp[i]);

14:

end for

15:

return histo[0:m-1];

16: end procedure

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 10 / 16

Implementation details & Optimizations

Warp-level MS

1 Pre-scan (Local):

read keys warp histogram

1

bit-by-bit balloting

2

⌈log m⌉ rounds store warp histogram

2 Scan (Global):

exclusive scan on histograms m × Nwarps elements · · ·

h0,0 h1,0 hm−1,0 h0,1 h1,1 hm−1,1

· · ·

h0,L−1 h1,L−1 hm−1,L−1

· · · · · ·

h0,0 h0,1 h0,L−1 hm−1,0 hm−1,1 hm−1,L−1 h1,0 h1,1 h1,L−1

· · · · · · · · · · · ·

Pre scan Scan

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 10 / 16

Implementation details & Optimizations

Warp-level MS

1 Pre-scan (Local):

read keys warp histogram

1

bit-by-bit balloting

2

⌈log m⌉ rounds store warp histogram

2 Scan (Global):

exclusive scan on histograms m × Nwarps elements

3 Post-scan (Local):

read keys (key-value) recompute warp histograms compute local offsets warp-level reordering compute final positions final data movement · · ·

h0,0 h1,0 hm−1,0 h0,1 h1,1 hm−1,1

· · ·

h0,L−1 h1,L−1 hm−1,L−1

· · · · · ·

h0,0 h0,1 h0,L−1 hm−1,0 hm−1,1 hm−1,L−1 h1,0 h1,1 h1,L−1

· · · · · · · · · · · ·

Pre scan Scan Post scan

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 10 / 16

Performance Evaluation

In this presentation:

1

NVIDIA Tesla K40c GPU

2

Radix sort from CUB

including the one in the reduced-bit sort method

3

Device-wide exclusive scan from CUB

4

Uniform distribution of keys in buckets

More results in the paper:

1

Detailed timing of different stages of our algorithm

2

Other GPU achitectures: Maxwell

3

Different distributions of keys

4

Using our Multisplit algorithms in SSSP method

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 11 / 16

Average running time vs. number of buckets

4 5 6 7 8 9 10 20 30 Number of buckets (m) Average running time (msec)

Block level MS Direct MS Reduced bit sort Warp level MS

(a) Key-only

8 12 16 10 20 30 Number of buckets (m) Average running time (msec)

(b) Key-value

Memory access quality: Block-level MS > Warp-level MS > Direct MS Computational load: Block-level MS > Warp-level MS > Direct MS

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 12 / 16

Performance vs Radix-Sort

2 4 6 2 4 6 8 12 16 20 26 32 Number of buckets (m) Speedup

Block level MS Direct MS Reduced bit sort Warp level MS Binary Split

(c) Key-only

2 4 6 8 2 4 6 8 12 16 20 26 32 Number of buckets (m) Speedup

Block level MS Direct MS Redcued bit sort Warp level MS Binary Split

(d) Key-value

key-only: 3.0x – 6.7x key-value: 4.4x – 8.0x

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 13 / 16

More buckets

For more buckets than the warp width (m > 32):

warp histograms → each thread in charge of multiple buckets Shared memory capacity the other bottleneck

Radix sort (key−only) Radix sort (key−value) 5 10 15 20 32 64 256 1024 4096 16384 65536 Number of buckets (m) Average running time (msec)

Block level MS Reduced bit sort Key−only Key−value

Average running time (msec) for more buckets for Block level MS and reduced-bit sort

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 14 / 16

Conclusions

Introduce a new efficient data organization primitive High performance especially for low or modest number of buckets Full paper:

Proceedings of the 21st ACM SIGPLAN Symposium on Principles and Practice of Parallel Programming (PPoPP 2016)

Code will soon be available in CUDPP:

https://github.com/cudpp/cudpp

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 15 / 16

Thank You

• S. Ashkiani (UC Davis)

GPU Multisplit GTC 2016 16 / 16
