GPRS optimisation and Network visualization Janne Myllyl T-110.456 Topics What do we need to know? Different types of information available Basics of GPRS capacity optimisation Janne Myllyl T-110.456 Planning The network


slide-1
SLIDE 1

Janne Myllylä T-110.456

GPRS optimisation and Network visualization

slide-2
SLIDE 2

Janne Myllylä T-110.456

Topics

  • What do we need to know?
  • Different types of information available
  • Basics of GPRS capacity optimisation
slide-3
SLIDE 3

Janne Myllylä T-110.456

Planning

  • The network elements:
  • type specific information (e.g. family, radiation patterns)
  • current settings
  • Geographic information
  • Land use
  • Building height
  • Statistics
  • Models
slide-4
SLIDE 4

Janne Myllylä T-110.456

Planning

  • Using the information we can estimate:
  • Network capacities in different areas
  • Overall service quality
  • Affect of changes in the network
  • Problems:
  • Models work in a perfect world
  • Map information is never up-to-date or accurate
  • Butterfly effect
slide-5
SLIDE 5

Janne Myllylä T-110.456

Are there more accurate methods?

  • Network performance can also be measured
  • Field measurements
  • Network measurements
slide-6
SLIDE 6

Janne Myllylä T-110.456

Optimisation basics

Nokia NetAct Measure Analyse Optimise Provision

slide-7
SLIDE 7

Janne Myllylä T-110.456

Measurement types

  • Call/Session
  • Radio Quality
  • Volume
slide-8
SLIDE 8

Janne Myllylä T-110.456

Field measurements

+

  • Basically a modified cellural phone is driven on a route.
  • Reliable information available without much traffic volume
  • Vendor independent
  • Can measure competitors network performance
  • A lot of driving around needed.
  • Measurement sample time is very limited
slide-9
SLIDE 9

Janne Myllylä T-110.456

Network measurements

+

  • Almost all possible events are measured.
  • Measurements span over a longer timeperiod
  • Not very standardized. Different vendors measure and collect

slightly different data.

  • Moderate traffic volume is needed for reliable measurements.
  • The total amount of data is huge.
slide-10
SLIDE 10

Janne Myllylä T-110.456

Busy Hour

  • The distribution of traffic is not even. During weekdays

there occurs peaks in the network usage.

  • Radio networks don’t generally react well to traffic increase
  • According to common sence:

Network behaviour during the busy hour is the weakest link.

  • Heuristics can be used to identify the bh.
slide-11
SLIDE 11

Janne Myllylä T-110.456

What is visualized

  • Network static information
  • Locations & directions
  • Parameter values
  • Relations between elements
slide-12
SLIDE 12

Janne Myllylä T-110.456

What is visualized

  • There are dozens of raw measurements (Performance Indicator)

that are related to GPRS performance.

  • User wants to see the result of a preliminary analysis based on

the raw measurements (Key Performance Indicator).

slide-13
SLIDE 13

Janne Myllylä T-110.456

KPI

  • Traditional benchmarks ( BER, FER, CSR, HSR )
  • (E) GPRS data related
  • Reliability, max probability of erroneous RLC
  • Throughput, amount of RLC payload
  • Delay, measured time between SGSN and mobile
  • (E)GPRS load, timeslots utilized by GPRS service
  • And many more
slide-14
SLIDE 14

Janne Myllylä T-110.456

Visualizing KPI

  • Snaphot of network state:
  • Performance of network on map
  • List of elements not behaving within thresholds
  • Trend of measurements
  • Time based comparison between different

elements / measurements

  • Performance animations on map
slide-15
SLIDE 15

Janne Myllylä T-110.456

Network capacity balancing

  • In GSM network the available capacity is defined by

timeslots dedicated for different services.

  • It is possible to dimension timeslot usage between
  • SDCCH
  • CS
  • PS
slide-16
SLIDE 16

Janne Myllylä T-110.456

Visualization of timeslot usage

slide-17
SLIDE 17

Janne Myllylä T-110.456

Visualizing service performance

slide-18
SLIDE 18

Janne Myllylä T-110.456

Visualizing cell level performance

slide-19
SLIDE 19

Janne Myllylä T-110.456

Effect of timeslot redimensioning

1 2 3 4 5 6 3.1 10.1 17.1 24.1 CS PS SDDCH

%

The relevant analysis of service performance need to be continuous, since without increase of total capacity timeslot dimensioning is always compromise.

slide-20
SLIDE 20

Janne Myllylä T-110.456

Treatment classes

  • Assigning GPRS capacity for different service classes
  • PoC
  • Streaming
  • Corporate
  • MMS
  • Diverse DL/UL QoS requirements.
slide-21
SLIDE 21

Janne Myllylä T-110.456

Capacity and QoS

Capacity offered for various services SMS Speech GPRS

TREC 0 TREC 1 TREC 2 TREC 3

  • Priorisation

Capacity Balancing QoS Priorisation

slide-22
SLIDE 22

Janne Myllylä T-110.456

Running out of capacity

1 2 3 4 5 6 7 3.1 10.1 17.1 24.1 CS PS SDDCH

Dimensioning can now

  • nly be used to increase

CS performance. The only way to improve PS performance is to increase the total capacity.

slide-23
SLIDE 23

Janne Myllylä T-110.456

How to increase capacity

  • Some of the traffic volume could be redirected to other cells
  • A new serving cell can be setup
  • TRXs can be added for the current cell(s) to increase

total amount of timeslots

  • Impact matrix
slide-24
SLIDE 24

Janne Myllylä T-110.456

Impact matrix

  • Also known as Interference matrix
  • All cells whose signal has been measured in serving

cells dominance area

  • Handover possibility
  • Used to determine which cells could cause interference

with serving cell.

slide-25
SLIDE 25

Janne Myllylä T-110.456

Interference basics

  • The frequencies have traditionally been planned using

reuse patterns and propagation models

  • In order to increase the traffic capacity, the channel re-use

becomes tighter

  • Too tight use of the same and adjacent channels

causes a decline of C/I

BER and FER increase,

worse coding schemes

slide-26
SLIDE 26

Janne Myllylä T-110.456

Interference without hopping

  • When no hopping is used some timeslots will constantly

have more problems than others.

  • After too much reuse performance deteriorates quickly
slide-27
SLIDE 27

Janne Myllylä T-110.456

Too tight reuse on map

slide-28
SLIDE 28

Janne Myllylä T-110.456

Averaging behaviour

  • Frequency hopping may be used to average network

behaviour

  • Main idea is to reduce continuous bad performance

between mobile and bss.

slide-29
SLIDE 29

Janne Myllylä T-110.456

Averaged behaviour on map

slide-30
SLIDE 30

Janne Myllylä T-110.456

Hopping mode: BB

  • In BB hopping TRX frequencies don’t change,

but TRX serving the mobile phone does.

  • Total amount of frequencies in BB hopping is the same as the

number of TRXs.

  • Also BCCH timeslots 1-7 are included in the hopping.
slide-31
SLIDE 31

Janne Myllylä T-110.456

Hopping mode: RF

  • In RF hopping TRX serving the mobile phone doesn’t change,

but TRX frequencies do.

  • In RF hopping an allocation list contains frequencies

that are used.

  • BCCH TRX is not hopping.
  • N channels enables 64*N different hopping sequences.
  • MAIO offset has as many values as allocation list has channels
  • HSN can be selected from 64 different sequences.
slide-32
SLIDE 32

Janne Myllylä T-110.456

Hopping mode comparison

BB RF BB RF BB RF

TRX-3 TRX-2 TRX-1

Mobile hops the same frequency pattern in both modes

slide-33
SLIDE 33

Janne Myllylä T-110.456

Measured performance

0.5 1 1.5 2 2.5 3 3.5 1 2 3 4 5 BB RF

EFL DCR Basically RF hopping enables a more tight channel reuse

slide-34
SLIDE 34

Janne Myllylä T-110.456

Extreme channel reuse

  • Two types of service areas inside cell:
  • Normal with regular reuse patterns (overlay)
  • Small with extreme reuse (underlay)
  • The same underlay frequencies are used even in neighboring

cells.

  • Cell tries to make as much as possible of the traffic volume

to use the underlay frequencies.

slide-35
SLIDE 35

Janne Myllylä T-110.456

Extreme channel reuse

  • The same traffic volume can be managed with less

frequencies.

  • With this example situation 3 underlay TRXs

could free 6 frequencies. underlay

slide-36
SLIDE 36

Janne Myllylä T-110.456

References

3GPP TS 25.215 V6.0.0 Physical layer – measurements 3GPP TS 23.107 V6.2.0 QoS concept and architecture Halonen, Romero, Melero: GSM, GPRS and EDGE performance
