GLV Systems Preliminary Design Report Electrical and Computer Engineering Class of 2015 Roadmap 2013 System Overview System Hierarchy Subsystem Reports Power Safety VCI TSI Budget Schedule


slide-1
SLIDE 1

GLV Systems Preliminary Design Report

Electrical and Computer Engineering Class of 2015

slide-2
SLIDE 2

Roadmap

  • 2013 System Overview
  • System Hierarchy
  • Subsystem Reports

○ Power ○ Safety ○ VCI ○ TSI

  • Budget
  • Schedule

Psdgraphics.com

slide-3
SLIDE 3

2013 Safety Box

  • Pros

○ Functioning safety loop ○ Materials

  • Cons

○ Not chassis mountable ○ Large

Source: CDR Presentation 2013

slide-4
SLIDE 4

2013 VSCADA Box

  • Pros

○ Working Relay system ○ Some Usable Parts

  • Cons

○ Not chassis mountable ○ Large ○ Messy Wiring

Source: CDR Presentation 2013

slide-5
SLIDE 5

2013 Load Controller

  • Pros

○ Many useful materials

  • Cons

○ Not chassis mountable ○ Needs better high/low voltage isolation ○ TSAL board

Source: CDR Presentation 2013

slide-6
SLIDE 6

2013 GLV Power

  • Pros

○ Acts as a good test stand

  • Cons

○ Not a battery

Source: CDR Presentation 2013

slide-7
SLIDE 7

GLV

slide-8
SLIDE 8

GLV Power

slide-9
SLIDE 9

VCI / Safety

slide-10
SLIDE 10

Driver Controls

slide-11
SLIDE 11

TSI

slide-12
SLIDE 12

GLV Power Subsystem

  • Priority #1 - buying a battery
  • Charging and power management
  • Cabling, distributing power to different parts
  • f the car
slide-13
SLIDE 13

Power - Requirements Highlights (End Goal)

  • power GLV and other non-tractive systems
  • power for >3 hours
  • battery protection
  • grounding to chassis
  • packaging and mounting

Psdgraphics.com

slide-14
SLIDE 14

Power - Test Plan Highlights

  • Analysis + Inspection

○ System ground, electrical insulation, prohibited insulators, battery type, fusing

  • Tests

○ System ground, tractive system power up, GLV failure, battery duration, charge from zero, data measurement

slide-15
SLIDE 15

Power - potential battery

24V, 10Ah, NiMH, High Temp Protection, $185

All-battery.com

slide-16
SLIDE 16

Power - potential smart charger

12V-24V, NiMH/NiCd, $20, includes temperature sensor

All-battery.com

slide-17
SLIDE 17

Power - potential battery

12V, 12Ah, Lead Acid, $49 (would need two)

Digi-Key.com

slide-18
SLIDE 18

Power - potential charger

12V, $99, indicator lights

Digi-Key.com

slide-19
SLIDE 19

Budget Comparison

$185 + $20 = $205 $49 + $49 + $99 = $196

All-battery.com Digi-Key.com

slide-20
SLIDE 20

Power Management

Digi-Key.com LTC4365 Overvoltage/Undervoltage Protection $2 LTC2945 Power Monitor $9 LTC4365 Data Sheet LVR055 PolySwitch $2 Max Currents: 1.2A - 7A options Board $30 Housing $150

slide-21
SLIDE 21

Safety Systems Description

  • Keeps high level voltage system in a safe state
  • Monitors status of the system and provides multiple

shutdown options to both driver and surrounding personnel

  • Interacts with each electrical subsystem
  • Follows rules presented in SAE International Formula

Hybrid Rules 2015

slide-22
SLIDE 22

Shutdown State Analysis

slide-23
SLIDE 23

Top Level Overview of the Safety Loop

ref 2012 PDR: slide 12

slide-24
SLIDE 24

Basic Components

  • Safety Controller
  • 1. Start and end to safety loop
  • 2. Contains system status LEDs
  • Safety Panel
  • 1. User access to the safety loop
  • 2. 4 ways to shut off the safety loop: one BRB for the

cockpit and one on each side of the car, and the Brake Over-Travel switch

slide-25
SLIDE 25

Basic Components Cont.

  • BRBs (owned)

1. Push-Rotate (in our case) where pushing opens the shutdown circuit 2. Pushing any of the 3 BRBs separates tractive system for the accumulator

  • Master Switch (owned)

1. GLVMS and TSMS are rotary type and direct acting with removable key 2. Disables power to all electrical circuits; all battery power flows through this switch

slide-26
SLIDE 26

Safety - Budget

  • Budget of $200 needed
  • BRBs and Master Switches are

already owned

  • $150 dollars required for fuses,

wires, sensors (according to 2013 BOM)

  • Could potentially reuse these

materials assuming they are up to spec

slide-27
SLIDE 27

Safety - End Goal

  • The safety loop will keep the driver and other team

members safe on and off the track

  • Maintain safe operating status of the system and shut

down if there are any failures

  • Meet the desired specifications and shutdown

appropriate systems when necessary

slide-28
SLIDE 28

Safety - Test Plan

  • Can demonstrate proper

function by triggering different shutdown protocol

  • Follow Table 17 from

the spec pertaining to shutdown priority

slide-29
SLIDE 29

TSI

  • Tractive System Interface
  • Load Controller

○ Connect motor controller to battery pack ○ Keep TSV isolated from the rest of the vehicle

slide-30
SLIDE 30

TSI - Requirements Analysis

  • Galvanic isolation
  • Electrical insulation and layout
  • TSMP and GLV GMP
  • TSAL
  • IMD
  • IMD indicator light
  • MCS cabling
  • Tractive System restart
slide-31
SLIDE 31

TSI - 2013 Load Controller

  • TSAL PCB

○ Opto-isolator resistor ○ IO Holes ○ Incorrect labeling

  • TSMP
  • GLV GMP
  • IR LEDs
  • VSCADA control
  • IMD
slide-32
SLIDE 32

TSI - What to Expect

  • Car ready container
  • Electrical insulating barriers
  • TSAL circuit board
  • MCS cabling

○ High voltage power-lock connectors

  • IMD indicator light
  • Interfaced with VSCADA
  • Tractive system reset
slide-33
SLIDE 33

TSI - Test Plan

  • TSAL Test
  • TSMP and IR Indicator Test
  • IMD Safety Loop Test
  • IMDT

○ As outlined in Formula EV rules

  • VSCADA Interface Test
slide-34
SLIDE 34

TSI - Budget

slide-35
SLIDE 35

Vehicle Computer Interface (VCI)

  • Collect and deliver data from sensors to VSCADA
  • The collected data will be converted from the analog to

digital and then formated by the VSCADA team

  • Important to coordinate with VSCADA to determine the

appropriate sensors

  • In charge of purchasing the sensors

ref Phidgets Inc.

slide-36
SLIDE 36

Top Level Overview of the VCI Subsystem

ref GLV Systems PDR page 5

slide-37
SLIDE 37

Ready to Drive Sound

  • When the car is set to ready to drive mode it must emit

a sound

  • Sound needs to be audible

in front of the vehicle in noisy environments

  • Modify the amplifier to

meet requirements

slide-38
SLIDE 38

VCI - Budget

  • Speaker/Amplifier - $50
  • Sensors

○ Temperature (x4) - $25 ○ Current (x2) - $30 ○ Voltage (x2)

  • $60

○ State of Charge - $6 ○ Rate of Charge - $15 ○ Rate of Discharge - $15

  • Container - $150
  • Total $330
slide-39
SLIDE 39

VCI - End Goal

  • Ready to Drive Sound feature is fully

functionable and meets the requirements

  • Sensors required by VSCADA are

implemented

  • Data is correctly converted from analog to

digital

  • Data is delivered to VSCADA
slide-40
SLIDE 40

VCI - Test Plan

  • RTD Sound Length Test

○ Should last for 1-3 seconds

  • RTD Sound Tone Test

○ Tone of 2500-3500 Hz ○ Minimum loudness of 68 db at 2 ft from the car

  • Required Sensor test

○ Compare sensors’ output to the specified requirement ○ VSCADA is receiving properly converted data

slide-41
SLIDE 41
  • Total

○ $1,399

Budget

slide-42
SLIDE 42

Budget

slide-43
SLIDE 43

Schedule

  • User Manual

○ February 12th

  • CDR Planned

○ March 5th

  • Hardware Purchase

○ March 12th

slide-44
SLIDE 44
slide-45
SLIDE 45
slide-46
SLIDE 46

Questions?
