GLUE Project: A Geo-cache based Mobile Sensor Network System Bin Zan,Tingting Sun, Marco Gruteser, Yanyong Zhang WINLAB, Rutgers University {zanb,tsun,gruteser,yyzhang} @winlab.rutgers.edu 1 Mobile Sensor Networks Technology trends

slide-1
SLIDE 1

1

GLUE Project: A Geo-cache based Mobile Sensor Network System

Bin Zan,Tingting Sun, Marco Gruteser, Yanyong Zhang WINLAB, Rutgers University {zanb,tsun,gruteser,yyzhang} @winlab.rutgers.edu

slide-2
SLIDE 2

2

Mobile Sensor Networks

Technology trends

Increasing integration of

sensors into mobile platforms

Accurate localization Large storage

Applications

accident analysis and

avoidance

dynamic noise pollution

mapping through cell phone

pothole detection

slide-3
SLIDE 3

3

Pothole Detection Example

Basic centralized approach: Transmit all data to external server

immediately

Pro: complete information available at the server Con: will soon saturate server capacity

slide-4
SLIDE 4

4

Pothole Detection Example

Basic distributed approach: Store locally and retrieved by

server later

Pro: no servers storage required Con: high retrieval overhead

slide-5
SLIDE 5

5

Challenge in Mobile Sensor Networks

  • How do we efficiently manage

mobile sensor data for applications that need to access information from multiple nodes?

slide-6
SLIDE 6

6

Key idea: tie data to the location

Car 1: Here might be a pothole Car 4: Here might be a pothole Car 8: Here might be a pothole … 1 8 4

slide-7
SLIDE 7

7

The Geo-Cache Concept Query

slide-8
SLIDE 8

8

The Geo-Cache entries and I-page

  • Geo-cache page is the

basic storage unit

  • Geo-cache page is

bound to “Anchor Location”

  • Each entry is a 4-

attribute tuple

  • I-page contains the latest

entries about a location and is kept around the location

  • Older entries can be

accessed through chaining

A

slide-9
SLIDE 9

9

Miss something?… Answer: the anchoring protocol How do the moving nodes hand off the Geo-Cache page among themselves?

slide-10
SLIDE 10

10

Anchoring Protocol: Relay

Relay Geo-cache Mode

slide-11
SLIDE 11

11

Anchoring Protocol: Boomerang

Boomerang Geo-cache Mode

slide-12
SLIDE 12

12

More about anchoring protocol

  • Switching
  • high geo-cache coverage (relay)
  • short geo-cache delay (relay)
  • low communication overhead (boomerang)
  • low node density (boomerang)
  • Reliability
  • Energy Efficiency

Achieve reliability in boomerang mode

…

slide-13
SLIDE 13

13

Preliminary Evaluation

  • ns2

NS-2 simulation, with a 70-km two-lane road Pothole in the middle of the road Each data point averaged over 1000 situations Average speed 30m/s, and radio range 100m

mean inter-car distance detection probability % mean message per car mean message per car Broadcast Relay Relay Boomerang

slide-14
SLIDE 14

14

Event Detection Module

Applications

Event Detection Module Event Detection Module Event Aggregation Module Event Aggregation Module Event Aggregation Module In-Car Sensor In-Car Sensor In-Car Sensor Camera Other Sensor Other Sensor Other Sensor GPS I-page Relay Mode Boomerang Mode Storage Radio

Glue Subsystem

Implementation

slide-15
SLIDE 15

15

Data Collection

slide-16
SLIDE 16

16

slide-17
SLIDE 17

17

Summary

Propose a distributed sensing and monitoring system for highly mobile vehicular networks named GLUE

  • Geo-cache
  • Anchoring protocol

The system is relying on inter-vehicle communication to exchange sensed and aggregated information. The Geo-cache abstraction allows nodes to specify a geographic location to store information.

slide-18
SLIDE 18

18

Questions?
