Globo Gym Purple Cobras TEAM A-14 Arnold Padron Stephen Trewhitt Victor Zaragoza Chris Oglesby EF 152 Spring 2017 April 6 th 2017 Dart Launcher-inator 3000 Conceptual Design Target audience Children 9-13


  1. Globo Gym Purple Cobras TEAM A-14 • Arnold Padron • Stephen Trewhitt • Victor Zaragoza • Chris Oglesby EF 152 Spring 2017 April 6 th 2017

  2. Dart Launcher-inator 3000

  3. Conceptual Design • Target audience – Children 9-13 • Foam dart turret • The sentry would be controlled with an external motor and an Arduino to be able to automate movements.

  4. CAD drawings and problems • The initial design was drawn like this in CAD and was going to be 3D printed. • However, due to the proposed size, no cost effective motor could handle it, so the motorized turret idea was ditched.

  5. Final Design

  6. Marketing Video

  7. Customer Feedback • “ I love it! It’s super fun.” • “ I really enjoy setting up targets and knocking them down with the darts.” • “ This is great, I love being able to set the height differences and not having to hold it myself.”

  8. Cost & Design Time Material Cost x1000 PVC Pipe $1.80 $1,800.00 Wood $2.77 $2,770.00 Tension Spring $3.25 $3,250.00 Nuts and bolts $0.88 $880.00 Total $8.70 $8,700.00 Retail Cost: $11.97 Design Time: ~ 10 Hours

  9. Conclusion
