SLIDE 1
Glaser et al., 2007
Glaser et al ., 2007 Biochar Meta-AnlysisStudies: 23 studies - - PowerPoint PPT Presentation
Glaser et al ., 2007 Biochar Meta-AnlysisStudies: 23 studies - - PowerPoint PPT Presentation
Glaser et al ., 2007 Biochar Meta-AnlysisStudies: 23 studies (2009-2011) (with 7 field studies) Jeffery et al ., 2011 Agriculture, Ecosystems & Environment Biederman et al ., 2013 GCB Bioenergy RR B = relative biochar effect = ln
SLIDE 2
SLIDE 3
Biederman et al., 2013 GCB Bioenergy Jeffery et al., 2011 Agriculture, Ecosystems & Environment 23 studies (2009-2011) (with 7 field studies)
RRB = relative biochar effect = ln (Biochar/Control) 371 Independent studies
Biochar Meta-AnlysisStudies:
SLIDE 4
Key Meta-Analysis Papers
- An analysis done by Dr. Humin Zhou et al. in 2017 found that biochar
increased Microbial Biomass Carbon an average of 26% from 413 academic research papers.
- Dr. Xiaoyu Liu and a series of other researchers published a
paper examining 238 studies of biochar's influence on plant
- productivity. They found that vegetables increased by an average of
28.6%, and that legume crops, such as peas, beans, and vetch, increased productivity by an average of 30.3%.
SLIDE 5
Biochar Studies: Soil nutrient retentions
Gao & DeLuca, 2016 Advances in Plants & Agriculture Research
…...
SLIDE 6
Key Considerations with Current Research
- The application of biochar to soils has also been shown to influence
nutrient retentions.
- Short-term studies, pot and column trials in lab or greenhouse
environment, very few are field studies.
- Also longer term field trials are in ag experiment stations using
conventional farming approaches. Very few studies are conducted in the field in active organic farming systems and as a part of a holistic closed loop system.
SLIDE 7
Field Trials Design @ Each Farm
1m 1m Block 1 Block 4 Block 3 Block 2
30 cm buffer
Block 5
Control Biochar (20 t ha-1) Poultry litter (70 kg N ha-1 poultry litter) Biochar charged with poultry litter (20 t ha-1 + 70 kg N ha-1)
SLIDE 8
Photo: Si Gao
SLIDE 9
20% + 7% + 46% + 47% +
50 100 150 200 250 300 350
Control Poultry litter Biochar Charged char
Soil microbial biomass C (mg kg-1)
2016 2015
SLIDE 10
45% + 40% + 35% + 35% +
10 20 30 40 50 60 70
Control Poultry litter Biochar Charged char
Soil total C (g kg-1)
2016 2015
SLIDE 11
24% + 28% +
20 40 60 80 100 120 140
Control Poultry litter Biochar Charged char
Average soil enzyme activity*
2016
*the geometric mean of beta-glucosidase, dehydrogenase, phosphatase, and urease. An overall index for soil biological activity.
SLIDE 12
115% + 80% + 65% + 63% +
2 4 6 8 10 12 14 16 18 20
Control Poultry litter Biochar Charged char
Soil potentially mineralizable N (mg kg-1 14d)
2016 2015
SLIDE 13
35% + 160% +
0.0 0.5 1.0 1.5 2.0 2.5 3.0 3.5 4.0 4.5 5.0
Control Poultry litter Biochar Charged char
Soil soluble inorganic P* (mg kg-1)
2016 2015
*exist in soil solution, readily available.
SLIDE 14
5% + 13% + 20% + 18% +
0% 20% 40% 60% 80% 100% 120%
Control Poultry litter Biochar Charged char
Soil water-hoding capacity
2016 2015
SLIDE 15
13% - 33% -
10 20 30 40 50 60
Control Poultry litter Biochar Charged char
Accumulated NH4
+ -N below rooting zone
(µg per resin capsule)
Waldron2016
SLIDE 16
28%+ 13%+
1 2 3 4 5 6 7 8 9
Control Poultry litter Biochar Charged char
Average yield per treatment plot (kg)
2016
SLIDE 17
Nutrient Density in Dry Beans 2015
20 40 60 80 100 120 140 160 Cu Fe Mn Zn Ca
Micro Nutrients in Micrograms
Dry Beans @ QFC Dry Beans @ San Juan Islands Dry Beans @ San Juan Islands Carbon Farming
