GIS at Brabant Water Adding social value and return on investment GEOSPATIAL WORLD FORUM Rotterdam May 15 th 2013 Ing. D.A.M. van Os

Agenda • Brabant Water • Water distribution maintenance • GIS for registration and decision support

Waterworks in the Netherlands WBG 280 Waterworks: 10 Employees (fte): 5.063 WMD Investment (million euro): 390 190 Production (million m 3 ): 1.141 Mains (x 1.000 km): 117 Connections (x 1.000): 7.659 Vitens 2400 Evides 1000 Brabant Water 1100 WML 530

Brabant Water Employees (fte): 737 WBG Investment (million euro): 30 282 Production (million m 3 ): 170 Mains (x 1.000 km): 18 WMD 193 Connections (x 1.000): 1.100 PWN Waternet 750 480 Dunea Vitens 603 335 2400 Brabant Water Evides Oasen 105 Brabant Water 1100 WML 532

Supply area Brabant Water Behoort tot het voorzieningsgebied van Evides Regio West Regio Midden Regio Noord Oost Regio Zuid Oost

Offices and production locations Drinkwaterproductiebedrijf Industriewaterproductiebedrijf Hoofdkantoor Nevenvestiging en regiokantoren Regiokantoor

Supply area in GIS

Malfunction

1,00,000 2,00,000 3,00,000 4,00,000 5,00,000 6,00,000 7,00,000 0 1897 1908 1913 1916 1923 1926 1929 1932 1935 Renewal 1938 1941 Length by building year 1944 1947 1950 1953 1956 1959 1962 1965 1968 1971 1974 1977 1980 1983 1986 1989 1992 1995 1998 2001 2004 2007 2010

Renewal main system • Malfunction • Complaints • Pipe materials • Building year • Plans from other utility companies • Plans from local government

Call before you dig • Information exchange • WION uses GIS • WION sends network information to contractors • Excavation polygons in GIS

Key figures • Production in m 3 per year 170 million • Main system 18.000 km • Amount connections 1,1 million • Amount inhabitants 2,4 million • Amount production facilities 33 • Turnover per year € 220 million • Amount of employees 800

GIS in numbers 200 180 160 140 120 100 80 60 40 20 0 edit analyse web mobile Gb data application database specialist administrator

Thank you for your attention! daan.van.os@brabantwater.nl
