Gigahertz Electromagnetic Structures via Direct Ink Writing Radio-Frequency Oscillator and Transmitter Applications Chengye Liu Inductors and Capacitors B B C. Liu et al., Advanced Material (2017) Coplanar Strip (CPS) Standing Wave Resonator

slide-1
SLIDE 1

Chengye Liu

Gigahertz Electromagnetic Structures via Direct Ink Writing Radio-Frequency Oscillator and Transmitter Applications

slide-2
SLIDE 2

Inductors and Capacitors

B

  • C. Liu et al., Advanced Material (2017)

B

slide-3
SLIDE 3

Coplanar Strip (CPS) Standing Wave Resonator (SWR)

  • C. Liu et al., Advanced Material (2017)
  • W. F. Andress, D. Ham, IEEE Journal of Solid-State Circuits (2005)

Ldz/2 Ldz/2 (C+β–³C)dz

𝑀𝑄 = 1 𝑀𝐷

slide-4
SLIDE 4

CPS Ring Resonators

  • C. Liu et al., Advanced Material (2017); W. F. Andress, D. Ham, IEEE Journal of Solid-State Circuits (2005)

β‰ˆ Simple CPS ring: V(𝜚 + 2𝜌)=V 𝜚 So π‘š = π‘œπœ‡ where n = 1, 2, 3… MΓΆbius CPS ring: V(𝜚 + 𝜌)=V 𝜚 So π‘š =

2π‘œβˆ’1 2

πœ‡ where n = 1, 2, 3…

slide-5
SLIDE 5

Colpitts Oscillator

  • C. Liu et al., Advanced Material (2017)
slide-6
SLIDE 6

Injection-Locked Colpitts Oscillators

  • C. Liu et al., Advanced Material (2017)
slide-7
SLIDE 7

Oscillators with Wave-Based Resonators

  • C. Liu et al., Advanced Material (2017)
slide-8
SLIDE 8

Injection-Locked Quadrature Oscillators

  • C. Liu et al., Advanced Material (2017)
slide-9
SLIDE 9

Wireless Transmitter

  • C. Liu et al., Advanced Material (2017)
slide-10
SLIDE 10

Wireless Transmitter

  • C. Liu et al., Advanced Material (2017)
slide-11
SLIDE 11
