Geometric Sound Transmission Micah Taylor Overview Geometric propagation Very fast Can be used realtime Several propagation methods Reflection Diffraction Transmission Propagation Reflection Primary propagation method Causes echos

SLIDE 1

Geometric Sound Transmission

Micah Taylor

SLIDE 2

Overview

Geometric propagation Very fast Can be used realtime Several propagation methods Reflection Diffraction Transmission

SLIDE 3

Propagation

Reflection Primary propagation method Causes echos

SLIDE 4

Propagation

Diffraction Sound bends around corners

SLIDE 5

Propagation

Transmission Sound travels through materials Hear sounds through walls

SLIDE 6

Implementation

Goals Base on frustum tracing system Add Transmission Add transmission properties Attenuation Refractive properties Support object interiors

SLIDE 7

Implementation

Accomplished Transmission Refraction Pass through Single transmission property Only supports thin walls

SLIDE 8

Future work

Support for interiors Multiple methods

f transmission

Multi-material objects Similar to multitexturing

SLIDE 9

Demo

SLIDE 10

Summary

Adds dimension to simulation Important for realism Allows much greater awareness Slower, but still realtime

SLIDE 11

References

Transmission of Reverberant Sound through Double Walls, London A, 1949 Sound transmission through single plates with absorptive facings,

D. Takahashi, 1990
