Geoapplications development http://rgeo.wikience.org

Higher School of Economics, Moscow, www.cs.hse.ru

Signal-based positioning

2

Satellite- based, e.g. GPS Beacons

https://encrypted-tbn3.gstatic.com/images?q=tbn:ANd9GcSYYC7irjytoGY7XaURz3UeRCWkK_pcKVBCBhGKCCnZ64MG4CQo http://www.steelintheair.com/imgs/new-cell-tower-lease.jpg http://www.smbretail.com/wp-content/uploads/2015/12/tumblr_inline_ndeolbm5PR1rd9i5u.png

Cellular WiFi

GPS applications

Tracking of birds and animals

http://dx.plos.org/10.1371/journal.pone.0039833;jsessi

Osprey (blue), Marsh Harrier (green), Egyptian Vulture (orange), Short-toed Eagle (red).

GPS applications

CYGNSS – Cyclone Global Navigation Satellite System Innovation: retrieve wind speed of tropical cyclones through clouds + with high frequency To be launched – Oct 2016

http://clasp.engin.umich.edu/files/articles/CYGNSS_FactSheet_1.pdf

GPS applications

Precision gunfire

http://www.nbcnews.com/technology/how-tomahawk-cruise-missiles-send-message-syria-8C11022222

The most advanced Tomahawks fly at 550 mph, have GPS, onboard digital maps, video cameras, two- way satellite links and a navigation system that allows them to loiter over an area and wait for their targets to pop up. That's in addition to the 1,000- pound bomb each Tomahawk typically carries.

GPS applications

Precision agriculture

https://www.gps4us.com/news /post/Global-positioning-and- geographic-information- systems-help-create-an- environmentally-friendly-farm- 20111228.aspx

The precision farming integrated solution includes suite of GPS and GIS enabled applications which together are being used for farm planning, field mapping, soil sampling, tractor guidance, crop scouting, variable rate applications, and yield mapping.

GPS applications

Railway

http://www.gps.gov/applications/rail/

Positive Train Control (PTC) systems prevent collisions, derailments, work zone incursions, and passage through switches in the wrong position. A PTC system can automatically vary train speeds, re-route traffic, and safely direct maintenance crews onto and off tracks. PTC increases track capacity by maintaining a constantly updated

• perating plan that optimizes rail use and flow.

GPS – Global Positioning System

8

1. Orbital segment 2. Control segment 3. User segment

http://image.slidesharecdn.com/pgdgi03semin arnavdeepsingh-140113095137- phpapp02/95/global-positioning-system-7- 638.jpg?cb=1389607822

GPS – Orbital Segment

9

Orbital segment: 21 satellites + 3 backup are sufficient to provide global

• coverage. Currently 31 GPS satellites orbiting the Earth.

http://www8.garmin.com/graphics/24satellite.jpg

The image shows N planes * M satellites

GPS satellite visibility

10

Minimum number of GPS satellites visible over 1 day, January 1, 2010

http://blogs.agi.com/navigationAccuracy/?p=315

GPS satellite visibility

11

Number of visible satellites

https://upload.wikimedia.org/wikipedia/commons/9/9c/ConstellationGPS.gif

GPS – Ground Segment

12

Also called control segment or ground stations: 1. a master control station (MCS) 2. an alternate master control station 3. four dedicated ground antennas 4. six dedicated monitor stations Satellites carry precise atomic clocks with nanoseconds accuracy. The responsibility of a control segment is to periodically send current precise time and location to each satellite. Ephemeris – position of satellite at a given time.

GPS – User Segment

13

Cheap and small receivers

http://www.ainonline.com/aviation-news/aviation-international-news/2012-05-02/gps- jamming-prompts-renewed-interest-system-backup

One of the key differences between receivers is

• accuracy. Special

equipment and special receivers increase accuracy.

GPS positioning in 2D: (lat, lon)

14

GPS positioning in 2D: (lat, lon)

15

GPS positioning in 2D: (lat, lon)

16

GPS positioning – 4 satellites for 3D (lat, lon, z)

17 https://openclipart.org/image/2400px/svg_to_png/191659/GPS-3D-trilateration.png

This and previous illustrations are idealized (case of having exact distance between receiver and transmitter).

GPS math

18

Distance between satellite and receiver = wave speed * time

• wave speed = speed of light = 186K miles/sec
• time?
• Satellite generates pseudo-random sequence and transmits it to receiver
• Receiver generates the same sequence as well
• After the sequence has arrived, receiver aligns it with its own sequence and

finds time shift

GPS drawbacks: errors

19

http://www.iranmap.com/wordpress/wp-content/uploads/2010/04/gps-errors.jpg

GPS drawbacks: satellite visibility

20

There are cases when less than 4 satellites may be visible at a time One of the ways around: add more satellites

http://www.geo.upm.es/postgrado/CarlosLopez/materiales/cursos/www.ncgia.ucsb.edu/educat ion/curricula/giscc/units/u017/figures/figure15.gif

Other drawbacks – indoor navigation impossible, canyon effects (this image), slow (in cold receiver state), high battery power consumption, low accuracy in some cases

GLONASS

21

Development started in Soviet Union, 1976 Now 24 Now 29 satellites on

• rbit (not all are

active – mainly due to backup purposes and maintenance)

http://www.navigadget.com/wp-content/postimages/2011/11/glonass-map.jpeg

GPS & GLONASS & Co

22

Several constellations

increase sat. visibility.

Global only are GLONASS – Russian GPS – US To be completed: Galileo – EU COMPASS – Chinese

https://upload.wikimedia.org/wikipedia/commons/thumb/b/b4/Comparison_satellite_navigation_orbits.svg/2000px- Comparison_satellite_navigation_orbits.svg.png

Now GPS receivers leverage satellite signals both from GPS and GLONASS Q: why are orbits so high?

WiFi positioning

23

Works for notebooks and other devices without GPS modules Works for indoor navigation Every network device is manufactured with a unique MAC Recall ARP (Address Resolution Protocol) On Windows type “ipconfig -all”

WiFi positioning

24

Basic idea – create mapping MAC  (lat, lon) for all MACs Fingerprinting 1 Calibration (offline phase) – MAC, signal strengths, location 2 Positioning (online phase) – worse than GPS, better than cellular Accuracy ~ tens of meters

WiFi calibration

25

Fingerprinting 1 Calibration (offline phase) – MAC, signal strengths, location (lat, lon) 2 Positioning (online phase) – worse than GPS, better than cellular

• War driving collects fingerprints for all visible WiFi points
• Volunteers, e.g. iPhones send fingerprint data anonymously to Apple

Requires no password or other authentication information

WiFi calibration

26

Databases store fingerprinting data However, they degrade over time

https://en.wikipedia.org/wiki/Wi-Fi_positioning_system

WiFi positioning

27

Fingerprinting 1 Calibration (offline phase) – MAC, signal strengths, location 2 Positioning (online phase) – worse than GPS, better than cellular The idea is similar to GPS; many algorithms exist to improve both phases

http://www.mobizen.pe.kr/attach/1/cfile27.uf.146D33355047FEFD04B938.gif

Cellular positioning

28

Less accurate, ~ hundreds of meters, order of magnitude higher than WiFi Same principles as in WiFi positioning

http://www.swri.org/3pubs/ird2002/images/16-9222.jpg

Readings

29

Practical task

30
