Generic Mission Pr Generic Mission Process

• cess

Modelling Modelling

for

Near Ear Near Earth As h Asteroid Pr id Prospecting

• specting

by

Tim Broadbent UNSW Sydney – Satellite Systems Engineering 3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney

The Introduction

• MEngSc Thesis
• Satellite Systems Engineering at UNSW
• Satellite Controller (Optus Satellite) … I fly spacecraft - 24h - 365d
• My perspective is Satellite Operations
• Statistics and processes

Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The Problem

• Progress is slow
• Gaps need to be bridged
• Greater emphasis on

prospecting

Industry Academia Business

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The Scope

• Near Earth Asteroids
• 100m – 1km
• Low ∆v
• Frequent opportunities
• No specific spacecraft size
• No specific mission type (e.g. flyby or sample return)

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The Objective

• Generalise the prospecting mission process
• Target selection
• Mission design
• Launch & transfer
• In-situ analysis
• Identify opportunities for increased automation

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The Stats

• ≈ 8,000 NEAs (100m-1km)
• ≈ 500 more are discovered

each year (>140m)

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The Stats

• Anything brighter than H = 21

is always > 100m

• Only ≈ 12% have documented

diameters or rotation rates

• 4% have both
• 50% at H < 16 (i.e. > 1km)

16 18 20 22 24 0.0 0.2 0.4 0.6 0.8 1.0 Abolute Magnitude (H) Diameter (km)

• Abs. Magnitude vs Diameter

21

12 14 16 18 20 22 0.0 1.0 2.0 3.0 4.0 5.0 Abolute Magnitude (H) Diameter (km)

• Abs. Magnitude vs Diameter

“Good” data

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The Stats

1) 74% have inclinations < 25° 2) 93% have Synodic Period < 5 years 3) 49% are in Apollo orbits

%’s of NEAs with H < 21 from JPLs Small Body Database query tool (13/9/17)

• 69% meet the first 2 criteria
• 33% meet all 3 criteria

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The Mission

• Flyby ($)
• 1D mass, shape imagery, rotation
• Orbiter ($$)
• 3D mass, surface spectrography
• Lander / Sample Return ($$$)
• Geology / minerology / chemistry

NEAR (1996-2001) $250m Deep Space 1 (1998-2001) $150m Hayabusa (2003-2010) $300m Chang’e 2 (2010-2012) $100m Dawn (2007- …) $500m Rosetta (2004-2016) $2b Hayabusa 2 (2014- …) $150m OSIRIS Rex (2016- …) $1b

O F S R F O O/L S R S R

3rd Off Earth Mining Forum Generic Mission Process Modelling for Near Earth Asteroid Prospecting

Generic Mission Process Modelling for Near Earth Asteroid Prospecting 3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney

The Process

The Process

Generic Mission Process Modelling for Near Earth Asteroid Prospecting 3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney

The Modelling

• Pre-mission
• Light curve
• Radar Doppler
• Mid/post-mission

1620 - Geographos 25143 - Itokawa

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The Solution(s)

• Integrated process models (e.g. BPMN 2.0)
• Automated cataloguing
• Model generation and refinement
• Swarm-focussed TT&C software

3rd Off Earth Mining Forum 20 - 21 September 2017, UNSW Sydney Generic Mission Process Modelling for Near Earth Asteroid Prospecting

Generic Mission Process Modelling for Near Earth Asteroid Prospecting

The End

Thank you for coming Any Questions?
