General-Relativistic Radiative Transfer Ziri Younsi 4th November 2014 Outline Background to ray-tracing around black holes General-Relativistic (GR) Radiative Transfer (RT) formulation GRRT for a geometrically thin and


slide-1
SLIDE 1

General-Relativistic Radiative Transfer

Ziri Younsi

4th November 2014

slide-2
SLIDE 2

Outline

  • Background to ray-tracing around black holes
  • General-Relativistic (GR) Radiative Transfer (RT) formulation
  • GRRT for a geometrically thin and optically thick accretion

disk

  • Applying GRRT to 3D accretion tori: optically thick, optically

thin and quasi-opaque (translucent)

  • Compton scattering in GR
  • Conclusions and future work
slide-3
SLIDE 3

Black Hole Geodesics

  • The Kerr (spinning) black hole is an exact solution of the

Einstein field equations

  • From the metric we may construct the following Lagrangian:
  • From the Euler-Lagrange equations we may obtain the

relevant ODEs which may be solved, given appropriate initial conditions, yielding the geodesics of photons and particles

slide-4
SLIDE 4

Black Hole Geodesics

  • Four constants of motion (μ, E, Lz, Q) allow problem to be

reduced to one of quadratures, yielding 4 ODE’s:

  • However, square roots in the red ODEs for r and θ

introduce ambiguity in their signs at turning points

slide-5
SLIDE 5

Black Hole Geodesics

  • At the expense of solving 2 additional ODEs we may

circumvent this problem:

slide-6
SLIDE 6

Schwarzschild Geodesics

slide-7
SLIDE 7

Kerr Geodesics

(a=0.998)

slide-8
SLIDE 8

‘Seeing’ a Black Hole

  • Although ‘invisible’, its presence is revealed through its

interaction with nearby matter and radiation

  • A black hole acts as a gravitational lens
  • Radiation moving in its vicinity is not just deflected but also

lensed due to the intense gravitational field

  • To ‘see’ it, we must construct an observer grid and specify

each photon by co-ordinates on this grid - each photon is now a pixel: integration is performed backwards in time

  • To calculate an image we must specify for each ray the initial

conditions

slide-9
SLIDE 9

Ray-Tracing Initialisation

  • Observer grid represented

by green axes

  • z-axis of observer oriented

towards black hole center

  • x- and y-axes oriented as

shown

  • Black hole spin axis and z’

axis taken to coincide

  • Although φobs is arbitrary we

keep it as a free parameter

Text

slide-10
SLIDE 10

Ray-Tracing Initialisation

  • Calculate observer’s co-ordinates in black hole co-ordinates:
  • We may then use the transformation between BL and Cartesian

co-ordinates to calculate the I.C’s for the ray:

  • Determine initial velocity of the ray in black hole co-ordinates:
slide-11
SLIDE 11

Ray-Tracing Initialisation

  • The initial conditions of the ray may now be written as:
  • With the initial conditions we may

now ray-trace an image

  • In practical calculations we set M =1, which is equivalent to

normalising the length scale to units of the gravitational radius

slide-12
SLIDE 12

‘Seeing’ a Black Hole

slide-13
SLIDE 13

Black Hole Shadow

x[rg] y[rg]

slide-14
SLIDE 14

(Classical) Radiative Transfer

Intensity Path Length Absorption Emission

Optical Depth Source Function Scattering

slide-15
SLIDE 15
  • Two important conserved quantities result:

(1) conservation of particle number in the bundle (2) conservation of phase space volume, i.e.

Covariant Radiative Transfer

  • Consider a bundle of particles threading a phase space volume

defined as

  • These two conserved quantities imply an invariant quantity:

affine parameter

slide-16
SLIDE 16

Covariant Radiative Transfer

  • For relativistic particles:
  • The specific intensity of a ray is given by:

Lorentz invariant intensity

slide-17
SLIDE 17

Covariant Radiative Transfer

  • The velocity of a particle in the co-moving frame of a medium is:
  • The variation in path length w.r.t. affine parameter is given by:
  • The energy shift is:
slide-18
SLIDE 18

Covariant Radiative Transfer

  • Optical depth, τ, is an invariant quantity
  • Lorentz invariant absorption coefficient:
  • Lorentz invariant emission coefficient:
  • We may now write down the Lorentz invariant RT equation as:
slide-19
SLIDE 19

General-Relativistic Radiative Transfer

  • We may solve the GRRT equation and obtain the intensity as:

where the optical depth is defined as:

  • We may now decouple the GRRT equation into two ODEs:
slide-20
SLIDE 20

GR Radiative Transfer

  • Specify space time metric
  • Solve photon geodesics
  • Solve RTE along geodesics
  • Assume as a first test a

geometrically thin, optically thick disk (Shakura & Sunyaev 1973)

  • Disk scale height negligible

compared to its radial extent, effectively 2D

Adapted from C.M. Urry and P . Padovani

slide-21
SLIDE 21

The Formation of an Emission Line

Fabian et al. 2000 Tanaka et al. 1995, Nandra et al. 1997

slide-22
SLIDE 22

Optically Thick Accretion Disk

Energy shift Emission line profile

slide-23
SLIDE 23

Optically Thick Accretion Tori

  • Assume optical depth τ>>1
  • Internal structure irrelevant
  • Solve torus equations of motion to determine parametric

equations describing emission boundary surface

  • Specify angular velocity profile for torus:
  • Torus is supported by pressure forces arising from the

differential rotation of neighboring fluid elements

  • Torus is stationary, axisymmetric and rotationally supported
slide-24
SLIDE 24

Optically Thick Accretion Torus

Energy shift Emission line spectrum

E/E0 F(E)

slide-25
SLIDE 25

Optically Thick Accretion Torus

Intensity Emission line spectrum

slide-26
SLIDE 26

Optically Thin Accretion Tori

  • Construct a general relativistic perfect fluid:
  • The momentum equation yields, for a static, axisymmetric

configuration:

  • Total pressure within torus is the sum of the gas and

radiation pressures:

slide-27
SLIDE 27

Optically Thin Accretion Tori

  • Assume a polytropic equation of state for the fluid within the

torus to close the system of equations for pressure:

  • Inserting this into the fluid equations yields the torus density

structure:

Define a new variable:

slide-28
SLIDE 28

Optically Thin Accretion Tori

slide-29
SLIDE 29

Emission From Optically Thin Accretion Torus

Intensity

slide-30
SLIDE 30

Emission From Optically Thin Accretion Torus

Multiple (blended) emission lines from an optically thin accretion torus

slide-31
SLIDE 31

Emission From Quasi- Opaque Accretion Torus

  • Consider two opacity sources with emission and corresponding

absorption coefficients in the rest frame given by:

B2 is chosen such that α0rout=1-5 across the torus

slide-32
SLIDE 32

Emission From Quasi- Opaque Accretion Torus

Intensity

slide-33
SLIDE 33

Emission From Quasi- Opaque Accretion Torus

Intensity

slide-34
SLIDE 34

GR Compton Scattering

  • When scattering is included the RTE takes the form:
  • Solving the above integro-differential equation is analytically

impossible except in very symmetrical, idealised situations

  • A covariant form of the Eddington approximation (e.g. Thorne

1981, Fuerst & Wu 2006) is needed to reduce the problem to solving a system of coupled ODEs

  • No available codes to do this - reliant on Monte-Carlo

simulations and semi-analytic approaches that are restrictive

/

slide-35
SLIDE 35

GR Compton Scattering

  • The scattering kernel and its angular moments must be

evaluated covariantly

  • First the Compton scattering cross-section must be rewritten:
slide-36
SLIDE 36

GR Compton Scattering

  • After some mathematical tricks and physical insight, angular

moments of the scattering kernel may be written in the following symmetrical form:

  • The next step is to perform the above integrals
slide-37
SLIDE 37
  • First change the order of integration:

GR Compton Scattering

  • Next define three angular moment integrals:
slide-38
SLIDE 38
  • Introduce the Gauss Hypergeometric function:

GR Compton Scattering

  • This series is absolutely convergent for
  • In all of our calculations
  • The case may be solved by analytic extension:
slide-39
SLIDE 39
  • With the aforementioned hypergeometric function we may

now write the moment integrals in closed form:

GR Compton Scattering

  • There already exist numerical codes to evaluate accurately
slide-40
SLIDE 40
  • We may now write the angular moments of the Compton

scattering kernel as:

GR Compton Scattering

slide-41
SLIDE 41

GR Compton Scattering

  • The additional terms are defined as:
slide-42
SLIDE 42

The GRCS Kernel

(zeroth moment)

slide-43
SLIDE 43

The GRCS Kernel

(zeroth moment)

Pomraning 1972

slide-44
SLIDE 44

The GRCS Kernel

(1st - 5th moments)

slide-45
SLIDE 45

Conclusions

  • GRRT is a powerful tool to calculate the observed images and

EM emission in general relativistic environments

  • The structure of the accretion flow significantly alters both

the images and the spectrum

  • Radiative transfer calculations can deal with the combined

relativistic, geometrical, optical and physical effects

  • Hard to determine key black hole parameters from emission

spectrum - strongly dependent on many physical effects

  • Future work must focus on more comprehensive treatment of

both radiation processes and the accretion flow

slide-46
SLIDE 46

Future Work

  • Re-formulate geodesic equations in Kerr-Schild form,

removing stiffness at event horizon

  • Construct interface between GRRT and GRMHD simulations
  • Parallelize code in MPI (trivial in OpenMP)
  • Consider more radiation processes
  • Proper treatment of scattering
  • Polarization
