Dalian Deep Blue Pump Co.,Ltd General Presentation March,2010 We are willing to be all customers partner with advanced technologies, excellent products and consummate services. Table of Contents Deep Blue in brief Customers and
We are willing to be all customers’ partner with advanced technologies, excellent products and consummate services.
2
Deep Blue in brief Customers and References Products and Services R & D and Engineering Foundry and Castings Machining and Fabrication Assembly Testing QA/QC After services Contact us at
3
Deep Blue in brief
The recognized Chinese top manufacturer for industrial engineered centrifugal pumps, especially for API610 pumps. One of the few nuclear island pumps manufacturers, certified by China National Nuclear Security Administration and ASME N type. The only one in China, one of the few manufacturers in the world who can design, make liquid oxygen pump unit running under -183 in air separation service. Respected specialized pumps manufacturer with more than enough references all
China, such as SINOPEC, CNPC, CNOOC, etc. One of the most cost-effective options for global customers, exporting pumps to 37 countries in the world up to now, customers including Gazprom, Rosneft, NIOC, Saudi Armco, Petronas, Pertamina, Technip, Linde, Saipem, etc.
4
Deep Blue in brief
Dalian Second Acid Proof Pump Works. In 1997, name changed to Dalian Deep Blue Pump Co., Ltd. In 2008, Deep Blue Industry Park put into use. Now, Dalian Deep Blue Pump Co.,Ltd is a member of Deep Blue Group with about 1,200 employees, three existing factories occupying 420,000 m2 and another new factory of 340,000 m2 under planning. .
Dalian Deep Blue International Industrial Group Dalian Deep Blue Pump Co.,LTd Deep Blue Trademark Original Trademark
5
Deep Blue in brief
Fields of Activities Deep Blue pumps are widely used in the fields of
highly anti-corrosion alloys are required.
51% 16% 18% 13% 2% Oil&Gas Petrochemicals Chemicals Coal gasification & liquidation Nuclear Others
Segments by industries Geographic location Headquarters and factories locate in the Dalian City, which is in the northeast China, half an hour drive to Dalian Port, which is a deepwater one and one of the important foreign trade ports of China, assures convenient and quick transportation.
6
Deep Blue in brief
R&D and engineering Melting and casting Machining and fabrication Assembly Testing and inspection Supply aftermarket products, consulting, repair and diagnostic services.
Large selection of pump types and sizes, covers most API610 pump types, large range of parameters, for various applications. Large selection of pump materials from Carbon Steel to Super Duplex, also Hastelloy, Monel, Zirconium, etc.
7
Customers and References
CHINA PETROLEUM & CHEMICAL CORPORATION
8
Detailed references to the above companies and many other compan Detailed references to the above companies and many other companies are available ies are available upon request. upon request.
9
Customers and References
Click here for more details Click here for more details
References. References.
10
Products and Services
With a wide variety of pumps and the excellent R&D, engineering abilities, Deep Blue
and related services. Pump types
Power Recover Turbines, Self-priming pumps, Low-flow high-head pumps, etc.
Parameters:
Materials:
Standards:
Due to continuous improvements, the above data are subject to ch Due to continuous improvements, the above data are subject to change without notice. ange without notice. Click here for more details of our Range and Features. Click here for more details of our Range and Features.
11
R & D and Engineering
Deep Blue has 320 professional engineering and technical personnel constantly endeavoring to infuse new know-how and continuously upgrading quality. About 100 in company’s R &D center, including 12 senior engineers and 65 engineers are focusing on research and development. About 60 in company’s engineering departments are offering customers with quick responses, quotations, engineering solutions and services.
12
R & D and Engineering
Planar and Three-dimensional Computer Aided Design Finite Element Analysis Computer Aided Process Planning Computational Fluid Dynamics Other various customized professional software and programs are applied widely.
13
R & D and Engineering
Supported by China National Development and Reform Commission and cooperating with first-class universities and research institutes. Deep Blue has accompli- shed and is undertaking various research tasks set by national government departments and some customers, such as localization and impro- vement, new products and technologies. Click here for more Click here for more details of R&D and details of R&D and Engineering. Engineering.
14
Foundry and Castings
Specialize in various pump parts’ die making, molding, melting and casting, heat treatment, etc. Materials as per ISO, ASTM and GB standards, such as carbon steel, stainless steel, duplex steel , supper duplex steel, Hastelloy, Monel and Inconel, etc. Physical properties and chemical composition laboratories with more than 50 sets of instruments and equipments, including Spark Spectrum Analyzer and PMI instruments.
15
Foundry and Castings
Nine sets of medium-frequency induction furnaces from 250 kg to 5 tons. Two AOD (argon oxygen decarburization) furnaces, each is of 5 tons. One VOD (vacuum oxygen decarburization) furnaces of 3 tons. Both resin sand casting and lost-wax casting are applied. Maximum Single piece part’s weight is 14 tons. Click here for more details of Foundry and Castings. Click here for more details of Foundry and Castings.
16
Machining and Fabrication
Four workshops equipped with more than 200 sets of various machine tools including NC machine tools and machining centers.
17
Machining and Fabrication
Turning diameter up to 4.0m, turning length up to 10.0m, grind length up to 4.0m, milling dimensions up to 2.5m x 5.0m, boring dimensions up to 2.5m x 2.5m. Various qualified operators including welders certified by ASEM and China government. ASME U Stamp certificate. Click here for more details our Machining and Fabrication. Click here for more details our Machining and Fabrication.
18
Assembly
Four workshops including two standard pumps workshops, one special pumps workshop and one nuclear pumps workshop. Standard pumps workshop: Floor area of 8,500 m2,lifting capacity of 10 tons. Special pumps workshop: Floor area of 7,000 m2,lifting capacity of 50 tons. Nuclear pumps workshop: Floor area of 5,000 m2,lifting capacity of 20 tons. Click here for more details our Assembly. Click here for more details our Assembly.
19
Testing
The four existing fully equipped testing stations ensure every pump supplied by Deep Blue is fully tested before its ex-works, to prove performance and ensure problem free commissioning on site. One testing station with power up to 4,500 kW is under construction. The testing station can heat the testing liquids to 240 degrees centigrade, the Thermal Shock Test can be executed. The testing station can test the pumps with slurry water.
20
Testing
All testing stations can do full string testing, performance testing, noise testing, vibration testing, NPSH testing, running testing and other testing deemed as necessary by Deep Blue are available and applied, also other testings are possible if required by customer. One standard pumps testing station has one closed test loop, five testing positions for horizontal pumps and one testing position for vertical pumps, power up to 250 kW and capacity up to 3,000 m3/h.
21
Testing
One special pumps testing stations has two closed test loops, eight testing positions for horizontal pumps, five testing positions for vertical pumps and one testing position for Hydraulic Power Recovery Turbines, power up to 3,000 kW and capacity up to 30,000 m3/h.
22
Testing
Click here for more details of our Testing. Click here for more details of our Testing. One ultra-low temperature pumps testing station has one closed test loop, one testing position for horizontal and vertical pumps, power up to 500 kW, apply liquid nitrogen as testing liquid, lowest temperature can be -198 ℃. This testing station is to test the liquid oxygen pumps of air separation unit under -183℃.
23
QC/QA
Engineered and manufactured, sold and service to ISO9001 quality certification since 1997. Now, our Quality Management System complies with national and international standards using ISO 9001:2000 as its basis, meets the strict nuclear pumps QC/QA requirements, cooperating with AREVA France. Being qualified vendor of many global customers. Equipped with various specialized measuring, inspection, testing instruments and equipments, and qualified operators and inspectors. Click here for more details our QA/QC. Click here for more details our QA/QC.
24
After service
With own after-service teams, consist of more than 30 qualified service engineers, supported by headquarters and cooperate with local partners in many countries, the company offers quick responses and comprehensive services to customers in most countries over the world, including on-site services for startup, commissioning, routine maintenance, repair, trouble-shooting and training programs. Click here for more details of our After service. Click here for more details of our After service.
25
Address: No.86, Xiwa Street, Ganjingzi District City: Dalian Province: Liaoning Country: The People’s Republic of China Post code: 116031 Tel.: +86 411-86425756 Fax.: +86 411-86429455 Email: Overseas@deepbluepump.com Website: www.deepbluepump.com
26
For more information, you may find on our website For more information, you may find on our website www.deepbluepump.com www.deepbluepump.com, or ask us directly. , or ask us directly.
