General Meeting 19 April 2011

slide-2
SLIDE 2

Disclaimer

This document is not a disclosure document nor does it constitute the provision of financial product advice. No representation or warranty is made as to the accuracy, completeness or reliability of the information. The information is provided expressly on the basis that recipients will carry out their own independent inquiries into the matters contained herein and make their own independent decisions about the affairs, financial position or prospects of the Company which reserves the right to update, amend or supplement any information at any time in its absolute discretion. COMPETENT PERSONS STATEMENT The information in this report that relates to Mineral Resources is based on information compiled by Hennie Theart, BSc (Hons), MSc, PhD, Pr. Sci. Nat (SACNASP 400069/88), FSEG, FGSSA, FAAG; Shaun Crisp, BSc (Hons), Pr.Sci.Nat. (SACNASP 400076/09); and Brent Barber, BSc (Hons), MPhil, AusIMM (222559), AAPG (59319-8). Hennie Theart and Shaun Crisp are registered with the South African Council for Natural Scientific Professions (SACNASP), a JORC Recognised Overseas Professional Organisation "ROPO" and Brent Barber is a member of the Australasian Institute of Mining and Metallurgy (AusIMM). They are full-time employees of SRK Consulting and have experience which is relevant to the style of mineralisation, type of deposits under consideration and to the activity which they have undertaken, to qualify them as a Competent Persons, as defined in the 2004 Edition of the 'Australasian Code for Reporting of Exploration Results, Minerals Resources and Ore Reserves'. Hennie Theart, Shaun Crisp and Brent Barber consent to the inclusion in the report of the matters based on their information in the form and context in which it appears. The information in this release that relates to the Exploration Process is based on information compiled by A Johnstone who is a member of the Australian Institute of Geoscientists (AIG). Andrew Johnstone provides exploration management consulting services to Gulf Industrials Ltd and has sufficient experience relevant to the style of mineralisation and type of deposit under consideration and to the activity which Andrew Johnstone has undertaken to qualify as a Competent Person as defined in the 2004 Edition of the 'Australasian Code for Reporting of Exploration Results, Mineral Resources and Ore Reserves'. Andrew Johnstone consents to the inclusion in the report of the matters based on his information in the form and context in which it appears.

slide-3
SLIDE 3

Gulf Board

NE Chairman Sir Sam Jonah KBE OSG CEO Vic Fitzmaurice CFO Wayne Kernaghan NE Directors Mike Brook African Lion 3 Jonathan Best Chris Innis Bobby Jurd Corporate Advisor Mark Arnesen

3

slide-4
SLIDE 4

Corporate Snapshot

  • Share on Issue

429 M (ASX : GLF)

  • Options

25M (ASX : GLFO) 52M (ASX : GLFOB) 39.5 M unlisted options

  • Major Shareholders

African Lion 3 Ltd 18.6% Jonah Capital BVI Ltd 14%

  • Top 20 Shareholders

52%

4

slide-5
SLIDE 5

Why Industrial Minerals?

  • Essential raw materials for a wide range of industrial and domestic

products

  • Building blocks for industrialization
  • Demand is consistent and long term
  • Vermiculite / phosphate / limestone
  • Logistics must be manageable and cost effective
  • Price increases >30% - 50%

(Vermiculite from 2010 - 2011).

slide-6
SLIDE 6

Gulf Projects

6

  • Uganda – Namekara Vermiculite Mine

 55Mt JORC Inferred Resource (Example: >50y mine life at 280,000tpa possible, thus not resource constrained)  Largest vermiculite resource with coarse grades  Preparation for expansion to 30,000 tpa in progress for July 2011  Operational Staffing successful  Expanded mining lease  Expansion planning in progress (base case to 80ktpa, and 130ktpa)  Carbonatite under explored (old Phosphate mine, Cu, Fe, REE, Etc.)

  • Madagascar

 Soalara Limestone project  Logistics study completed  BFS planned

  • Kenya

 Mwingi project (greenfields) – Review Strategy

slide-7
SLIDE 7

Namekara Vermiculite

Namekara Mine Namekara Mine

slide-8
SLIDE 8

Namekara Vermiculite Resource

  • JORC Inferred Resource (Red Block):

54.9mt @ 26.7% V_180μm and 18.8% @ V_425μm

  • Rio Tinto (2008)
  • SRK Consulting (2009)
  • 15m x 15m x 10m block model (grade

estimation by inverse distance weighted method)

Total Contained Vermiculite: 100% Premium (+9.50 mm) 8 % Large Grade (+5.60 mm) 21 % Medium Grade (+2.00 mm) 30 % Fine Grade (+1.18mm) 20 % < S/ Fine, micron, super-micron (-1.18mm) 21 %

slide-9
SLIDE 9

Vermiculite – from mine to final product

9

  • Vermiculite is a product of weathered phlogopite (mica), i.e. A natural mineral

that occurs in the ground, in veins and mixed with other minerals in the soil.

  • Vermiculite ore is mined by opencast means in a quarry
  • The ore is dried, screened, crushed and winnowed (air separated) and produces

a concentrate graded by size, and sold to Exfoliators.

  • Vermiculite expands when heated in a kiln, thus producing lightweight particles

called ‘exfoliated’ or ‘expanded’ vermiculite.

  • Exfoliators will apply the exfoliated product in industrial processes or onward sell

it

  • Its many uses are derived from its unique physical and chemical properties,

mostly after exfoliation:-

  • low weight,
  • its capacity to absorb and slowly release liquids,
  • Its excellent insulation values against heat and sound and
  • its ability to withstand chemical attack.
slide-10
SLIDE 10

Vermiculite Process Flowsheet

10

slide-11
SLIDE 11

Vermiculite Markets

11

  • Namekara is one the world’s largest vermiculite resource with coarse grades

(>60% of product)

  • Coarse grades attract higher prices (>100% price differential between “FINE”

and “Coarse” product)

  • World demand 700ktpa – 1,000ktpa (Dupre) (Roskill 650ktpa)
  • Shortfall of 200ktpa – 400ktpa (Actual demand not being met)
  • Vermiculite pricing for 2011 increased between 30% and 50%
  • Namekara resource can produce up to 280ktpa (logistics study currently

underway)

  • Dupre has sales orders >120ktpa (in Europe only) from 2012 onwards
  • Other producers:-
  • South Africa produce about 190ktpa, declining, no coarse grades
  • USA – Shortfall and declining mine production
  • India, China, Japan, etc. Shortfall
  • Brazil new capacity (Fine products only)
slide-12
SLIDE 12

Vermiculite Marketing DUPRE MINERALS

12

  • Dupre Minerals, a wholly owned subsidiary of the Goodwin Group PLC UK.
  • Experienced in vermiculite processing and marketing
  • Experienced Sales force
  • Purchase product F.O.B. Mombasa
  • Handle all product from port to final destination
  • Technical assistance (laboratory, product improvement, R&D, etc.)
  • World wide distributor of Namekara product
  • In discussions to assist Gulf to advance capacity to 130ktpa
slide-13
SLIDE 13

Vermiculite – Namekara

13

Trenching in the Pit, Pit dug at site of old RioTinto drill hole PWC, Palabora (Very dark) Unweathered Namekara (Darker) Weathered Namekara (Light colour)

slide-14
SLIDE 14

Namekara Vermiculite Concentrate (Crude)

Medium Premium Large

slide-15
SLIDE 15

Namekara Vermiculite Exfoliated

slide-16
SLIDE 16

Vermiculite uses

  • Industrial
  • Friction products (Brakes, clutch, etc.)
  • Construction
  • Fire proofing products
  • Insulation and insulating products
  • Horticultural
  • Agricultural
  • General

16

slide-17
SLIDE 17

Namekara Vermiculite Sales Projection (000 tons pa)

20 40 60 80 100 120 140 2011 2012 2013 2014 Plant 3 Plant 2 Plant 1

slide-18
SLIDE 18

Namekara Current Status

18

  • Social, Environmental, Safety & Health

 Good community relationships  Equator principles  Land relocation plan to date successful  Nil fatalities, Nil lost time accidents, Nil community incidents

  • Production sold

 1,125t Q1/2011  1,351t Q2/2011  1,800t Q3/2011

  • Forecast 2,500t pm from July 2011
slide-19
SLIDE 19

Namekara Future

19

  • Feasibility Study – Vermiculite Production Expansion

 Resource  Reserve  Marketing (coarse products)  Logistics (130,000tpa confirmed)  Mine Planning (confirmed up to 280,000tpa product)  Plant Expansions planned (50,000tpa modules)

  • Exploration

 Mining Licence increased  Additional minerals (Cu, Fe, Phosphate, REE)

  • Technical Studies

 Phosphate, etc  Vermiculite extraction improvements

slide-20
SLIDE 20

Namekara Exploration

  • Resource and sterilisation drilling: Increased in drilling pattern

around the mine to move JORC resource to reserve (mine planning)

  • Consultant appointed to review and renew Independent

Competent Person’s Report (Due End 2011)

  • Exploration drilling and activities on tenements surrounding the

mine (retain licenses in good standing)

  • Exploration targets identified and project planning in progress

based on 2010 drilling (6 x RC Holes) and exploration

  • Drilling expected to start in May 2011
  • Target minerals – Vermiculite, Phosphate, Copper, Iron Ore, REE

20

slide-21
SLIDE 21

Namekara Rio Tinto Drilling (2 campaigns)

21

slide-22
SLIDE 22

Namekara Future

22

slide-23
SLIDE 23

Namekara Future - Exploration

23

slide-24
SLIDE 24

Namekara Export Route / Logistics study Confirmed 130,000tpa / 280ktpa underway

24

Namekara Mine Port of Mombasa

slide-25
SLIDE 25

Namekara Export Route / Logistics study Confirmed 130,000tpa

25

slide-26
SLIDE 26

Namekara Mine – Vermiculite veins

26

slide-27
SLIDE 27

Namekara Mine pit

27

slide-28
SLIDE 28

Namekara haulers

28

slide-29
SLIDE 29

Namekara Mine – New Drier

29

slide-30
SLIDE 30

Namekara Exploration (2010)

30

slide-31
SLIDE 31

Community Clinic

31

slide-32
SLIDE 32

Community – New house for relocation

32

slide-33
SLIDE 33

Community – Foot ball kit

33

slide-34
SLIDE 34

Community – Food garden trials

34

slide-35
SLIDE 35

Community – first ladies employed

35

slide-36
SLIDE 36

Madagascar

36

slide-37
SLIDE 37

Company Growth Strategy

  • Madagascar Soalara concept planning:-
  • Develop Soalara Limestone: From zero  2Mtpa (BFS limestone)  5Mtpa (PFS on
  • ther products)
  • Drilling / Environmental / BFS
  • Time table – TBC
  • Funding - TBC
  • Harbour development (3rd party) delayed
  • Logistic study completed (Confirmed temporary harbour solution for 2Mtpa)
  • Strategic Alliance discussions (Underpinning off take, logistics, etc)
  • Off take(s) strategy and timing critical

37

slide-38
SLIDE 38

Madagascar Limestone – Soalara Project

slide-39
SLIDE 39

Conclusion

39

slide-40
SLIDE 40

Conclusion

  • Company moving from very small scale vermiculite producer to

significant staged expansion, underpinned by strong market demand and robust feasibility studies

  • Unlocking the exploration potential of one of the world’s

largest Carbonatites

  • Assets under-explored
  • Capital Requirement
  • Uganda vermiculite mine expansions
  • resource and sterilisation drilling
  • working capital
  • Feasibility studies (future expansion)
  • Evaluate growth opportunities

40

slide-41
SLIDE 41

Thank You

41

slide-42
SLIDE 42

General Meeting 19 April 2011

slide-43
SLIDE 43

General Meeting Additional Slides 19 April 2011

slide-44
SLIDE 44

Vermiculite – Uses

  • Industrial
  • Construction
  • Horticultural
  • Agricultural
  • General

44

slide-45
SLIDE 45

Vermiculite – Uses

  • Industrial
  • Friction products, clutches, brake pads / shoes
  • Fire proofing (paints, boards, plaster, etc.)
  • Insulation (furnaces, buildings, molten materials, etc.)
  • refractories
  • Fixation of hazardous materials
  • Insulation blocks and shapes
  • Low & High temperature insulation
  • Molten metal insulation
  • Moulded products
  • Nuclear waste disposal
  • Paints
  • Perfume absorbents, etc.

45

slide-46
SLIDE 46

Vermiculite – Uses

  • Construction
  • Acoustic finishes
  • Air setting binders
  • Construction boards (fire proof and insulating)
  • Floor & Roof screeds
  • Combined with Gypsum plasterboard
  • Loose fill loft and wall insulation
  • Filtration
  • Ceiling boards
  • Roof profiles and tiles
  • Wall and floor tiles
  • Floor boards
  • etc.

46

slide-47
SLIDE 47

Vermiculite – Uses

  • Horticultural
  • Blocking mixes
  • Hydroponics
  • Micro – propagation
  • Potting mixes
  • Root cuttings
  • Seed germination
  • Sowing compost
  • etc.

47

slide-48
SLIDE 48

Vermiculite – Uses

  • Agricultural
  • Animal feed
  • Anti-caking agent
  • Bulking agent
  • Fertilizer carrier
  • Pesticide carrier
  • Seed encapsulement
  • Soil conditioner, etc
  • General
  • Kitty litter
  • Flower decorations (freshness)
  • Odour absorption, etc.

48
