General Aviation Apron Improvements 2019 KSPE Annual Conference June 13, 2019 Project Location Project Limits Original Construction in 1952 129,000 SY of pavement Aircraft Variety Pavement Condition (2016) Remaining Life (2016)

slide-1
SLIDE 1

General Aviation Apron Improvements 2019 KSPE Annual Conference

June 13, 2019

slide-2
SLIDE 2

Project Location

slide-3
SLIDE 3

Project Limits

  • Original Construction in 1952
  • 129,000 SY of pavement
slide-4
SLIDE 4

Aircraft Variety

slide-5
SLIDE 5

Pavement Condition (2016)

slide-6
SLIDE 6

Remaining Life (2016)

Functional Remaining Life <5 Yrs

slide-7
SLIDE 7

W I C H I T A D W I G H T D . E I S E N H O W E R N A T I O N A L A I R P O R T

Project Overview & Goals

Pavement Condition Operational Safety Apron Expansion Non-Standard Taxiways North Taxi/Tug Route Construction Sequencing

slide-8
SLIDE 8

Non-Movement Area

slide-9
SLIDE 9

W I C H I T A D W I G H T D . E I S E N H O W E R N A T I O N A L A I R P O R T

Stakeholder Engagement

  • Four Stakeholder Meeting Sessions
  • Active Participation
  • Most Productive
slide-10
SLIDE 10

W I C H I T A D W I G H T D . E I S E N H O W E R N A T I O N A L A I R P O R T

Tenant Survey

  • Forecast Data-Annual and Peak
  • Operational Requirements
  • Parking Requirements
  • Accessibility Requirements
  • Infrastructure Requirements
  • Safety Issues
slide-11
SLIDE 11

Tenant Lease Areas

slide-12
SLIDE 12

Projected Annual Departures

slide-13
SLIDE 13

Baseline Operations

ICT GA Apron Fleet Mix - Existing Conditions and Forecasts

ADG Textron Yingling Hangar 1 Signature Bevan Rabell Yingling Hangar 10 Hangar 16 MCAS

ADG breakdown of Ops I 24% 25% 36% 67% 33% 0% 75% II 71% 68% 59% 33% 67% 86% 25% III 5% 6% 4% 0% 0% 14% 1% IV 0% 0% 1% 0% 0% 0% 0% Busy Day Fleet Mix I 5 16 23 19 1 4 II 14 42 38 9 1 5 2 III 1 4 3 1 1 1 IV 1 1 (totals) 20 63 65 29 3 6 7 Note: Proposed Hangar rebuild at Yingling North changes fleet mix to ADG I-26%, ADG II-60%, ADG III- 14% in 2020 and increased maintenance activity increases operations.

slide-14
SLIDE 14

Baseline Operations

ICT GA Apron Fleet Mix - Existing Conditions and Forecasts

ADG Textron Yingling Hangar 1 Signature Bevan Rabell Yingling Hangar 10 Hangar 16 MCAS 2022 Busy Day I 6 18 25 20 3 6 II 16 47 42 10 5 7 2 III 2 5 3 1 2 2 1 IV 1 1 2027 Busy Day I 6 20 27 20 3 6 II 18 53 44 10 5 8 2 III 2 5 3 1 2 2 1 IV 1 1 2037 Busy Day I 7 23 31 20 3 6 II 21 62 52 10 6 9 2 III 2 6 4 1 2 2 1 IV 1 1 Note: Proposed Hangar rebuild at Yingling North changes fleet mix to ADG I-26%, ADG II-60%, ADG III- 14% in 2020 and increased maintenance activity increases operations.

slide-15
SLIDE 15

Apron Space Requirements

ADG I II III IV Area (SY) 390 580 2000 2500

  • Typ. Aircraft

Lear 45 Hawker 400 Cessna 425 Kodiak Beech Baron Beech Bonanza F-15/16/18 Cessna 172/182 Cessna Caravan Phenom 100/200 Challenger 300 Citation Latitude Citation X Beech King Air Gulfstream III CS100/CS300 Boeing 737 Gulfstream V Global Express BBJ C-130

slide-16
SLIDE 16

Calculated Apron Needs

ICT GA Apron Forecast Busy Day Ramp Space Requirements Ramp Areas Textron Yingling H-1 Signature Bevan Rabell Hangar 10 Yingling H-16 MCAS Totals Current Ramp Area (SY) 21,704 25,322 29,077 11,482 10,213 5,186 14,214 117,198 Current Busy Day Ramp Required (SY) 12,070 41,100 39,510 14,630 970 4,900 4,720 117,900 Difference (SY) - deficiency 9,634 15,778 10,433 3,148 9,243 286 9,494 2022 Busy Day Ramp Required (SY) 15,620 46,780 42,610 15,600 8,070 8,060 5,500 142,240 Difference (SY) - deficiency 6,084 21,458 13,533 4,118 2,143 2,874 8,714 2027 Busy Day Ramp Required (SY) 16,780 51,040 44,550 15,600 8,070 8,640 5,500 150,180 Difference (SY) - deficiency 4,924 25,718 15,473 4,118 2,143 3,454 8,714 2037 Busy Day Ramp Required (SY) 18,910 59,430 52,750 15,600 8,650 9,220 5,500 170,060 Difference (SY) - deficiency 2,794 34,108 23,673 4,118 1,563 4,034 8,714

slide-17
SLIDE 17

Apron Areas

  • North Apron
  • Center Apron
  • South Apron
slide-18
SLIDE 18

South Apron Alternative No. 1

slide-19
SLIDE 19

South Apron Alternative No. 2

slide-20
SLIDE 20

South Apron Alternative No. 3

slide-21
SLIDE 21

Connector Taxiway Alternatives

slide-22
SLIDE 22

Center Apron Alternative No. 1

slide-23
SLIDE 23

Center Apron Alternative No. 2

slide-24
SLIDE 24

Center Apron Alternative No. 3

slide-25
SLIDE 25

North Apron Alternative No. 1

slide-26
SLIDE 26

Taxilane H-3 Alternative 1

slide-27
SLIDE 27

Taxilane H-3 Alternative 2

slide-28
SLIDE 28

GA Apron – Preferred Alternative

  • Aircraft Parking Areas
  • Taxilanes
  • Vehicle Service Roads
  • GSE Parking
slide-29
SLIDE 29

Aircraft Parking Areas – South Apron

slide-30
SLIDE 30

Aircraft Parking Areas – Center Apron

slide-31
SLIDE 31

Aircraft Parking Areas – North Apron

slide-32
SLIDE 32

Pavement Strengths

slide-33
SLIDE 33

Apron Lighting

HIGH MAST APRON LIGHTING

slide-34
SLIDE 34

Funding Scenario 1 (Entitlements Only)

slide-35
SLIDE 35

Funding Scenario 2 (Entitlements + Discretionary)

slide-36
SLIDE 36

Funding Scenario 3 (Single Project)

slide-37
SLIDE 37

Current Status

slide-38
SLIDE 38

Questions!
