Formal Methods Group ETH Z¨ urich

June 2003 Armin Biere, Cyrille Artho, Malek Haroud, Viktor Schuppan Computer Systems Institute ETH Z¨ urich, Switzerland

FMICS’03, Røros, Norway

Vision

2

Formal method tools are used like compilers: In the context of (formal)       

• 1. verification.
• 2. synthesis.
• 3. analysis.

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

Overview

3

• 1. Model Checking, SAT, and QBF

.

• 2. Translation of liveness into safety.
• 3. High-level data races.
• 4. Replaying of multi-threaded executions.
• 5. Equivalence checking of SDL vs C.

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

Model Checking

4

➤ BDD based mu-calculus model checker mu-cke – Efficient implementation. – Input language with C++ syntax for specifying model and properties. ➤ Performance study of BDD based model checking ➤ Bounded Model Checking – Leverages power of SAT solvers for model checking purposes. – Wide industrial acceptance.

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

SAT and QBF

5

➤ SAT (propositional satisfiability solvers) – Continuing increase in reasoning power. – Instances with million of variables can often be handled. – Dedicated heuristics for bounded model checking possible. ➤ Solvers for QBF (quantified boolean formula), e.g., ∀ x ∃ y [(x∨y)∧(x∨y)] – Start to become practical ... – ... although more practical research necessary (efficient implementations). – Potentially allow to make bounded model checking complete. ➤ Applications of QBF and SAT in other domains (e.g., SW checking).

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

Translating Liveness into Safety: Finite State Systems

6

1 2 3

+

Liveness

→

1’ 3’ 2’ ⊥ 1 2 3

+

Safety

If the number of states is finite:

• 1. A system with a liveness property can be transformed into a system with an

equivalent safety property.

• 2. The transformed system can be model-checked efficiently.

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

Translating Liveness into Safety: Predicated Radius/Diameter

7

d =3 ¬p ¬p ¬p ¬p ¬p p d=2

Bounds stated at FMICS’02 require further restrictions:

➤ Search for counterexample traverses paths where ¬p holds. ➤ Notion of predicated radius and diameter. ➤ Leads to tight bound for bounded model checking of Fp.

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

JNuke: Our own Java Virtual Machine

8

Platform for static and dynamic analysis

Loader VM Instrumenter Bytecode

➤ Java VM written in C. ➤ API for run-time analysis. ➤ Small state representation. ➤ Rollback (undo) operations. ➤ “Exhaustive” scheduling possible (Rivet). ➤ Instrumentation: reproducing counterexamples.

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

JNuke: High-level data race analysis

9

X Y Z X Y

Thread 2 Thread 1

➤ Both accesses are protected by a common lock (Eraser). ➤ Different atomicity assumptions by the two threads. ➤ New source of potential errors, found by view consistency.

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

JNuke: Replay of Multi-Threaded Executions

10

modified .class replay engine .class jreplay Dynamic Checker Checker Static VM JNuke compliant

T0 T1 T2

t

T1

before Class 1 0 1 switch 1 before Class 2 1 1 switch 2 before Class 1 2 1 switch 1 terminate in Class 2 1 10

VM/ debugger schedule deterministic execution

➤ Enables replay of thread schedules independently of specific VM. → Off-the-shelf debuggers. ➤ Schedule format not tailored to JNuke VM. → Usable by other tools.

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

Equivalence Checking SDL vs C

11

SDL Synthesized C Program Manually Generated Optimized C Program

Equivalence Checking Verification with

S y n t h e s i s S y n t h e s i s SDL as modelling language in telecommunication applications same motivation as in HW equivalence checking (or more general for embedded SW) Model

FMICS’03 – Røros – Norway – June 2003 Formal Methods Group – Computer Systems Institute – ETH Z¨ urich

Establishing formal methods

12

Short-term: Scalability, light-weight process. Long-term: Formal loop: Formal methods on all levels.
