forensics tries to reconstruct and explain activities and events - - PowerPoint PPT Presentation

2

• forensics tries to reconstruct and explain activities and events

–

their actors and participants

–

causes

–

consequences

• individual forensic procedures

–

in the best case can only provide parts of the puzzle

• for the whole picture/story

–

they need to be put in the right sequence

–

interpreted in broader context

• the legal ramifications of forensic investigation it is important to

–

make sure that forensic material cannot be changed (tampered)

• after being acquired

–

and that this can be proved

• therefore we need a well defined procedure(s)

2015-2017 (c) P.Pale: Računalna forenzika - Procedures 21.12.2018.

3

• police (court) forensics

▪ have their required, mandatory procedures ▪ scope defined by law

• this course teaches generic/general forensics

▪ applicable in industry

• therefore it is not based on

procedures defined by any law(s)

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

4

• reconnaissance of the target system
• planning the evidence acquisition
• acquisition of evidence material
• storing and guarding the material
• analysis of the material
• reporting
• But!

▪ before the beginning ▪ acquire/define the questions you need to give answers to

• in written form

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

5

• what is it all about – what are we invetigating

▪ disaster, attack, problems , suspicion…

• define the scope of the system –

what are we going to observe/analyse

▪ computer/device, cluster, system, data, organization, public …

• enumerate/list components

▪ servers, workstations, portable devices, phones, other equipment connected with IT components

• interview actors and stakeholders

▪ operators, managers, management, users, partners …

• gather the documentation

▪ communication system’s blueprints ▪ logic blueprints of information system

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

6

• gather as many as possible information

▪ about the subject of investigation

• passive gathering
• interviews

▪ users ▪ operates ▪ authorized persons ▪ everybody involved

• find out

▪ which network resources are used ▪ which communication systems

• mail servers
• social networks
• …

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

7

• identify target device/program/data
• if this is not possible, than enumerate/list:

▪ computers: servers, users’ ▪ handheld devices ▪ communication equipment ▪ other

• identify other target devices
• identify other targed data
• determine which devices can be turned off
• define the sequence of acquisition
• ensure the legitimacy
• f the procedure, authority, support

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

8

• remove all persons from the

physical space except forensics

• do not touch anything
• take photos of the scene

▪ record (in written) everything that seems important

• take photos and document

how things were connected

• seize devices
• take cables too, if they are special

▪ power supplies

• take media
• do not forget printed documents

▪ hand written, reminders etc.

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

• physically protect

the objects

▪ for transport ▪ for storage ▪ prepare instructions for transport

• label every object

uniquely

▪ the very object ▪ and its packaging

• prepare all necessary

documentation for takeover of evidence

▪ and acquire all signatures

9

• do not turn off devices which are turned on gasite

▪ du not turn on those which are turned off

• communication devices which have wireless

communication put in Faraday bags

• look around the devices

▪ take all gadgets which could be part of the device

• if you have to turn the device off

▪ first take the photo of the screen ▪ make a list of active applications, visited web sites, …

• if it can be done safely!!!

▪ capture the RAM ▪ take the battery out from portable devices

• when detaching cables

▪ label them, make sketches ▪ and take photos

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

10

• storage and protection must be according to law
• keep separate inventory of stored materials
• copy everything that can be copied

▪ analysis should not be done on original evidence material

• access to stored evidence material

must be under strict surveillance

▪ this pertains to investigator’s notes and reports ▪ keep the access log to stored material

• take special care about parts of devices

that can be detached

▪ each part should be separately labeled and logged

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

11

• acquire the order for analysis

▪ what are we looking for? ▪ which questions do we need to answer?

• perform the forensic analysis

▪ but on copies of data

• keep precise log

▪ what was investigated ▪ why ▪ who performed investigation ▪ how, with what ▪ what did they find

• data
• conclusions
• prepare data for report

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

12

• question or hypothesis
• the object (which material) will be analyzed
• which method
• which tools
• when (from– to)
• results
• conclusion/finding
• next step - proposal

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

• Investigation
• Expert
• Date
• Place
• ID of analysis
• ….

13

• who (all) will receive reports & what are their questions
• separate report for different recipients

▪ based on gathered documentation and ▪ results of analyses

• Important! Forensic expert is not the judge.

Does not define the responsibility.

▪ but merely states facts & offers expert interpretation ▪ in ideal case, the forensic expert merely answers the questions

• take care about the level of confidentiality

▪ mark confidentiality in appropriate manner

• get ready for oral presentation of findings and or

▪ questions ▪ counter-arguments

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

Keep detailed log about given answers

14

• Case description
• Broader assignment

▪ order/warrant

• Expert opinion

▪ answer to question #1 ▪ answer to question # 2 ▪ … ▪ answer to question # N

• Argumentation

▪ by each question ▪ short

• Findings od analyses

▪ results ▪ by each question/analysis

• Forensic team

▪ their competences

• Methods od work
• Addenda

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures

• the report is result of your entire work
• thers do not seee te rest
• any other expert should understand it
• and reach same conclusions

15

• when you are sure there will be no more

investigation

▪ return all evidence material ▪ archive all documentation

• lists
• minutes
• logs
• reports

▪ in special cases – destroy all work materials

• and have the proof you did it

21.12.2018. 2015-2017 (c) P.Pale: Računalna forenzika - Procedures
