Flight Readiness Review Presentation Vanderbilt Aerospace Design Lab Vanderbilt Aerospace Design Lab: FRR 3/6/2017 Meeting Agenda Mission Overview Vehicle Design & Verification Payload Design & Verification Launch Results Ground

slide-1
SLIDE 1

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Flight Readiness Review Presentation

Vanderbilt Aerospace Design Lab

slide-2
SLIDE 2

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Meeting Agenda

2

Conclusion Project Plan Mission Overview Vehicle Design & Verification Payload Design & Verification Launch Results Ground Based Testing

slide-3
SLIDE 3

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Mission Overview

3

Vehicle Objectives

  • Reach desired apogee with

minimal overshoot

  • Recover flight vehicle

Payload Objectives

  • Perform roll induction via cold

gas thruster actuation

○ Achieve 4π radians of rotation ○ Halt all rolling motion for remainder

  • f flight
  • Develop roll control system

algorithms

○ Utilize ground-based testing

slide-4
SLIDE 4

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

CDR Questions

What will be done to increase thrust?

  • Tank pressure increased to combat inherent regulator droop
  • Purchased higher flow regulator to further combat droop

Late parachute time for subscale vehicle

  • Full scale design offers improved avionics bay and parachute storage
  • Drogue deployment time at 1 second post apogee, 2 second backup

Solenoid Factor of Safety

  • Detailed description of solenoid needs and waiver request can be seen in

FRR appendix

4

slide-5
SLIDE 5

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Meeting Agenda

5

Mission Overview Vehicle Design & Verification Payload Design & Verification Launch Results Conclusion Project Plan Ground Based Testing

slide-6
SLIDE 6

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Vehicle Overview

6

Full Scale Properties Value at CDR Current Value Mass 30.3 lb 34.0 lb Length 94.75” 99” Center of Gravity 50.4” 52.2” Center of Pressure 62.3” 65.6” Static Stability Margin at Exit 2.29 2.43

Launch Vehicle Weight By Section

slide-7
SLIDE 7

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Vehicle Sections

7

slide-8
SLIDE 8

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Kinetic Energy and Stability Information

8

Component Weight (lb) Landing Energy (ft-lb) Nosecone/Payload 14.75 (14.0 dry) 49.6 Avionics 7.00 24.8 Tail 12.25 (9.16 dry) 32.5 CP 65.6” from nose CG 52.2” from nose Static Stability Margin = 2.43 (launch pad)

slide-9
SLIDE 9

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Loki L1400

  • Burn Time: 2.0 s
  • Total Impulse: 2842.9 N-s
  • Weight: 2.540 kg
  • Max Thrust: 1906.4 N
  • Avg. Thrust: 1421.4 N

Motor Selection

9

Requirements

  • Short burn time
  • Reasonable acceleration
  • Reach target altitude
slide-10
SLIDE 10

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Avionics Section

10

slide-11
SLIDE 11

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Recovery System Redundancy

11

Ensure Proper Testing of Equipment

  • Altimeter Testing
  • Deployment Testing
  • Check Conditions of the Parachutes
  • Check Quality of Shock Cords
slide-12
SLIDE 12

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Recovery System

12

Avionics Bay Big Red Bee Radio Transmitter

Parachute Drogue Main Diameter 18” 96” Shape Elliptical Toroidal Cd 1.5 2.2 Source Fruity Chutes Fruity Chutes Deployment Altitude Apogee +1s 750 ft Descent Speed 74 fps 15.1 fps Shock Cord Length 15’, 25’ (40’) 18’, 25’, (43’) Shock Cord Material Kevlar Kevlar Kinetic Energy of Heaviest Section 500 lbf-ft 60 lbf-ft 4F Black Powder Charge Mass 1.5 grams 4.50 grams Backup Charge Mass 2.0 grams 5.00 grams Fire Retardant Blanket Nomex Nomex

slide-13
SLIDE 13

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 13

Vehicle Performance Predictions

slide-14
SLIDE 14

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Flight Simulations - Vehicle Flight Analysis

14

slide-15
SLIDE 15

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Flight Simulations - Wind Speed Effects

15

slide-16
SLIDE 16

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Meeting Agenda

16

Mission Overview Vehicle Design & Verification Payload Design & Verification Launch Results Conclusion Project Plan Ground Based Testing

slide-17
SLIDE 17

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Payload Systems Overview

17

Sensing - Inertial Measurement Unit (IMU) to monitor acceleration, angular velocity, and orientation Control - Custom software operating on BeagleBone Black computer to control thruster actuation Actuation - Thrusters fed by pressurized air tank to induce roll and counter roll

Cold Gas Thruster System Payload Electronics & Control Systems

slide-18
SLIDE 18

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 18

Thruster System

slide-19
SLIDE 19

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Cold Gas Thrusters

19

Problem Statement

  • A thrust system will be used to

induce and reverse in-flight rotations after MECO and prior to apogee

Solenoid and Thruster Nozzle

slide-20
SLIDE 20

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 20

Cold Gas Thruster System Rocket Integration

  • All payload components housed within removable forward section

○ Allows ease of assembly and 360 degree on-pad access

  • Forward section bolted to vehicle for removability and security
  • Nose cone bulkheads and foam supports air tank during flight
  • Thruster couples aligned with exhaust ports for roll actuation
slide-21
SLIDE 21

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 21

Cold Gas Thruster System Rocket Integration

slide-22
SLIDE 22

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 22

Cold Gas Thruster System Rocket Integration

slide-23
SLIDE 23

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 23

Thruster Testing

slide-24
SLIDE 24

Vanderbilt Aerospace Design Lab: FFR 3/6/2017 24

Nozzle Thrust Test Stand Arrangement

Air Tank U-bolt Support Data Acquisition Board Load Cell Solenoid and Nozzle

slide-25
SLIDE 25

Vanderbilt Aerospace Design Lab: FFR 3/6/2017

Higher Pressure Thrust Results

  • Problem - 2000 psi gave low roll performance in initial subscale launch

○ Regulator delivery pressure drops with increased flow rate ○ Leads to lower mass flow → Lower thrust obtained

  • Proposed Solution - Increase tank pressure to combat regulator droop

○ Use N2 in addition to compressed air due to high pressure supply tank availability

25

slide-26
SLIDE 26

Vanderbilt Aerospace Design Lab: FFR 3/6/2017

Higher Pressure Thrust Results

  • Result: Increase of 1.5 N

26

Tank Pressure (psi) Thrust (N) 2000 ~ 6.5 N 3000 ~ 7.5 N 4000 ~ 8.0 N

slide-27
SLIDE 27

Vanderbilt Aerospace Design Lab: FFR 3/6/2017

New Regulator Purchase

27

Ninja Regulator Orifice CP Regulator Orifice

  • Problem - 4000 psi only achieved 1.5 N increase

○ Regulator droop still a major factor ○ Regulator orifice limiting mass flow

  • Proposed Solution - Purchase higher flow regulator

○ Orifice comparison shown below

slide-28
SLIDE 28

Vanderbilt Aerospace Design Lab: FFR 3/6/2017

New Regulator Thrust Results

  • Result: Increase of 4 N (5.5 N total)

28

Pressure Regulator Thrust (N) 3000 Ninja ~ 7.5 N 4000 Ninja ~ 8.0 N 4000 Custom Products ~ 12.0 N

slide-29
SLIDE 29

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 29

Payload Electronics & Control Systems

slide-30
SLIDE 30

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Payload and Control System Electronics

30

VectorNav VN-100 IMU

  • 3-axis Accelerometer (± 16g)
  • 3-axis Gyroscope (± 2000 °/s)
  • 3-axis Magnetometer (± 2.5 Gauss)
  • Quaternion-based singularity-avoiding
  • utput with Kalman filtering

BeagleBone Black with PCB Shield

  • Miniature Computer
  • Many Inputs/Outputs
  • Internal/External Data Capabilities
  • WiFi Adapter
  • Custom PCB Shield

ROSMOD

  • System modeling environment

in C++

  • Visualization for system

component interactions

  • Used for all software integrated

systems

slide-31
SLIDE 31

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Payload Electronics Schematic

31

Power Management Data Collection and Processing Solenoid Triggering

slide-32
SLIDE 32

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Payload Electronics Layout and Assembly

32

IMU

  • Circuit board designed for greater in-flight reliability

○ Eliminated unnecessary potential failure points ○ Improved design of screw switch

  • Payload assembly features lighter sled and batteries
slide-33
SLIDE 33

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Software Overview

33

slide-34
SLIDE 34

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

High Level Controller State Machine

34

slide-35
SLIDE 35

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Control System Overview

Position-Based Control

  • Oscillation about rotation

setpoint

  • No steady-state error
  • Returns to setpoint after

disturbances Omega-Based Control

  • Maintain zero angular

velocity after setpoint is reached

  • Allows for steady-state error
  • Opposes disturbances

35

slide-36
SLIDE 36

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 36

Payload Performance Predictions

slide-37
SLIDE 37

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Payload Simulations - Vehicle Roll Analysis

37

Simulation Pulsing Conditions

  • Continuous thrust to roll 720°
  • Alternating thrust to hold 720° position
  • Thrusters turn off as apogee is approached
slide-38
SLIDE 38

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Meeting Agenda

38

Mission Overview Vehicle Design & Verification Payload Design & Verification Launch Results Conclusion Project Plan Ground Based Testing

slide-39
SLIDE 39

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 39

Full Scale Launch

slide-40
SLIDE 40

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Full Scale Launch Summary

February 19, 2017: Manchester, TN

  • Successful drogue deployment
  • Successful main deployment
  • Verification of control system
  • Obtained valuable data on

natural roll

40

slide-41
SLIDE 41

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Safety

Types of Hazard Analysis

  • Personnel Hazard Analysis
  • Propulsion/Motor Failure Modes
  • Payload/Control Failure Modes
  • Recovery System Failure Modes
  • Miscellaneous Vehicle Failures
  • Environmental Effects
  • Project Management

41

slide-42
SLIDE 42

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Launch Operations Procedures

For each independent section:

  • Necessary Hardware
  • Assembly Procedure
  • Required Personnel/Signatures

Also included:

  • Troubleshooting
  • Post-Flight Inspection

42

slide-43
SLIDE 43

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Altitude vs. Projection

43

slide-44
SLIDE 44

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Ignition Delay

44

slide-45
SLIDE 45

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Motor Output

45

Elapsed Time (s) Acceleration (G’s)

  • Similar Impulse
  • Longer Burn Time
  • Motor performance below manufacturer specs
  • 4% less ≈ 300’ lower
slide-46
SLIDE 46

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Increased CD from Launch Angle

CD = 0.27 → 4400’ CD = 0.40 → 4000’ Conclusion

  • High-drag launch

configuration can lead to significant apogee reduction

46

slide-47
SLIDE 47

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Revised Projection

47

slide-48
SLIDE 48

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Full Scale Payload Experiment

48

  • 720 degree rotation obtained
  • Control system shows actuation signals sent
slide-49
SLIDE 49

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Full Scale Payload Experiment

49

  • Lower than expected air tank mass ejection points to natural roll
  • To verify thruster system, electronics were inspected and subscale re-launch planned
slide-50
SLIDE 50

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 50

Subscale Re-launch

slide-51
SLIDE 51

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Subscale Re-Launch

51

slide-52
SLIDE 52

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Natural Roll

52

slide-53
SLIDE 53

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Subscale Takeaways

1. Electronics performance under high “g” conditions verified

○ Certified full scale electronics error resolved

2. Gained valuable flight data

○ Roll, pitch, yaw, and acceleration data successfully obtained ○ Data will help to refine the drag model for ground-based testing

3. Thruster actuation successful

○ Solenoid successfully actuated by electronics

4. Ability to achieve significant active displacement against natural roll verified

○ >200 degree roll against natural roll with 2800 psi ■ After ground-based thruster performance analysis, 4000 psi will be flown for full scale ○ When combined with natural roll from full scale, verifies thruster system roll capabilities

5. Additional vehicle recovery experience gained by team

53

slide-54
SLIDE 54

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Meeting Agenda

54

Mission Overview Vehicle Design & Verification Payload Design & Verification Launch Results Conclusion Project Plan Ground Based Testing

slide-55
SLIDE 55

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

The FRAME

55

Emulate in-flight conditions

  • Freedom of motion about roll axis
  • Vertical orientation
  • Torque input to rocket to simulate in-flight

aerodynamic forces Easily reproducible testing

  • Real-time data collection and visualization
  • Robust construction to eliminate need for

calibration between tests

  • Characterization of system transfer function
slide-56
SLIDE 56

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Testing Software

56

slide-57
SLIDE 57

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Testing Flow Chart

57

slide-58
SLIDE 58

Vanderbilt Aerospace Design Lab: FRR 3/6/2017 58

FRAME Integration Test: Varying Axial Flow

slide-59
SLIDE 59

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

FRAME Integration Test: Varying Axial Flow

59

Effect of Motor-Induced Damping

slide-60
SLIDE 60

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

FRAME Integration Test: Control System Comparison

60

slide-61
SLIDE 61

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

FRAME Integration Test Video

61

Comparison of Control Systems

slide-62
SLIDE 62

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Meeting Agenda

62

Mission Overview Vehicle Design & Verification Payload Design & Verification Launch Results Conclusion Project Plan Ground Based Testing

slide-63
SLIDE 63

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Future Testing Plans and Procedures

The FRAME

  • Continuous testing of control system will verify its robustness under

aerodynamic disturbances

Full Scale Launch Opportunity 3/18

  • Further data acquisition regarding vehicle, payload system, and recovery
  • Testing of control system and characterization of system dynamics

Finalizing Vehicle Aesthetics

63

slide-64
SLIDE 64

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Requirements Verification

See section 7.2 of the FRR for a complete view of verification status. Vehicle

  • Successful full scale and subscale-relaunch recovery
  • Team now has valuable experience from three successful launches
  • Lower altitude than expected - root causes analyzed and solutions in place

for March 18 and NASA SL Payload

  • Full scale launch verified robust control system
  • Subscale re-launch verified electronics with successful thruster actuation
  • Comprehensive ground-based testing and simulations verify roll capability

64

slide-65
SLIDE 65

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Meeting Agenda

65

Mission Overview Vehicle Design & Verification Payload Design & Verification Launch Results Conclusion Project Plan Ground Based Testing

slide-66
SLIDE 66

Vanderbilt Aerospace Design Lab: FRR 3/6/2017

Conclusion

Designed

  • Subscale payload flight provided essential design considerations for

fullscale launch vehicle Built

  • Full list of construction procedures with detailed photos in FRR

Tested

  • FRAME allows robust testing for full characterization with low risk

READY TO FLY!

  • Excited to get to Huntsville next month and demonstrate our High Roller!

66
