FireClass FC501 Whats FC501 ? 2 New Addressable Panel for Conventional Needs An entry level Triple Circuit Single Loop addressable system featuring Intelli-Zone mapping An out of the box panel that replaces conventional

slide-1
SLIDE 1

FireClass FC501

slide-2
SLIDE 2

What’s FC501 ?

  • An entry level Triple Circuit Single Loop

addressable system featuring Intelli-Zone mapping

  • An “out of the box” panel that replaces

conventional technology with a more powerful, cost effective solution

  • A perfect choice for small systems, with up

to 128 devices

  • A panel that uses the wide range of loop

devices provided by FireClass

New Addressable Panel for Conventional Needs

2

slide-3
SLIDE 3

Where can FC501 be used?

Ideal for small system applications

  • Small Factory
  • Small Warehouse
  • Small School
  • Small Hotel
  • Supermarket

Suitable for many applications

3

slide-4
SLIDE 4

What do you want from FC501?

  • Save installation cost & time
  • Out of the box: no need for configuration

tools or software

  • Easy to configure and use, little training

needed

  • Full local and remote monitoring and control

What do you want from a panel?

4

slide-5
SLIDE 5

How does FC501 meet your needs?

How does FC501 meet your needs?

5

Digital ¡Loop ¡ 3 ¡in ¡1 ¡Loops ¡ Auto ¡ Addressing ¡ Intelli-­‑Zone ¡ mapping ¡ USB ¡Interface ¡ On ¡screen ¡ Help ¡ User ¡friendly ¡ so@ware ¡ IP ¡and ¡PSTN ¡ Interface ¡ Free ¡Graphic ¡ So@ware ¡

  • Full local and remote monitorning

and control

  • Save installation cost & time
  • Easy to configure and use, little

training needed

  • Out of the box, no need for

programming tools or software

slide-6
SLIDE 6

How does FC501 meet your needs?

Save installation cost & time

6

3 ¡in ¡1 ¡ Loops ¡ Digital ¡ Loop ¡

Save ¡ installaIon ¡ cost ¡& ¡ Ime ¡

3 in 1 Loops

  • Flexible loop, can be wired in

1,2 or 3 circuits

  • Up to 400mA dynamically

shared current across the 3 loop circuits

  • Up to 128 loop devices
  • Multi-channel devices
  • Up to 32 Zones

Digital Loop

  • High immunity to false alarm
  • Tolerant to wide variety of

cables

slide-7
SLIDE 7

How does FC501 meet your needs?

Out of the box Easy and quick to configure

7

Install ¡the ¡panel ¡

  • Mount ¡the ¡

panel ¡

  • Wire ¡the ¡

loops ¡ Auto ¡Learning ¡

  • Check ¡the ¡

loop ¡devices ¡ addresses ¡ Auto ¡ Addressing ¡

  • Auto ¡address ¡

all ¡loop ¡ devices ¡

  • The ¡system ¡is ¡

ready ¡to ¡ protect ¡the ¡ site ¡

  • Loop ¡devices ¡

are ¡grouped ¡ in ¡1,2 ¡or ¡3 ¡ zones, ¡ according ¡to ¡ the ¡loop ¡they ¡ are ¡wired ¡to ¡ Intelli-­‑Zone ¡ mapping ¡

  • AcIvate ¡all ¡

loop ¡devices ¡ in ¡the ¡ building ¡

  • Go ¡in ¡front ¡of ¡

the ¡panel ¡

  • Enter ¡via ¡

keypad ¡ address, ¡ label, ¡zone ¡ per ¡each ¡ loop ¡device ¡

  • Loop ¡devices ¡

automaIcally ¡ ¡ grouped ¡in ¡8 ¡ zones, ¡ according ¡to ¡ their ¡address ¡

slide-8
SLIDE 8

How does FC501 meet your needs?

Out of the box

8

Programmable via keypad

  • Front panel controls enabling text

and configuration changes

  • No need for configuration

software

  • 8 Users / 2 Engineers password

USB Inteface

  • Upload/download panel

configuration

  • Upload languages
  • Upload vocal dial out messages
  • Firmware upgrade
slide-9
SLIDE 9

How does FC501 meet your needs?

Easy to configure and use – Little training needed

9

On screen Help

  • User friendly
  • Guides installer and user at any

page of the user interface menu, clicking the ? button

User friendly software

  • User friendly graphics interface
  • Fast and simple configuration,

also offline

  • Link to all installation manuals
  • Device graphic displayed
  • Battery/wiring calculation
  • Customizable cables database
  • Visualization of all the devices

assigned to a single zone

slide-10
SLIDE 10

How does FC501 meet your needs?

Full local and remote monitoring and control

10

Full control from display

  • 4000 Event Log
  • Loop break location
  • Displays temperature, CO level

and smoke level at any point

PSTN interface

  • Alarm, Fault, Warning vocal

messages via landline phone or

  • ptional GSM module to up to 32

numbers

  • Vocal messages can be recorded

using FireClass Console software

  • Supports Contact ID and SIA

protocol

slide-11
SLIDE 11

How does FC501 meet your needs?

Full local and remote monitoring and control

11

IP module (optional)

  • Remote Real time visualization of

control panel loop & zone status, etc from any location in the world

  • Easy Remote user interface with

control buttons (reset, silence, evacuate)

Free Graphic software

  • Multilevel map based on a tree

structure

  • Access device data from any pages
  • f the map
  • Supports standard formats file

(.bmp, .jpeg, etc)

slide-12
SLIDE 12

To summarize

To summarise…

12

  • EN54-2 and EN54-4 approved
  • 3 in 1 Loops for Flexible wiring
  • 128 Devices
  • 2,5 A PSU
  • 2 Sounder Circuits 500mA
  • Loop current 400mA
  • Fire/Fault relay
  • 4 Repeaters
  • Out of the box
  • Auto Addressing/Intelli-Zone Mapping
  • On Screen Help
  • USB port Host/Device
  • PSTN interface for dial out messages EN54-21

approved

  • IP module EN54-21 approved
  • User friendly configuration software
  • User friendly graphics software for remote

monitoring and control
