Fire Safety passive protection and routes to compliance Tony Bolder Prism Fire Risk Management Ltd www.prismsafety.co.uk Legislation and Guidance Legislation conflict case study Fire Dynamics Compartmentation and Passive Fire Safety

slide-1
SLIDE 1

‘Fire Safety’

passive protection and routes to compliance Tony Bolder

Prism Fire Risk Management Ltd

www.prismsafety.co.uk

slide-2
SLIDE 2

Legislation and Guidance Legislation conflict case study Fire Dynamics Compartmentation and Passive Fire Safety Use of Regulation 38 Routes to Compliance for buildings >18m Rapidly changing sector

slide-3
SLIDE 3

Regulatory Reform (Fire Safety) Order 2005 (FSO) Housing Act 2004/HHSRS Building Regulations Approved Document B (Parts 1 & 2) BS 9991 and BS 9999 BS 5839 1/6 BS 5266 BS 7671 BS 5306 BS 9990 BS 5499 Regulations: Management of HMO 2006 & 2007 / Smoke and Carbon Monoxide Alarm 2015 Gov.UK FRA Guides/ Building Design 100 PAS 79 FRA PAS 7 FMS Industry Guides: GGF/IFSA/LACORS/ CFOA/ASFP/WISH/Risc Auth Associations: IFE/FIA/FPA/IFSM/IFPM/IFSO Internet: FireSafe/SafeLincs etc

slide-4
SLIDE 4

Legislation Conflict?

Houses in Multiple Occupancy (HMO)/blocks of flats FSO: Common parts of residential buildings Housing Act: internal flats /bedsits etc by virtue of HHSRS section 24 `Fire` FSO enforced by FRS HHSRS enforced by LA EHO (who also use HA 2004 Section 10 for consultation with FRS on Category 1 risks) Therefore under FSO ….FRA only required for communal areas and external fabric…

slide-5
SLIDE 5

Legislation Conflict?

Source: Building a Safer Future

slide-6
SLIDE 6

FSO Part 2 Article 9

The Responsible Person must make a suitable and sufficient assessment of the risks to which relevant persons are exposed

slide-7
SLIDE 7

Legislation Conflict?

Case Study :

HMO East Ham London Regulatory Reform (Fire Safety) Order 2005

V

Housing Act 2004/HHSRS

slide-8
SLIDE 8
slide-9
SLIDE 9

Current FSO = 3.5 metres empty space with two doors

slide-10
SLIDE 10

Legislation Conflict?

Who is responsible for the flat entrance doors? Under Article 5.4 the leaseholder of the flat because: However, responsible person for the `common areas` also has a duty to under Article 5.2:

slide-11
SLIDE 11

Legislation Conflict?

Article 14 Emergency routes and exits, where 14 2 (b) : Lets also add in: Management of HMO Regulations 2006 where: Manager .....not responsible person

slide-12
SLIDE 12

Legislation Conflict?

Manager, where regulation 2 (c ) But in relation to East Ham…… Ground floor flat leased by one company First floor flat leased by a separate company Property owned by another company No known `manager` Who has overall control and responsibility?

slide-13
SLIDE 13

Legislation Conflict? Building for a Safer Future (Hackitt Review)

Recommendation 3.7 (b) “For other multi occ buildings LAs and FRS work more closely to ensure fire safety of whole building is assessed and regulated effectively” Possible future change in FSO and HA?

slide-14
SLIDE 14

Heat Transfer

slide-15
SLIDE 15

Fire Dynamics

slide-16
SLIDE 16
slide-17
SLIDE 17

Compartmentation and Passive Fire Safety

ADB/BS9991/9999 based on `Means of Escape`(MoE) principles Requirement to compartment areas by `passive` fire safety measures (non-interaction) Attempts to `box in` identified risks and create safe `protected areas and routes` Key elements of structure and where required, fire doors

slide-18
SLIDE 18

Compartmentation and Passive Fire Safety

Floors/ceilings/walls Normally either 30 minutes or 60 minutes fire resistance Floor to ceiling (above any suspended ceilings) Intrusions to be `fire-stopped`

slide-19
SLIDE 19

Compartmentation and Passive Fire Safety

Source: ASFP Document XX

slide-20
SLIDE 20

Compartmentation and Passive Fire Safety Service piping/cabling

Intumescent collars mastics dependant upon size/material/thickness Competent installers?

Fireboarding/Interlocking

Competent Builders?

slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29

Compartmentation and Passive Fire Safety

Pink Fire Foam Cited as `fire rated` to Class B1 for fire `reaction` not resistance Polyurethane based so will shrink in elevated temperatures and may combust to give off toxic fumes Use of intumescent fire mastics BS 476-20 & 22 BS EN 1366-4 for linear gaps BS EN 1366-3 for penetration seals

  • r use of intumescent collars/boxes
slide-30
SLIDE 30

Compartmentation and Passive Fire Safety

Protected routes Class 0 or 1 finishes to internal coverings All suspended ceilings within protected routes to class 0 or 1 tiles (BS EN 13501-1 s1 d0 A2 rating) Cabling to BS 7671 amendment 3 must be suitably supported to avoid collapse and potential entanglement of persons

slide-31
SLIDE 31
slide-32
SLIDE 32

Compartmentation and Passive Fire Safety Fire Doors

Third party accreditation/notional types Door set/door assembly Ironmongery Passive seals and gaps

slide-33
SLIDE 33

Compartmentation and Passive Fire Safety Fire Doors

Third party accreditation to BS 476 -22 or EN 1634 BWF `Certifire` scheme BM Trada Q Mark `FD` (`E`) type doors of 30/60/90/120 mins

slide-34
SLIDE 34

Compartmentation and Passive Fire Safety Fire Doors

Certification to each structural element (leaf/frame) TT FD30 TM FD60(S) Only `approved competent persons` allowed to make changes to certified doors/frames (replace vision panels/insert letterplates)

slide-35
SLIDE 35

Compartmentation and Passive Fire Safety

Only certain allowances permitted to certified door leaves Non-certified doors are termed `notional` fire doors

slide-36
SLIDE 36

Compartmentation and Passive Fire Safety

Fire Doors

Door set Door assembly

FD 30 Timber density softwood/hardwood 450kgs/m³ 15% moisture content 44mm thickness leaf FD 60 Timber density hardwood only 640kgs/m³ 15% moisture content 54mm thickness leaf Frames can have solid or `planted` rebates of 25 to 30mm

slide-37
SLIDE 37

Compartmentation and Passive Fire Safety Fire Doors Ironmongery

100mm hinges (min 800°c melting) Stainless steel/brass x 3 c/w intumescent packing BS1935 Grade 7 or above Self closers of either pivot-arm or concealed types BS 1154 power rating 3 or above `Perko` type internal chains not effective as self-closures All ironmongery must not breach core material of door leaf

slide-38
SLIDE 38

Compartmentation and Passive Fire Safety Fire Doors Passive seals & gaps

Intumescent only strip (plastic/graphite types) Combination cold smoke seals (brush or wipe) Top and side rails 3mm Bottom threshold 5-8mm (3mm if smoke seal)

slide-39
SLIDE 39
slide-40
SLIDE 40
slide-41
SLIDE 41
slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44
slide-45
SLIDE 45
slide-46
SLIDE 46

When correctly fitted

slide-47
SLIDE 47

Use of Regulation 38

Building Regulations 2010 Key is `responsible person` under the FSO

slide-48
SLIDE 48

Use of Regulation 38

Article 3 FSO RP is: Not necc `client` under CDM 2015 Potential loss of critical information?

slide-49
SLIDE 49

Use of Regulation 38

Oct 2017 National Fire Chiefs Council identified: Hackitt Review final report highlights:

slide-50
SLIDE 50

Routes to Compliance for buildings over 18m

LINEAR BASED ROUTE MATERIAL PERFORMANCE

Defined by the materials being either listed,

  • r its ability to meet basic performance criteria

when subjected to simple small scale fire tests.

PERFORMANCE BASED ROUTE EXACT SYSTEM TEST DATA DESKTOP STUDY REPORT FIRE SAFETY ENGINEERING ROUTE SCIENTIFIC APPROACH

Uses large scale fire test data from BS 8414-1 & BS 8414-2 demonstrating performance of complete façade assembly in accordance with BR 135. Requires empirical data, but not exacting system test data, to determine application suitability in accordance with BR 135. Pre-defined minimum specifications for common façade build-ups issued, assessed and approved by warranty provider or house builder. A sophisticated holistic approach based on scientific principles from an integrated or a ‘Whole Building’ perspective.

slide-51
SLIDE 51

Routes to Compliance for buildings over 18m

LINEAR BASED ROUTE MATERIAL PERFORMANCE

Defined by the materials being either listed,

  • r its ability to meet basic performance criteria

when subjected to simple small scale fire tests.

EXACT SYSTEM TEST DATA FIRE SAFETY ENGINEERING ROUTE

A sophisticated holistic approach based on scientific principles from an integrated or a ‘Whole Building’ perspective.

Basic Performance criteria Simple small scale fire tests

slide-52
SLIDE 52

`Class 0` and `Limited Combustibility`

ADB diagram 40 for external surfaces or walls (inc. cladding systems)

Source: ADB V2

slide-53
SLIDE 53

`Class 0` and `Limited Combustibility`

Class 0 is a building regulations classification, not BS To achieve class 0 need to pass BS 476 parts 6 & 7 BS 476 parts 6 & 7 are `reaction to fire tests` against the face of a sample Any aluminium composite material (ACM) will be against the

  • uter aluminium face only, not include the centre insulating core

(PE / FR PuR / mineral wool) Therefore can only be a `surface spread of flame` classification

slide-54
SLIDE 54

BCA Technical Guidance Note 18 June 2014

slide-55
SLIDE 55

BCA Technical Guidance Note 18 June 2014

slide-56
SLIDE 56

BS 476 Part 6 & 7

slide-57
SLIDE 57

`Class 0` and `Limited Combustibility`

ADB Vol 2 (England & Wales) `limited combustibility` allowed on buildings > 18 m

Table A7 Appendix A Para 13 (a)

Is the surface the aluminium face only or does it include the core?

slide-58
SLIDE 58

`Class 0` and `Limited Combustibility`

ADB Section 12.7 DCLG report 30th June 2018

slide-59
SLIDE 59

`Class 0` and `Limited Combustibility`

Clear confusion over the classification of ACM material core as `any element of the cladding system` when applying the linear based route across the sector against class `0` rating for surface spread of flame

slide-60
SLIDE 60

Supporting view

Paul Fuller, Chair of Fire Sector Federation: Fire Ex 2018

Source: SHP Online July 2018

slide-61
SLIDE 61
slide-62
SLIDE 62
slide-63
SLIDE 63
slide-64
SLIDE 64

PERFORMANCE BASED ROUTE EXACT SYSTEM TEST DATA DESKTOP STUDY REPORT FIRE SAFETY ENGINEERING ROUTE

Uses large scale fire test data from BS 8414-1 & BS 8414-2 demonstrating performance of complete façade assembly in accordance with BR 135. Requires empirical data, but not exacting system test data, to determine application suitability in accordance with BR 135.

BRE 135 Principles and guidance application with performance characteristics BS 8414 Large scale fire tests of complete façade assembly

Routes to Compliance for buildings over 18m

slide-65
SLIDE 65

BR135

slide-66
SLIDE 66

BR135

slide-67
SLIDE 67

BR135

slide-68
SLIDE 68

6 metre complete cladding system build with 1 Mega Watt fire crib

BS 8414 fire tests

slide-69
SLIDE 69

LINEAR BASED ROUTE MATERIAL PERFORMANCE PERFORMANCE BASED ROUTE DESKTOP STUDY REPORT FIRE SAFETY ENGINEERING ROUTE SCIENTIFIC APPROACH

BS 8414 fire tests

Pre June 2017 little empirical data on testing results to match the statement of BR135 of rapidly changing designs

slide-70
SLIDE 70

Government led BS 8414/BRE 135 tests June 2017

slide-71
SLIDE 71

Rapidly changing sector

MATERIAL PERFORMANCE PERFORMANCE BASED ROUTE EACT SYSTEM TEST DATA DESKTOP STUDY REPORT FIRE SAFETY ENGINEERING ROUTE SCIENTIFIC APPROAH

Requires empirical data, but not exacting system test data, to determine application suitability in accordance with BR 135.

March 2018 ASSA Abloy launch white paper on fire doors April 2018 MHCLG consultation paper on restricting use of assessments in lieu of test (ended May 2018) May 2018 `Building a Safer Future` final report with 53 recommendations June 2018 MHCLG consultation on banning use of combustible materials in the external walls of high rise residential buildings (ends August 2018) July 2018 MHCLG consultation on draft ADB (ends October 2018)

slide-72
SLIDE 72

Rapidly changing sector

MATERIAL PERFORMANCE PERFORMANCE BASED ROUTE EACT SYSTEM TEST DATA DESKTOP STUDY REPORT FIRE SAFETY ENGINEERING ROUTE SCIENTIFIC APPROAH

Requires empirical data, but not exacting system test data, to determine application suitability in accordance with BR 135.

slide-73
SLIDE 73

Rapidly changing sector

MATERIAL PERFORMANCE PERFORMANCE BASED ROUTE EACT SYSTEM TEST DATA DESKTOP STUDY REPORT FIRE SAFETY ENGINEERING ROUTE SCIENTIFIC APPROAH

Requires empirical data, but not exacting system test data, to determine application suitability in accordance with BR 135.

Default to A1/A2 European ratings or BRE 135/BS8414

slide-74
SLIDE 74

Rapidly changing sector

MATERIAL PERFORMANCE PERFORMANCE BASED ROUTE EACT SYSTEM TEST DATA DESKTOP STUDY REPORT FIRE SAFETY ENGINEERING ROUTE SCIENTIFIC APPROAH

Requires empirical data, but not exacting system test data, to determine application suitability in accordance with BR 135.

Table A7

slide-75
SLIDE 75

Thank you

www.prismsafety.co.uk
