File Systems and Storage

Marco Serafini

COMPSCI 532 Lecture 14

2

33

Why GFS?

• Store “the web” and other very large datasets
• Peculiar requirements
• Huge files
• Files can span multiple servers
• Coarse granularity blocks to keep metadata manageable
• Failures
• Many servers à many failures
• Workload
• Concurrent append-only writes, reads mostly sequential
• Q: Why is this workload common in a search engine?

44

Design Choices

• Focus on analytics
• Optimized for bandwidth not latency
• Weak consistency
• Supports multiple concurrent appends to a file
• Best-effort attempt to guarantee atomicity of each append
• Minimal attempts to “fix” state after failures
• No locks
• How to deal with weak consistency
• Application-level mechanisms to deal with inconsistent data
• Clients cache only metadata

55

Implementation

• Distributed layer on top of Linux servers
• Use local Linux file system to actually store data

66

Master-Slave Architecture

• Master
• Keeps file chunk metadata (e.g. mapping to chunkservers)
• Failure detection of chunkservers
• Procedure
• Client contacts master to get metadata (small size)
• Client contacts chunkserver(s) to get data (large size)
• Master is not bottleneck

77

Architecture

88

Advantages of Large Chunks

• Small metadata
• All metadata fits in memory at the master à no bottleneck
• Clients cache lots of metadata à low load on master
• Batching when transferring data

99

Master Metadata

• Persisted data
• File and chunk namespaces
• File to chunks mapping
• Operation log
• Stored externally for fault tolerance
• Q: Why not simply restart master from scratch?
• This is what MapReduce does, after all
• Non-persisted data: Location of chunks
• Fetched at startup from chunkservers
• Updated periodically

10

10

Operation Log

• Persists state
• Memory mapped file
• Log is a WAL - we will discuss it
• Trimmed using checkpoints

11

Chunkserver Replication

• Mutations are sent to all replicas
• One replica is primary for a lease – time interval
• Within that lease, it totally orders and sends to backups
• After old lease expires, master assigns new primary
• Separation of data and control flow
• Data dissemination to all replicas (data flow)
• Ordering through primary (control flow)

12

12

Replication Protocol

• Client
• Finds replicas and primary (1,2)
• Disseminates data to chunkservers (3)
• Contacts primary replica for ordering (4)
• Primary
• Determines write offset and persists it to disk
• Sends offset to backups (5)
• Backups
• Apply write and ack back to primary (6)
• Primary
• Acks to client (7)
• Q: Quorums?
• Q: Primary election and recovery?

13

13

Weak Consistency

• In presence of failures,
• There can be inconsistencies (e.g. failed backup)
• Client simply retries the write
• Successful write (acknowledged back to client) is
• Atomic: all data written
• Consistent: same offset at all replica
• This is because the primary proposes a specific offset
• File contains
• Stretches of “good” data with successful writes data
• Stretches of “dirty” data inconsistent and/or duplicate data

14

14

Implications for Applications

• Applications must deal with inconsistency
• Add checksums to data to detect dirty writes
• Add unique record ids to detect duplication
• Atomic file renaming after finishing a write (single writer)
• More difficult to program!
• But “good enough” for this use case

15

15

Other Semantics Beyond FSs

• Object store (e.g. AWS S3)
• Originally conceived for web objects
• Write-once objects
• Offset reads
• Often offer data replication
• Block store (e.g. AWS EBS)
• Mounted locally like a remote volume
• Typically accessed using a file system
• Not replicated

16

Data Structures for Storage

17

17

Storing Tables

• How Good are B+ trees?
• Q: Are they good for reading? Why?
• Q: Are they good for writing? Why?

18

Log Structured Merge Trees

• Popular data structure for key-value stores
• Bigtable, H-Base, RocksDB, LevelDB
• Goals
• Fast data ingestion
• Leverage large memory for caching
• Problems
• Write and read amplification

19

19

LSMT Data Structures

• Memtable
• Binary tree or skiplist à sorted by key
• Receives writes and serves reads
• Persistency through a Write Ahead Log
• Log files (runs) arranged over multiple levels
• L0: dump of memtable
• Li: merge of multiple Li-1 runs
• Goal: make disk accesses sequential
• Writes are sequential
• Merges of sorted data are sequential

20

20

Write Operations

• Store updates instead of modifying in place
• New writes go to memtable
• Periodically write memtable to L0 in sorted key order
• When level Li becomes too large, merge its runs
• Take two Li runs and merge (sequential)
• Create new run Li+1
• Iterate if needed (Li+1 full)
• Runs at each level store overlapping keys
• Each level has fewer and larger runs

21

21

Read Operations

• Search memtables and read caches (if available)
• If not found, search runs level by level
• Bloom filters – indices in each run
• Binary search in each run or index

22

22

Leveled LSMTs (e.g. RocksDB)

• Difference with standard LSMT
• Fixed number of runs per level, increasing for lower levels
• From L1 downwards, every run stores a partition of keys
• Goals
• Split the cost of merging
• Reads only need to access one run
• New merge process
• Take two Li runs and merge with the relevant Li+1 runs
• Create new run Li+1 to replace the merged one
• If new run too large, split and create a new Li+1 run
• Iterate if needed (Li+1 full)

23

Providing Durability

24

24

Write Ahead Log

• Goals
• Atomicity: transactions are all or nothing
• Durability (Persistency): completed transactions are not lost
• Principle
• Append modifications to a log on disk
• Then apply them
• After crash
• Can redo transactions that committed
• Can undo transactions that did not commit

25

25

Example: WAL in LSMTs

• Transactions
• Create/Read/Update/Delete (CRUD) on a key-value pair
• Append CUD operations to the WAL
• Trimming the WAL?
• Execute checkpoint
• All operations reflected in the checkpoint removed from WAL
• Recovery?
• Read from the checkpoint, re-execute operations in WAL
• ARIES: WAL in DBMSs (more complex than this)
