conference & convention enabling the next generation of networks & services Fibers for Next Generation High Spectral Efficiency Undersea Cable Systems Undersea Cable Systems Neal S. Bergano and Alexei Pilipetskii Tyco Electronics


slide-1
SLIDE 1 enabling the next generation of networks & services

conference & convention

Fibers for Next Generation High Spectral Efficiency Undersea Cable Systems Undersea Cable Systems

Neal S. Bergano and Alexei Pilipetskii

Tyco Electronics Subsea Communications

slide-2
SLIDE 2 enabling the next generation of networks & services

conference & convention

Presenter Profile

Alexei Pilipetskii received his M.S degree in physics from Moscow State University in 1985. From 1985 to 1994 he worked at the General Physics Institute in Russia. He received his Ph.D. in 1990 for research in nonlinear fiber optics. From 1994 to 1997 he was with the University

  • f Maryland Baltimore County, where his

Alexei Pilipetskii Director - System Modeling & Signal Processing Research email: apilipetskii@subcom.com Tel: 732-578-7533

  • f Maryland Baltimore County, where his

interest shifted to fiber optic data

  • transmission. Since 1997 he has been

with SubCom, where he works on a number of research and development

  • projects. He is currently the director of a

research group focusing on next generation technologies for undersea transmission systems.

slide-3
SLIDE 3 enabling the next generation of networks & services

conference & convention

Fibers for Next Generation High Spectral Efficiency Undersea Cable Systems

  • The importance of new “linear” fiber types
  • Dispersion management in transoceanic length

cable systems

– 10G DPSK transmission – 10G DPSK transmission

  • High spectral efficiency systems:

– Will require polarization multiplexed formats – The DP-PSK format with coherent receivers

  • Transmission Fiber “Figure-Of-Merit” (FOM)
  • New transmission results
slide-4
SLIDE 4 enabling the next generation of networks & services

conference & convention

Advances in Technology – New Fiber Types are Important!

100 320 640 1,800 2,560 3,730 6,000 1000 10000 100000

Experimental Transmission Capacity (Gb/s)

155x100G in 60nm

Year

2.5 5 10 40 100 160 640 1 10 100 1988 1990 1992 1994 1996 1998 2000 2002 2004 2006 2008 2010 2012

slide-5
SLIDE 5 enabling the next generation of networks & services

conference & convention

Why Fibers are So Important: Linear and Nonlinear Transmission

Q (dB)

15 16 17 18

OSNR limited Nonlinearity limited

Ref: Golovchenko, E.A., et. al. , OFC 1999, paper ThQ3

Q Relative pre-emphasis (dB)

  • 3

3 12 13 14 15 experiment simulation

  • One of the first Q vs. power curves published: 16x10Gb/s at 7500 km
  • Nonlinearity limits achievable performance (Q-factor), distance and

spectral efficiency

slide-6
SLIDE 6 enabling the next generation of networks & services

conference & convention

Fibers and Dispersion Management

  • First optically amplifier systems were not designed to support WDM

– Transmission at or close to zero dispersion

  • Deep dispersion management:

– NZDSF with SMF Suppressed nonlinear effects between WDM channels – Further improvement: large effective area NZDSF (~ 70 µm2) – Further improvement: large effective area NZDSF (~ 70 µm2) – 10 Gb/s bit rates, OOK signals, true WDM transmission

  • Dispersion slope compensated systems

– Increased transmission bandwidth – Large effective area SMF (~105 µm2)

Ref: A. Gnauck, et al; IEEE JLT, vol. 26, 2009, p1032 N.S. Bergano, IEEE JLT,” Vol. 23, 2005, p 4125

slide-7
SLIDE 7 enabling the next generation of networks & services

conference & convention

NZDSF Dispersion Map

Large Area NZDSF NZDSF SMF

~ 500 km

~ 500 km

Large Area NZDSF 70µm2 0.1ps/km -nm 2 NZDSF 55µm2 0.07ps/km -nm 2

SMF Large Area NZDSF NZDSF Wavelength Dispersion SMF NZDSF Large Area NZDSF Total

  • True WDM map

– Performance may vary with dispersion within the transmission band

slide-8
SLIDE 8 enabling the next generation of networks & services

conference & convention

Dispersion Flattened Map

D+ D- D+ D- D+

~ 500 km

~ 500 km

D+ 75/110 µm2 D- 25-35 µm2

Wavelength Dispersion

D+ D-

Total

  • Increased linearity

– Performance equalized across transmission bandwidth

slide-9
SLIDE 9 enabling the next generation of networks & services

conference & convention

10G DPSK Transmission in NZDSF Dispersion Map

Transmission simulation: 9000 km Ref: W. Anderson, et. al., OFC 2005, OthC1 Experiments: 13000 km,

12 13 14 15 16 factor (dB) Large dispersion RZ-DPSK Low dispersion Large dispersion

  • Properly-built dispersion map optimizes performance

Experiments: 13000 km, Ref: J.-X. Cai., et. al., OFC 2004, PDP34

9 10 11 12 1535 1540 1545 1550 1555 1560 1565 Wavelength (nm) Q fac RZ-OOK

slide-10
SLIDE 10 enabling the next generation of networks & services

conference & convention

Modulation format RZ-OOK (10 Gb/s) RZ-DPSK (10 Gb/s) Channel spacing 33 GHz 33 GHz

10G DPSK in Undersea Transmission – Success of Dispersion Management

Fiber plant Dispersion Flattened Fibers (DFF) DFF Amplifier spacing 45 км 75 км System length 9000 км 12700 км

  • Combination 3dB in Rx sensitivity, better nonlinear

tolerance in pulse overlapped regimes, and better FEC

Very difficult to beat this performance at SE up to 0.4 bit/s/Hz

slide-11
SLIDE 11 enabling the next generation of networks & services

conference & convention

The Need for High Spectral Efficiency Will Require Polarization Multiplexed Formats

Ref: J.-X. Cai et. al OFC’08, PDP4 50x42.8 Gb/s, 5200 km, 66.7GHz channel spacing 11 13 15 ctor [dB] Pol.Mux.- RZ-DBPSK

42.8 Gb/s

  • Polarization Multiplexed format shows superior performance

– Higher nonlinear tolerance & higher spectral efficiency – Favors coherent polarization multiplexed transponders

150 km repeater spacing 7 9 11

  • 6
  • 3

3 6 Pre-Emphasis [dB] Q-Facto CSRZ-DBPSK RZ-DQPSK

slide-12
SLIDE 12 enabling the next generation of networks & services

conference & convention

Coherent Detection with DSP

  • Ref. A. Salamon, et al., MILCOM ′03, M. Taylor, PTL 2004, no. 2, pp. 674–676

PBS 90° Optical Hybrid LO A/D DSP A/D Transmission PBS 90° Optical Hybrid LO DSP A/D A/D Path

  • Coherent detection allows access to the signal field:

– Polarization de-multiplexing of PDM signals – High spectral efficiency in excess of 1 bit/s/Hz – Digital signal processing at the receiver

slide-13
SLIDE 13 enabling the next generation of networks & services

conference & convention

Dispersion Management with Coherent Technology

  • In-line dispersion compensation

can be dropped with coherent Rx

  • No in-line dispersion

compensation reduces nonlinear penalties and

1 2 3 (dB)

Optimized for coherent

1 2 3 (dB) 1 2 3 (dB)

Optimized for coherent

nonlinear penalties and improves OSNR

  • Very simple transmission line

design Difficulty: >105 ps/nm need to be compensated in DSP for the long undersea cases

  • 2
  • 1
  • 2

2 4 6 Relative Launch Power (dB) Delta Q (

Legacy

  • 2
  • 1
  • 2

2 4 6 Relative Launch Power (dB) Delta Q (

  • 2
  • 1
  • 2

2 4 6 Relative Launch Power (dB) Delta Q (

Legacy

slide-14
SLIDE 14 enabling the next generation of networks & services

conference & convention

“Linear” Fibers are Important for Coherent Detection Systems

  • Transition from OOK to PSK with 3 dB better receiver sensitivity and

better FEC resulted in reduction of required power per channel

  • Helped in managing nonlinearity
  • Transition to PDM modulation formats with 40G and 100G rates will

result in higher required OSNR and power per channel

  • We’ll need more “linear” fibers
slide-15
SLIDE 15 enabling the next generation of networks & services

conference & convention

Advanced Fiber Types

nce Q(dB)

Better nonlinear tolerance

ance Q(dB)

Better span losses

Performance target Difference in span Smaller loss Higher loss Performance target Aeff1 Aeff2

) )( ( ) / log( 10 ) (

2 1 2 1

dB SpanLoss SpanLoss A A dB in FOM

eff eff

− + ≈

Performanc Channel power (dB)

Performan

Channel power (dB) Difference in span loss (dB)

eff2

(Aeff1/A

eff2)[dB]

slide-16
SLIDE 16 enabling the next generation of networks & services

conference & convention

Improved Fibers

180 170 160 150 140 130 180 170 160 150 140 130

0.17dB/km, 150µm2 ∆FOM ≈ 3.5dB 0.17dB/km, 150µm2 ∆FOM ≈ 2.5dB

50 km Spans 100 km Spans

) )( ( ) / log( 10 ) (

2 1 2 1

dB SpanLoss SpanLoss A A dB in FOM

eff eff

− + ≈

130 120 110 100 90 80 130 120 110 100 90 80

0.19dB/km, 105µm2 ∆FOM ≈ 3.5dB 0.19dB/km, 105µm2 ∆FOM ≈ 2.5dB

0.14 0.15 0.16 0.17 0.18 0.19 0.20 0.14 0.15 0.16 0.17 0.18 0.19 0.20

slide-17
SLIDE 17 enabling the next generation of networks & services

conference & convention

The Push to Higher Spectral Efficiency: New Experimental Results

  • 96x100G over 10600 km (300% spectral efficiency) & 400% spectral

efficiency over 4400 km

  • Short 52 km amplifier spacing (better performance)
  • New experimental transmission

12 Transmission distance at optimal power

  • New experimental transmission

fiber (0.183 dB/km, 150 µm2 area)

  • 100G on 33GHz (300%)
  • 100G on 25GHz (400%)
  • Post-deadline paper

– OFC 2010 PDPB10

8 9 10 11 12 5000 10000 15000 Transmission Distance [km] Q-factor [dB] 400% SE 300% SE Transmission distance at optimal power

slide-18
SLIDE 18 enabling the next generation of networks & services

conference & convention

Conclusions

  • Advances in fiber technology have played a key role in

the past 20 years of long-haul transmission progress

  • 10G RZ-DPSK in combination with modern dispersion

management have allowed systems with TB/s capacity per fiber pair

  • Next generation systems will need high spectral

efficiency:

– Higher level modulation formats & higher bit rates – Requiring high OSNR/channel – Resulting in very high launch powers

  • Fiber performance is very important for next generation

systems!

slide-19
SLIDE 19

2010

enabling the next generation of networks & services

conference & convention

Pacifico Convention Plaza Yokohama & InterContinental The Grand Yokohama 11 ~ 14 May 2010 www.suboptic.org The 7th International Conference & Convention

  • n Undersea Telecommunications
