Fantastic Attacks and How Kalipso can find them Kamila Babayeva Sebastian Garcia babaykam@fel.cvut.cz, @_kamifai_ sebastian.garcia@agent.fel.cvut.cz, @eldracote What if you need to analyze a very large pcap to find if there was an

SLIDE 1

Fantastic Attacks and How Kalipso can find them

Kamila Babayeva babaykam@fel.cvut.cz, @_kamifai_ Sebastian Garcia sebastian.garcia@agent.fel.cvut.cz, @eldracote

SLIDE 2

What if you need to analyze a very large pcap to find if there was an infection?

SLIDE 3

A real android infection

Kalipso demo

SLIDE 4

What was helping the detection? Behavioral letters

Slips can identify some weird situations and alert you about them

Red Alerts Dst ports

In “dst ports as a client” we can see a lot of bytes and packets going to a dst port Tuples with a strong periodicity

Dst ips

In “dst IPs as a client” we can see a lot of connections to this IP in a weird port

SLIDE 5

How does slips work?

Implement everything in modules as independent processes

Home net idea

Machine Learning for Network Detection. Backend

profiles

Profile per src IP. Computes all the features in the profile

directionality

Out: Only consider traffic going out of the profile All: Consider traffic in and out of the profile Defines for which IPs it creates profiles

timewindows

Profiles and detections happen in TW. Behaviors change.

modules

SLIDE 6

Modules kalipso Threat Intelligence Portscan detection geoip ASN timeline Virus total whois Anomaly detection ml C&C detection

SLIDE 7

directionality

SLIDE 8

directionality

SLIDE 9

directionality

SLIDE 10

directionality

SLIDE 11

kalipso

SLIDE 12

Build terminal dashboards using ascii/ansi art and javascript https://github.com/yaronn/blessed-contrib A high-level terminal interface library for node.js https://pypi.org/project/blessed/ Open source in-memory data structure store Node.js is an open-source, cross-platform, JavaScript runtime environment that executes JavaScript code outside of a browser.

kalipso’s magic

Blessed-contrib Blessed library redis nodejs

SLIDE 13

Blessed library

SLIDE 14

Blessed-contrib library

SLIDE 15

In-memory key store

kalipso’s magic

SLIDE 16

redis example of entry

DstIPs: {123.123.123.123: 1, '1.1.1.1':3} SrcIPs: {'2.2.2.2':4} Modified: True OutTuples: {'3.3.3.3:80:tcp': ['98a,a,a,a,a,a', previous_time, T2, IPINFO]} Detections: { [ ['Port Scan',1,0.5], ['Exploit', 0.3, 1] ]} BlockRequest: True/False DstPortsClientUDPEstablished: {80: {'totalbytes': 23, 'totalflows': 2, 'totalpkt': 4, 'dstips': {'3.4.5.6':25 ,'6.6.6.6':44}}} DstPortsClientUDPNotEstablished: {80: {'totalbytes': 23, 'totalflows': 2, 'totalpkt': 4, 'dstips': {'1.1.1.1':32 ,'2.2.2.2':44 ,'3.3.3.3': 66}}} DstPortsClientTCPEstablished: {80: {'totalbytes': 23, 'totalflows': 2, 'totalpkt': 4, 'dstips': {'1.1.1.1':32 ,'2.2.2.2':44 ,'3.3.3.3': 66}}} DstPortsClientTCPNotEstablished: {80: {'totalbytes': 23, 'totalflows': 2, 'totalpkt': 4, 'dstips': {'1.1.1.1':32 ,'2.2.2.2':44 ,'3.3.3.3': 66} }} DstPortsServerUDPEstablished: {80: {'totalbytes': 23, 'totalflows': 2, 'totalpkt': 4}} SrcPortsClientUDPEstablished: {1234: {'totalbytes': 23, 'totalflows': 2, 'totalpkt': 4, 'dstips': {'1.1.1.1':32 ,'2.2.2.2':44 ,'3.3.3.3': 66}}}

profile_10.0.0.1_timewindow1 (hash)

SLIDE 17

kalipso

profiles

All profiles and all the time windows when this profile communicated. Detected profiles and time windows are highlighted in red.

SLIDE 18

kalipso

timeline

A combined timeline of what happened and

when. Based on Zeek
files. Each main line (e.g

DNS) has below its corresponding interpretation (Query:)

SLIDE 19

kalipso

Clicking on a IP shows its

information. Both in the

timeline and the profiles tree.

Ip info

SLIDE 20

kalipso

evidence

The evidence is generated by all detection modules. This is the supporting evidence for the detection.

SLIDE 21

kalipso

hotkeys

Help on what you can do

SLIDE 22

kalipso

E hotkey

Src ports when the IP of the profile acted as client. Separated in Established and Not Established histograms. Shows the amount of total flows, total packets and total bytes going in a specific source port.

SLIDE 23

kalipso

C hotkey

Dst IPs when the IP of the profiles acted as client. Separated in Established and Not Established

histograms. Shows the amount of

total flows, total packets and total bytes going to a specific dst IP.

SLIDE 24

kalipso

p hotkey

Dst ports when the IP of the profile acted as client. Separated in Established and Not Established histograms. Shows the amount of total flows, total bytes and total packets going to a specific dst port.

SLIDE 25

kalipso

Dst Ports when the IP of the profile acted as client. Separated in Established and not Established histograms. Shows the amount of connections to a dst IP on a specific port .

n hotkey

SLIDE 26

kalipso

Shows geolocations of all dst IPs to which the src IP of the profile connected to during the time window.

m hotkey

SLIDE 27

kalipso

H Hotkey

Out Tuples Behavioral letters about the out tuples ‘IP-port-protocol’ combined together with ASN, geo country and Virus Total summary

SLIDE 28

Behavioral letters Outtuples

Group flows together Aggregation key is Src IP Dst IP Dst Port Protocol For each flow compute duration, size, and periodicity.

SLIDE 29

Behavioral letters

Behavior in time

SLIDE 30

kalipso

Fake scroll

We implemented a fake scroll capability to deal with the limitations of the library.

SLIDE 31

Installation

https://github.com/stratosphereips/StratosphereLinuxIPS

SLIDE 32

CREDITS: This presentation template was created by Slidesgo, including icons by Flaticon, and infographics & images by Freepik. Please keep this slide for attribution.

THANK YOU!

Kamila Babayeva babaykam@fel.cvut.cz, @_kamifai_ Sebastian Garcia sebastian.garcia@agent. fel.cvut.cz, @eldracote
