Eye Tracking System

• n Embedded Platform

Matěj Černý

Department of Electrical Engineering 4.12. 2013

INTRODUCTION

1

• Main motivation for this system was the need for

high definition image of eye which is fundamental for accurate gaze tracker.

• Accurate gaze tracker can be used to control PC with

common GUI by gaze to help disabled people interact with PC or to improve PC work efficiency.

• High definition image is acquired from PTZ camera

which is controlled by output of Eye Tracker.

• System should be composed of common components

and should have compact dimensions, for easy use and implementation.

Department of Electrical Engineering 4.12. 2013

OBJECTIVES

2

• Evaluate eye position on embedded platform from

image from standard webcam.

• Create servo driven mount for high definition camera

with narrow field of view.

• Create servo driver with USB interface.
• Design simple communication protocol between servo

unit and embedded platform.

Department of Electrical Engineering 4.12. 2013

MATERIAL & METHOD

3

• Eye position evaluation software was developed

directly on Pandaboard evaluation board (Cortex A9) in C++ using feature based object detector from OpenCV library.

• Prototype of servo driven camera mount was built

from two RC servos and building kit Merkur.

• Servo drive interface was based on Atmel

ATMEGA32U4 providing PWM signals controlling servos and USB interface to communicate with evaluation board.

• Communication protocol between servo drive and

evaluation board is using virtual COM port on USB and was implemented into both devices.

Department of Electrical Engineering 4.12. 2013

RESULTS

4

• Presented system is very well reflecting expectations

and can be used as a part of accurate gaze tracker.

• Processing time of one frame is approx. 50ms which is

sufficient for this application but it can be improved using embedded platform with higher performance.

• Direction accuracy of camera is sufficient and can be

improved by distance measuring device.

Department of Electrical Engineering 4.12. 2013

ACKNOWLEDGEMENT & CONTACT

5

Matěj Černý matej.cerny@student.upce.cz Department of Electrical Engineering

Faculty of Electrical Engineering and Informatics University of Pardubice Czech Republic http://www.upce.cz/en/fei/ke.html The research was supported by the specific research project of the IGA (SGFEI05/2013), University of Pardubice.
