SLIDE 1
Mark Harris, NVIDIA
EXTENDING THE REACH OF PARALLEL COMPUTING WITH CUDA
@harrism #NVSC14
2
EXTENDING THE REACH OF PARALLEL COMPUTING WITH CUDA Mark Harris, - - PowerPoint PPT Presentation
EXTENDING THE REACH OF PARALLEL COMPUTING WITH CUDA Mark Harris, - - PowerPoint PPT Presentation
EXTENDING THE REACH OF PARALLEL COMPUTING WITH CUDA Mark Harris, NVIDIA @harrism #NVSC14 EXTENDING THE REACH OF CUDA 1 Machine Learning 2 Higher Performance 3 New Platforms 4 New Languages 2 GPUS: THE HOT MACHINE LEARNING PLATFORM GPU
SLIDE 2
SLIDE 3
3
GPUS: THE HOT MACHINE LEARNING PLATFORM
1.2M training images • 1000 object categories
Hosted by
Image Recognition Challenge
person car helmet motorcycle bird frog person dog chair person hammer flower pot power drill
4 60 110 20 40 60 80 100 120 2010 2011 2012 2013 2014
GPU Entries Classification Error Rates
28% 26% 16% 12% 7% 0% 5% 10% 15% 20% 25% 30% 2010 2011 2012 2013 2014
SLIDE 4
4
GPU-ACCELERATED DEEP LEARNING
Optimized for current and future NVIDIA GPUs Integrated in major open-source frameworks
Caffe, Torch7, Theano
Flexible and easy-to-use API Also available for ARM / Jetson TK1 https://developer.nvidia.com/cuDNN
High performance routines for Convolutional Neural Networks
Caffe (CPU*) 1x Caffe (GPU) 11x Caffe (cuDNN) 14x Baseline Caffe compared to Caffe accelerated by cuDNN on K40
*CPU is 24 core E5-2697v2 @ 2.4GHz Intel MKL 11.1.3
SLIDE 5
5
Machine Learning
1
Higher Performance
2
New Platforms
3
New Languages
4
EXTENDING THE REACH OF CUDA
SLIDE 6
6 6
NVLINK
HIGH-SPEED GPU INTERCONNECT
NVLink NVLink
POWER CPU X86 ARM64 POWER CPU X86 ARM64 POWER CPU
PASCAL GPU KEPLER GPU 2016 2014
PCIe PCIe
SLIDE 7
7
1.00x 1.25x 1.50x 1.75x 2.00x 2.25x ANSYS Fluent Multi-GPU Sort LQCD QUDA AMBER 3D FFT
7
NVLINK UNLEASHES MULTI-GPU PERFORMANCE
3D FFT, ANSYS: 2 GPU configuration, All other apps comparing 4 GPU configuration AMBER Cellulose (256x128x128), FFT problem size (256^3)
TESLA GPU TESLA GPU CPU
5x Faster than PCIe Gen3 x16
PCIe Switch
GPUs Interconnected with NVLink Over 2x Application Performance Speedup
When Next-Gen GPUs Connect via NVLink Versus PCIe
Speedup vs PCIe based Server
SLIDE 8
8
NVLINK + UNIFIED MEMORY
Simpler, Faster
Unified Memory
NVLink 80 GB/s
TESLA GPU TESLA GPU CPU
5x Faster than PCIe Gen3 x16
PCIe Switch
Share Data Structures at CPU Memory Speeds, not PCIe speeds Eliminate Multi-GPU Scaling Bottlenecks
SLIDE 9
9
Machine Learning
1
Higher Performance
2
New Platforms
3
New Languages
4
EXTENDING THE REACH OF CUDA
SLIDE 10
10
Development Data Center Infrastructure
Tesla Accelerated Computing Platform
GPU Accelerators Interconnect System Management Compiler Solutions
GPU Boost … GPU Direct NVLink … NVML … LLVM …
Profile and Debug
CUDA Debugging API …
Development Tools Programming Languages Infrastructure Management Communication System Solutions
/
Software Solutions
Libraries
cuBLAS …
SLIDE 11
11
COMMON PROGRAMMING APPROACHES
Across a Variety of Heterogeneous Systems
x86
Libraries Programming Languages Compiler Directives
AmgX cuBLAS
/
SLIDE 12
12
Machine Learning
1
Higher Performance
2
New Platforms
3
New Languages
4
EXTENDING THE REACH OF CUDA
SLIDE 13
13
MAINSTREAM PARALLEL PROGRAMMING
Enable more programmers to write parallel software Give programmers the choice of language to use Embrace and evolve key programming standards
C
SLIDE 14
14
C
MAINSTREAM PARALLEL PROGRAMMING
Enable more programmers to write parallel software Give programmers the choice of language to use Embrace and evolve key programming standards
SLIDE 15
15
C++ PARALLEL ALGORITHMS LIBRARY PROGRESS
- Complete set of parallel primitives:
for_each, sort, reduce, scan, etc.
- ISO C++ committee voted unanimously to
accept as official tech. specification working draft
N3960 Technical Specification Working Draft:
http://www.open-std.org/jtc1/sc22/wg21/docs/papers/2014/n3960.pdf
Prototype:
https://github.com/n3554/n3554
std std:: ::ve vecto tor< r<int int> > vec vec = . ... .. // previ // previous st
- us standard s
andard sequent equential loop ial loop std std:: ::for_each(vec.begi vec.begin(), (), vec.end(), f); // expli // explicitly citly sequenti sequential loo al loop std std:: ::fo for_e _eac ach(std std:: ::seq seq, , ve vec.beg c.begin in() (), ve vec. c.end nd() (), , f); f); // permi // permitting tting parallel parallel execu execution tion std std:: ::for_each(std std::par ::par, , vec.begin(), vec.end(), f);
SLIDE 16
Linux GCC Compiler to Support GPU Accelerators
Open Source
GCC Effort by Mentor Embedded
Pervasive Impact
Free to all Linux users
Mainstream
Most Widely Used HPC Compiler
Oscar Hernandez Oak Ridge National Laboratories
Incorporating OpenACC into GCC is an excellent example of open source and
- pen standards working together to make accelerated computing broadly
accessible to all Linux developers.
“ ”
On Track for GCC 5
SLIDE 17
17
NUMBA PYTHON COMPILER
numba.cuda module integrates CUDA directly into Python NumbaPro: commercial extension of Numba
Python interfaces to CUDA libraries
http://numba.pydata.org/
Free and open source JIT compiler for array-oriented Python
@cuda uda.j .jit it(“void(float32[:], float32, float32[:], float32[:])”) de def sax saxpy py(ou (out, t, a, a, x x, y , y): ): i = = cud cuda.g a.grid rid(1 (1) if if i < < ou
- ut.s
.siz ize:
- ut[
- ut[i] =
= a a * x * x[i] ] + y + y[i] # # Lau Launc nch h saxpy saxpy ker kernel el sa saxpy xpy[1 [100, 00, 51 512](out
- ut, a
, a, x , x, y) y)
SLIDE 18
18
ACCELERATING JAVA 3 WAYS
Accelerate Java SE Libraries with CUDA Accelerate Pure Java
java.util.Arrays.sort(int[] a)
Drop-In Acceleration
8
CUDA C++ Programming Via Java APIs
CUDA4J
IBM Developer Kits for Java: ibm.com/java/jdk
SLIDE 19
19
void add(int[] a, int[] b, int[] c) throws CudaException, IOException { CudaDevice device = new CudaDevice(0); CudaModule module = new CudaModule(device, getClass().getResourceAsStream(“ArrayAdder”)); CudaKernel kernel = new CudaKernel(module, “Cuda_cuda4j_samples_adder”); CudaGrid grid = new CudaGrid(512, 512); try (CudaBuffer aBuffer = new CudaBuffer(device, a.length * 4); CudaBuffer bBuffer = new CudaBuffer(device, b.length * 4)) { aBuffer.copyFrom(a, 0, a.length); bBuffer.copyFrom(b, 0, b.length); kernel.launch(grid, new CudaKernel.Parameters(aBuffer, bBuffer, a.length)); aBuffer.copyTo(c, 0, a.length); } }
CUDA4J: GPU PROGRAMMING IN A JAVA API
Access CUDA Programming Model with Java Best Practices
Manage CUDA devices and kernels Easily transfer data between Java heap and CUDA device Simple, flexible kernel launch
SLIDE 20
20
ACCELERATING PURE JAVA ON GPUS
Express computation as aggregate parallel operations on data streams
IntStream.range(0, N).parallel().forEach(i -> c[i] = a[i] + b[i]);
Benefits
Standard Java idioms, so no code changes required No knowledge of GPU programming model required No low-level device manipulation – Java implementation has the controls Future JIT smarts do not require application code changes
Java 8 Streams and Lambda Expressions
SLIDE 21
21
JIT / GPU OPTIMIZATION OF LAMBDA EXPRESSION
JIT-recognized Java matrix multiplication
Speed-up factor when run on a GPU enabled host
IBM Power 8 with Nvidia K40m GPU
Public void multiply() { IntStream.range(0, COLS*COLS).parallel().forEach( id -> { int i = id / COLS; int j = id % COLS; int sum = 0; for (int k = 0; k < COLS; k++) { sum += left[i*COLS + k] * right[k*COLS + j]; }
- utput[i*COLS + j] = sum;
}); }
SLIDE 22
22
COMMON PROGRAMMING APPROACHES
Across a Variety of Heterogeneous Systems
x86
Libraries Programming Languages Compiler Directives
AmgX cuBLAS
