Extending OAuth2 to Join Local Services into a Federative SOA M. Politze IT Center RWTH Aachen University Where are we now? You are here! 20 km Source: http://www.wissenschaft.nrw.de/studium/informieren/hochschulkarte-nrw/ 3 Extending

slide-1
SLIDE 1

Extending OAuth2 to Join Local Services into a Federative SOA

  • M. Politze

IT Center RWTH Aachen University

slide-2
SLIDE 2

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 3

Where are we now?

You are here! 20 km

Source: http://www.wissenschaft.nrw.de/studium/informieren/hochschulkarte-nrw/

slide-3
SLIDE 3

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 4

Setting Support the core processes: Teaching, Learning and Research

  • Connect legacy systems with a single, consistent API
  • Develop an SOA that fits to the processes at the university

 Start with eLearning  Generalize and try to apply to other fields:

  • Campus Management, Identity Management
  • Research Data Management / eScience
  • Security by design

 Confidentiality  Integrity  Availability

  • Protect personal and confidential data
slide-4
SLIDE 4

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 5

OAuth2 at Commercial Service Providers

  • Tightly coupled with their web services

 Authorization for local scopes  Used for applications

  • Applications using multiple services still

require multiple logins

 1:1 mapping of services and logins  Hinders crossing system boundaries for process supporting application

  • Authentication via authorization

 Use user info supplied by a service to identify the user  Leads to possible security vulnerabilities [1]

[1] R. Yang, W. C. Lau, and T. Liu, Signing into One Billion Mobile App Accounts Effortlessly with OAuth2.0, in Black Hat Europe, 2016.

slide-5
SLIDE 5

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 6

OAuth2 at RWTH Aachen University

  • Secure, device based Authorizations

 (De)Authorizations via Webinterface  No credentials are passed to apps

  • OAuth2 as a service

 Integrates Shibboleth as authentication  Possibility to provide a federative service (DFN, …)

  • Established at RWTH

 RWTHApp has ~20.000 active users  Procedure scales across different applications

slide-6
SLIDE 6

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 7

A Bit More Detail?

slide-7
SLIDE 7

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 8

Security Implications

  • The token service is the authority
  • The token service is trusted
  • Users are known
  • Applications and web services are separated
slide-8
SLIDE 8

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 9

Problem Statement

OAuth2 Workflows allow apps to cross system boundaries

  • … because apps and systems are known to the OAuth2 server
  • … because each user is known to the OAuth2 server
  • … because systems trust the OAuth2 server to handle authorizations

Can we always assume this? No

slide-9
SLIDE 9

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 10

Partially Solved!

Inf Inf Inf Inf Inf Inf

O OAuth Token Service

Inf Inf Inf

OAuth Token Service

RWTH Aachen University A University B

slide-10
SLIDE 10

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 11

Long Answer

  • Ferderated services (SaaS)

 Offered by one University  Members of other Universities may use  Likely each University has on OAuth2 server

  • Suppose an app is using APIs from several services

 User needs to log in multiple times  Application has to decide which are the correct servers  User likely has many places to manage authorizations

  • Services need validate authorizations

 May need to query multiple servers  Have to establish a trust relationship to all authorization servers

slide-11
SLIDE 11

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 12

Security Implications

  • The token service is the authority
  • The token service is trusted
  • Users are known
  • Applications and web services are separated ?
slide-12
SLIDE 12

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 13

Goals

Always use the home institution

  • Let users manage their authorizations at their home institution
  • Let applications request authorizations from their home institution
  • Let services validate authorizations in their home institution

Reuse existing technology for federated (web) applications Build a federated OAuth infrastructure

slide-13
SLIDE 13

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 14

OAuth2 Federated Workflow

slide-14
SLIDE 14

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 15

Establishing Authority / Trust

  • Local OAuth2 service remains

authority

 … for apps  … for services  … for users

  • Discover remote OAuth2

services

  • Trust is established to local

OAuth2 service

 Local OAuth2 trusts remote services in the federation  Hides complexity of the federation from developers

{ ... "token_services" : { "https://oauth.example.com" : { "displayName" : "Example University", "namespace" : "example.com", "key" : "-----BEGIN PUBLIC KEY-----\nMIGfM...", "endpoints" : { "authorize" : "https://oauth.example.com/authorize", "code" : "https://oauth.example.com/code", "token_info" : "https://oauth.example.com/token_info", "context" : "https://oauth.example.com/context" } }, ... } }

slide-15
SLIDE 15

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 16

Knowing the User

  • Transfer user information on validation

 Reuse existing eduPerson sheme  Likely sufficient for many services

  • Use namespaces to distinguish users

 Reuse existing namespaces (scopes)  Tie user IDs to the ones delivered by authentication infrastructure

{ "isValid" : true, "application" : "ahcndwlsajcnalfejalsd@example.com", "mail" : "max.power@example.com", "displayName" : "Max Power", "eduPersonPrincipalName" : "anpqr7d@example.com", "eduPersonScopedAffiliation" : "student@example.com" }

slide-16
SLIDE 16

Extending OAuth2 to Join Local Services into a Federative SOA Marius Politze EUNIS 2017, 08.06.2017 17

Conclusion

  • Rising need to share services among Universities

 Highly decentralized environments  Reuse of existing techniques is mandatory

  • Rising demand among researchers and students

 … to customize tools  … to combine existing systems

  • Federated OAuth2 may satisfy some demands
  • Currently evaluating proof-of-concept

 Two OAuth instances operated at RWTH Aachen  In cooperation with Forschungszentrum Jülich

slide-17
SLIDE 17

Thank you for your attention Vielen Dank für Ihre Aufmerksamkeit
