Observations 2009 Exposition Paths of Neonicotinoids Hedwig Riebe, DBIB Paris, 10.12.2009 Wintering problems as acute symptoms Recommendation for nucs 15 years ago: 30 % Nuc recommendation 2009: 100 % Exposition paths of

slide-1
SLIDE 1

Exposition Paths

  • f

Neonicotinoids

Hedwig Riebe, DBIB Paris, 10.12.2009

Observations 2009

slide-2
SLIDE 2

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

2 / 10.12.09

Wintering problems as acute symptoms

  • Recommendation for nucs

15 years ago: 30 %

  • Nuc recommendation 2009:

100 %

slide-3
SLIDE 3

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

3 / 10.12.09

Possible Causes?

  • Pollen and nectar contamination (sublethal

doses)

  • Increase of neonicotinoid usage in

agriculture

  • Guttation Drops as possible cause in

discussion in Germany since beginning of 2009

  • Exposure to neonics through other water

sources

slide-4
SLIDE 4

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

4 / 10.12.09

Activities in Germany regarding guttation/water/clothi in 2009

  • Feb.: Girolami
  • Apr.: Call for pictures of drinking bees
  • May: guttating crops
  • July: Presentation at BVL
  • Aug.: Viewed Poncho files
  • Sep.: Presentation at Agric. Ministry
  • Oct.: Tests of canola guttation
slide-5
SLIDE 5

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

5 / 10.12.09

Guttation ./. Dew

slide-6
SLIDE 6

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

6 / 10.12.09

Guttation ./. Dew – 2 hours later

slide-7
SLIDE 7

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

7 / 10.12.09

Plant sap & Seed coating

  • Xylem =

Water from roots to leaves

  • Phloem =

Water from leaves downwards

  • Seed coating =

Poison dissolves in water, dissolves in dressing zone, absorbed through roots and distributed in entire plant

slide-8
SLIDE 8

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

8 / 10.12.09

Guttation Droplets

  • Guttation droplets = Xylem

Minerals, proteins, sugars Minerals, proteins, sugars, Insecticide, Fungicide

slide-9
SLIDE 9

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

9 / 10.12.09

Studies / thesis / publications

  • Doc. Thesis Michael Schneider, 1988:

„Aufnahme von (14C) Triadimenol über Korn und Wurzel nach Flüssigbeizung von Wintergerste: Einfluss von Bodenfeuchte und Saattermin auf Radioaktivitätsverteilung und Wirkstoffgehalt in Pflanze und Boden“

  • Doc. Thesis. Ulrike Stein-Döneke, 1993:

„Beizhofausbildung, Aufnahme, Translokation und Wirkung von [14C]Imidacloprid bei Winterweizen und Zuckerrüben nach Saatgutbehandlung und unter dem Einfluss verschiedener Bodenfeuchten“ (Infuence of soil moisture on the formation of dressing zones and uptake of imidacloprid after seed treatment

  • f winter wheat)
  • Hughes R. N., Brimblecombe P., 1994:

„Dew and guttation: formation and environmental significance“

  • Guttation water content 1966; various studies mentioning

guttation referenced in thesis

slide-10
SLIDE 10

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

10 / 10.12.09

A few facts about guttation

  • Not limited to a specific time of year or

specific groups of plants

– Spring (observed) – Summer (observed) – Fall (observed, also Doc. The. Schneider) – Winter ? (unless frozen)

(guttation observed on Dec. 9, 2009)

– Guttation and dew available for at least two hours in the morning (Pub. UK)

slide-11
SLIDE 11

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

11 / 10.12.09

Water requirements of bees

  • Why water in the morning??

– Dilution of honey/nectar to feed larvae – Water reserve against ‚thirst‘ after heating at night – High water demand by nurse bees digesting pollen for jelly production (average water content is 67 %)

Water homeostasis in bees, with the emphasis von sociality ,

  • S. W. Nicolson, Journal of Experimental Biology 212, Feb. 2009
slide-12
SLIDE 12

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

12 / 10.12.09

Observations 2009

  • Neonicotinoid seed coatings

– Exposure of bees – (Sublethale Effects)

  • Exposition in non-relevant crops
  • Brood damage through blossom

treatments?

  • Residues in honeys after blossom

treatments

slide-13
SLIDE 13

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

13 / 10.12.09

Known danger?

  • Doc. The. USD, p. 149:

„Es gilt zu prüfen, inwieweit die Wirkstoffausscheidung mit der Guttation neben einem Wirkungsverlust für die Pflanze auch eine Gefährdung von Nützlingen wie Marienkäfer und Bienen darstellen kann, da diese die Guttationstropfen als Wasserquelle nutzen (Poehling, 1992; Schmidt, 1992b).“

„It still needs to be tested in how far the loss of a. i. through guttation poses a danger to beneficial insects like ladybugs and bees, because they use guttation drops as a water source (oral communication, Poehling, 1992; Schmidt, 1992b).“

Poehling, M.-H. (1992): Pers. Mitteilung. Institut für Pflanzenpathologie und Pflanzenschutz, Universität Göttingen Schmidt, H.-W. (1992b): Pers. Mitteilung. Bayer AG, Geschäftsbereich Pflanzenschutz, Entwicklung/Insektizide, 5090 Leverkusen, Bayerwerk.

slide-14
SLIDE 14

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

14 / 10.12.09

Documentation of Guttation

  • 1 beekeeper
  • 1 canola field
  • 2 apiaries
  • Small digital camera
  • Location: northern area of county

Düren, Germany

  • 85 % agricultural use
slide-15
SLIDE 15

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

15 / 10.12.09

Canola field & surroundings

SugB SugB Pota Pota Pota Cer Cer Cer Cer Cer Pota

8 ha Canola

Corn Pota

slide-16
SLIDE 16

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

16 / 10.12.09

Everything‘s guttating!

slide-17
SLIDE 17

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

17 / 10.12.09

Some observations ...

  • Water puddle, but bees collect

guttation drops as long as available

  • Bees prefer sunny spots for water

collection

  • Water collectors in sunny field seam

strips up to 40 m from hives

  • Dew in shaded spots (driving lanes) still

available after everything else dries

slide-18
SLIDE 18

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

18 / 10.12.09

Bee drinking guttation drop

They do drink it!

slide-19
SLIDE 19

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

19 / 10.12.09

Everything‘s guttating: Canola

slide-20
SLIDE 20

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

20 / 10.12.09

Everything‘s guttating: Sugar Beet

slide-21
SLIDE 21

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

21 / 10.12.09

Everything‘s guttating: Potatoes

slide-22
SLIDE 22

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

22 / 10.12.09

Everything‘s guttating: Cereals

slide-23
SLIDE 23

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

23 / 10.12.09

Everything‘s guttating: Corn

slide-24
SLIDE 24

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

24 / 10.12.09

Active Ingredients

  • Per sugar beet seed 0,9 mg

Neonicotiniode (Poncho Beta+)

  • Per Corn seed 0,5 mg Neonicotinoid

(PONCHO) resp. 1,25 mg (PONCHO PRO)

  • Main distribution in top 5 cm of soil

with r = 5-6 cm around plant

slide-25
SLIDE 25

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

25 / 10.12.09

Dressing zones

  • Bilder USD

80 % in top fraction

slide-26
SLIDE 26

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

26 / 10.12.09

Concentration of seed coating

  • Concentration in first few drops acc.

USD 0,3 % of total a.i. per seed

  • Higher concentration of a.i. in leaf tips

(and thus in guttation drops) than compared to rest of plant and xylem

slide-27
SLIDE 27

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

27 / 10.12.09

Distribution

  • f A. I.

Makroautoradiographie wheat plant (45 days after seeding)

slide-28
SLIDE 28

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

28 / 10.12.09

Distribution

  • f A. I.

Makroautoradiog- raphie of sugar beet plant in 6-leaves stage (32 days after seeding)

slide-29
SLIDE 29

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

29 / 10.12.09

Bon appetit!

slide-30
SLIDE 30

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

30 / 10.12.09

Weeds in dressing zones

slide-31
SLIDE 31

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

31 / 10.12.09

Weeds in Corn

slide-32
SLIDE 32

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

32 / 10.12.09

Long term poisoning effects

  • Concentration of a. i. in guttation droplets in

fall and spring?

  • Which concentrations in the different crops?
  • Potatoes, salads, other plants?
  • How much a. i. remains in soil and becomes

available later on, e. g. fertilizer plants like ‚Senf‘ (sinapis alba)?

slide-33
SLIDE 33

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

33 / 10.12.09

Seed coating expositon

  • Guttation droplets of crops

– Direct consumption of drops by bees – Dried and re-soluted remains of guttation drops

  • n leaf surfaces
  • „Leaching“
  • Water collection from soil in dressing zone,

eventually increased by fallen guttation droplets?

  • Guttation of weeds growing in dressing zones
slide-34
SLIDE 34

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

34 / 10.12.09

Guttating Canola

slide-35
SLIDE 35

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

35 / 10.12.09

Dried residues of guttation droplets

  • Bild Girolami
slide-36
SLIDE 36

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

36 / 10.12.09

Guttating Cereals

slide-37
SLIDE 37

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

37 / 10.12.09

Dried residues of ? on potatoes – Pesticide Spray?

slide-38
SLIDE 38

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

38 / 10.12.09

Dew as water source

  • Especially in areas with intensive agriculture

guttation drops and dew are the most important water sources in the morning

  • A. I. dangerous for bees may be used on

crops, which are not attractive for bee foraging

  • Danger of transfer from leaf (phloem) to dew

(or rain) on leaf = „Leaching“ (Diss. Schneider)

slide-39
SLIDE 39

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

39 / 10.12.09

„Hoover-Biene“

slide-40
SLIDE 40

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

40 / 10.12.09

Dew as water source

slide-41
SLIDE 41

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

41 / 10.12.09

Water collector on soil

slide-42
SLIDE 42

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

42 / 10.12.09

7:30 h in the morning, at the hive

slide-43
SLIDE 43

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

43 / 10.12.09

Noon 12:20 h, in front of the hive

slide-44
SLIDE 44

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

44 / 10.12.09

Noon 12:21 h, in front of the hive

slide-45
SLIDE 45

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

45 / 10.12.09

Relevance

  • Why dead bees?
  • How many water collectors does a hive

lose?

  • „Der Herr schickt den Gockel aus …“

Research required!!!

slide-46
SLIDE 46

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

46 / 10.12.09

Bee loss per hive

  • Daily loss in Canola: 1.500 bees
  • „what does it matter, if 200 more die?“

+ 13 % - daily

  • Continuous weakening of hive!
slide-47
SLIDE 47

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

47 / 10.12.09

Dew & „Leaching“

  • Transfer of a. i. from leaf to dew

possible (acc. to Doc.Th. Schneider)

– Neonicotinoids (seed coating) – Other insecticides (seed coatings) – Topical sprays from previous day?

  • Italian results: Leaching + Dew or

a mix of guttation & dew?

slide-48
SLIDE 48

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

48 / 10.12.09

Additional exposition paths of neonics through water

  • Lost seeds in puddles
  • Washed out seeds
  • Puddles in driving lanes
  • Puddles between potato dams
slide-49
SLIDE 49

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

49 / 10.12.09

Lost seeds in puddles

slide-50
SLIDE 50

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

50 / 10.12.09

Washed out seeds

slide-51
SLIDE 51

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

51 / 10.12.09

Puddles in driving lanes

... available all day long

slide-52
SLIDE 52

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

52 / 10.12.09

Water between potato dams

Clothianidin has permit for seed potatoes, soil treatment before laying

  • f potatoes.
slide-53
SLIDE 53

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

53 / 10.12.09

Neonicotinoids in adjacent crops

  • High a. i. dosis in sugar beets
  • High a. i. dosis in corn
  • Soil treatment for seeding potatoes
  • Effects on subsequent fertilizer plants?

Hive poisoning in fall?

slide-54
SLIDE 54

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

54 / 10.12.09

Neonicotinoids in Fall

  • Young canola plants
  • Winter cereals
  • Guttating fertilizer plants
slide-55
SLIDE 55

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

55 / 10.12.09

Canola guttation in Fall

slide-56
SLIDE 56

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

56 / 10.12.09

Neonicotinoid content in Canola guttation, fall 2009

4-leaf-stage 6-leave- stage 172 ppb 63 ppb

slide-57
SLIDE 57

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

57 / 10.12.09

Neonicotinoide im Herbst

slide-58
SLIDE 58

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

58 / 10.12.09

Neonicotinoid seed coatings …

  • … poison agricultural crops and soils for

months

  • … poison for month and

indiscriminatingly any and all insects, not just the targets

  • … still require carefull handling of the

treated seeds

slide-59
SLIDE 59

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

59 / 10.12.09

Neonicotinoids in Germany

  • Direct application

B1

  • - no application -

B2

  • Seed coating

B3

  • Sprays

B4 Contamination of nectar and pollen by blossom sprayapplications Brood losses?

slide-60
SLIDE 60

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

60 / 10.12.09

Brood damage by neonicotinoids

  • Neonics through water into hive
  • ‚Harmless‘ substances, e. g. Thiacloprid

 blossom spray application  Nectar, Pollen

  • Distribution of contaminated water

and/or nectar through thropalaxix and snowball-system in entire hive population of collectors, hive bees, and

  • pen larvae
slide-61
SLIDE 61

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

61 / 10.12.09

Literatur about „snowball system“

  • Food transmission within the honeybee

community, H.L. Nixon + C. R. Ribbards, 1952

  • The flow of incoming nectar througha honey

bee colony as revealed by a protein marker,

  • G. DeGrandi-Hoffman + J. Hagler, 2000
  • Inner nest homeostasis in a changing

environment with special emphasis on honey bee brood nursing and pollen supply,

  • T. Schmickl, K. Crailsheim, 2004
slide-62
SLIDE 62

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

62 / 10.12.09

Schneeball-System

  • Marked sugar syrup
  • After 2 hours:

65 % hive bees, 42 % nurse bees,

35 % Larvae

  • After 8 hours:

100 % hive bees, 90 % nurses,

75 % Larvae

  • After 48 hours:

100 % hive and nurse bees as well as all open Larvae

slide-63
SLIDE 63

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

63 / 10.12.09

Brood damage through „safe“ a.i.?

  • Nectar storage right next to brood for

direct larvae feeding

  • Danger for nurse bes?
  • Can poison be passed on through royal

jelly?

  • ‚Long term damage‘ of adult bees

raised as larvae with these substances?!

slide-64
SLIDE 64

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

64 / 10.12.09

Fungicides as blossom sprays, e. g. CANTUS

  • Nectar storage right next to brood for

direct larvae feeding

  • Danger for nurse bes?
  • Can poison be passed on through royal

jelly?

  • Effects of fungicides on microorganisms

important for the productionof bee bread (G. DeGrandi-Hoffman)

slide-65
SLIDE 65

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

65 / 10.12.09

GMO plants

  • Nectar storage right next to brood for direct

larvae feeding

  • Danger for nurse bes?
  • Can poison be passed on through royal jelly?
  • GMO plants produce their own poison –

danger to bees through guttation drops?

  • Leaching of GMO poison into dew/rain, drops

falling to the soil, weeds?

slide-66
SLIDE 66

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

66 / 10.12.09

Demands of DBIB

  • Immediate stop of all neonicotinoid

seed coatings in crops

  • No blossom spray applications

(during daylights)

  • Larvae tests for all substances to be

applied to blossoms

slide-67
SLIDE 67

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

67 / 10.12.09

Bees drinking phloem?

  • Observed in corn 2008
  • Reports about the same in

sunflower in 2009 (extrafloral nectar or phloem?)

slide-68
SLIDE 68

DBIB – H. Riebe

Exposition paths of neonicotinoids – Paris 2009

68 / 10.12.09

Latest results

  • Girolami publication
  • Canola guttation in spring at approx. 20

ppb (UFOP research, Wallner)

  • JKI greenhouse results presented in
  • Sept. in Brussels
  • AFSSA presentation at SETAC in Sept. in

Brussels
