EXPLORER+300 Compact for individual usage EXPLORER+ 300 The - - PowerPoint PPT Presentation

EXPLORER+300

Compact – for individual usage

2

• The smallest EXPLORER terminal:
• Weighs only 1.4 kg
• A single-user terminal:
• Ideal if your primarily need voice, or

moderate speed internet access

• Compact:
• Easy to carry, simple system set-up and
• peration

EXPLORER Update

EXPLORER+ 300

3

• New features
• Remote Management features
• SMS wakeup
• Core software same as BGAN-X
• Chinese language support
• Advantage
• Better performance
• Value
• New features in future more rapidly deployed

to all terminals

EXPLORER Update

EXPLORER+ 300

Software release 3.01

4

• TT-3705A EXPLORER+ 300
• TT-3682L AC/DC Power

Supply

• TT-3686L Li-Ion Battery
• 2m LAN Cable
• CD-ROM with:
• User Guide
• Getting Started
• Quick Guide
• CD-ROM with Inmarsat

LaunchPad

EXPLORER Update

EXPLORER+ 300

What’s in the box

5

EXPLORER+ 300 EXPLORER+ 500 EXPLORER+ 700

Bandwidth (UL / DL) 240 / 384 kbps 448 / 464 kbps 492 / 492 kbps Streaming IP (QoS) 32 & 64 kbps 32, 64 & 128 kbps 32, 64, 128 & 256 kbps ISDN No via USB & BT Yes – 2 ports Premium Voice No 3.1 kHz Audio 3.1 kHz Audio 2-wire Yes – 1 port Yes – 1 port Yes – 2 ports Ethernet Yes Yes Yes – 2 ports WLAN No No Yes – 802.11a/b/g USB (slave) No Yes Yes Solar panel input No No Yes Bluetooth Yes – Class 2 Yes – Class 1 Yes – Class 1 Single-user / Multi-user Single Multi Multi Detachable antenna No No Yes – up to 100 m Battery Li-Ion – 36h standby 3h – standard voice Li-Ion – 36h standby 3h – standard voice Li-Ion – 36h standby 5h – standard voice Weight 1.3 kg 1.4 kg 3.2 kg Size (H x W x D): Transceiver Antenna 170 x 217 x 52 mm 218 x 217 x 52 mm 280 x 228 x 40 mm 297 x 399 x 51 mm Ingress Protection Rating IP-54 IP-54 IP-52 (Transceiver) IP-66 (Antenna)

EXPLORER+

Portable BGAN

EXPLORER+ Series

• an unmatched portfolio of BGAN products
