Exploiting Spatial Data for Site Declaration

21 October 2014 Graham Smith Bruce Power LP Ontario, Canada

T

• pics
• About Bruce Power
• Geographic Informatjon Systems - GIS
• GIS at Bruce Power
• A Data Sharing Imperatjve
• A Model to Support Site Declaratjon
• Challenges and the Up Side

2

Geography

3

Bruce Power Bruce Power

Largest Nuclear Facility In The World

• 8 units in operatjon

since 2012

• 6300 megawatus
• 30 % of the total power

for the province of Ontario

• Refurbishment of units

1 & 2 enabled the province to close its coal plants

4

Geographic Information Systems (GIS) More Than Just A Map

• Locatjon Matuers
• Integratjon
• Informatjon As An Asset
• Common Operatjng Picture
• The Map as a Portal
• Time Enabled
• Empowerment
• Decision Support
• Informatjon Management
• Adaptjve, Responsive and Flexible
• Communitjes of Users
• Multj-Agency Collaboratjon

5

GIS at Bruce Power

• Late adopter - a paper and CAD mindset
• GIS ofgers a new vision for managing informatjon

about the site

• Aim for a commercial approach for non-nuclear

facilitjes

• Paradigm shifu from drawings as ‘controlled

documents’ to records in a ‘controlled database’

• We have begun in the Property Management

Department…

6

7

Site Declaration Map - Business As Usual

8

Site Declaration Map – A GIS Approach

9

T elecom and Steam Heating

10

Sanitary Sewer

11

Domestic and Fire Water

12

Electrical Distribution

13

Facility Condition Index

14

Joint Health and Safety Committee Zones

15

Land T enure – Legal Boundaries

16

Digital T errain Model - DTM

Property Management Legal Engineering

Producer Producer Producer Consumer Consumer Consumer

The Data Sharing Imperative How does data sharing evolve and grow? In the beginning…its local 17

Security Space Managers Legal

Producer Producer Producer Consumer Consumer Consumer

I need some of your data…

18

Environment Maintenance Operations

Producer Producer Producer Consumer Consumer Consumer

Leading to local functional interdependence

19

Municipalities IAEA Safeguards Provincial Ministries Universities Colleges Consultants Industry Federal Agencies

Producer Producer Producer Consumer Consumer Consumer

Public, NGO’s

Non-local Functional Interdependence

Human Resources IT Property Management

Facilitjes Management GIS for Facilitjes Management

20

Spatial Information Management T ree

Raw Data Data Warehouse Data Workspaces Information Collection Maintenance Architecture Metadata Knowledge Decisions & Best Practices Standards & Procedures Analyze Report Transform (OGC,Sharable) Publish Processes Dependencies Intelligence Management

Reality

Transformatjon

Data Custodians

Corporate Mandate Strategic Plan

Data Models

21

Digital Declaration Data on Nuclear Sites

22

Geospatjal Exploitatjon System (GES)

• Dept. of

Safeguards Data Model ? Transformatjon Of Data Models Translatjon of Format Operators and States

Consider:

• Promotjng the adoptjon of GIS for sites and its

potentjal benefjts

• Providing tools for translatjon of local formats and

the GES standard data model

• Is it viable to web-enable GIS tools to allow operators

to manage their data in a cloud environment?

23

Digital Declaration Data for Nuclear Sites

Challenges

24

Resistance to Change: “When new technologies impose themselves on cultures long habituated to older technologies, anxietjes of all kinds exists.”

• Marshall McLuhan

Red Queen Efgect: "in this place it takes all the running you can do, to keep in the same place."

• Lewis Carrol

Foundatjon building: “If you wish to make an apple pie from scratch, you must fjrst invent the universe."

• Carl Sagan

• GIS is a mature, proven technology
• There is a wealth of experience
• The tools are easy to learn for end users
• There are many cost-efgectjve technical optjons
• The frontjer of change lies with Partnership and

Collaboratjon

25

The Up Side

26

Thanks for Listening! Questjons?
