Expert for innovative wear solutions Seite 1 We offer: Maximum work safety as well as health- and environmental protection The only Austrian service team* with SCC certificate Maximum quality ISO 9001 certified Maximum

SLIDE 1

Expert for innovative wear solutions

Seite 1

SLIDE 2

We offer:

Maximum work safety as well as health- and

environmental protection

The only Austrian service team* with SCC certificate

Maximum quality

ISO 9001 certified

Maximum technology

Intensive cooperation with the Papermakers‘ School

Seite 2

SLIDE 3

Gerhard Sigl

Productmanger - ROBASERV

7 years experience in the international paper industry Expert for various repairs on dewatering elements First contact person for installation- and service on the

papermachine

Problem solving for defect dewatering elements Contact person for ROBATOP-Nano surface refinement

for different materials

Seite 3

SLIDE 4

ROBASERV

Mobile repair- & service team for ceramic dewatering elements

SLIDE 5

Improved runability of the paper machine Increase of fabrics lifetime up to 40 % Risk assumption during installation and dismantling

Main advantages

Seite 5

SLIDE 6

Regrinding of ceramic

elements

All repairs in general Service on paper machine Installations and mounting Laser measurement Mobile grinding center

Our services

Operations at LERIPA Operations at customer

Seite 6

SLIDE 7

Our services in detail

Inspection Wear measurement Visual check Sensitive check UV crack check Surface roughness measurement Report

Seite 7

SLIDE 8

Our services in detail

Service Manual edge optimization Geometry shape grinding Regrinding Segment changing on compound strips Leveling & checking of steel boxes Laser measurement Report SCC certified

Seite 8

SLIDE 9

Our services in detail

Logistik Assumption of risk Spare parts stock check

Seite 9

SLIDE 10

Operations

at LERIPA

Seite 10

SLIDE 11

After the unload, all service parts get immediately an entrance number for internal receipt of goods. This system grants us a perfect follow up of all parts. All items are immediately identifiable and any confusion is impossible.

Entrance number

Seite 11

SLIDE 12

Carefully cleaning of dewatering elements

Cleaning

Seite 12

SLIDE 13

Visual check Sensitive check

Checking

UV crack checking Wear measurement

Seite 13

SLIDE 14

Entrance report & repair possibilites

Actual situation including pictures Repair proposal Drawing where you can see the damaged segments

Seite 14

SLIDE 15

Segment exchange Wear diagram

Repair

(after getting the order)

Surface roughness measurement Finish Surface grinding

Seite 15

SLIDE 16

End report

Height of ceramic BEFORE vs. AFTER Is further repair possible? Yes/No List of all completed work steps

Seite 16

SLIDE 17

What can we repair without restriction?

Leripa products solid ceramic competitor

Altes Design Neues Design Ceramtec Design

Seite 17

SLIDE 18

What can we repair limited?

All composite blades with single ceramic segments

Using similar Leripa segments which are on stock
Remanufacturing a profile and using the old segments

Seite 18

SLIDE 19

What is irreparable?

Huyck Johnson Johnson Scandfoil

All elementes with rod systems All ceramic coated elements Alle Inserts or Outserts ceramic/plastic elements

Seite 19

SLIDE 20

Operations at customer

(service | installation | laser measurement | mobile grinding center)

Seite 20

SLIDE 21

Service

Visual checking Sensitive checking UV crack checking Wear measurement Manual edge optimization

Seite 21

SLIDE 22

Service

The machine must be stopped The fabrics must be removed Enough time

Requirements for a service

Seite 22

SLIDE 23

Installation

Change of elements Installation of new constructions

Seite 23

SLIDE 24

Laser measurement

Foudrinier machines alignment with a precision of 0,01 mm/m At former units (gap former / top former) is no alignment possible

Seite 24

SLIDE 25

Servie on site At 24/7 All foils an covers Grinding of elements on the steel frame

Mobile regrind center (truck)

Seite 25

SLIDE 26

Needs: No needs:

Space for truck:

(20 m x 3 m solid underground)

Electricity:

(400 V ~, 16 Ampere)

Water connection Discharge water connection Compressed air connection

Seite 26

SLIDE 27

Regrinding possibilites?

Width max.

800 mm

Height max. 300 mm
Length max. 8.000 mm

Covers and lists Covers and lists on steel boxes

Seite 27

SLIDE 28

Service report

Each service, either grinding on truck or ony laser measurement ends in a final report for the customer.

Seite 28

SLIDE 29

Important information

Seite 29

SLIDE 30

Wire life time

Piano keying, cracks and sharp edges can destroy the wire. Optimum rounded edges prevent the wire from damages and increase the wire life time by apprximately 40 %

Seite 30

SLIDE 31

The right time for regrinding?

Piano-keying > 0,1 mm Damages with course stirps on the paper wire Sharp edges If the contact area between foils and the wire reaches

40 – 50 % of the whole ceramic surface.

Seite 31

SLIDE 32

Standard values

Regrinding intervall

Influencing variables:

Speed Paper grade Type of filler

3-4 years 2-3 years

approx. 2 years

1-1,5 years

Amount of filler Ceramic material Installation position

Seite 32

SLIDE 33

Certificates & references

Seite 33

SLIDE 34

ISO 9000 & SCC

ISO 9000 certificate Well trained and SCC certified team!

Seite 34

SLIDE 35

References

Burgo Ardennes (Belgium) Stora Enso Langerbrugge (Belgium) Mondi Swiecie (Poland) Saica (Spain) Papierfabrik VAREL (Germany) Leipa Schwedt (Germany) Palm Eltmann/Wörth (Germany) Rhein Papier Hürth (Germany) SCA Laakirchen (Austria) …. and much more!

we would be pleased to send you our extened reference list on request

Seite 35
