Experimental and Theoretical Approach of a Multi-Stage Membrane Distillation System P. Boutikos, E.S. Mohamed, E. Mathioulakis and V. Belessiotis Solar and Other Energy Systems Laboratory NCSR DEMOKRITOS 14 16 September 2016, Athens


slide-1
SLIDE 1

Experimental and Theoretical Approach of a Multi-Stage Membrane Distillation System

  • P. Boutikos, E.S. Mohamed, E. Mathioulakis and V. Belessiotis

Solar and Other Energy Systems Laboratory NCSR «DEMOKRITOS» 14 – 16 September 2016, Athens

slide-2
SLIDE 2

Contents

 Introduction  Aim  Mathematical Model Development  Experimental Approach  Model Validation  Conclusions

slide-3
SLIDE 3

Introduction – Membrane Distillation (MD)

 Membrane

Distillation (MD): A thermal membrane separation process, in which water vapor molecules or volatile compounds are transferred from a hot aqueous solution (usually saline water), through a microporous hydrophobic membrane, because of the partial pressure difference created due to the temperature difference across the membrane.

slide-4
SLIDE 4

Introduction – Membrane Distillation (MD)

Advantages Disadvantages

Production of high purity distillate. Reduced production of the water vapor flux. The possibility of operating at lower temperatures. The temperature polarization affects negatively the flux through the membrane. Operates at relative low pressures. The trapped air in the membrane pores increases the resistance to mass transfer. It can treat high concentration or supersaturated solutions. High specific energy consumption, mainly due to the heat losses by conduction. The capability of utilizing solar thermal energy or even waste heat from other processes.

slide-5
SLIDE 5

Optimized design

  • f a pilot-scale

unit The development of a mathematical model, which can be used to study the effect of the significant parameters that influence the quality and quantity

  • f the produced desalinated water.

The experimental approach of the multi-stage membrane distillation system.

Aim

slide-6
SLIDE 6

Mathematical Model Development

slide-7
SLIDE 7

Mathematical Model Development

Mass and Energy Balances

 Evaporator (Hot water stream):

, , , ,,, ,,,

 Stage Feed saline solution:

,

,

  • ,

,

, ,

  • ,
  • , ,

, , ,

 Condenser (Cold water stream):

, , ,

slide-8
SLIDE 8

Transport Phenomena – Mass Transfer

 Mass Transfer:  Feed boundary layer (concentration polarization).

 Through the membrane pores.  The mass transfer in the feed boundary layer can be described by the film

theory. ,

  • ,

 The mass flux through the membrane is proportional to the water vapor partial

pressure difference (Darcy’s Law).

,

  • : membrane mass transfer coefficient
  • Function of membrane structural properties
  • Knudsen diffusion, Viscous flow, Molecular diffusion or combination
slide-9
SLIDE 9

Transport Phenomena – Heat Transfer

Evaporator

 The total heat is transferred from the bulk feed through the hot water boundary

layer to the feed membrane interface by conduction.

,

 The transferred heat is consumed, at the membrane surface, only by the latent

heat of vaporization. ,∆

Stage

 The generated vapor is completely condensed at the surface of the impermeable

foil (Qconds,st = Qevap).

 The latent heat of condensation is transferred through the condensing film and

the foil by conduction and heats up the feed saline stream.

slide-10
SLIDE 10

Transport Phenomena – Heat Transfer

Stage

 In the feed channel the feed saline solution is initially pre-heated to its boiling

point, Tsat, and then is partially evaporated at the membrane interface, where new water vapor is produced. , ,∆ Condenser

 The produced vapor from the last stage is completely condensed.  The latent heat of condensation is transferred through the condensing film and

the foil by conduction.

 In the boundary of the cold water stream the heat is transported by convection.

,

slide-11
SLIDE 11

Experimental Desalination Unit

slide-12
SLIDE 12

Experimental Desalination Unit

 Multi-stage membrane distillation unit that employs both the vacuum

membrane distillation and multi-stage distillation concept.

 Membrane module  Heating Loop

  • Hot water inlet temperature (Thw,in) at 75 oC.
  • Hot water flow rate (Fhw): 1500 – 3500 L/h .

 Feed Loop

  • Feed inlet temperature (Tf,in) at 25 oC.
  • Feed solution flow rate (Ff,sw): 40 – 120 L/h .

 Cooling Loop

  • Cold water inlet temperature (Tcw,in) at 30 oC.
  • Cold water flow rate (Fcw): 1500 – 3500 L/h .

 Vacuum system (Vacuum pressure at ~ 800 mbar)

slide-13
SLIDE 13

 Water Productivity, Fdist (L/h):

 Recovery Rate, RR (%): 100 ∗  Gained Output Ratio, GOR:  Specific Thermal Energy Consumption, STEC (kWh/m3):

Performance and Energy Efficiency Indicators

slide-14
SLIDE 14

Influence of Hot Water Inlet Temperature

Pure water, Fhw= 3500 L/h, Tf,in= 25 oC, Ff,sw= 80 L/h, Tcw,in= 30 oC, Fcw= 3500 L/h

40 60 80 100 0,5 1,0 1,5 2,0 2,5

Gained Output Ratio, GOR Hot Water Inlet Temperature (

  • C)

300 600 900 1200 GOR STEC

STEC (kWh/m

3)

40 60 80 10 20 30 40

Water Productivity (L/h) Hot Water Inlet Temperature (

  • C)

Recovery Ratio, RR (%)

20 40 60 WP RR

slide-15
SLIDE 15

Influence of Feed Flow Rate

50 100 150 0,5 1,0 1,5 2,0

STEC (kWh/m

3)

GOR STEC

Feed Flow Rate (L/h) Gained Output Ratio, GOR

250 500 750

Pure water, Thw,in= 75 oC, Fhw= 3500 L/h, Tf,in= 25 oC, Tcw,in= 30 oC, Fcw= 3500 L/h

50 100 150 10 20 30 40 WP RR

Feed Flow Rate (L/h) Water Productivity (L/h)

20 40 60 80 100

Recovery Ratio, RR (%)

slide-16
SLIDE 16

Model Validation – Hot Water Inlet Temperature

50 60 70 80 90 20 40 Pure water Experimental data Simulation Curve

Hot Water Inlet Temperature (oC) Water Productivity (L/h)

50 60 70 80 90 20 40 60 Saline Solution (30 mS/cm) Experimental data Simulation Curve

Hot Water Inlet Temperature (oC) Water Productivity (L/h)

slide-17
SLIDE 17

Model Validation – Feed Flow Rate

80 100 120 20 40 60 Pure water Experimental data Simulation Curve

Feed Flow Rate (L/h) Water Productivity (L/h)

60 80 100 120 10 20 30 40 50 Saline Solution (30 mS/cm) Experimental data Simulation Curve

Water Productivity (L/h) Feed Flow Rate (L/h)

slide-18
SLIDE 18

 An experimental multi-stage membrane desalination unit was designed and tested to several operating conditions.

 A mathematical model was developed with aim of maximizing the productivity

and the energy optimization of the process.

 The water productivity and the recovery ratio increases with the increase of the hot

water inlet temperature. The GOR also increases and obtains an asymptotic value at high values of the hot water inlet temperature. However, the STEC decreases as the hot water inlet temperature increases.

 Increasing the feed flow rate the residence time decreases and the water vapor

flux and the recovery ratio decreases. The GOR ratio increases, whereas the specific thermal energy consumption increases.

 The model predictions were in a good agreement with the experimental results,

presenting low deviations (1 – 15%) from the experimental data for the pure water, whilst for the saline water the deviations were in the range of 5 – 22%.

Conclusions

slide-19
SLIDE 19

Thank you for your attention
