Expanding the Boundaries of the AI Revolution: Changyong Ahn & Nayoung Lee | March 2019 Outline 1 2 Machine Learning/Deep Learning Use Cases 3 Memory Challenges of Deep Learning Simple View Deep Neural Network Fundamental Concepts


slide-1
SLIDE 1

Changyong Ahn & Nayoung Lee | March 2019

Expanding the Boundaries of the AI Revolution:

slide-2
SLIDE 2

1

Outline

slide-3
SLIDE 3

2

slide-4
SLIDE 4

3

Machine Learning/Deep Learning Use Cases

slide-5
SLIDE 5

4 Source: Standford

Deep Neural Network

Simple View

Σ

(Activation function, Compute) = Multiply & Accumulate sum Weights x Input Output Layer Weights x Input Weights x Input … ……

MEM Write MEM Read

Ye Year CN CNN # of layers rs # of Pa Param rameters rs Mem Memory ry size (MB MB) Top5 5 Er Error Ra Rate 1998 LeNet 8 60K 2012 AlexNet 7 60 million 240 15.3% 2014 GoogleNet 19 4 million 6.67% 2014 VGG Net 16 138 million 574 7.3% 2015 ResNet 50/152 519 3.6%

Deep Neural Network Fundamental Concepts

Memory Challenges of Deep Learning

slide-6
SLIDE 6

5

Memory Solution for ML/DL Systems

* Source : SK hynix

Memory Sub system hierarchy change

Co Conventio ional DRAM IPM IPM Target Market/Price Broad & Cheap Specific & high Premium Standardization JEDEC Semi Custom Qualification Period Relatively short Relatively long Key factors Price Competitiveness Reliability / Performance

TSV Region

Interposer Substrate(“PCB”)

“In Package Memory”

Fast Storage(SSD) HDD

LLC

DRAM

1) In-Package Memory 2) SCM(“Storage Class Memory”) : 3DXP, PCRAM

Storage Class Memory

Fast Storage(SSD) HDD LLC

IPM

DRAM

<10ns 50ns 100ns – 1us 50-100us ~10ms

slide-7
SLIDE 7

6

slide-8
SLIDE 8

7

HBM, What’s the difference?

GDDR/DDR/LPDDR HBM

  • FBGA
  • KGSD
  • HBM in 2.5D SiP

PHY TSV DA ball

DRAM Slice DRAM Slice DRAM Slice DRAM Slice

Interposer

SoC

PHY

Side Molding Side Molding

Substrate

Directly soldered on PCB or used as a DI MM

Mold DRAM DRAM PCB Substrate

slide-9
SLIDE 9

8

HBM Advantages

More e Bandwid idth th High h Power r Efficien iciency Small ll Form m Factor tor

DDR DDR4 LPDD PDDR4(X (X) GDD GDDR6 HBM BM2 HBM BM2E (JED EDEC) HBM BM3 (TBD) BD) Data rate 3200Mbps 3200Mbps (up to 4266 Mbps) 14Gbps (up to 16Gb ps) 2.4Gbps 2.8Gbps >3.2Gbps (TBD) Pin count x4/x8/x16 x16/ch (2ch per die) x16/x32 x1024 x1024 x1024 Bandwidth 5.4GB/s 12.8(17)GB/s 56GB/s 307GB/s 358GB/s >500GB/s Density (per package) 4Gb/8Gb 8Gb/16Gb/2 4Gb/32Gb 8Gb/16Gb 4GB/8GB 8GB/16GB 8GB/16GB/ 24GB (TBD)

To Achieve 1TB Bandwidth ……

160ea of DDR4-3200 40ea of DDR4-3200 Module 4ea HBM2 in a single 50mm x 50mm Sip

Note: Advil is a registered trademark

slide-10
SLIDE 10

9

slide-11
SLIDE 11

10

HBM Architecture

HBM2 core

  • re die suppor
  • rts

ts 4 ps pseudo

  • channel

nels s or 2 c chann nnels els Each ch channe nel l consis sists ts of 2 P Pseudo

  • Channe

nels ls. . Only y BL4 i is suppor

  • rte

ted

Items Target

# of Stack 4/8(Core) + 1(Base) Ch./Slice 2 Total Ch. for KGSD 8/16 (8ch based operation) IO/Ch. 128 Total IO/KGSD 1024(=128 x 8) Address/CMD Dual CMD Data Rate DDR

CH-A CH-B

B0 B1 B2 B3 B4 B5 B6 B7

64 I/O ADD CMD 64 I/O

CH-A CH-B

B0 B1 B2 B3 B4 B5 B6 B7

64 I/O ADD CMD 64 I/O

slide-12
SLIDE 12

Next-Gen. System Architecture Leveraging HBM

HPC & Server

(B/W & Capacity)

Network & Graphics

(B/W)

Client-DT & NB

(B/W & Cost) +

Bandwidth Solution Cost Solution

+

Bandwidth Solution Bandwidth Solution

+

Bandwidth Solution Capacity Solution Post-DDR4

+

Post-DDR4

+

B/W B/W B/W B/W & Capacity B/W & Cost

HBM

HBM and 2.5D SiP integration unlock new system architecture

slide-13
SLIDE 13

HBM Test Flow

General DRAM Test Flow HBM Test Flow

slide-14
SLIDE 14

13

Quality and Reliability Features

SoC Substrate

PMBIST Cell Repair BISS (Built In Self Stress) Microbump Repair Error Correcting Code Storage

HBM

PHY DRAM DRAM DRAM PHY Logic die PHY TSV micro bump

PKG Substrate

Proxy Package

HBM Features enable high quality and reliability at post 2.5D assembly

1 2 3 4 5 6

Interposer

1 2 3 4 5 6

slide-15
SLIDE 15

14

Collaterals Available from HBM vendors

Item Remarks Functionality Datasheet (Jedec/Vendor) Verilog (mission mode and DFT) IBIS Hspice Mechanical/Interposer design GDS Bump pad netlist Bump Ballout Thermal Simulation Flotherm Icepak

slide-16
SLIDE 16

Future of HBM Solution

HBM would penetrate various market segments in the short future.

Auto motiv e

HBM1

GFX

HBM2

GFX

NT W

HP C Client

HBM3

SVR GFX

NT W

HPC SVR Client PC

Consum er

128GBps 1GB 256GBps 1G/2G/4G/8GB 105C ECC 95C 512GBps 2G/4G/8G/16GB 105C ECC/ In DRAM ECC Optimized Base die Low Cost Ver.

Expansion to various Applications Moving to Volume Market

Con sumer 15
