SLIDE 1
Walker River Decision Support Tool Groundwater Model Component
Greg Pohll
EXHIBIT 119 Walker River Decision Support Tool Groundwater Model - - PDF document
EXHIBIT 119 Walker River Decision Support Tool Groundwater Model - - PDF document
EXHIBIT 119 Walker River Decision Support Tool Groundwater Model Component Greg Pohll DST 2.0 Model Components MODSIM River Basin Management system PRMS models of headwater areas (Supply Side) MODFLOW models of Mason & Smith (Demand
SLIDE 2
SLIDE 3
DST 2.0 Model Components
MODFLOW models
- f Mason & Smith
(Demand Side) PRMS models of headwater areas (Supply Side) MODSIM River Basin Management system
SLIDE 4
Groundwater/Surface Water – One Resource
5 – 25% of the surface water budget
SLIDE 5
Stream/Aquifer Interaction
SLIDE 6
Phreatophyte ET
Deep Water Table Shallow Water Table
SLIDE 7
Groundwater Model Construction
- Two groundwater
models were built
- Smith Valley
- Mason Valley
- Key inputs
- Recharge
- Well information
- Hydraulic conductivity
- Phreatophyte ET
- Stream and ditch
information
q
2 2 4 6 8 1 Miles SLIDE 8
Groundwater Model Revisions
- Two groundwater
models were built
- Smith Valley
- Mason Valley
- Key inputs
- Recharge
- Well information
- Hydraulic conductivity
- Phreatophyte ET
- Stream and ditch
information
SLIDE 9
Groundwater Model Revisions
- NDOW properties included and ponds simulated
using General Head Boundary (GHB package
- Smith Valley model initial conditions adjusted to
yield better agreement with measured water levels
- HRU water balance, which includes calculations of
groundwater pumping rates is handled in MODSIM
SLIDE 10
Recharge
Irrigation Excess Ditch & Drain Losses Mountain Block Recharge
SLIDE 11
Well Information
SLIDE 12
Hydraulic Conductivity
Mason Smith
SLIDE 13
Phreatophyte ET
SLIDE 14
Stream & Ditch Information
- A complete water
budget is calculated using the SFR package within MODFLOW for the Walker River and agricultural drains
- Losses from irrigation
ditches are handled separately in MODSIM and are treated as a fluid source term in MODFLOW
SLIDE 15
Model Accuracy
SLIDE 16
Model Accuracy
SLIDE 17
Model Accuracy
SLIDE 18
Model Accuracy
Mason Valley Relative Error = 1.98% RMSE = 3.7 m
SLIDE 19
Model Accuracy
Smith Valley Relative Error = 5% RMSE = 8.8 m
SLIDE 20
Stream Gains and Losses
- Warm Colors –
Losing
- Cool Colors –
Gaining
SLIDE 21
Conclusions
- Two groundwater
models were constructed for use in the DST
- These models were
calibrated, validated, and peer-reviewed
- The models are
integrated into the DST to provide groundwater flux information at every time step
