Porter McGuffie, Inc. Engineering Measurement and Analysis Services Examining the Cost Return Ratio for CFD in the Gas, Oil and Chemical Industries Mike Porter, P.E Principal Engineer Porter McGuffie, Inc. 544 Columbia Dr., Lawrence, KS 66049

slide-1
SLIDE 1

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Examining the Cost Return Ratio for CFD in the Gas, Oil and Chemical Industries

Porter McGuffie, Inc. 544 Columbia Dr., Lawrence, KS 66049 www.pm-engr.com Mike Porter, P.E Principal Engineer

slide-2
SLIDE 2

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

512,000 lb/hr 85’ long 20’ ID

Tail Gas Unit

slide-3
SLIDE 3

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

The initial goal:

Reduce pressure drop

− Driven by low available fan power

Evaluate two different inlet piping geometries

slide-4
SLIDE 4

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Inlet piping system pressure magnitudes

slide-5
SLIDE 5

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Surface plot of Y-velocities above bed

slide-6
SLIDE 6

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Streamlines colored by velocity

slide-7
SLIDE 7

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Inlet piping system pressure magnitudes

slide-8
SLIDE 8

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Streamlines colored by velocity

slide-9
SLIDE 9

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Surface plot of Z-velocities above bed

slide-10
SLIDE 10

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Savings? 1.5” w.c. reduced pressure drop Catalyst life – 4-8 years − 8,000 ft3 catalyst − $400/ft3 catalyst cost

slide-11
SLIDE 11

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Plane 1 Plane 2 Plan 3

Feed water heat exchanger

slide-12
SLIDE 12

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Velocity Magnitudes on Cut Plane 1

slide-13
SLIDE 13

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Inlet Modifications

Additional Extraction Steam Nozzle

slide-14
SLIDE 14

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Near Inlet Modifications

Additional Tube Support Plate Additional Tube Support Plate Increased Impingement Plate Size

slide-15
SLIDE 15

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Velocity Magnitudes on Cut Plane 1

slide-16
SLIDE 16

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Savings? Vessel life – 30 vs 15 years Capacity increase – 15%

slide-17
SLIDE 17

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

SRU Boiler

slide-18
SLIDE 18

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

The Problem:

slide-19
SLIDE 19

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

slide-20
SLIDE 20

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

slide-21
SLIDE 21

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

When that happens:

slide-22
SLIDE 22

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

The variables:

  • Heat Flux
  • Superheat
  • Void fraction
slide-23
SLIDE 23

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Water Side Model– 4.3 Million Cells

slide-24
SLIDE 24

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Volume Fraction of Steam at time = 25 seconds

slide-25
SLIDE 25

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Volume Fraction of Steam at time = 28 seconds

slide-26
SLIDE 26

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Upper Tubes Showing Steam Void > 0.9

slide-27
SLIDE 27

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

External Tube Temperature

slide-28
SLIDE 28

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

SRU Data vs. Peak Heat Flux Curve

20000 40000 60000 80000 100000 120000 20 40 60 80 100 120 140 160 180 200 Superheat Temperature (F) Flux (BTU/hr*ft^2) Flux Curve Point 1 Point 2 Point 3 Point 4 Point 5

slide-29
SLIDE 29

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

The heat flux is proportional to the Mass Flow Rate and the Dynamic Viscosity

− Unfortunately, the Dynamic Viscosity is not a process parameter

If the parameters are plotted and curve fit, for a particular geometry, it is possible to relate the heat flux to the mass flow rate and the process temperature.

− These are measured process parameters

This allows the development of a simple graph to control the process

slide-30
SLIDE 30

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

slide-31
SLIDE 31

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Savings? SRU repair cost – less than analysis Plant throughput reduction – less than analysis – per hour

slide-32
SLIDE 32

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Baghouse flow analysis

slide-33
SLIDE 33

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

slide-34
SLIDE 34

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Velocity Pressure

slide-35
SLIDE 35

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Location % Difference from Mean 1 3.55% 2 .090% 3

  • 1.35%

4

  • 4.68%

5

  • 3.65%

6

  • 6.68%

7

  • 3.90%

8

  • 6.44%

9

  • 3.65%

10

  • 7.43%

11 17.32% 12 15.49% 13 1.78% 14

  • 1.26%
slide-36
SLIDE 36

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

slide-37
SLIDE 37

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Before After

slide-38
SLIDE 38

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Result? 2006 installation

slide-39
SLIDE 39

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

“Overall this was a very successful project for Lafarge” said project manager Nick Trout. “The results exceeded our expectations in terms of providing an excellent quality product that continues to perform within the operating parameters set forth in the justification for the project. We have gone from spending over US $40,000 per month on baghouse repairs to no cost at all. In addition, we are using a lot less compressed air to clean the filter bags and we have reduced the static pressure on the fan by over 4” (10 mm) w.c….”

World Cement, May, 2009

slide-40
SLIDE 40

Porter McGuffie, Inc.

Engineering Measurement and Analysis Services

Porter McGuffie, Inc. 544 Columbia Drive – Suite 19 Lawrence, Kansas 66049 V: 785.856.7575 F: 785.856.3658
