Ethernet Access Technologies 2 Moldovn Istvn Department of Budapest University of Technology and Economics Telecommunications and Media Informatics Ethernet Forwarding BME-TMIT MAC Forwarding Topology VLAN Forwarding Topology Active

slide-1
SLIDE 1

Budapest University of Technology and Economics Department of Telecommunications and Media Informatics

Ethernet

Access Technologies 2 Moldován István

slide-2
SLIDE 2

BME-TMIT

Ethernet Forwarding

Physical Topology Active (Spanning Tree) Topology VLAN Forwarding Topology MAC Forwarding Topology

slide-3
SLIDE 3

BME-TMIT

3

Ethernet Switches

  • Layer 2 forwarding – MAC address based
  • Learns MAC addresses
  • Store-and-forward operation
  • No collision
  • High speed backplane
  • Many interfaces
  • Different interface speeds
  • Different media
slide-4
SLIDE 4

BME-TMIT

4

Switches

  • Standard refers them as bridges
  • They divide the broadcast domains
  • Types
  • Unmanaged

– SOHO use, low level aggregation – No support for STP nor VLAN

  • Managed

– VLAN and STP support – management interface

  • L2/L3
slide-5
SLIDE 5

BME-TMIT

5

P-to-P mode

  • On links between bridges CSMA-CD not

needed

  • Separate RX/TX paths at phy
  • No collision
  • Full duplex
  • Higher achievable BW
  • Can be used
  • Between bridges
  • Between bridge-PC
  • HUB and shared media can not use it
slide-6
SLIDE 6

BME-TMIT

6

Ethernet local network design

  • Hierachically

HUB SWITCH, Bridge Multiservice switch Router

slide-7
SLIDE 7

BME-TMIT

Page 7

Metro Ethernet

Metro Backbone

National IP Network

GE

Aggregation Switch

2 x GE GE GE

VOD Server

TV Headend

3rd Party ISP

VOD Server VOD Server

POP

B-RAS Router

Internet

E.PON EFM G.PON 100BaseFX B.PON GE GE GE GE

Location Server

SIP Proxy Server

Triple Play

slide-8
SLIDE 8

Budapest University of Technology and Economics Department of Telecommunications and Media Informatics

Ethernet based transport in provider networks

The Ethernet way

slide-9
SLIDE 9

BME-TMIT

Challenges

  • Carrier grade requirements
  • Scalability
  • Service Quality
  • Multicast
  • Management

– Fault – performance

Upgrade the cheap Ethernet (IEEE) Extend the proven MPLS (IETF) Provide Ethernet service

slide-10
SLIDE 10

BME-TMIT

Page 10

Multicast

  • Multicast possibilities
  • Ethernet multicast support

– Ethernet multicast addresses - mapping

  • Multicast support in switches

– IGMP support at BNG – IGMP snooping in bridges

  • A multicast manual constrain by VLANs

– VLANs for multicast trees – Traffic can not leave the tree – Basically broadcast within the VLAN, not the best solution

slide-11
SLIDE 11

BME-TMIT

Page 11

Multicast – IGMP snooping

  • The swich listens to IGMP join messages
  • For an IGMP join adds an entry to the forwarding

table

  • Assigns the multicast traffic to a port
  • An IGMP leave message removes the entry
  • Simple, but violates the OSI layering
  • L2 decision on L3 information
  • IGMPv3 – next upcoming standard
slide-12
SLIDE 12

BME-TMIT

Page 12

Multicast - DSLAM

  • Different levels of IGMP handling
  • Snooping
  • Proxy
  • Multicast router
  • DSLAM should support at least proxy
  • Decrease load on IGMP routers
  • faster
  • Multicast in home network
  • HGW should also support snooping
  • If not - broadcast
  • Fast leave
  • Immediately blocks traffic
slide-13
SLIDE 13

BME-TMIT

Carrier Ethernet: service types

  • E-Line service:
  • Ethernet Private Line
  • Virtual Private Line
  • Ethernet Internet Access
  • E-LAN Service:
  • Multipoint L2 VPN
  • Transzparent LAN
  • Needed for IPTV multicast etc

E-Line E-LAN

Point-to-Point EVC Carrier Ethernet Network UNI: User Network Interface, CE: Customer Equipment

CE UNI UNI CE

Multipoint-to-Multipoint EVC

Carrier Ethernet Network

CE UNI

MEF által hitelesített Carrier Ethernet termékek

CE UNI

slide-14
SLIDE 14

BME-TMIT

IEEE 802.1Q - VLAN

  • VLAN tag
  • QoS: priority
  • 12 bit VLAN ID: 4096 VLANs
  • Usage
  • User identification
  • Service identification
  • The 4096 limit is there– Too few for a provider!
  • The most wide spread UNI
  • Also we must be prepared to transfer VLAN tagged packets

MAC DA MAC SA 802.1Q ethertype VLAN tag

Data

CRC VLAN ID (12 bit) Pri (3 bits) CFI (1 bit)

slide-15
SLIDE 15

BME-TMIT

Provider Bridges (IEEE 802.1ad)

  • Also known as Q-in-Q
  • Widely used
  • 4K services (12-bits)
  • Unique service ID
  • (S-VID)
  • Forwarding is the same, L2 learning bridge with STP, filtering for the outer

VLAN (S-VID)

  • Scalability
  • 4K service
slide-16
SLIDE 16

BME-TMIT

Provider Backbone Bridges

  • 4K connected LAN
  • Unique per service ID
  • (LAN = I-SID)
  • Forwarding is the same, L2 learning bridge with STP, filtering for the
  • uter VLAN (B-VID)
  • Service management is simple
  • Scalability
  • Massive sservice

scalability (24-bit)

  • Only learn MAC of the Provider

bridges

  • Mapping of C-MAC to VIDs
slide-17
SLIDE 17

BME-TMIT

Comparison – headers added

slide-18
SLIDE 18

BME-TMIT

PB/PBB facts

  • Scalability solved

  • Cheap Ethernet switching remains

  • Still no support for Traffic Engineering

  • Protection/restoration based on STP

  • Management is more complex

  • Different layers of VLANs
  • No adequate management
  • Still not good in the core…
slide-19
SLIDE 19

BME-TMIT

PBT

  • Goal
  • Keep the Ethernet forwarding
  • Change the control plane (no STP and learning)
  • Set up paths ”manually“

= Traffic Engineering - Ethernet

  • What we get:
  • Point-point tunnel
  • Traffic Engineering
  • Protection

BVID=1 BVID=2 BVID=1 BVID=2

slide-20
SLIDE 20

BME-TMIT

PBT

  • Provider Backbone Transport – IEEE 802.1Qay
  • Nortel started
  • based on PBB
  • Uses the existing technologies
  • Deterministic QoS for service is the target
  • scalability
slide-21
SLIDE 21

BME-TMIT

PBT - operation

  • Data plane
  • Static forwarding tables
  • Addressing

– 60 bit MAC + VLAN based

  • Totally different control plane
  • Manual
  • MPLS based
slide-22
SLIDE 22

BME-TMIT

Ethernet Transport technology use

IP/MPLS mag Voice Data Video PB PBB PBT 802.1Q 802.1Q: 4K user PB: 4K service, Not too many MAC Added value: TE, OAM PBB: good scalability PB – Q-in-Q – IEEE 802.1ad PBB – Mac-in-Mac – IEEE 802.1ah PBT – PBB-TE – IEEE 802.1Qay

slide-23
SLIDE 23

Budapest University of Technology and Economics Department of Telecommunications and Media Informatics

Ethernet based transport in provider networks

The other way – IP/MPLS

slide-24
SLIDE 24

BME-TMIT

24 | Áramkör kapcsolt Ethernet? | Moldován István | Elsinco szeminárium | 12 Szeptember 2007

MPLS Pseudowire - WPWS

  • Ethernet p2p service
  • IETF pwe3 study group, the draft name Martini –encapsulation
  • MPLS label is encapsulated, multiple virtual connections within an UNI (VC)
  • Forwarding based on tunnel label
  • The solution inherits all MPLS solutions
  • Traffic Engineering, protection, OAM

CE CE PE PE

SP

CE CE PE PE

SP

slide-25
SLIDE 25

BME-TMIT

Ethernet Szolgáltatások 25 moldovan@tmit.bme.hu

Reserved Sequence Number EXP TTL 1 Label (VC) EXP TTL Label (Tunnel) 0 1 2 3 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 Layer2 PDU Control Word

VC Label L2 header Original Ethernet Frame Tunnel Label

Data Plane : EoMPLS packet

  • Tunnel label :
  • LSP label to get the packet from ingress PE to egress PE (IGP label or RSVP (TE) label)
  • VC Label :
  • demultiplexing label identifying an emulated VC
  • Identifies outgoing interface/vlan
  • Control Word : extra information regarding the VC
  • VC Label TTL = 2
slide-26
SLIDE 26

BME-TMIT

Ethernet Szolgáltatások 26 moldovan@tmit.bme.hu

Pseudo-Wire reference model

|<--- Emulated Service:FR/Ether/ATM/PPP/HDLC --->|

|<------ PW:Pseudowire VC ----->| |<-- FR -->| Ethernet ATM/PPP/HDLC |<--FR -->| Ethernet ATM/PPP/HDLC

ES  Emulated Services: FR/Ether/ATM/PPP/HDLC Attachment VC (AVC): FR DLCI/Ethernet VLAN/ATM PVC/PPP/HDLC PW  Pseudo-Wire: Emulated VC (EVC): MPLS LSP PSN  Packet Switched Network (Tunnel): MPLS LSP or RSVP-TE IP/MPLS Core

Attachment VC / L2 circuit Attachment VC / L2 circuit Attachment VC / L2 circuit

Site1A Site 2A

Attachment VC / L2 circuit

PE1

Site1B Site 2B

PE2

CE 1A CE 2A CE 1B CE 2B PSN Tunnel: (IP/)MPLS Tunnel MPLS (LDP or RSVP-TE)

slide-27
SLIDE 27

BME-TMIT

Ethernet Szolgáltatások 27 moldovan@tmit.bme.hu

MTU Calculations for EoMPLS:

Max Frame Size = Link Header + labels + Transported L2 Header + Payload Transported Ethernet Header: AToM removes (1) Preamble (2) SFD (3) FCS Ethernet II Encapsulation  18 Bytes Ethernet SNAP  26 Bytes Dot1q tag(s)  4 Bytes per tag Labels : usually 2 labels Example : Ethernet II + dot1q tag + 2 labels + Ethernet II + 2 dot1q tags (QinQ) + Payload 18B 4B 8B 18B 8B 1500B

Comment on VPWS: MTU

  • EoMPLS does not support fragmentation
  • MTU > layer2 VLAN frame
  • No e2e detection
  • MTU in core should be bigger
  • MTU values
  • a PE-CE should match
  • MTU set them correctly
slide-28
SLIDE 28

BME-TMIT

Ethernet Szolgáltatások 28 moldovan@tmit.bme.hu

VPLS

PE

Service Provider Backbone

PE PE VPLS

  • A

VPLS

  • B

VPLS

  • B

VPLS

  • A

Emulated LAN CE

  • 1

CE

  • 2’

CE

  • 2

CE

  • 1’

Bridged LAN

Customer Edges (CE): Client side device, tyically Ethernet Provider Edges (PE): VPLS inteligence, start/end Core: just forwarding

slide-29
SLIDE 29

BME-TMIT

Ethernet Szolgáltatások 29 moldovan@tmit.bme.hu

VPLS example

Full Mesh PEs are acting like a bridge towards the CE nodes

slide-30
SLIDE 30

BME-TMIT

Ethernet Szolgáltatások 30 moldovan@tmit.bme.hu

VPLS Operation

  • VPLS instance : Service–identifier (Svc-id)
  • Full mesh tunnels
  • Targeted LDP messages
  • Forwarding: learning bridge
  • Flooding
  • Split-horizon – never send to the receiving

interface

slide-31
SLIDE 31

BME-TMIT

Ethernet Szolgáltatások 31 moldovan@tmit.bme.hu

Number of PE in VLAN Number of LSPs Number of Retransmissions/ Broadcast 5 20 4 10 90 9 20 380 19 40 1 560 39

Why not VPLS End-to-End?

  • VPLS scalability
  • eg. 5 PE - 20 LSP, 40 PE: 1,536.
  • High bandwidth waste because of broadcasts
  • VPLS – new requirements
  • Protection, OAM, mapping
slide-32
SLIDE 32

BME-TMIT

Ethernet Szolgáltatások 32 moldovan@tmit.bme.hu

MPLS core

PE CE CE PE CE

MPLS core

PE CE CE PE CE

E.g ARP-request E.g ARP-reply

VPLS – Flooding & forwarding

  • Flooding

(Broadcast, Multicast, Unknown Unicast)

  • Dynamic learning
  • f MAC

addresses on PHY and VCs

  • Forwarding

– Physical Port – Virtual Circuit

slide-33
SLIDE 33

BME-TMIT

Ethernet Szolgáltatások 33 moldovan@tmit.bme.hu

VPLS scalability- hierarchical

  • MTU - Multi-Tenant Unit: owned by multiple

users, bridge

  • VPLS can be extended to the MTUs
  • MAC/VLAN scalability increased
  • More complex MTU
  • Hierarchical VPLS
  • „HUB” pseudowire (hub PW) between PEs
  • „spoke” PW between MTU-PE

– Spoke PW can be QiQ, MPLS, …

slide-34
SLIDE 34

BME-TMIT

Ethernet Szolgáltatások 34 moldovan@tmit.bme.hu

Hierarchical VPLS

slide-35
SLIDE 35

BME-TMIT

Ethernet Szolgáltatások 35 moldovan@tmit.bme.hu

H-VPLS

MPLS core MPLS edge Ethernet edge p2p or ring

H-VPLS

n-PE u-PE u-PE n-PE

MPLS core MPLS edge Ethernet edge

VPLS

n-PE CE CE n-PE

VPLS – Architectures

  • VPLS
  • One big hierarchy
  • MPLS to the Edge
  • H-VPLS
  • 2 level Hierarchy
  • MPLS or

Ethernet Edge

  • MPLS core
slide-36
SLIDE 36

BME-TMIT

Ethernet Szolgáltatások 36 moldovan@tmit.bme.hu

VPLS proposal Auto-discovery Signalling / label distribution Draft Kompella VPLS BGP BGP Draft Lasserre-Vkompella VPLS None (several options possible) LDP

VPN Discovery Signaling Centralized DNS, LDAP, Radius Directory Services Distributed BGP Label Distribution Protocol (LDP, BGP)

VPLS signaling and auto-discovery

  • VPLS requires full mesh of LSPs between PEs:
  • Manual procedures (static)
  • Provisioning systems(NMS/OSS)
  • Signalling protocols:

– LDP (“Lasserre-V. Kompella” draft) – BGP ( “Kompella” draft, Juniper) – other (Radius, DNS, stb.)

slide-37
SLIDE 37

BME-TMIT

Ethernet Szolgáltatások 37 moldovan@tmit.bme.hu

.1 .2 .5 .4 .3

VPLS related issues

  • Problems:
  • One big switch visible, but in fact

many VCs

  • What if one VC fails?
  • How to find the problem root

cause?

  • “Emulated” LAN model
  • All devices are equal peers:

– Routing protocol interaction – Traffic patterns – QoS policies – Security policies – Troubleshooting

slide-38
SLIDE 38

BME-TMIT

Ethernet Szolgáltatások 38 moldovan@tmit.bme.hu

Some unuseful properties

  • VPLS with more than 2 ports, RSTP is not an option
  • VPLS is a"fat yellow cable" – style shared media.
  • No tunneling for user BPDUs – no redundancy
  • VPLS and 802.1ad Provider Bridges are similar from this point of view
  • CE = Switch OR Router
  • Other things to take into consideration when using VPLS to connect

CE devices

slide-39
SLIDE 39

BME-TMIT

Ethernet Szolgáltatások 39 moldovan@tmit.bme.hu

*optionally including a DCN supporting management and control plane communications **802.1p (8 Class of Service) ***802.1p default = PQ

Ethernet UNI – many requirements

  • Ethernet UNI - Where user traffic enters the network
  • ITU-T G.8012/Y.1308
  • Carry informational elements of three planes :

– Data (or User) Plane* – Control Plane (e.g., related to BPDUs, ASON etc.) – Management Plane

  • "Standard IEEE 802.3 Ethernet PHY and MAC"
  • Functions of the Ethernet UNI include:

– Customer separation (Security) – Rate policing (Bandwidth, BW granularity) – Marking** (CoS transparency) – Queuing*** (PQ+CBWFQ) – Accounting (operational statistics) – other (e.g. filtering, OAM, L2CP, VLAN transparency, etc.)

  • Not provided at the UNI:

– Synchronization (CES)

slide-40
SLIDE 40

BME-TMIT

Ethernet Szolgáltatások 40 moldovan@tmit.bme.hu

WDM SDH RPR Ethernet Over MPLS Q-in-Q VPLS VPWS L2TPv3 L2VPN Customers do NOT care about technology! They are interested in the SERVICE!

Ethernet transport alternatives- Ethernet over anything

  • Ethernet over legacy networks
  • ATM: rfc2684-B
  • FR: rfc2427-B
  • PPP: rfc2878
  • Ethernet over Ethernet
  • QinQ, MACinMAC
  • Ethernet over SDH
  • GFP, VCAT, LCAS
  • Ethernet over IP/MPLS
  • L2TPv3
  • VPWS, VPLS
  • Ethernet over WDM
  • Ethernet over RPR
  • Which technology to use?
  • What Service to offer?
  • Depend:
  • SP strategy
  • Service definition
  • Existing

investments

slide-41
SLIDE 41

BME-TMIT

Conclusions

  • All are assuming Ethernet aggregation
  • All provide basic Ethernet level connectivity
  • All provide similar ways for service

identfication

  • S-VLANs
  • PPPoE still can be used
  • Support for Multicast
  • QoS handling is similar

– Or can be mapped (DSL line PVCs-> VLANs)

  • No specific requirements!

41

slide-42
SLIDE 42

Budapest University of Technology and Economics Department of Telecommunications and Media Informatics

Thank You for your attention
