ETERNITY GE ETERNITY GE The All-Integrated Communication Platform for Growing Enterprises ETERNITY GE ETERNITY GE12S ETERNITY GE6S Matrix ETERNITY GE The All-Integrated Communication Platform for Growing Enterprises Introduction

slide-1
SLIDE 1

ETERNITY GE ETERNITY GE

The All-Integrated Communication Platform for Growing Enterprises

slide-2
SLIDE 2

ETERNITY GE

ETERNITY GE12S ETERNITY GE6S

Matrix ETERNITY GE The All-Integrated Communication Platform for Growing Enterprises

slide-3
SLIDE 3

Introduction

  • Integrated Digital Voice Communication Switch
  • Field Proven and Time-Tested
  • Widely Deployed (Asia, Australia, Europe, Africa and North America)
slide-4
SLIDE 4

Key Aspects

  • Flexible and Scalable Communication Platform
  • Rich Feature and Functions
  • Intuitive User Interface
  • Flexible Call Management
  • Easy Installation and Setup
  • Comprehensive Monitoring and Management Reports
  • Universal Connectivity and Routing
  • All-In-One High Integration
  • A Perfect Blend of Innovation, Intelligence and Integration
slide-5
SLIDE 5

Certifications

Conformité Européene FEDERAL COMMUNICATIONS COMMSSION Restriction of Hazardous Substance

slide-6
SLIDE 6

Applications

  • IP-PBX for Enterprise
  • PBX-KTS Solution form SME
  • Hotel-Motel PBX Solution
  • GSM/3G PBX
  • GSM/3G-T1/E1 ISDN PRI Gateway
  • GSM/3G-VoIP Gateway
  • Applications like ACD, IVR, Voice logger, Dialer, etc. via Computer

Telephony Integration

slide-7
SLIDE 7

Why ETERNITY GE?

  • Feature-rich and Scalable up to 240 Users

at Single Site

  • Platform with Universal Connectivity

VoIP, GSM/3G, ISDN T1/E1 PRI, ISDN BRI, CO and E&M

  • Multi-Purpose Platform

IP-PBX, Hospitality PBX and Universal Gateway

  • CTI and Radio interface
  • Hybrid and High Density Expansion Cards
  • Built-in Web-Server Functionality
  • Most Compact Enterprise Platform
slide-8
SLIDE 8
  • Provide Flexibility to Meet every Business Needs

Unified Messaging Multi-Site Networking Mobile Extensions IP Telephony SIP Trunking Voice Mail

Why ETERNITY GE?

Mobile Extensions CTI Voice Mail SMS Gateway/SMS Server

slide-9
SLIDE 9

ETERNITY GE Family ETERNITY GE Family

slide-10
SLIDE 10

ETERNITY GE6S

  • 6 Universal Slots
  • 500 IP Users
  • 120 TDM Ports
  • Analog Input-Output Port (AIP/AOP)
  • Digital Input-Output Port (DIP/DOP
  • 2 RS232C Ports
  • Ethernet Port
  • 15 Participants Conference
  • 16 Voice Modules (16 Seconds Each)
  • Mains or DC Power Supply
slide-11
SLIDE 11

ETERNITY GE12S

  • 12 Universal Slots
  • 500 IP Users
  • 240 TDM Ports
  • Analog Input-Output Port (AIP/AOP)
  • Digital Input-Output Port (DIP/DOP
  • 2 RS232C Ports
  • Ethernet Port
  • 15 Participants Conference
  • 16 Voice Modules (16 Seconds Each)
  • Mains or DC Power Supply
slide-12
SLIDE 12

ETERNITY GE – System Resources

SYSTEM RESOURCES (MAXIMUM CAPACITY) ETERNITY GE 6S 12S

Analog Extensions 120 240 DKP Ports 48 48 CO Ports 96 128 BRI Ports 24 32 BRI Ports 24 32 T1/E1 ISDN PRI Ports 6 8 GSM/3G SIMs 24 40 IP Extensions 500 500 VoIP Trunk 16 16 VoIP Calls 192 384 E&M Ports 24 48 Voice Mail System 16 Ports 16 Ports

slide-13
SLIDE 13
  • Interchangeable Cards (ETERNITY GE Models)
  • Easy Expansion of the system
  • Passive Back-Plane
  • Sturdy Assembly (Fully Loaded Transportation)
  • Common Software for ETERNITY GE/ME/PE Applications

Platform Highlights

  • Interchangeable User Terminals (ETERNITY GE/ME/PE)
slide-14
SLIDE 14

Network Interfaces Network Interfaces

slide-15
SLIDE 15
  • CO Lines (TWT)
  • ISDN BRI (2B+D) (TE Mode)
  • ISDN T1/E1/PRI/QSIG (23B+D or 30B+D )
  • GSM/3G (SIM)
  • VoIP (SIP)

Interfaces: Trunk Side

  • VoIP (SIP)
  • E&M
  • Radio
slide-16
SLIDE 16
  • Analog Extensions (FXS)
  • Digital Key Phones (DKP)
  • IP Extensions (IP Phones, Softphones, Mobile SIP Client)
  • Voice Mail System (VMS)
  • ISDN SØ – ISDN BRI S/T (NT Mode)

Interfaces: User Side

  • QSIG
slide-17
SLIDE 17

System Cards System Cards

slide-18
SLIDE 18

Critical Cards – ETERNITY GE

90-265 VAC, 47-63 Hz

Power Supply – Universal Input

48VDC Power Supply

Power Supply - DC

slide-19
SLIDE 19

Critical Cards – ETERNITY GE

COM Port, USB Port and Ethernet Port 32-Bit RISC Processor 1024x1024 High Density Switching Matrix DSP based Conferencing Built-in DIP, DOP, AIP and AOP Built-in DIP, DOP, AIP and AOP

CPU Card

slide-20
SLIDE 20

Trunk Expansion Cards – ETERNITY GE

16 CO Ports Card to Connect 16 CO Lines 8 CO Ports Card to Connect 8 CO Lines

CO16 CO8 CO Lines Card (Two Wire Trunk – TWT)

slide-21
SLIDE 21

4 BRI Ports Card to Connect 4 ISDN BRI Lines

  • r ISDN Compatible Devices

Trunk Expansion Cards – ETERNITY GE

ISDN BRI Card (BRI4) ISDN T1/E1/PRI Card (PRI SINGLE)

T1E1PRI SINGLE : Single Port T1/E1/PRI Card to Connect 1 T1/E1/PRI line or T1/E1/PRI Compatible Device NT and TE Modes

slide-22
SLIDE 22

Extension Expansion Cards – ETERNITY GE

SLT20 SLT8

20 Ports SLT Card to Connect 20 Single Line Telephones 8 Ports SLT Card to Connect 8 Single Line Telephones RJ45 MDF, CLIP (DTMF/FSK), Polarity Reversal, Programmable Speech Gains,

SLT16

Reversal, Programmable Speech Gains, Programmable Ring Cadence and Secondary Protection

Single Line Telephone (SLT) Card

slide-23
SLIDE 23

DKP8

Extension Expansion Cards – ETERNITY GE

16 DKP Ports Card to Connect 16 Digital Key Phones / DSS Consoles 8 DKP Ports Card to Connect 8 Digital Key Phones / DSS Consoles 2-Wire Digital Interface RJ45 MDF

DKP16

RJ45 MDF

Digital Key Phone (DKP) Card

slide-24
SLIDE 24

Expansion Cards – ETERNITY GE

GSM4

4 Port GSM Card to Insert 4 GSM SIM Cards for GSM Network Connectivity Quad-Band (850/900/1800/1900 MHz) Tri-Band(3G): WCDMA 850/1900/2100 MHz Antenna Combiner (1 Antenna for 4 Ports)

GSM4-3G

Antenna Combiner (1 Antenna for 4 Ports)

GSM Card

slide-25
SLIDE 25

Expansion Card having Server and Trunks Personalities for 16/32 Concurrent Calls Register with any 3rd Party SIP Registrar Proxy or IP PBX Codecs: G.711A/µ, G.729A/B, G.723,

Expansion Cards – ETERNITY GE

VoIP16

Codecs: G.711A/µ, G.729A/B, G.723, GSM-FR, iLBC

VoIP32 VoIP Card

slide-26
SLIDE 26

16 Channel Voice Mail System with 512 Mail Boxes Integrated Auto-Attendant E-Mail Notification

Expansion Cards – ETERNITY GE

VMS16 Voice Mail Card Voice Mail Card

slide-27
SLIDE 27

Expansion Cards – ETERNITY GE

CO4SLT16 DKP4SLT16 CO4DKP2SLT12 CO2DKP2SLT16 Mixed Cards Mixed Cards

4 Port E&M Card to Connect to 4 E&M Lines Type IV and Type V Speech Interface : 2-Wire and 4-Wire

E&M4 E&M Card

slide-28
SLIDE 28

Connectivity Connectivity

slide-29
SLIDE 29

ETERNITY GE - Universal Connectivity

slide-30
SLIDE 30

User Terminals User Terminals

slide-31
SLIDE 31

User Terminals

Analog Phones Digital Key Phones IP Phones Android/iPhones Mobility Clients PC Soft phones IP-DECT

slide-32
SLIDE 32

IP Phones

SPARSH VP248S

  • 3 SIP Accounts
  • Multiple-Programmable Keys
  • 2 Line Display
  • Auto Configuration
  • SPARSH

VP248SE

  • Multiple Call Handling
  • Peer-to-Peer Calling
  • Power over Ethernet (PoE)
  • Phone Book
  • Voice Mail Key
slide-33
SLIDE 33
  • 132 x 64 Pixel Graphical Display
  • Context Sensitive and Fixed Function Key
  • Full Duplex Speakerphone with AEC, VAD, CNG
  • TLS/SRTP for Voice Security
  • IP Phones
  • Integrated PoE (802.3af)
  • Auto Provision, TR069
  • IPv6 Ready, PC and LAN Ports
  • Power Supply Included in the Box
  • Stores up to 1000 entries
  • Wall Mount, Table-top

SPARSH VP110

slide-34
SLIDE 34

Digital Key Phone

  • 6 Line, 2 Line Display
  • Programmable Feature Keys
  • Touch-Sense Feature Keys
  • Full Duplex Speaker Phone
  • Headset Connectivity
  • Flexible Desktop Mounting

EON48P EON48S

slide-35
SLIDE 35

Direct Station Selection – DSS16X4

  • Companion DSS for EON48
  • 64 Keys for Direct Station Selection
  • DSS16X4 Use One DKP Port
  • Dual Color LEDs for Port Status
slide-36
SLIDE 36

SPARSH M2S Softphone Client for Android/iPhone

  • Comprehensive Call Management
  • One-Touch Access to PBX Features
  • Corporate Directory Integration
  • Video Calling
  • Presence Sharing and Instant Messaging
  • Voice Mail Access
  • Voice Mail Access
  • Conversation Recording
slide-37
SLIDE 37

IP-PBX Universal Connectivity Convenience Built-in functions Productivity

  • Dynamic DNS

(DDNS)

  • SIP trunks and

IP users

  • NAT and

STUN

  • Call forking
  • VoIP,

GSM/3G, ISDN BRI PRI, CO

  • Analog,

digital, IP and mobile users

  • Alarms,

Background music, Voice guidance for tones

  • Return call to
  • riginal caller
  • Auto-

attendant

  • Call detail

records

  • CLI (DTMF &

FSK)

  • LCR
  • Auto answer
  • CLI based

routing

  • Conference

dial-in

  • Memory

dialing

Key Features

  • Call forking
  • Mobile

extension mobile users

  • riginal caller
  • DID and DDI
  • Hot desking ,

Hotline

  • SMS Gateway
  • Email to SMS
  • LCR
  • Logical

Partitioning

  • Multi-party

conference dialing

  • Department

call

  • Multi-stage

dialing

slide-38
SLIDE 38

Flexibility & Scalability Versatility Integration Monitoring Cost Reduction

  • Configuration
  • ptions
  • Universal

slots

  • Localization
  • Hybrid cards
  • IP-PBX
  • PBX-KTS
  • Universal

gateway

  • Hotel PBX
  • Video

conferencing

  • AIP-AOP
  • GSM/3G
  • Voice mail

system

  • Computer

Telephony Integration

  • Conversation

recording

  • Room

monitoring

  • Call

budgeting on trunks and extensions

  • Call duration

control

  • Common

Cont..

conferencing (ISDN BRI) Integration

  • Common

platform

  • Toll control
  • VoIP
slide-39
SLIDE 39

Technical Specifications Technical Specifications

slide-40
SLIDE 40

Technical Specifications

SPECIFICATIONS ETERNITY GE 6S 12S

Power Supply (Input) Option 1 (Mains): 100-240VAC, 47-63 Hz Option 2 (DC): 48 VDC +/- 20% Power Consumption (Typical) 30W 50W Power Consumption (Typical) 30W 50W Dimensions (WXHXD) 26x16x25.4cm (10.24”x6.29”x10”) 41.2x16x25.4cm (16.22”x6.29”x10”) Unit Weight 3.5kg (7.7lbs) 6.5kg (14.3lbs) Installation Wall Mount, Table Top Wall Mount, Table Top, 19” Rack

slide-41
SLIDE 41

For Further Information Please contact:

#113-A, Periyar Pathai West, Arumbakkam, Chennai-600106. Phone: +91-44-236 235 04/05 Mobile: +91-89 39 670 670 Email: nutech@nutech.co.in Website: www.nutechsolution.com
