ETERNITY ME ETERNITY ME

The Complete Communication System for Medium Enterprises

ETERNITY ME

ETERNITY ME16S

Matrix ETERNITY ME The Complete Communication System for Medium Enterprises

Introduction

• Integrated Digital Voice Communication Switch
• Field Proven and Time-Tested
• Widely Deployed (Asia, Australia, Europe, Africa and North America)

Key Aspects

• Flexible, Scalable and Reliable Communication Platform
• Rich Feature and Functions
• Intuitive User Interface
• Flexible Call Management
• Easy Installation and Setup
• Comprehensive Monitoring and Management Reports
• Universal Connectivity and Routing
• All-In-One High Integration
• A Perfect Blend of Innovation, Intelligence and Integration

Certifications

Conformité Européene FEDERAL COMMUNICATIONS COMMSSION Restriction of Hazardous Substance

Applications

• IP-PBX for Enterprise
• PBX-KTS Solution form SME
• Hotel-Motel PBX Solution
• GSM PBX
• GSM-T1/E1 ISDN PRI Gateway
• GSM-VoIP Gateway
• Applications like ACD, IVR, Voice logger, Dialer, etc. via Computer

Telephony Integration

• Scalability: Up to 512 User Ports
• Flexibility: All-integrated Platform
• Future Proof Investment: Can Grow with Business
• Telephony Cost Reduction

Universal Network Connectivity with Built-in Least Cost Router

Why ETERNITY ME?

Universal Network Connectivity with Built-in Least Cost Router

• Round the Clock Connectivity: Multiple Network Interfaces

VoIP, GSM, ISDN T1/E1 PRI, ISDN BRI, CO and E&M

• Enhance Staff Productivity and Customer Responsiveness: Intelligent

Features and Functionalities, CTI interface, Radio interface

• Reduced Downtime: Hot-standby, Hot swappable

(DC Power Supply and CPU)

• Provide Flexibility to Meet every Business Needs

Unified Messaging IP Telephony

Why ETERNITY ME?

Multi-Site Networking Mobile Extensions CTI SIP Trunking Voice Mail SMS Gateway/SMS Server

ETERNITY ME Family ETERNITY ME Family

ETERNITY ME16S

• 16 Universal Hot-Swappable Slots
• 999 IP Users
• 512 TDM Ports
• Analog Input-Output Port (AIP/AOP)
• Digital Input-Output Port (DIP/DOP)
• 2 RS232C Ports
• Parallel Printer Port
• Ethernet Port
• 21 Participants Conference
• 16 Voice Modules (16 Seconds Each)
• Mains or DC Power Supply
• Hot Stand-by (DC Power Supply and Critical Cards)

ETERNITY ME – System Resources

SYSTEM RESOURCES (MAXIMUM CAPACITY) ETERNITY ME 16S

Analog Extensions 320 or 512* DKP Ports 64 or 128* CO Ports 128 BRI Ports 32 T1/E1 ISDN PRI Ports 8 IP Extensions 999 VoIP (SIP) Trunks 32 VoIP Calls 512 GSM SIMs 24 or 64* E&M Ports 128 Magneto Phones 128 Voice Mail System 16 Ports * With PS48VDC – 500W

• Interchangeable Cards (ETERNITY ME and ETERNITY LE Models)
• Easy Expansion of the system
• Passive Back-Plane
• Sturdy Assembly (Fully Loaded Transportation)
• Common Software for ETERNITY PE/GE/ME Applications

Platform Highlights

• Common Software for ETERNITY PE/GE/ME Applications
• Interchangeable User Terminals (ETERNITY PE/GE/ME )
• Optional Redundancy DC Power Supply and Control Cards
• Hot-Swappable Expansion Cards
• Multiple Mounting Options

Network Interfaces Network Interfaces

• CO Lines (TWT)
• ISDN BRI (2B+D) (TE Mode)
• ISDN T1/E1/PRI/QSIG (23B+D or 30B+D )
• GSM (SIM)
• VoIP (SIP)

Interfaces: Trunk Side

• VoIP (SIP)
• E&M
• Radio

• Analog Extensions (FXS)
• Digital Key Phones (DKP)
• IP Extensions (IP Phones, Softphones, Mobile SIP Client)
• MAGNETO Subscriber
• Voice Mail System (VMS)

Interfaces: User Side

• ISDN SØ – ISDN BRI S/T (NT Mode)
• QSIG

System Cards System Cards

Critical Cards – ETERNITY ME

CPU Card

Control and Handle Events of all Interface Cards Hot Swappable

Power Supply – Universal Input Power Supply - DC

90-265 VAC, 47-63 Hz 48VDC Power Supply Hot Swappable

8 CO Ports Card to connect 8 CO Lines 16 CO Ports Card to connect 16 CO Lines RJ45 MDF and Hot-Swappable

Trunk Expansion Cards – ETERNITY ME

CO8 CO Lines Card (Two Wire Trunk – TWT) CO16 CO Lines Card (Two Wire Trunk – TWT)

4/8 BRI Ports Card to connect 4/8 ISDN BRI Lines or connect ISDN Compatible Devices NT and TE Modes Hot-Swappable

Trunk Expansion Cards – ETERNITY ME

ISDN BRI Card (BRI4)

Single Port T1/E1/PRI Card to Connect T1/E1/PRI line or Compatible Device Dual Port T1/E1/PRI Card to Connect 2 T1/E1/PRI line or Compatible Devices Q.SIG Support, NT and TE Modes, Hot- Swappable

ISDN T1/E1/PRI Card PRI SINGLE ISDN T1/E1/PRI Card PRI DUAL

8 Port GSM Card to insert 8 GSM SIM Cards Quad band (850/900/1800/1900 MHz) Antenna Combiner (1 Antenna for 4

GSM8

Trunk Expansion Cards – ETERNITY ME

GSM Cards

Antenna Combiner (1 Antenna for 4 Ports) Hot-Swappable

Expansion Card having Server and Trunk Personalities for 16/32 Concurrent Calls Register with any 3rd Party SIP Registrar Proxy or IP PBX

Trunk Expansion Cards – ETERNITY ME

VoIP16

Registrar Proxy or IP PBX Hot-Swappable

VoIP32 VoIP Card

Trunk Expansion Cards – ETERNITY ME

To Connect 8 CO Lines and 24 SLTs RJ45 MDF and Hot-Swappable

CO8SLT24 Combo Card (Mixed Card)

8/16/32 SLT Ports Card to connect 8/16/32 Single Line Telephones (Analog Phones) RJ45 MDF, Hot-Swappable, CLIP (DTMF/FSK), Polarity Reversal,

SLT8

Extensions Expansion Cards – ETERNITY ME

SLT32

(DTMF/FSK), Polarity Reversal, Programmable Speech Gains, Programmable Ring Cadence and Secondary Protection

SLT16 SLT32 Single Line Telephone (SLT) Card

8/16/32 DKP Ports Card to connect 8/16/32 Digital Key Phones 2-Wire Digital Interface RJ45 MDF and Hot-Swappable

DKP8

Extensions Expansion Cards – ETERNITY ME

DKP32 DKP16 Digital Key Phone (DKP) Card

16 Channel Voice Mail System with 512 Mail Boxes Integrated Auto-Attendant E-Mail Notification Hot-Swappable

Expansion Cards – ETERNITY ME

VMS16

Hot-Swappable

Voice Mail Card

8 Port Magneto Card to Connect 8 Magneto Subscribers Hot-Swappable

Expansion Cards – ETERNITY ME

MAGNETO8 MAGNETO Card

8 Port E&M Card to connect to 8 E&M Lines 4 Port E&M Card to connect to 4 E&M Lines Type IV and Type V

Expansion Cards – ETERNITY ME

E&M4

Type IV and Type V Speech Interface : 2-Wire and 4-Wire Hot-Swappable

E&M8 E&M Card

Connectivity Connectivity

ETERNITY ME - Universal Connectivity

User Terminals User Terminals

User Terminals

Analog Phones Digital Key Phones IP Phones Android/iPhones Mobility Clients PC Soft phones IP-DECT

IP Phones

SPARSH VP248S

• 3 SIP Accounts
• Multiple-Programmable Keys
• 2 Line Display
• Auto Configuration
• SPARSH

VP248SE

• Multiple Call Handling
• Peer-to-Peer Calling
• Power over Ethernet (PoE)
• Phone Book
• Voice Mail Key

• 132 x 64 Pixel Graphical Display
• Context Sensitive and Fixed Function Key
• Full Duplex Speakerphone with AEC, VAD, CNG
• TLS/SRTP for Voice Security
• IP Phones
• Integrated PoE (802.3af)
• Auto Provision, TR069
• IPv6 Ready, PC and LAN Ports
• Power Supply Included in the Box
• Stores up to 1000 entries
• Wall Mount, Table-top

SPARSH VP110

Digital Key Phone

• 6 Line, 2 Line Display
• Programmable Feature Keys
• Touch-Sense Feature Keys
• Full Duplex Speaker Phone
• Headset Connectivity
• Flexible Desktop Mounting

EON48P EON48S

Direct Station Selection – DSS16X4

• Companion DSS for EON48
• 64 Keys for Direct Station Selection
• DSS16X4 Use One DKP Port
• Dual Color LEDs for Port Status

SPARSH M2S Softphone Client for Android/iPhone

• Comprehensive Call Management
• One-Touch Access to PBX Features
• Corporate Directory Integration
• Video Calling
• Presence Sharing and Instant Messaging
• Voice Mail Access
• Voice Mail Access
• Conversation Recording

IP-PBX Universal Connectivity Convenience Built-in functions Productivity

• Dynamic DNS

(DDNS)

• SIP trunks and

IP users

• NAT and

STUN

• Call forking
• VoIP,

GSM/3G, ISDN BRI PRI, CO

• Analog,

digital, IP and mobile users

• Alarms,

Background music, Voice guidance for tones

• Return call to
• riginal caller
• Auto-

attendant

• Call detail

records

• CLI (DTMF &

FSK)

• LCR
• Auto answer
• CLI based

routing

• Conference

dial-in

• Memory

dialing

Key Features

• Call forking
• Mobile

extension mobile users

• riginal caller
• DID and DDI
• Hot desking ,

Hotline

• SMS Gateway
• Email to SMS
• LCR
• Logical

Partitioning

• Multi-party

conference dialing

• Department

call

• Multi-stage

dialing

Flexibility & Scalability Versatility Integration Monitoring Cost Reduction

• Configuration
• ptions
• Universal

slots

• Localization
• Hybrid cards
• IP-PBX
• PBX-KTS
• Universal

gateway

• Hotel PBX
• Video

conferencing

• AIP-AOP
• GSM
• Voice mail

system

• Computer

Telephony Integration

• Conversation

recording

• Room

monitoring

• Call

budgeting on trunks and extensions

• Call duration

control

• Common

Cont..

conferencing (ISDN BRI) Integration

• Common

platform

• Toll control
• VoIP

Technical Specifications Technical Specifications

SPECIFICATIONS ETERNITY ME 16S

Power Supply (Input) Option 1 (Mains): 100-240VAC, 47-63 Hz Option 2 (DC): 48 VDC +/- 20% Power Consumption (Typical) 100W

Technical Specifications

(Typical) 100W Dimensions (WXHXD) 52.3x33.0x39.9cm (20.5”x12.9”x15.55”) Unit Weight 10.5kg (23.1lbs) Installation Wall Mount, Table Top
