SLIDE 1

Equipment Configuration

SLIDE 2

Objective

At the end of the module you will be able to

prepare ISAM for the services in terms of equipment configuration
LTs
NT-B and NT-I/O cards
NT-B and NT-I/O cards
Remote Modules like REM, SEM…

SLIDE 3

Prepare the system for accepting HiCAP boards configure system max-lt-link-speed link-speed twodotfive-gb

r

ten-gb [save IHUB database - requires a reboot] configure system

3

configure system security profile admin slot-numbering type-based

TL1-style of numbering

logout and login again to actually apply this change

SLIDE 4

Equipment configuration

the system detects presence of equipment at startup and auto-configures a number of items

auto configuring of ISAM (no description) , rack, shelf and NT

equipment configuration

unit configuration
system, rack, shelf
board configuration

Equipment configuration

4

board configuration
LT’s, appliques

as long as equipment is not planned, it is impossible to configure/offer services

SLIDE 5

Configuration of extended LT slots

Network

Select subrack

5

CLI

configure equipment shelf <rack/shelf> extended-lt-slots

SLIDE 6

Configuration of boards on FD LT LT LT LT LT LT LT LT LT LT LT LT LT LT LT LT NTA NTB/LT NTIO/LT

FD physical slot numbers

NT-slot - slots 9 &11
NT I/O - applique 1
16 LT-slots
slots 1 8
slots 12 19

12 13

6

PWR

Dust filter

Fan unit

fiber conduct

slots 12 19

LT slot number + 3

slot 4 slot 1 slot 2 slot 12 slot 13

For LT-4: configure slot 1/1/4 (= rack 1/shelf 1/slot 4) For LT-10: configure slot 1/1/13 (= rack 1/shelf 1/slot 13)

SLIDE 7

Configuration of LT and applique boards

Network

Select subrack/slot Actions

AMS suggests detected board

7

LT

configure equipment slot <rack/shelf/slot>

[no] planned-type <Board Type>

applique

configure equipment applique <rack/shelf/slot>

[no] planned-type <Board Type>

Plan

SLIDE 8

Other equipment related commands

unconfigure equipment

[no] planned-type

lock or unlock equipment

[no] unlock

Network

select subrack/slot Reset

Lock
Unlock

Unplan Actions

8

power down equipment

[ no] power-down
Unlock

to power down the board use the object details view

SLIDE 9

Subrack view icons

no icon plugged type = planned type not planned equipment missing

perational state: disabled

9

board mismatch

perational state: enabled

SLIDE 10

Retrieval of equipment information

view the status

show equipment
isam (detail)
rack (detail)
shelf (detail)
slot/applique (detail)

Network

select object:

rack
subrack

10

slot/applique (detail)
e.g. show equipment slot/applique 1/1/5

verify the configuration

info configure equipment ...
configure>equipment> ... > info detail
slot
bject details view

SLIDE 11

Configuring the expansion units on a 7330 FTTN ISAM

create the expansion module:

configure equipment shelf <rack/shelf>

planned-type <Shelf Type> class ext-ethernet

configure equipment slot ctrl:<rack/shelf>

planned-type <nrcd-a or nrca-a>

plan the board:

Network

select subrack

bject details view:

edit planned type

11

plan the board:

configure equipment slot <rack/shelf/slot> planned-type

planned-type:

nfxr-a : 7356 FD REM
nfxr-b : 7357 SEM

edit planned type

SLIDE 12

Configurable use of NTIO ports

n a 7330 some NTIO ports are configurable
amount of configurable ports depends on HW type & NTIO card

(see next slides)

Up Link:

Up Link: network, user or subtending port

Down Link:

Down Link: towards an expansion module

CLI:

configure equipment external-link-host <SFP nr.>

Network

infrastructure transmission

12

configure equipment external-link-host <SFP nr.>

direction remote-lt

r

direction network

system reset needed after reconfiguring SFPs

configure association between host shelf SFP and remote unit (REM/SEM):

configure equipment external-link-assign <SFP nr> remote

SFP

SLIDE 13

Rack and shelf assignment

7 racks, 4 shelves per rack 12 remote shelves configurable SHUB SFP view

13

configure uplink/downlink configure which board is connected in case of downlink: NTA / LT1 / LT2

SLIDE 14

www.alcatel-lucent.com

14

www.alcatel-lucent.com

SLIDE 15

ppendix : NANT-A port numbers for NTIO

A

15

A

SLIDE 16

7330 FD NTIO use from ISAM R3.4 onwards

SFP-2 SFP-3 SFP-5 SFP-4 SFP-6 SFP-7

NT

SFP-0 SFP-1

up up

NCNC-B/D (6 SFP’s)

2 3 4 5 6 7 1 LANX (Logical Ports) 24 23 20 19 18 17 16 15 14 13

NANT-A (2 SFP’s)

up/down up/down up/down up/down up/down up/down

16

From ISAM R3.4 all ports on the NTIO type B & D are configurable in a 7330

Expansion link (downlink)
Ethernet link (uplink)

LT 1 - 8

13 12 11 10 9 22 21 1 – 8

(down)

unused 21 22

SLIDE 17

7330 FD NTIO use from ISAM R3.4 onwards

SFP-2 SFP-3 SFP-5 SFP-4 SFP-6 SFP-7 SFP-8 SFP-10 SFP-9

NT

SFP-0 SFP-1

up up

NCNC-E (14 SFP’s)

2 3 4 5 6 7 8 9 10 1 LANX (Logical Ports) 24 23 20 19 18 17 16 15 14 13 12

NANT-A (2 SFP’s)

up/down up/down up/down up/down down down down up/down up/down

17

LT 1 - 8

SFP-10 SFP-11 SFP-12 SFP-14 SFP-13 SFP-15

10 11 12 13 14 15 12 11 10 9 22 21 1 – 8

(down) up up down down down down

From ISAM R3.4, 6 ports on the NTIO type C & E are configurable

Expansion link (downlink)
Ethernet link (uplink)

21 22

SLIDE 18

7330 FD NTIO use from ISAM R3.4 onwards

SFP-2 SFP-3 SFP-5 SFP-4 SFP-6 SFP-7 SFP-8 SFP-9

NT

SFP-0 SFP-1

up up

NCNC-C (12 SFP’s)

2 3 4 5 6 7 8 9 10 1 LANX (Logical Ports) 24 23 20 19 18 17 16 15 14 13 12

NANT-A (2 SFP’s)

up/down up/down up/down up/down down down up/down up/down

18

LT 1 - 8

SFP-10 SFP-11 SFP-12 SFP-13

10 11 12 13 12 11 10 9 22 21 1 – 8

(down) down down down down

unused

From ISAM R3.4, 6 ports on the NTIO type C & E are configurable

Expansion link (downlink)
Ethernet link (uplink)

21 22
