EO-253 Operating Systems Instructor: Vinod Ganapathy IISc Slide - PowerPoint PPT Presentation

EO-253 – Operating Systems Instructor: Vinod Ganapathy IISc Slide credits: David Mazieres (Stanford University) 1 / 33

Outline Administrivia 1 2 Substance 2 / 33

Administrivia • Class web page: http://www.csa.iisc.ac.in/~vg/teaching/E0-253 - All assignments, handouts, lecture notes on-line • Textbook: Operating Systems: Three Easy Pieces, Remzi and Andrea Arpaci-Dusseau • Goal is to make lecture slides the primary reference - Almost everything I talk about will be on slides - PDF slides contain links to further reading about topics - Please download slides from class web page 3 / 33

Course topics • Threads & Processes • Concurrency & Synchronization • Scheduling • Virtual Memory • I/O • Disks, File systems • Protection & Security • Virtual machines • Note: Lectures will ofen take Unix as an example - Most current and future OSes heavily influenced by Unix - Won’t talk much about Windows 4 / 33

Course goals • Introduce you to operating system concepts - Hard to use a computer without interacting with OS - Understanding the OS makes you a more effective programmer • Cover important systems concepts in general - Caching, concurrency, memory management, I/O, protection • Teach you to deal with larger sofware systems - Programming assignments much larger than many courses - Warning: Many people will consider course very hard - Expect to spend about ≥ 15 hours/week 5 / 33

Programming Assignments • Implement parts of Pintos operating system - Built for x86 hardware, you will use hardware emulator • Four implementation projects: - Threads - User processes - Virtual memory - File system • Implement projects individually 6 / 33

Grading • Labs: 40% - For each lab, 50% of score based on passing test cases - Remaining 50% based on design and style • Most people’s labs pass most test cases - Please, please, please turn in working code, or no credit here • Means design and style matter a lot - Large sofware systems not just about producing working code - Need to produce code other people can understand • Mid-term Exam: 30% • Final Exam: 30% 7 / 33

Style • Must turn in a design document along with code - We supply you with templates for each project’s design doc • We will manually inspect code for correctness - E.g., must actually implement the design - Must handle corner cases (e.g., handle malloc failure) • Will deduct points for error-prone code w/o errors - Don’t use global variables if automatic ones suffice - Don’t use deceptive names for variables • Code must be easy to read - Indent code, keep lines and (when possible) functions short - Use a uniform coding style (try to match existing code) - Put comments on structure members, globals, functions - Don’t leave in reams of commented-out garbage code 8 / 33

Assignment requirements • Do not look at other people’s solutions to projects - We reserve the right to run MOSS on present and past submissions - Do not publish your own solutions on the Web - That means using (public) github can get you in big trouble - Do not copy homework solutions from sources on the Web (e.g., Stackoverflow) • You may read but not copy other OSes - E.g., Linux, OpenBSD/FreeBSD, etc. • Cite any code that inspired your code - As long as you cite what you used, it’s not cheating - In worst case, we deduct points if it undermines the assignment 9 / 33

Outline Administrivia 1 2 Substance 10 / 33

What is an operating system? • Layer between applications and hardware emacs gcc firefox OS Hardware • Makes hardware useful to the programmer • [Usually] Provides abstractions for applications - Manages and hides details of hardware - Accesses hardware through low/level interfaces unavailable to applications • [Ofen] Provides protection - Prevents one process/user from clobbering another 11 / 33

Why study operating systems? • Operating systems are a mature field - Most people use a handful of mature OSes - Hard to get people to switch operating systems - Hard to have impact with a new OS • High-performance servers are an OS issue - Face many of the same issues as OSes • Resource consumption is an OS issue - Battery life, radio spectrum, etc. • Security is an OS issue - Hard to achieve security without a solid foundation • New “smart” devices need new OSes • Web browsers increasingly face OS issues 12 / 33

Primitive Operating Systems • Just a library of standard services [no protection] App OS Hardware - Standard interface above hardware-specific drivers, etc. • Simplifying assumptions - System runs one program at a time - No bad users or programs (ofen bad assumption) • Problem: Poor utilization - ...of hardware (e.g., CPU idle while waiting for disk) - ...of human user (must wait for each program to finish) 13 / 33

Multitasking emacs firefox OS Hardware • Idea: More than one process can be running at once - When one process blocks (waiting for disk, network, user input, etc.) run another process • Problem: What can ill-behaved process do? 14 / 33

Multitasking emacs firefox OS Hardware • Idea: More than one process can be running at once - When one process blocks (waiting for disk, network, user input, etc.) run another process • Problem: What can ill-behaved process do? - Go into infinite loop and never relinquish CPU - Scribble over other processes’ memory to make them fail • OS provides mechanisms to address these problems - Preemption – take CPU away from looping process - Memory protection – protect process’s memory from one another 14 / 33

Multi-user OSes emacs firefox OS Hardware • Many OSes use protection to serve distrustful users/apps • Idea: With N users, system not N times slower - Users’ demands for CPU, memory, etc. are bursty - Win by giving resources to users who actually need them • What can go wrong? 15 / 33

Multi-user OSes emacs firefox OS Hardware • Many OSes use protection to serve distrustful users/apps • Idea: With N users, system not N times slower - Users’ demands for CPU, memory, etc. are bursty - Win by giving resources to users who actually need them • What can go wrong? - Users are gluttons, use too much CPU, etc. (need policies) - Total memory usage greater than in machine (must virtualize) - Super-linear slowdown with increasing demand (thrashing) 15 / 33

Protection • Mechanisms that isolate bad programs and people • Pre-emption: - Give application a resource, take it away if needed elsewhere • Interposition/mediation: - Place OS between application and “stuff” - Track all pieces that application allowed to use (e.g., in table) - On every access, look in table to check that access legal • Privileged & unprivileged modes in CPUs: - Applications unprivileged (unprivileged user mode) - OS privileged (privileged supervisor/ kernel mode) - Protection operations can only be done in privileged mode 16 / 33

Typical OS structure P1 P2 P3 P4 user kernel VM file schedulerIPC system sockets TCP/IP device device device driver driver driver network console disk • Most sofware runs as user-level processes (P[1-4]) • OS kernel runs in privileged mode (shaded) - Creates/deletes processes - Provides access to hardware 17 / 33

System calls • Applications can invoke kernel through system calls - Special instruction transfers control to kernel - ...which dispatches to one of few hundred syscall handlers 18 / 33

System calls (continued) • Goal: Do things application can’t do in unprivileged mode - Like a library call, but into more privileged kernel code • Kernel supplies well-defined system call interface - Applications set up syscall arguments and trap to kernel - Kernel performs operation and returns result • Higher-level functions built on syscall interface - printf, scanf, fgets, etc. all user-level code • Example: POSIX/UNIX interface - open, close, read, write, ... 19 / 33

System call example • Standard library implemented in terms of syscalls - printf – in libc, has same privileges as application - calls write – in kernel, which can send bits out serial port 20 / 33

UNIX file system calls • Applications “open” files (or devices) by name - I/O happens through open files • int open(char *path, int flags, /*int mode*/...); - flags : O_RDONLY , O_WRONLY , O_RDWR - O_CREAT : create the file if non-existent - O_EXCL : (w. O_CREAT ) create if file exists already - O_TRUNC : Truncate the file - O_APPEND : Start writing from end of file - mode : final argument with O_CREAT • Returns file descriptor—used for all I/O to file 21 / 33

Error returns • What if open fails? Returns -1 (invalid fd) • Most system calls return -1 on failure - Specific kind of error in global int errno • #include <sys/errno.h> for possible values - 2 = ENOENT “No such file or directory” - 13 = EACCES “Permission Denied” • perror function prints human-readable message - perror ("initfile"); → “ initfile: No such file or directory ” 22 / 33

Operations on file descriptors • int read (int fd, void *buf, int nbytes); - Returns number of bytes read - Returns 0 bytes at end of file, or -1 on error • int write (int fd, const void *buf, int nbytes); - Returns number of bytes written, -1 on error • off_t lseek (int fd, off_t pos, int whence); - whence : 0 – start, 1 – current, 2 – end ⊲ Returns previous file offset, or -1 on error • int close (int fd); 23 / 33
