ENVIRONMENTAL GEOTECHNICS CE-488 Lecture No. 18 Prof. D N Singh Department of Civil Engineering Mercury Intrusion Porosimetry (MIP) Geomaterials are composed of wide range of particle sizes and shapes and are porous in nature. A

SLIDE 1

ENVIRONMENTAL GEOTECHNICS

CE-488 Lecture No. 18

Prof. D N Singh

Department of Civil Engineering

SLIDE 2

Geomaterials are composed of wide range of particle sizes and

shapes and are porous in nature.

A knowledge of pore structure of these materials is important as it can

give insight in to both the microstructure and the performance.

Rather than measuring the porosity, It becomes more informative if the

manner in which volume is distributed With respect to pore size.

Mercury Intrusion Porosimetry (MIP) Dead end Closed Inter-connected Passing

SLIDE 3

Non-porous solids (Extremely low surface area) Porous solids medium high surface area, pore volume and dimension Particulates particle size and surface area Catalysts: activated sites on porous support or powder

Porosity

SLIDE 4

Conical Slits Cylindrical Spherical or Ink Bottle Interstices

Shape of Pores

SLIDE 5

Ultra Pycnometer

SLIDE 6
