Enterprise AOP

With the Spring Framework

Jürgen Höller

VP & Distinguished Engineer, Interface21

Agenda

Spring Core Container Spring AOP Framework AOP in Spring 2.0 Example: Transaction Advice What's Coming in Spring 2.1?

Spring Framework (1)

Java / J2EE Application Framework

• riginally based on Rod Johnson’s book

“J2EE Design & Development” (Wiley, 2002)

popularized by "J2EE Development without EJB"

(Rod Johnson, Jürgen Höller; Wiley, 2004)

Focus on "Plain Old Java Objects" (POJOs)

natural component model for applications

Open Source Project on SourceForge

since February 2003 Apache license >40000 downloads per month

Spring Framework (2)

Business objects as decoupled POJOs

configuration and wiring through framework

• or usage as normal Java objects

independent from the actual environment

• no unnecessary ties to a framework

reusable in any kind of environment

• in particular: testability in unit / integration tests

Generic middleware services

e.g. declarative transactions for POJOs

• flexible alternative to EJB CMT

for all applications, including standalone

• leverage container services when available

Core Container (1)

"Inversion of Control"

configuration and lifecycle of application objects

• bjects do not configure themselves, but get

configured from the outside

• bjects don't know the origin of their

configuration

"Dependency Injection"

"setter-based" (JavaBean properties) "constructor-based" (constructor arguments) alternative: "Service Lookup"

• for example: JNDI

Core Container (2)

public class ShopFacadeImpl implements ShopFacade { private OrderDao orderDao; private ItemDao itemDao; ... public void setOrderDao(OrderDao orderDao) { this.orderDao = orderDao; } public void setItemDao(ItemDao itemDao) { this.itemDao = itemDao; } ... public void insertOrder(Order order) { this.orderDao.insertOrder(order); this.itemDao.updateQuantity(order); } }

Core Container (3)

Fine-grained externalized configuration

representing the internal structure of the

application

• references to other components
• configuration parameters

enables flexible configuration management

• at fine-grained component level
• switching between different deployment scenarios

XML bean definitions

most common configuration format

• ften: separate admin properties file
• linked into XML bean definitions through placeholders

Core Container (4)

<bean id="dataSource" class="org.apache.commons.dbcp.BasicDataSource"> <property name="driverClassName" value="${jdbc.driver}"/> <property name="url" value="${jdbc.url}"/> <property name="username" value="${ jdbc.username}"/> <property name="password" value="${ jdbc.password}"/> </bean> <bean id="orderDao" class="com.myshop.dao.jdbc.JdbcOrderDao"> <property name="dataSource" ref="dataSource"/> </bean> <bean id="petStore" class="com.myshop.service.ShopFacadeImpl"> <property name="orderDao" ref="orderDao"/> <property name="itemDao" ref="itemDao"/> </bean>

AOP Framework (1)

Proxy-based Aspect Orientation

proxies for arbitrary POJOs

• no fixed component model

flexible combination of interceptors instance-based AOP

Interceptors for Cross-Cutting Concerns

actions at beginning/end of method call

Target method Caller intercept

AOP Framework (2)

Do not repeat code: factor out interceptor

e.g. logging: configurable trace log e.g. security: authorization checks e.g. common exception handling e.g. transaction demarcation

Method interceptor

interceptor can be applied to any methods interceptor can be enabled/disabled AOP Alliance: MethodInterceptor interface reuse of pre-built interceptors

AOP Framework (3)

Custom interceptor implementations

rarely necessary, but straightforward usually delegate to target ("proceed") can also abort invocations

• for example: authorization interceptor

public class TestInterceptor implements MethodInterceptor { public Object invoke(MethodInvocation inv) throws Throwable { System.out.println("before invocation"); try { return inv.proceed(); } finally { System.out.println("after invocation"); } } }

AOP Framework (4)

AOP Framework = creation of proxies

build proxy for target object

• JDK dynamic proxy or CGLIB proxy

build interceptor chain between proxy

and target

• according to AOP advice configuration

Hooks into Spring's core container

FactoryBean or auto-proxy creator core container does not create proxies

itself!

ProxyFactory

ShopFacadeImpl facade = new ShopFacadeImpl(); facade.setOrderDao(...); ProxyFactory pf = new ProxyFactory(); pf.setTarget(facade); pf.addAdvice(new SimpleTraceInterceptor()); pf.addInterface(ShopFacade.class); ShopFacade proxy = (ShopFacade) pf.getProxy(); proxy.insertOrder(...); // Every call on the proxy will delegate to the target // but first go through the trace interceptor. ProxyFactory pf = new ProxyFactory(); pf.setTarget(facade); pf.addAdvice(new SimpleTraceInterceptor()); pf.setProxyTargetClass(true); ShopFacadeImpl proxy = (ShopFacadeImpl) pf.getProxy(); // Enforce CGLIB proxy that can be cast to the target class!

ProxyFactoryBean

<bean id="petStoreTarget" class="com.myshop.service.ShopFacadeImpl"> <property name="orderDao" ref="orderDao"/> <property name="itemDao" ref="itemDao"/> </bean> <bean id="traceInterceptor" class="org.springframework.aop.interceptor.SimpleTraceIntercepto r"/> <bean id="petStore" class="org.springframework.aop.framework.ProxyFactoryBean"> <property name="target" ref="petStoreTarget"/> <property name="interceptorNames" value="traceInterceptor"> <property name="proxyInterfaces" value="com.myshop.service.ShopFacade"> </bean>

AOP in Spring 2.0

Simplified configuration

using <aop:*/> tags

Closer AspectJ integration

pointcut expression language AspectJ-style aspects in Spring AOP @AspectJ-style aspects in Spring AOP

• fully interoperable with ajc compiled aspects

@Configurable

dependency injection on domain objects

Simplified AOP Configuration

<aop:config> <aop:advisor id="getAgeAdvisor" pointcut="execution(* *..TestBean.getAge(..))" advice-ref="getAgeCounter"/> </aop:config> <bean id="getAgeCounter" class="...CountingBeforeAdvice"/>

public class JavaBeanPropertyMonitor { private int getterCount = 0; private int setterCount = 0; public void beforeGetter() { this.getterCount++; } public void afterSetter() { this.setterCount++; } }

AspectJ-style Aspects

<aop:config> <aop:aspect ref="javaBeanMonitor"> <aop:before pointcut="execution(public !void get*())" method="beforeGetter"/> <aop:after pointcut="execution(public void set*(*))" method="afterSetter"/> </aop:aspect> </aop:config>

AspectJ-style Aspects

@AspectJ-style Aspects

@Aspect public class AjLoggingAspect { @Pointcut("execution(* *..AccountService.*(..))") public void callsToAccountService(){} @Before("callsToAccountService()") public void before(JoinPoint jp) { System.out.println("Before " + jp.toShortString()); } @AfterReturning("callsToAccountService()") public void after() { System.out.println("After."); } }

@AspectJ-style Aspects

<!-- detects all @AspectJ aspects among the bean definitions, and applies them to all

• ther beans in the application context -->

<aop:aspectj-autoproxy/> <bean id="aspect" class="demo.AjLoggingAspect"/> <bean id="account" class="demo.AccountService"/>

@Configurable("accountBean") public class Account { private AccountService service; public void setAccountService(AccountService service) { this.service = service; } … } // Automatically injected on 'new'! Account acc = new Account(…); <aop:spring-configured/>

Configuration Aspect for Domain Objects

Spring 2.0: AOP Unification

Same programming model for proxy-based

and weaving-based AOP

choice of implementation strategies consistent programming model based on AspectJ

Typically: start with proxy-based AOP

seamlessly works in any kind of ClassLoader

environment

Use AspectJ compile-time / load-time weaving

for more demanding needs

with same configuration model

Using <tx:advice/>

<aop:config> <aop:advisor pointcut="execution(* *..AccountService.*(..))" advice-ref="txAdvice"/> </aop:config> <tx:advice id="txAdvice" transaction-manager="txManager"> <tx:attributes> <tx:method name="find*" read-only="true"/> <tx:method name="save*"/> </tx:attributes> </tx:advice>

<bean id="txManager" class="org.springframework.transaction.jta. JtaTransactionManager"/>

@Transactional

Java 5 annotation for tx demarcation

available since Spring 1.2

public class AccountService { @Transactional(readOnly = true) public List<Account> findAccounts(...) { ... } @Transactional public void saveAccount(Account account) { ... } }

<tx:annotation-driven/>

<!-- automatically detects annotated beans --> <tx:annotation-driven transaction-manager="txManager"/> <bean id="txManager" class="org.springframework.transaction.jta. JtaTransactionManager"/> <!-- proxied: allowed to use @Transactional on public, externally called methods only --> <bean id="accountService" class="demo.AccountService"/>

AspectJ AnnotationTransactionAspect

<!-- configures AspectJ transaction aspect --> <bean id="txAspect" class="org.springframework.transaction.aspectj. AnnotationTransactionAspect" factory-method="aspectOf"> <property name="transactionManager" ref="txManager"/> </bean> <bean id="txManager" class="org.springframework.transaction.jta. JtaTransactionManager"/> <!– weaved: allowed to use @Transactional on any methods --> <bean id="accountService" class="demo.AccountService"/>

AspectJ Class Weaving

How does the AnnotationTransactionAspect on

the previous slide get applied?

We configured the aspect, but how does it kick in?

Option 1: compile-time weaving

AccountService class statically weaved using

the AspectJ compiler

Option 2: load-time weaving

• n-the-fly weaving of classes when they get

loaded into a Spring application context

driven by AspectJ's META-INF/aop.xml Spring 2.0: need to use AspectJ VM agent

What's Coming in Spring 2.1?

Support for Spring-driven AspectJ load-time

weaving

through Spring's LoadTimeWeaver abstraction same as used for JPA (Java Persistence API)

entity weaving

for any supported platform

• generic Spring VM agent, various application servers

"beanName" pointcut element

in AspectJ-based pointcut expressions

• as a custom extension element

matching specific beans by name rather than

by type

• leverage availability of named beans in Spring

Summary

Spring 2.0 offers broad AOP support,

integrated into its core container

proxy-based

• pre-built AOP Alliance MethodInterceptors
• AspectJ-style and @AspectJ-style aspects
• note: public, externally called methods only!

weaving-based

• standard AspectJ aspects
• supports private, internally called methods too
• however: requires weaving infrastructure

Typical usage: middleware aspects

transaction management statistics, event notification, etc

And of course...

… we'll be happy to assist you! ☺

Interface21 – Spring from the Source

Spring Training: e.g. 26.6.-29.6. Frankfurt

... or in-house

Quick Scan: How can Spring help you? Support contracts for Spring
