SLIDE 1
Enabling cross-library optimization and compile-time error checking in the presence of procedural macros
Andrew W. Keep R. Kent Dybvig
1
1
Library Groups
Andrew W. Keep R. Kent Dybvig
2
2
Enabling cross-library optimization and compile-time error checking - - PowerPoint PPT Presentation
Enabling cross-library optimization and compile-time error checking - - PowerPoint PPT Presentation
Enabling cross-library optimization and compile-time error checking in the presence of procedural macros Andrew W. Keep R. Kent Dybvig 1 1 Library Groups Andrew W. Keep R. Kent Dybvig 2 2 Goals Cross-library
SLIDE 2
SLIDE 3
Goals
- Cross-library optimizations
- Type checking across library boundaries
- Single binary for multiple libraries
- Unchanged development process
3
3
SLIDE 4
Library Groups
- Explicitly combine libraries
- Optionally add a top-level program
- A new form: library-group
4
4
SLIDE 5
Example
(library (tree) (export make-tree ---) (import (rnrs)) (define make-tree ---)
- --)
5
5
SLIDE 6
(library (tree constants) (export quote-tree t0 ---) (import (rnrs) (tree)) (define-syntax quote-tree
- -- (make-tree ---) ---)
(define t0 (quote-tree))
- --)
Example
6
6
SLIDE 7
(import (rnrs) (tree) (tree constants)) (define tree->list ---) (tree->list t0) (tree-value (tree-children t2)) (tree->list (quote-tree 5 (7 9)))
Example
7
7
SLIDE 8
(library-group (library (tree) (export make-tree ---) (import (rnrs)) (define make-tree ---)
- --)
(library (tree constants) (export quote-tree t0 ---) (import (rnrs) (tree)) (define-syntax quote-tree
- -- (make-tree ---) ---)
(define t0 (quote-tree))
- --)
(import (rnrs) (tree) (tree constants)) (define tree->list ---) (tree->list t0) (tree-value (tree-children t2)) (tree->list (quote-tree 5 (7 9))))
Example
8
8
SLIDE 9
Example
(library-group (include “tree.sls”) (include “tree/constants.sls”) (include “app.sps”))
9
9
SLIDE 10
Library Group Syntax
library-group -> (library-group (library-group (library-group lglib* lgprog) | (library-group (library-group (library-group lglib*) lglib
- > library | (include filename)
lgprog
- > program | (include filename)
10
10
SLIDE 11
Challenges
- Achieving proper phasing
- Handling cyclic dependencies
- Enabling cross-library optimization/checking
11
11
SLIDE 12
Implementation: Libraries
- Visit code, invoke code, metadata
- Import dependencies form a DAG
- Invoke code body uses letrec* semantics
12
12
SLIDE 13
(letrec* ([make-tree ---]
- --)
(set-top-level! $make-tree make-tree)
- --)
Example
13
13
SLIDE 14
(letrec* ([t0 tree-constant]
- --)
(set-top-level! $t0 t0)
- --)
Example
14
14
SLIDE 15
(letrec* ([tree->list ---]) (tree->list $t0) ($tree-value ($tree-children $t2)) (tree->list tree-constant))
Example
15
15
SLIDE 16
Implementation: Library Groups
- Combine letrec* expressions
- Preserve existing library exports
- Invoke libraries needed during expansion
16
16
SLIDE 17
Library Group 1
(lambda (uid) (case uid [(tree) (letrec* ([make-tree ―]
- --)
- --)]
[(constants) (letrec* ([t0 ---] ---)
- --)]
[else (letrec* ([tree->list ---]) (tree->list $t0) ($tree-value (car ($tree-children $t2))) (tree->list ---))]))
17
17
SLIDE 18
Library Group 1
- Advantages:
- Single output binary
- Matches existing library semantics
- Disadvantages:
- Hinders cross-library optimizations
18
18
SLIDE 19
Library Group 2
(letrec* ([make-tree ---] ---) (set-top-level! $make-tree make-tree)
- (letrec* ([t0 tree-constant] ---)
(set-top-level! $t0 t0)
- (letrec* ([tree->list ---])
(tree->list $t0) ($tree-value (car ($tree-children $t2)))) (tree->list tree-constant)))
19
19
SLIDE 20
Library Group 2
- Advantages:
- Creates a single invoke code
- Allows optimizations and checking
- Disadvantage:
- Causes dependency problems
20
20
SLIDE 21
Dependency Problems
(A) (B) (C)
21
21
SLIDE 22
Dependency Problems
(A) (B) (C)
21
21
SLIDE 23
Dependency Problems
(A) (B) (C)
21
21
SLIDE 24
(lambda (uid) (letrec* ([make-tree ---] ---)
- (mark-invoked! ‘tree)
(let ([nested-lib (lambda (uid) (letrec* ([t0 ---] ---)
- (mark-invoked! ‘constants)
(let ([nested-lib program code]) (if (eq? uid ‘constants) nested-lib (nested-lib uid)))))]) (if (eq? uid ‘tree) nested-lib (nested-lib uid)))))
Library Group 3
22
22
SLIDE 25
Library Group 3
- Advantages:
- Avoids synthetic cycles
- Allows optimization and checking
- Single output binary
23
23
SLIDE 26
Caveat: Dynamic Dependencies
- Arises from use of eval in init expressions
- Library groups allow explicit ordering
- Work arounds
- Transform into import dependency
- Move into initialization function
24
24
SLIDE 27
Fixing Dynamic Dependencies
- Start with case-based library-group
- Lift “simple” letrec* bindings
- Requires letrec* style optimization
25
25
SLIDE 28
Library Phasing
- Retain phasing between libraries in group
- Cannot simply recompile from source
- Relatively straightforward solution
26
26
SLIDE 29
Summary
- Library groups meet our goals:
- Cross-library optimization
- Type checking across library boundaries
- Single output binary
- Maintains proper phasing order
- Avoids synthetic import dependency cycles
27
27
SLIDE 30
Thanks
Questions?
