1

V.A.0.0 PPT-SFMTG-ELVWRK

Safety Meeting

Elevated Work

2

V.A.0.0 PPT-SFMTG-ELVWRK

• There are many jobs that require working at

heights

• This requires the use of walking working surfaces

such as ladders, scaffolds and stairways

• Safety in elevated work areas requires

companies to follow strict standards for height, width, building materials, load capacity and proper housekeeping

Elevated Work

2

3

V.A.0.0 PPT-SFMTG-ELVWRK

• Designed primarily to provide access to an

elevated area

• Must not be used as a work platform unless the

job can be performed using only one hand

• Be constructed according to OSHA regulations

Ladders

3

4

V.A.0.0 PPT-SFMTG-ELVWRK

• Get authorization to perform elevated work
• Clear footing area of excess tools, debris, waste and
• ther obstructions
• Place the ladder on a firm, level surface
• Fully open the legs of the ladder
• Use proper PPE

− Fall protection if necessary

• Secure tools and equipment properly
• Carry only necessary tools in pockets or tool belt
• Attach a hand line and lift items once on stable surface
• Maintain a 3-point contact with the ladder

Ladders

4

5

V.A.0.0 PPT-SFMTG-ELVWRK

3-point Contact

5

1 2 3

6

V.A.0.0 PPT-SFMTG-ELVWRK

• Inspect the following before using a ladder

− Footing − Rungs or steps − Side rails − Hinges − Spreaders

Ladder Inspection

6

7

V.A.0.0 PPT-SFMTG-ELVWRK

• Put a warning tag on a damaged ladder

immediately

• Report a damaged ladder to a supervisor
• Take a damaged ladder out of service until it is

repaired

− Portable ladders are often damaged by being moved

from worksite to worksite and while in storage

− Fixed ladders may deteriorate if they are exposed to

the weather or corrosive chemicals

Damaged Ladders

7

8

V.A.0.0 PPT-SFMTG-ELVWRK

• Two types of ladders commonly found in

industrial facilities

− Portable − Fixed

Ladders

8

9

V.A.0.0 PPT-SFMTG-ELVWRK

• Avoid overreaching when performing work

from a ladder

• The worker’s belt buckle must never pass the

side rail of the ladder

• Never allow more than one person at a time
• n a ladder

Portable Ladders

9

10

V.A.0.0 PPT-SFMTG-ELVWRK

Portable Ladders

10

• Portable ladders are subdivided into two

categories

− Step ladders − Extension ladders

11

V.A.0.0 PPT-SFMTG-ELVWRK

Step Ladders

11

• A step ladder is used to perform work at

relatively low levels or when an appropriate upper support is not available

12

V.A.0.0 PPT-SFMTG-ELVWRK

• Most commonly used to transit to a higher level

where permanent access is not provided

• Ladder footing must be on a firm, level surface to

prevent the base from kicking out

• Open ladder must maintain a 4:1 slope

− Angled so the base of the ladder is one foot away from

the vertical plane for each rise of four feet

• Top of the ladder must rest against a sturdy support
• Top of the ladder must extend three feet past the

upper level

• Must be tied off to avoid slippage

Extension Ladders

12

13

V.A.0.0 PPT-SFMTG-ELVWRK

Extension Ladders

13

14

V.A.0.0 PPT-SFMTG-ELVWRK

• Never use a metal ladder when

electrical hazards are present

• Be aware of overhead power

lines and other electrical connections when setting up and moving a metal ladder

Metal Ladders

14

15

V.A.0.0 PPT-SFMTG-ELVWRK

• Provided in frequently accessed, elevated areas
• A visual inspection ensures it is in an acceptable

condition before climbing

• A fixed ladder higher than 20 feet must be

equipped with fall protection cages or other protective devices

• Rest platforms must be provided every 30 feet

Fixed Ladders

15

16

V.A.0.0 PPT-SFMTG-ELVWRK

Fixed Ladders

16

17

V.A.0.0 PPT-SFMTG-ELVWRK

• Designed primarily as a work platform
• Allow workers to perform a job that

− Takes a long time − Requires both hands − Requires more than one person

• Only use a scaffold for its intended purpose

based on the type of scaffold used

• A stairway or ladder must be provided and used

for climbing onto a scaffold

• Always place on a firm level surface

Scaffolds

17

18

V.A.0.0 PPT-SFMTG-ELVWRK

• Store in a place that will avoid excessive

weathering or damage

• Securely fasten risers and braces with the locking

mechanism properly engaged

• Keep materials away from the bracing and

footing of a scaffold

• Use of scaffolds that are covered with snow, ice
• r other slippery materials is prohibited
• Use of shore and lean-to scaffolds is prohibited

Scaffolds

18

19

V.A.0.0 PPT-SFMTG-ELVWRK

Scaffolds

19

20

V.A.0.0 PPT-SFMTG-ELVWRK

• Pole
• Tube and coupler
• Fabricated frame
• Outrigger
• Single point adjustable suspension
• Two point adjustable suspension

Types of Scaffolds

20

21

V.A.0.0 PPT-SFMTG-ELVWRK

• Can only be used on a smooth, firm, level surface
• Workers are only allowed on the scaffold when it

is stationary

Wheeled Scaffolds

21

22

V.A.0.0 PPT-SFMTG-ELVWRK

• Design and assembly of a scaffold
• Dismantle or move a scaffold
• Repair or alter a scaffold
• Determine the maximum load capacity and

ensure that it is not exceeded at any time

• Inspection of a scaffold

Qualified Worker Responsibilities

22

23

V.A.0.0 PPT-SFMTG-ELVWRK

• Must be inspected for

− Deterioration − Damage − Missing parts

• Must be inspected

− Before workers are allowed to use them − Before each shift − After any occurrence that may affect the

stability or safe use of the scaffolding

Scaffold Inspection

23

24

V.A.0.0 PPT-SFMTG-ELVWRK

• The structure that the scaffold is secured to must

be capable of withstanding the load

• The load includes

− Vertical load, such as the weight of the scaffold − Horizontal load, such as the wind blowing on tarps

• All scaffolds and components must support,

without failure, its own weight and at least four times the maximum intended load applied or transmitted to it

Load Capacity

24

25

V.A.0.0 PPT-SFMTG-ELVWRK

• The height of a freestanding scaffold is limited to

four times the smallest dimension of the base

− For example, a 5 x 10 freestanding scaffold cannot

exceed a height of 20 feet tall

• Guying or tying is necessary if a scaffold needs

to be taller

− Secure scaffold to a tall structure − Prevent swaying or displacement − Must be tied at least every 30 feet horizontally and

every 26 feet vertically

Height Limitations

25

26

V.A.0.0 PPT-SFMTG-ELVWRK

• Must be made of scaffolding grade material
• Must completely cover the entire working platform
• Must form a smooth, continuous working surface
• Must not have any gaps large enough for tools or

materials to fall through

• Wooden planking must extend past the end supports

by no less than 6 inches and no more than 12 inches

• Metal planking must not extend past the end

supports

Planking

26

27

V.A.0.0 PPT-SFMTG-ELVWRK

• Electrical hazards can include

− Working near energized or exposed electric lines − Using electric power tools − Using welding equipment

• Scaffolds must not be closer than 10 feet to power lines
• Electric power tools create a risk of electrocution or

shock because a metal frame scaffold is conductive

− Scaffold should be grounded to reduce the risk of injury

• To reduce the risk of electrocution or shock

− Use a GFCI − Assured Grounding program

Scaffold Hazards

27

28

V.A.0.0 PPT-SFMTG-ELVWRK

• Area above and below the work being done on

a scaffold can create fall hazards

• Area must be inspected before the job begins

and cleared of any objects with the potential to fall on workers

• Ladders should not be used on a scaffold to

increase the working height unless specific conditions are met

• Workers should not stand on boxes, crates or

barrels to increase their working height

Scaffold Hazards

28

29

V.A.0.0 PPT-SFMTG-ELVWRK

• A fall arrest system should be worn even if a

scaffold is equipped with handrails

• The company must ensure that wearing fall

protection does not create a greater hazard

• The tie-off point selected for a fall arrest system

cannot be a part of the scaffold

• A hard hat must be worn at all times if there is a

chance of falling hand tools, debris or other small

• bjects

Fall and Falling Object Protection

29

30

V.A.0.0 PPT-SFMTG-ELVWRK

• Eliminate the chance of materials falling from the

scaffold

− Do not stack materials where they can be knocked off − Tie hand tools and equipment to a safety line

• The area below the scaffold should be protected

using a barricade and worker access must be restricted

Fall and Falling Object Protection

30

31

V.A.0.0 PPT-SFMTG-ELVWRK

• Handrails must be installed on all open ends and

sides of scaffolding greater than 10 feet high

− Handrails must be equipped with a top rail between 36

and 42 inches high and a mid-rail

− Never climb or work from the handrail, midrail, braces or

cross-braces of a scaffold system

• Toeboards must be placed along the edge of

platforms greater than 10 feet high for a distance sufficient to protect workers below

− Toeboards must be at least 4 inches high to prevent loose

• bjects from being kicked over the side

Fall and Falling Object Protection

31

32

V.A.0.0 PPT-SFMTG-ELVWRK

• Additional protection that will deflect or contain

falling objects can include

− Toeboards − Screens − Guardrails − Debris nets − Catch platforms − Canopy structures

Fall and Falling Object Protection

32
