Energy for a sustainable future

October 2016

Electric Vehicle Overview

Energy for a sustainable future

FZ SoNick

Energy Valuable Solutions

3 Energy for a sustainable future

14 PRODUCTION PLANTS

3.000 EMPLOYEES

2015 Turnover 590 M€

4 Energy for a sustainable future

FIAMM SoNick/ Businesses

Micro Hybrid Vehicles

• Start & Stop Batteries

Sodium Batteries

• Energy Storage
• Energy Backup (TLC)
• Electric Vehicles

 General Lighting

• OLED

(Organic Light Emitting Diode)

Starters

• Batteries
• Horns
• Antennas and

Cables Industrial Backup

• Backup Power

Core Business Proximity Business NEW Business

5 Energy for a sustainable future 32% 2% 4% 20% 22% 20% Salt Cu Miscellaneous Ni Fe Ceramic

Zero Impact Battery  NO dangerous materials  100% recyclable  NO pollution materials  NO gas emissions Safety

 Intrinsically safe, electrochemical safety

 No gas emissions  No flammable materials  No fire/water flood reaction  Industrial Process Control  Tested in the field

(EV, TLC, ESS,...)

 BMS control  Cell/Battery Mechanical case

Performances

 Temperature Immunity

(-40 -; +60°C)

 Cycling Capability

> 1.500 cycles - MOBILITY > 4.500 cycles - ESS (80% DOD)

 Battery energy density

100-;120Wh/kg 150-190Wh/lt

 Shelf life (> 20 years)  No memory effect

2NaCl + Ni NiCl2 + 2Na discharged charged cell

6 Energy for a sustainable future

Production

7 Energy for a sustainable future

Applications

ST SoNick

for SUSTAINABLE MOBILITY for ENERGY STORAGE

EV SoNick TL SoNick

for Railways ENERGY BACK-UP for ENERGY BACK-UP, UPS and TELECOMS

RW SoNick TR SoNick

for TRAILER STORAGE

8 Energy for a sustainable future

• The required capacity and voltage specifications are obtained by connecting an

appropriate number of cell strings in series and parallel.

• The cells are vertically assembled into the battery box with or without aircooling.

External Case Internal Case Heater Cells CAN interface Charger Cooling Fan Traction Net Battery Management System Thermal Insulation

SoNick Technology

9 Energy for a sustainable future

Solution Range

10 Energy for a sustainable future

Marine transportation Harsh environment Extreme temperature Safe from physical damage No hazardous emissions

Suitable for any place of installation:

Energy for a sustainable future

Applications and References

12 Energy for a sustainable future

Electric Vehicles

SoNick Technology for Sustained Mobility

EV

13 Energy for a sustainable future

Location: Australia

EV

• 3 Buses operated by Adelaide council

since 2008

• Travel 50,000 kms a year
• Save 14,000 litres of diesel a year
• Save 70,000 kg of CO2 emissions a year

14 Energy for a sustainable future

Location: Australia

EV

• Tindo buses are recharged using 100% solar energy using a

unique solar photovoltaic charging system and have the ability to travel over 200 kilometres between recharges.

• As the SoNick batteries are virtually maintenance free, it

results in significant cost savings.

• The unique battery management interface ensures that the

batteries system can’t be damaged by inappropriate

• peration or charging protocols.
• Unlike other batteries available for electric buses, these

controlled temperature batteries operate without loss of performance or life expectancy in virtually any condition.

• In addition to conventional controls and instrumentation, a

driver display panel is provided, from which the bus

• perator and maintenance staff can check the status of

Tindo’s drive and charge.

15 Energy for a sustainable future

Public Transport

From north…

Location: Abu Dhabi +50°C

With Tecnobus With Designline

Location: Canada -30°C

To south…

EV

16 Energy for a sustainable future

Light Commercial Vehicles

IVECO MY 2014 awarded as Van of the Year 2015!

With IVECO

Location: Europe

EV

17 Energy for a sustainable future

Light Commercial Vehicles

EV

With CITROEN Berlingo- Venturi With DOBLÓ

Location: Europe

18 Energy for a sustainable future

With IRIZAR

Location: Europe

Busses

19 Energy for a sustainable future

Refuse Trucks EV and School Buses

Location: USA

With CITY OF CHICAGO With SSTE

EV

20 Energy for a sustainable future

Shuttle Buses

EV

With GBV

Location: USA

With GOOGLE

Energy for a sustainable future

EV V With TECNOBUS

Location: Europe

Shuttle Buses

22 Energy for a sustainable future

Shuttle Buses

Location: Europe

With IRIZAR

EV

23 Energy for a sustainable future

Location: Wold

Mining and Heavy duties

• Pag. 18

24 Energy for a sustainable future

Mining and Heavy duties

• Pag. 19

Parameter Na-Ni-Cl2 Package Lead Acid Module Ni-Cd Module Ni-mH Package Li-Ion Module Battery Weight Battery Volume Operating Temp. optimal Cooling Medium, techn. Energy loss per cell fail. Locomotive Robust P. Expected Price, Prod.

25 Energy for a sustainable future

Light Vehicle

Location: BRAZIL

With ITAIPU With ITAIPU and President LULA With IVECO

EV

26 Energy for a sustainable future

Light Vehicle

With TH!NK city

Location: Europe

EV

27 Energy for a sustainable future

ROLLS ROYCE - NATO Submarine Rescue System

With ROLLS ROYCE

Location: UK and China UNIT: 8 Z43 (258V 64Ah). 4 in use and 4 as back-up ENERGY: 30-35 Wh for traction and 12 Wh for auxiliary services

• Free-Swimming Submersible
• Rescue
• Remotely Operated Vehicle
• 10 meters long, 27 tons weight

EV

28

• Pag. 71
