Planning for Adoption of Electric Buses April 7, 2020 Michael Groh, Sam Schwartz Consulting 1 Agenda 1. State of the Electric Bus Industry a. Growth of Electric Buses b. Benefits of Electric Buses c. Challenges 2. Electric Bus

slide-1
SLIDE 1

April 7, 2020 Michael Groh, Sam Schwartz Consulting

Planning for Adoption of Electric Buses

1

slide-2
SLIDE 2

Agenda

  • 1. State of the Electric Bus

Industry

  • a. Growth of Electric Buses
  • b. Benefits of Electric Buses
  • c. Challenges
  • 2. Electric Bus Technologies
  • a. Slow and Fast Charging
  • b. Charging Mechanisms
  • c. Real World Performance
  • 3. Planning Needed to Adopt

Electric Buses

  • a. Schedule Compatibility
  • b. Facilities Updates
  • c. Fleet Planning
  • d. Cost Projections
slide-3
SLIDE 3

State of the Electric Bus Industry: Growth of Electric Buses

slide-4
SLIDE 4
slide-5
SLIDE 5

Current State of Electric Bus Market

  • Battery-electric bus manufacturing and technology are still new but

progressing rapidly.

  • Dozens of transit agencies in the US with electric bus experience – most

with less than 10 buses

  • Currently, six agencies in the United States are operating 10 or more electric

buses.

  • The industry is currently focusing on 40-foot standard bus designs. Offerings

in the 60-foot articulated bus category are still limited.

  • Electric bus manufacturers include New Flyer, Nova, Gillig, BYD, and

Proterra.

  • INGENUITY. ACCESSIBILITY. INTEGRITY

5

slide-6
SLIDE 6

Electric Bus Projects in the US

  • Key agencies with electric bus experience:
  • King County Metro: 120 electric buses by 2020
  • IndyGo: 34 buses, 18 more on order
  • Antelope Valley Transportation Authority: 30 electric buses (two 60-foot),

anticipated 100% conversion in 2019/2020.

  • Foothill Transit: 37 buses, 100% fleet conversion by 2030
  • California Air Resources Board mandate for transit agencies to

transition to electric buses by 2040

  • 425,000 electric buses deployed worldwide (99% in China)

Source: TCRP Synthesis 130: Battery Electric Buses State of the Practice, Union of concerned scientists 6

slide-7
SLIDE 7

Electric Bus Growth

7

Source: National Transit Database

6 8 10 16 27 35 44 5 10 15 20 25 30 35 40 45 50 2012 2013 2014 2015 2016 2017 2018

US US Transit it Ag Agencie ies with ith Ba Battery ry Elec lectric Bus Buses

slide-8
SLIDE 8

Electric Bus Growth

8

Source: National Transit Database

52 52 81 114 148 251 329 50 100 150 200 250 300 350 2012 2013 2014 2015 2016 2017 2018

Tot

  • tal

l Ba Battery ry Elec lectric Bus Buses in in US US

slide-9
SLIDE 9

State of the Electric Bus Industry: Benefits of Electric Buses

slide-10
SLIDE 10
  • Health benefits: eliminates tailpipe

air pollution emissions

  • Reduces noise to levels equivalent

to a passenger car

  • Reduces fuel costs and

price uncertainty

  • Long-term reduction of greenhouse

gases

  • Show leadership to decarbonize

transportation sector

Benefits of Electric Buses

10

Source: CTA

slide-11
SLIDE 11

Electric Bus Emissions

11

Transit Bus GHG Emissions

Source: MJB&A

slide-12
SLIDE 12

State of the Electric Bus Industry: Challenges

slide-13
SLIDE 13
slide-14
SLIDE 14
  • Early models had limited battery capacities
  • Ambitious manufacturer claims not matched with

real-world performance

  • Need to anticipate impacts of cold weather,

running heat/air conditioning, difficult terrain

  • Thorough planning is needed before placing

electric buses into service

Electric Bus Challenges

14

slide-15
SLIDE 15

Electric Bus Technologies

15

slide-16
SLIDE 16

Electric Bus Technologies: Slow and Fast Charging

slide-17
SLIDE 17

Two Strategies for Charger Power

SLOW CHARGING AT GARAGES FAST CHARGING ON-ROUTE

Larger Electrical Requirement Shorter Charging Duration Smaller Electrical Requirement Needs Longer Charging Duration

17

slide-18
SLIDE 18

Slow and Fast Charging (Example)

18

Bus Layover

(10 minutes) 25-75* miles

Bus Layover

(10 minutes)

Bus Layover

(10 minutes)

Bus Layover

(10 minutes) 25-75* miles 25-75* miles 25-75* miles FAST CHARGING ON-ROUTE SLOW CHARGING AT GARAGES

Bus Garage

(2-5 hours) 150-200* miles or less

*”Real world” battery mileage vary based on technology and real-world conditions.

slide-19
SLIDE 19

Electric Bus Technologies: Charging Mechanisms

slide-20
SLIDE 20

Charging Mechanisms

20

Photo credit: Autoblog.com Photo credit: ABB.com Photo credit: electrive.com Photo credit: Siemens

Plug-in Conductive Charging Continuous Charging Inductive Charging

slide-21
SLIDE 21

Mechanisms: Plug-in Charging

(Typically Slow/Garage Charging)

21 Source: https://www.oppcharge.org/

slide-22
SLIDE 22

Mechanisms: Conductive Charging (Can be Fast or Slow)

22

slide-23
SLIDE 23

Mechanisms: Inductive Charging

(Typically Fast/On-route Charging)

Photo credit: electrive.com

slide-24
SLIDE 24

Mechanisms: Continuous Charging

Trolleybuses require overhead catenary wire for most of their route. This is also called In Motion Charging (IMC) when buses spend significant time off-wire.

Photo credit: Wikipedia

slide-25
SLIDE 25

Standardizing Chargers

Overhead charging standard (J3105) Plug-in standard (J1772)

Photo credit: insideevs.com Photo credit: chargedevs.com

25

slide-26
SLIDE 26

Agency Charging Types

AGENCY Plug-in Conductive Inductive Continuous

King County Metro X X X Foothill Transit X X New York City Transit X X Antelope Valley Transit Authority X X LADOT X X Greensboro Transit Authority X X SEPTA X IndyGo X X DART (Dallas) X X Vineyard Transit Authority X X

26

slide-27
SLIDE 27

Pros/Cons of E-bus & Charger Types

Consideration Slow Charging in Garages Fast Charging On-Route Bus Cost ― Larger battery packs cost more. + Smaller battery packs cost less. Charger Cost + Slow-chargers typically cost less to purchase/install. ― Fast-chargers typically cost more to purchase/install. Garage Space ― Somewhat reduced garage capacity, likely need for indoor storage. + Lessened garage capacity impact.

27

slide-28
SLIDE 28

How will this technology evolve?

  • Maintenance costs
  • Battery prices
  • Charging
  • Bus prices

28

slide-29
SLIDE 29

Electric Bus Technologies: Real World Performance

slide-30
SLIDE 30

Real World Performance

  • Transit agencies should anticipate:
  • How much energy (kWh) is consumed per mile?

May increase 64% to 75% on very cold days due to heating May increase on hot days due to aid conditioning Also varies based on driver behavior (acceleration, braking)

  • Battery capacity will degrade over time
  • Not all of the battery capacity is usable (to avoid damage)
  • There should be a minimum reserve capacity drivers do not go below

(to avoid breakdowns)

30

Manufacturer claims will not tell the whole story!

Source: TriMet/CTE

slide-31
SLIDE 31

Battery Capacity

31

Source: TriMet/CTE

slide-32
SLIDE 32

Battery Capacity

32

Source: TriMet/CTE

slide-33
SLIDE 33

Planning Needed to Adopt Electric Buses

slide-34
SLIDE 34

Planning Needed to Adopt Electric Buses: Schedule Compatibility

slide-35
SLIDE 35

Schedule Analysis

Purpose

  • Determine whether electric buses can actually operate the transit

service they would be assigned

Methodology

  • Obtain the schedules of trips that buses would be assigned to
  • perate
  • Calculate each bus’s state of charge as it completes its schedule

Charge declines based on miles traveled Charge increases if on-route charging occurs

  • Identify what service is difficult to electrify so agency can make

changes

  • Repeat for various technologies being considered
  • INGENUITY. ACCESSIBILITY. INTEGRITY
slide-36
SLIDE 36

4:00 AM 6:00 AM 8:00 AM 10:00 AM 12:00 PM 2:00 PM 4:00 PM 6:00 PM 8:00 PM 10:00 PM 12:00 AM 2:00 AM

slide-37
SLIDE 37

Example of Technology Assumptions

Considered 8 different scenarios with range of inputs:

Operation Analysis Scenario Minimum layover charge time Maximum distance between charges Analysis 1: Fast-charge battery- electric buses

1 4 minutes 25 miles FC 2 10 minutes 25 miles FC 3 15 minutes 25 miles FC 4 15 minutes 40 miles FC

Analysis 2: Slow-charge battery- electric buses

5

  • 150 miles SC

6

  • 200 miles SC

7

  • 250 miles SC

8

  • 300 miles SC
slide-38
SLIDE 38

Example Results:

Service Eligible for BEB Operation

slide-39
SLIDE 39

39

Example Results:

Service Eligible for BEB Operation

slide-40
SLIDE 40

Planning Needed to Adopt Electric Buses: Facilities Updates

slide-41
SLIDE 41

Where Are On-Route Chargers Feasible?

  • Agency owns the layover space
  • There is space for the charging cabinet
  • Buses have dedicated bays (not back-to-back,

not on street)

slide-42
SLIDE 42
  • Identify locations that would be used

the most by electric buses

  • More chargers can make more

service eligible for BEBs

  • On-route chargers are very

expensive…

Develop Network of On-Route Charger Locations

slide-43
SLIDE 43

Garage Charging Impacts Capacity

43

1 2 3 4 5 6 7 9 8 8 2 3 4 5 6 7 1 Diesel Buses Electric Buses

slide-44
SLIDE 44

44

Equity Analysis

44

  • Deployment of electric buses

should consider social equity

  • f the areas that would

benefit

slide-45
SLIDE 45

Planning Needed to Adopt Electric Buses: Fleet Planning

slide-46
SLIDE 46
  • Depends on lifetime of a bus.

A bus fleet naturally turns over through one lifetime.

  • Example: The TriMet bus fleet

naturally turns over from 2020 to

  • 2036. Their bus lifetime is 16 years.

Replacing an Entire Fleet

slide-47
SLIDE 47

Replacing the Fleet

660 694 709 728 749 778 796 817 836 855 869 883 897 911 925 939 953 967 981

200 400 600 800 1,000 1,200 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027 2028 2029 2030 2031 2032 2033 2034 2035 2036

40- foot buses

slide-48
SLIDE 48

Replacing the Fleet

660 694 709 728 749 778 796 817 836 855 869 883 897 911 925 939 953 967 981

200 400 600 800 1,000 1,200 2018 2019 2020 2021 2022 2023 2024 2025 2026 2027 2028 2029 2030 2031 2032 2033 2034 2035 2036

Committed Diesel Fleet New Electric Fleet

Committed Purchases Transition Period 40- foot buses

slide-49
SLIDE 49
  • What garage is each bus assigned?
  • What size is each bus? (standard, articulated, other)
  • Is a pilot period needed before agency stops buying

diesel buses?

49

Also Consider

slide-50
SLIDE 50

King County Metro – Seattle, WA

Pilot Program

  • Started in 2016 with three fast charge

electric buses running on two routes

  • Strategy of leasing electric buses from

different manufacturers Type of E-Bus

  • Fast Charge battery-electric buses

(Proterra Catalyst)

  • Legacy E-Bus Fleet:
  • 174 Electric trolleys
  • 11 Battery-electric buses

Transition Period

  • Planning new zero emission bus garage
  • Goal for zero-emission fleet by 2040
  • Aims to purchase only zero-emission

buses starting in 2020

50

slide-51
SLIDE 51

Metropolitan Transportation Authority – New York, NY

Pilot Program

  • Three-year pilot program started in

2018

  • 10 electric buses running on the B32,

M42, and M50 routes Type of E-Bus

  • Battery-Electric buses (New Flyer

Excelsior CHARGE & Proterra) Current Fleet

  • 10 battery-electric buses
  • 15 articulated electric models

expected in October 2019

  • MTA intends to order 60 all-electric

buses depending on lessons learned from the pilot Transition Period

  • Aiming to transition to 100% electric fleet

by 2040

51

slide-52
SLIDE 52

Planning Needed to Adopt Electric Buses: Cost Projections

slide-53
SLIDE 53

Costs to Analyze

Costs to Agency

  • 1. Fuel Use
  • 2. Electricity Use
  • 3. Maintenance
  • 4. Vehicle Purchase
  • 5. Charger Infrastructure
  • 6. Savings from Incentives or Credits

Social Costs

  • 1. Emissions (Tailpipe and From Grid)
  • 2. Noise
  • ingenuity. accessibility. integrity.

53

slide-54
SLIDE 54

Building a Cost Model

  • Create a “fleet progression” showing

what vehicles will be in use during your planning period

  • For each cost category you model,

create a new tab that follows the structure of the progression

  • Accounting assumptions:
  • Inflation rate for future years
  • Discount rate for future dollars
  • Show one scenario or a range of

possibilities?

Fleet Progression

FLEET BUS GARAGE ID TYPE 2020 2021 2022 2023 2024 2025 2026 2027 2028 2029 2030 2031 2032 2033 2034 2035 2036 52 D P 54 7 55 D C 25 25 56 D M 39 39 33 20 57 D M 40 40 40 40 40 14 58 D P 51 51 51 51 51 51 51 51 51 5 59 D P 4 4 4 4 4 4 4 4 4 60 D C 70 70 70 70 70 70 70 70 70 70 23 61 D M 60 60 60 60 60 60 60 60 60 60 60 31 61 D C 8 8 8 8 8 8 8 8 8 8 8 8 59 D P 4 4 4 4 4 4 4 4 4 4 4 4 62 D C 30 30 30 30 30 30 30 30 30 30 30 30 18 64 D C 77 77 77 77 77 77 77 77 77 77 77 77 77 34 65 D P 50 50 50 50 50 50 50 50 50 50 50 50 50 50 12 66 D P 57 57 57 57 57 57 57 57 57 57 57 57 57 57 57 67 C P 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 68 D P 64 64 64 64 64 64 64 64 64 64 64 64 64 64 64 64 69 D C 71 71 71 71 71 71 71 71 71 71 71 71 71 71 71 71 71 70 D P 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 47 71 S M 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 72 D M 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 9 73 D C 29 29 29 29 29 29 29 29 29 29 29 29 29 29 29 74 S N 10 10 10 10 10 10 10 10 10 10 10 10 10 10 10 75 D N 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 76 D M 32 32 32 32 32 32 32 32 32 32 32 32 32 32 77 S M 10 10 10 10 10 10 10 10 10 10 10 10 10 10 78 D M 28 28 28 28 28 28 28 28 28 28 28 28 28 79 S M 10 10 10 10 10 10 10 10 10 10 10 10 10 80 S N 38 38 38 38 38 38 38 38 38 38 38 38 81 S M 9 9 9 9 9 9 9 9 9 9 9 9 82 S M 33 33 33 33 33 33 33 33 33 33 33 83 S M 19 19 19 19 19 19 19 19 19 19 84 S N 14 14 14 14 14 14 14 14 14 85 S P 46 46 46 46 46 46 46 46 86 S N 18 18 18 18 18 18 18 18 87 S C 34 34 34 34 34 34 34 88 S N 32 32 32 32 32 32 32 89 S M 20 20 20 20 20 20 90 S N 46 46 46 46 46 46 91 S C 44 44 44 44 44 92 S M 25 25 25 25 25 93 S C 47 47 47 47 94 S N 28 28 28 28 95 S P 25 25 25 96 S N 61 61 61 97 S P 65 65 98 S N 18 18 99 S P 52 100 S N 31 101 S N 102 S P 103 S N 104 S M 105 S N 106 S M 107 S N

slide-55
SLIDE 55

Vehicle Purchase 41% Maintenance 42% Fuel 1% Electricity 5% Charging Infrastructure 2% Credits

  • 9%

Costs by category for diesel fleet scenario Costs by category for electric bus fleet scenario

(50/50 Fast/Slow Mix)

Vehicle Purchase 30% Maintenance 59% Fuel 11% Only costs and credit to TriMet are shown. Moderate assumptions are used. Analysis covers vehicles added 2020-36.

Fiscal Analysis: Costs by Category

slide-56
SLIDE 56

Fiscal Analysis: Costs Over Time

56

$- $20,000,000 $40,000,000 $60,000,000 $80,000,000 $100,000,000 $120,000,000 $140,000,000 $160,000,000 $180,000,000 $200,000,000 2020 2021 2022 2023 2024 2025 2026 2027 2028 2029 2030 2031 2032 2033 2034 2035 2036 2037 2038 2039 2040 2041 2042 2043 2044 2045 2046 2047 2048 2049 2050 2051 2052

Projected Fleet Costs Over Time for Vehicles Added 2020-36

Diesel Scenario 50/50 Fast/Slow Scenario Only costs and credit to TriMet are shown. Moderate assumptions are used. All costs are shown in 2018 dollars.

slide-57
SLIDE 57
  • $300,000,000
  • $200,000,000
  • $100,000,000

$0 $100,000,000 $200,000,000 Fuel Use Electricity Use Maintenance Vehicle Purchase Charger Infrastructure Clean Fuel Credits RIN Credits

Costs Savings

Electric Bus Cost Differences

57

Average of moderate assumptions are used. Analysis covers vehicles added 2020-36.

  • $300,000,000
  • $200,000,000
  • $100,000,000

$0 $100,000,000 $200,000,000 Emissions (Tailpipe) Emissions (Power) Noise

Costs Savings

slide-58
SLIDE 58

Questions?
