slide-1
SLIDE 1

EHA Information Day

Regulation Air Operation Regulation Aircrew

Maritim Hotel, Cologne 20 September 2012

slide-2
SLIDE 2

Agenda - morning

Time Title Speakers 09.30-09.50 Introduction Vittorio Morassi Elisabetta Dalla Benetta Jean-Marc Cluzeau 09.50-10.20 Overview of Regulation on Air Operations Willy Sigl 10.20-10.50 Cover Regulation OPS Daniela Defossar 10.50-11.05 Coffee Break 11.05-12.05 Part-ORO (Organisation Requirements for Air Operations) Julia Egerer Arthur Beckand Daniela Defossar 12.05-13.05 Part-CAT (Commercial Air Transport) Willy Sigl Giovanni Cima Bas van der Weide 13.05-14.05 Lunch break

20.09.2012 EHA Information Day 2

slide-3
SLIDE 3

Agenda - afternoon

Time Title Speakers 14.05-14.50 Part-SPA (Specific Approvals) Willy Sigl Bas van der Weide 14.50-15.10 FTL (Flight and Duty Time Limitations) Daniel Coutelier 15.10-15.25 Coffee Break 15.25-15.40 On-going/future rulemaking tasks - introduction Daniela Defossar 15.40-16.00 HEMS, PIS Darko Vucic 16.00-16.20 Offshore operations Oyvind Friis-Ottessen 16.20-16.50 Overview to Regulation Aircrew Gerda Pardatscher 16.50-17.00 Final remarks Daniela Defossar Vittorio Morassi Elisabetta Dalla Benetta

20.09.2012 EHA Information Day 3

slide-4
SLIDE 4

Outline

Moderation – Introduction

Vittorio Morassi, EHA Elisabetta Dalla Benetta, EHA Jean – Marc Cluzeau, EASA

Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO Part-CAT Part-SPA FTL On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations Overview to Regulation Air crew Final remarks

20.09.2012 EHA Information Day 4

slide-5
SLIDE 5

Outline

Introduction

Overview of Regulation on Air Operations

Willy Sigl, EASA

Cover Regulation OPS Part-ORO Part-CAT Part-SPA FTL On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations Overview to Regulation Air crew Final remarks

20.09.2012 EHA Information Day 5

slide-6
SLIDE 6

European rule structure – Regulations

20.09.2012 EHA Information Day 6

Basic Regulation Airworthiness Regulation Initial airworthiness Regulation Continuing airworthiness Flight Standards Regulation Aircrew Regulation Air operations Regulation TCO ATM/ANS Regulation ATCO Regulation ANS Providers Regulation AUR Regulation ATM/ANS Oversight Regulation SERA Aerodromes Regulation ADR

ATM/ANS: air traffic management, air navigation services TCO: third country

  • perators

ATCO: air traffic controllers AUR: airspace usage requirements SERA: single European rules of the air ADR: aerodromes

slide-7
SLIDE 7

7

Rule structure – Regulation Air operations

Part-ARO: Authority requirements - OPS Part-ORO: Organisation requirements - OPS Part-CAT: Commercial air transport operations Part-SPA: Operations requiring specific approvals Part-NCC: non-commercial operations with complex motor-powered aircraft (CMPA) Part-NCO: non-commercial operations with

  • ther-than-CMPA

Part-SPO: specialised operations, e.g. aerial work

‘Cover’ Regulation Air operations Annex I Definitions Annex II Part-ARO Annex III Part-ORO Annex IV Part-CAT Annex V Part-SPA Annex VI Part-NCC Annex VII Part-NCO Annex VIII Part-SPO

EHA Information Day 20.09.2012

slide-8
SLIDE 8

Rule development in 4 phases

20.09.2012 EHA Information Day 8

Cover Reg. Definitions Part-ARO Part-ORO Part-CAT Part-SPA Part-NCC Part-NCO Part-SPO Phase OPS I

A, H

Phase OPS II Phase OPS III Phase OPS IV

S, B, A-to-A

initial version amendment

slide-9
SLIDE 9

Documents’ status

Publication planned for 4q/2012

20.09.2012 EHA Information Day 9

Cover Reg. Definitions Part-ARO Part-ORO Part-CAT Part-SPA Part-NCC Part-NCO Part-SPO Phase OPS I

A, H

Phase OPS II Phase OPS III Phase OPS IV

S, B, A-to-A

Adopted in EASA Committee Discussed in EASA Committee To be discussed in EASA Committee

IR:

  • Rule

development finalised

  • IR to be

published in the Official Journal AMC/GM:

  • Rule

development finalised/ final stage

  • Will be

published when IR are published

slide-10
SLIDE 10

Rule applicability

20.09.2012 EHA Information Day 10

Cover Reg. Definitions Part-ARO Part-ORO Part-CAT Part-SPA Part-NCC Part-NCO Part-SPO CAT

  • perator

NCC

  • perator

NCO

  • perator

NAA

S, H, A-to-A

SPO

  • perator

Com/non-com CMPA

slide-11
SLIDE 11

Annex II: Part-ARO

ARO – authority requirements, national aviation authorities, EASA .GEN – general requirements .OPS – air operations .RAMP – ramp inspections

Part-ARO .GEN

General Management Oversight, certification, enforcement

.OPS

Certification

  • f CAT

Approvals

.RAMP 20.09.2012 EHA Information Day 11

slide-12
SLIDE 12

12

Annex VI: Part-NCC

NCC – non-commercial

  • perations with complex

motor-powered aircraft

.GEN – general requirements

.OP – operational procedures .POL – performance and

  • perating limitations

.IDE – instruments, data, equipment .A, .H - aeroplanes, helicopters Part-NCC .GEN .OP .POL .IDE .A .H 20.09.2012 EHA Information Day

slide-13
SLIDE 13

13

Annex VII: Part-NCO

NCO – non-commercial

  • perations with other-than-

complex motor-powered aircraft

.GEN – general requirements

.OP – operational procedures .POL – performance and

  • perating limitations

.IDE – instruments, data, equipment .A, .H, .S, .B - aeroplanes, helicopters, sailplanes, balloons Part-NCO .GEN .OP .POL .IDE .A .H .S .B 20.09.2012 EHA Information Day

slide-14
SLIDE 14

14

Annex VIII: Part-SPO

SPO – specialised operations – commercial and non- commercial, all type of aircraft .SPEC – specific requirements

.HESLO – helicopter external

sling load operations .HEC – human external cargo

  • perations

.PAR – parachute operations .ABF – aerobatic flights Part- SPO .GEN .OP .POL .IDE .A .H .S .B .SPEC .HESLO .HEC .PAR .ABF 20.09.2012 EHA Information Day

slide-15
SLIDE 15

Transposition of JAR-OPS 3

20.09.2012

JAR-OPS 3 Part-CAT Part-SPA Part-ORO Part-ARO Annex 1 Others SUBPART A — Applicability and definitions DEF CR OPS SUBPART B — General GEN NVIS/HHO/ HEMS GEN/AOC/ MLR DEF SUBPART C — Operator certification and supervision GEN/AOC GEN/OPS SUBPART D — Operational procedures OP PBN GEN/MLR OPS DEF SERA AMC-20 SUBPART E — All weather operations OP LVO OPS DEF SERA SUBPART F — Performance general POL.H DEF SUBPART G — Performance Class 1 POL.H SUBPART H — Performance Class 2 POL.H SUBPART I — Performance Class 3 POL.H SUBPART J — Mass and balance POL.MAB DEF

EHA Information Day 15

slide-16
SLIDE 16

Transposition of JAR-OPS 3

JAR-OPS 3 Part-CAT Part-SPA Part-ORO Part-ARO Annex 1 Others SUBPART K — Instruments and equipment IDE.H. SUBPART L — Communication and navigation equipment IDE.H. SUBPART M — Helicopter maintenance Part-M SUBPART N — Flight crew FC DEF Part-FCL SUBPART O — Crew members other than flight crew TC SUBPART P — Manuals, logs and records OP GEN/MLR SUBPART Q — Flight and duty time limitations and rest requirements FTL DEF SUBPART R — Transport of dangerous goods by air GEN DG OPS DEF SUBPART S — Security GEN SEC

20.09.2012 EHA Information Day 16

slide-17
SLIDE 17

X-REF tables

  • Reg. OPS

IR/AMC/GM

  • Reg. OPS

rule reference

  • Reg. OPS

rule title EU-OPS/JAR-OPS3 IR/AMC/GM/IEM EU-OPS rule reference JAR-OPS3 rule reference EU-OPS/JAR-OPS3 rule title Difference to EU-OPS Classification Difference to EU-OPS Description Difference to JAR-OPS3 Classification Difference to JAR-OPS3 Description CAT.GEN.100 Competent Authority n.a. n.a. n.a. New Added to define the term "competent authority" in the context of CAT operations. New Added to define the term "competent authority" in the context of CAT operations. CAT.GEN.MPA.100 Crew responsibilities 1.085(a), (b), (c), (d) 3.085(a), (b), (c), (d) Crew responsibilities Amended Includes rules for crew undertaking duties for more than one operator. Amended Includes rules for crew undertaking duties for more than one operator. AMC1 CAT.GEN.MPA.100(b) Crew responsibilities COPIES OF REPORTS 1.085(b)(3) 3.085(b)(3) Crew responsibilities No change No change AMC1 CAT.GEN.MPA.100(c) Crew responsibilities ALCOHOL CONSUMPTION 1.085(e) 3.085(e) Crew responsibilities No change No change GM1 CAT.GEN.MPA.100(c) Crew responsibilities ELAPSED TIME BEFORE RETURNING TO FLYING DUTY n.a. n.a. n.a. New To further describe the term "elapsed time"; based on stakeholder comments. New To further describe the term "elapsed time"; based on stakeholder comments. GM1 CAT.GEN.MPA.100(c) Crew responsibilities PART-MED ACJ 1.085(e)(3) Crew responsibilities Amended Updated with link to Part-MED New scope of former ACJ extended to helicopter

  • perations

CAT.GEN.MPA.105 Responsibilities of the commander 1.085(f), (g) 3.085(f), (g) Crew responsibilities Amended Rules on the use of flight recorders amended to align with recent amendments to ICAO Annex 6. Amended Rules on the use of flight recorders amended to align with recent amendments to ICAO Annex 6. CAT.GEN.MPA.105(a)(13) Responsibilities of the commander 1.330 3.330(b) Accessibility of emergency equipment No change No change CAT.GEN.MPA.110 Authority of the commander 1.090 3.090 Authority of the commander No change Amended Aligned with CAT operations with

  • aeroplanes. The rule is addressed to the
  • perator and not to passengers.

CAT.GEN.MPA.115 Personnel or crew members other than cabin crew in the passenger compartment 1.040(b) Crew members No change AMC1 CAT.GEN.MPA.115 Personnel or crew members other than cabin crew in the passenger compartment MEASURES TO PREVENT CONFUSION BY PASSENGERS 1.989(b) Identification Amended Text amendment should better describe the intent of the rule. GM1 CAT.GEN.MPA.115 Personnel or crew members other than cabin crew in the passenger compartment CREW MEMBERS ON POSITIONING FLIGHTS 1.989(b) Identification New providing guidance on crew members on positioning flights and to prevent confusion with operating cabin crew A CAT.GEN.MPA.120 Common Language 1.025(a) 3.025(a) Common Language No change Amended Aligned with CAT operations with

  • aeroplanes. The rule does not mention
  • ther means acceptable to the authority.

A CAT.GEN.MPA.125 Taxiing of aeroplanes 1.095 Authority to taxi an aeroplane No change

20.09.2012

X-REF tables Comparison EASA OPS with JAR-OPS 3 and EU-OPS Difference statements Status: under progress, when finalised available for stakeholders

EHA Information Day 17

slide-18
SLIDE 18

Outline

Introduction Overview of Regulation on Air Operations

Cover Regulation OPS

Daniela Defossar, EASA

Part-ORO Part-CAT Part-SPA FTL On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations Overview to Regulation Air crew Final remarks

20.09.2012 EHA Information Day 18

slide-19
SLIDE 19

Cover Regulation

Article 1 Subject matter and scope Article 2 Definitions Article 3 Oversight capabilities Article 4 Ramp inspections Article 5 Air operations Article 6 Derogations Article 7 Air operator certificates Article 8 Flight time limitations Article 9 Minimum equipment lists Article 10 Entry into force

EHA Information Day 19 20.09.2012

slide-20
SLIDE 20

Cover Regulation

Scope OPS Regulation Applicable to all EU operators using EU or third country registered aircraft and the personnel involved in the

  • peration of such aircraft

Initial issue of cover regulation will address CAT by aeroplane and helicopter, except A-A operations with performance class B aeroplanes and non-complex helicopters and CAT by sailplane and balloons Amending regulations will cover (later): Non-commercial operations (NCC/NCO) Specialised operations (SPO) Operational Suitability Data (OSD) CAT A-A and CAT sailplanes and balloons

20 20.09.2012 EHA Information Day

slide-21
SLIDE 21

Cover Regulation

Scope OPS Regulation Excluded for the time being: certain Annex II aircraft when used in CAT operations: to be operated in accordance with the conditions contained in a Commission Decision adopted under EU-OPS airships, tilt-rotor aircraft, tethered balloons and remotely piloted aircraft flights conducted by design or production organisations and related to this activity Those will be subject to future Rulemaking tasks

21 20.09.2012 EHA Information Day

slide-22
SLIDE 22

Cover Regulation

Scope OPS Regulation Derogations applicable to helicopter operations: Additional conditions and approval for helicopter

  • ffshore operations

Helicopter operations to public interest sites may continue outside performance class 1 and under conditions defined by the MS On-going rulemaking tasks will gradually address these issues

22 20.09.2012 EHA Information Day

slide-23
SLIDE 23

Cover Regulation

Conversion of JAR-OPS 3 AOC MS to establish conversion report describing: the national requirements on the basis of which the AOCs were issued; the scope of privileges that were given to the

  • perators;

the differences between the national requirements on the basis of which the AOCs were issued and the requirements of Part-ORO/CAT/SPA, together with an indication of how and when the operators will be required to ensure full compliance with those Annexes New AOC to be issued when full compliance is shown

23 20.09.2012 EHA Information Day

slide-24
SLIDE 24

Cover Regulation

Entry into force and applicability Expected publication date by end October 2012 Enters into force and applies 3 days after publication in Official Journal MS may postpone applicability by 2 years for CAT Existing rules remain in force during that time

24 20.09.2012 EHA Information Day

slide-25
SLIDE 25

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS

Part-ORO

Julia Egerer, EASA Arthur Beckand, EASA Daniela Defossar, EASA

Part-CAT Part-SPA FTL On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations Overview to Regulation Air crew Final remarks

20.09.2012 EHA Information Day 25

slide-26
SLIDE 26

Annex III: Part-ORO

Applicability: CAT operators NCC operators SPO operators Commercial Non-commercial with complex aircraft

20.09.2012

‘Cover’ Regulation Air operations Annex I Definitions Annex II Part-ARO Annex III Part-ORO Annex IV Part-CAT Annex V Part-SPA Annex VI Part-NCC Annex VII Part-NCO Annex VIII Part-SPO

EHA Information Day 26

slide-27
SLIDE 27

Annex III: Part-ORO

.GEN – general requirements .AOC – air operator certification .DEC – declaration .MLR – manual, logs, records .SEC – security .FC – flight crew .CC – cabin crew .TC – technical crew .FTL – flight time limitations

Part-ORO .GEN .AOC .DEC .MLR .SEC .FC .CC .TC .FTL

20.09.2012 EHA Information Day 27

slide-28
SLIDE 28

ORO.GEN

20.09.2012 EHA Information Day 28

ORO.GEN.105 Competent authority

  • Definition of principle place of

business as Reg. (EC) No 1008/2008 ORO.GEN.130 Changes to organisations

  • Prior approval for some major

changes, see GM in ORO.GEN, e.g. changes to management system

  • Minor changes: procedure agreed

with competent authority ORO.GEN.200 Management system

  • Implements ICAO standards on

safety management systems (SMS)

  • Lists the elements that the
  • rganisations must address.
  • Safety concern for all personnel

Part-ORO .GEN .AOC .DEC .MLR .SEC .FC .CC .TC .FTL

slide-29
SLIDE 29

ORO.GEN.200 : KEY POINTS

SMS is addressed as part of “Organisation Requirements – Management System” Organisation requirements

  • are compatible with existing management systems
  • encourage integrated management
  • provide proportionality (complex versus non-complex
  • rganisations)
  • provide flexibility (details in AMC)

These organisation requirements set the standard for implementing SMS in the other areas within EASA’s remit.

EHA Information Day 20.09.2012 29

slide-30
SLIDE 30

(a) An operator shall establish, implement and maintain a management system that includes: (1) clearly defined lines of responsibility and accountability throughout the

  • rganisation, including a direct safety accountability of the accountable

manager; (2) a description of the overall philosophies and principles of the organisation with regard to safety, referred to as the safety policy; (3) the identification of aviation safety hazards entailed by the activities

  • f the organisation, their evaluation and the management of

associated risks, including taking effective actions to mitigate the risk; (4) maintaining personnel trained and competent to perform their tasks; (5) documentation of all management system key processes, including a process for making personnel aware of their responsibilities, and its amendment procedure; (6) a function to monitor compliance of the organisation with the relevant

  • requirements. Compliance monitoring shall include a feedback system of

findings to the accountable manager to ensure effective implementation of corrective actions as necessary.

Management System

most relevant IR: ORO.GEN.200 (extract)

EHA Information Day 20.09.2012 30

slide-31
SLIDE 31

SMS integrated approach

31

Management System

Safety management Compliance monitoring Responsibilities & Accountability Personnel requirements Facilities Contracting Finance & Budget

20.09.2012 EHA Information Day

slide-32
SLIDE 32

32

Integrated approach

Safety, as well as compliance with rules, should be a concern for all personnel and for all activities of the organisation. Safety management should include every facet of management that may impact aviation safety (financial, operational, health and safety, etc…). SMS should not be implemented through an additional management system requirement superimposed onto the existing rules, but be fully integrated in the organisation’s existing management system.

20.09.2012 EHA Information Day

slide-33
SLIDE 33

33

Proportionality

How is this achieved?

different sets of AMCs for “complex” and “non-complex”

  • rganisations

details of SMS implementation are contained as AMC The management system shall correspond to the size of the

  • rganisation and the complexity of its activities, taking into

account the hazards and associated risks inherent in these activities. (see also ICAO Annex 6 Appendix 7)

20.09.2012 EHA Information Day

slide-34
SLIDE 34

34

Proportionality

Definition of organisational complexity - three criteria:

Size, in terms of staffing Complexity of the activities

number of operating sites number and type of contractors …

Risks involved

type of operations, e.g. specialised operations (helicopter external sling load) type of aircraft

  • perating environment (offshore ….)

20.09.2012 EHA Information Day

slide-35
SLIDE 35

35

Organisations may use means alternative to those established in the AMC issued by the Agency: “alternative means of compliance”

  • Organisations need to apply to their competent

authority and demonstrate that an equivalent level

  • f safety can be reaiched.
  • They may use such alternative means of compliance

following approval by their competent authority.

Flexibility

20.09.2012 EHA Information Day

slide-36
SLIDE 36

Annex III: Part-ORO

.GEN – general requirements .AOC – air operator certification .DEC – declaration .MLR – manual, logs, records .SEC – security .FC – flight crew .CC – cabin crew .TC – technical crew .FTL – flight time limitations

Part-ORO .GEN .AOC .DEC .MLR .SEC .FC .CC .TC .FTL

20.09.2012 EHA Information Day 36

slide-37
SLIDE 37

Subpart AOC – Air Operator certification

20.09.2012 EHA Information Day 37

slide-38
SLIDE 38

Main Issues/changes

20.09.2012 EHA Information Day 38

  • Non-commercial operations of

aircraft listed in the operations specifications by the holder of an AOC

  • Leasing
slide-39
SLIDE 39

Leasing

Main comments from stakeholders: Imposing Part-OPS and ORO will make wet lease-in impossible Realign with EU.OPS and Regulation (EC) No 1008/2008 “Community or equivalent safety standards” Dry lease – in not addressed

20.09.2012 EHA Information Day 39

slide-40
SLIDE 40

Leasing

20.09.2012 EHA Information Day 40

slide-41
SLIDE 41

ORO.AOC.125

Non-commercial operations of aircraft listed in the

  • perations specifications by the holder of an AOC

No declaration is needed Identification of: the applicable requirements differences between operating procedures when used in commercial and non-commercial operations Update of personnel Prior approval

20.09.2012 EHA Information Day 41

slide-42
SLIDE 42

Annex III: Part-ORO

.GEN – general requirements .AOC – air operator certification .DEC – declaration .MLR – manual, logs, records .SEC – security .FC – flight crew .CC – cabin crew .TC – technical crew .FTL – flight time limitations

Part-ORO .GEN .AOC .DEC .MLR .SEC .FC .CC .TC .FTL

20.09.2012 EHA Information Day 42

slide-43
SLIDE 43

Subpart DEC- Declaration (ORO.DEC.100)

This Subpart complements ARO.GEN.345 Applicability

  • Non-commercial operators of complex motor-powered aircraft (NCC
  • perators) to provide a declaration to the state of the operator.
  • includes managed aircraft operations which are undertaken as non-

commercial operations

Intent

  • perator acknowledges its responsibilities under the applicable safety

regulations and that it holds all necessary approvals;

  • informs the competent authority of the existence of an operator; and
  • enables the competent authority to fulfil its oversight responsibilities

20.09.2012 EHA Information Day 43

slide-44
SLIDE 44

Subpart DEC- Declaration

Procedure The operators submits the declaration to the competent authority before the intended starting date of operations In case of changes to the content of the declaration, the operator informs the competent authority thereof Declaration form is included as Appendix I to Part-ORO The competent authority acknowledge receipt of the declaration - such a receipt is not a condition for starting the operation

20.09.2012 EHA Information Day 44

slide-45
SLIDE 45

ORO.MLR: Manuals, Logs and Records

20.09.2012 EHA Information Day 45

ORO.MLR.100 Operations Manual- general

  • Up to date & inform relevant personnel
  • n changes to manual

ORO.MLR.101 Structure of Manual for CAT

  • Part A, B, C & D

ORO.MLR.105 Minimum Equipment List

  • Approved by competent authority
  • MEL based on MMEL resulting from the

OSD ORO.MLR.110 Journey log ORO.MLR.115 Record Keeping

  • Management System information 5 yrs
  • Operational information 3 yrs

Part-ORO .GEN .AOC .DEC .MLR .SEC .FC .CC .TC .FTL

slide-46
SLIDE 46

Annex III: Part-ORO

.GEN – general requirements .AOC – air operator certification .DEC – declaration .MLR – manual, logs, records .SEC – security .FC – flight crew .CC – cabin crew .TC – technical crew .FTL – flight time limitations

Part-ORO .GEN .AOC .DEC .MLR .SEC .FC .CC .TC .FTL

20.09.2012 EHA Information Day 46

slide-47
SLIDE 47

ORO.FC

20.09.2012 EHA Information Day 47

Additional requirements NCC & all commercial

  • perators

Section I Common requirements Section II CAT Section III com SPO & CAT (A-to-A)

slide-48
SLIDE 48

ORO.FC

NCC based on ICAO Annex 6 commercial SPO and CAT (A-to-A) in addition: annual proficiency check CAT based on JAR-OPS 3

20.09.2012 EHA Information Day 48

slide-49
SLIDE 49

ORO.FC

Highlights CRM for single pilot operations now mandated (ORO.FC.115) Integration of Operational Suitability Data (OSD) (ORO.FC.145) for operators to account for OSD standards and recommendations when developing their training programmes FSTD “user approval” for commercial operators: FSTD shall replicate the aircraft, as far as possible management of differences between FSTD and aircraft management of changes to the FSTD

20.09.2012 EHA Information Day 49

slide-50
SLIDE 50

Annex III: Part-ORO

.GEN – general requirements .AOC – air operator certification .DEC – declaration .MLR – manual, logs, records .SEC – security .FC – flight crew .CC – cabin crew .TC – technical crew .FTL – flight time limitations

Part-ORO .GEN .AOC .DEC .MLR .SEC .FC .CC .TC .FTL

20.09.2012 EHA Information Day 50

slide-51
SLIDE 51

ORO.TC – applicability and main change

51

Applicability:

technical crew members in commercial air transport HEMS, HHO, NVIS operations further experience and training requirements for HEMS, HHO and NVIS operations are contained in the specific Part-SPA subparts aerial work task specialists are included in Part-SPO

20.09.2012 EHA Information Day

slide-52
SLIDE 52

ORO.TC – applicability and main change

20.09.2012 EHA Information Day 52

Main change compared to JAR-OPS 3: no limitation

  • n number of types in IR anymore
  • perator to specify the maximum number of

types in the OM, taking into account the specific

  • perating environment, equipment, procedures
slide-53
SLIDE 53

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO

Part-CAT

Willy Sigl, EASA Bas van der Weide, EASA Giovanni Cima, EASA

Part-SPA FTL On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations Overview to Regulation Air crew Final remarks

20.09.2012 EHA Information Day 53

slide-54
SLIDE 54

Annex IV: Part-CAT

Applicability: CAT operators complex aircraft: A,H non-complex aircraft: A, H, S, B A-to-A operations

20.09.2012

‘Cover’ Regulation Air operations Annex I Definitions Annex II Part-ARO Part-III Part-ORO Annex IV Part-CAT Annex V Part-SPA Annex VI Part-NCC Annex VII Part-NCO Annex VIII Part-SPO

EHA Information Day 54

slide-55
SLIDE 55

Annex IV: Part-CAT

CAT – commercial air transport .GEN – general requirements .OP – operational procedures .POL – performance and

  • perating limitations

.IDE – instruments, data, equipment .MPA – motor-powered aircraft .NMPA – non-motor-powered aircraft .A, .H, .S, .B - aeroplanes, helicopters, sailplanes, balloons .MAB – mass and balance

Part-CAT .GEN .MPA .NMPA .OP .MPA .NMPA .POL .A .H .MAB .S .B .IDE .A .H .S .B 20.09.2012 EHA Information Day 55

slide-56
SLIDE 56

Annex IV: Part-CAT

General remarks Part contains technical rules for all CAT operations Part structured into aircraft-specific sections/chapters Part can be easily amended for other aircraft categories, e.g. tilt rotor, airships, remotely piloted aircraft systems Rule material aligned with the content of Section 1 of JAR-OPS 3 Section 2 material of JAR-OPS 3 Improved balance between Implementing Rules and AMC/GM JAR-OPS 3 text has been given precedence over ICAO SARPs

20.09.2012 EHA Information Day 56

slide-57
SLIDE 57

CAT.GEN.MPA – amendments

Crew responsibilities CAT.GEN.MPA.100 / 3.085(a), (b), (c), (d) Includes rules for crew undertaking duties for more than

  • ne operator

Portable electronic devices AMC 1 CAT.GEN.MPA.140 Transposing and amending parts of TGL29: new approach to risk assessment general allowance for Bluetooth is removed definition for switched-off status added criteria for demonstrating that radiation levels are tolerable to the aircraft systems added

20.09.2012 EHA Information Day 57

slide-58
SLIDE 58

CAT.GEN.MPA – amendments

Documents, manuals and information to be carried CAT.GEN.MPA.180 / 3.050, 3.125, 3.130, 3.135 extends the use of electronic documents clarifies which documents need to be original: CoR, CoA, radio licence copy of the AOC to be a certified true copy journey log to be carried alleviations for A-to-A and local operations Preservation, production and use of flight recorder recordings CAT.GEN.MPA.195 / 3.160 rule updated with recent ICAO amendments

20.09.2012 EHA Information Day 58

slide-59
SLIDE 59

CAT.GEN.MPA – amendments

Transport of dangerous goods CAT.GEN.MPA.200 / 3.1160, 3.1165 CAT.GEN address the circumstances under which DG might be carried without holding an SPA.DG approval Dynamic reference to T.I. Extracts from the T.I. are not repeated except those specifying certain operator responsibilities

20.09.2012 EHA Information Day 59

slide-60
SLIDE 60

CAT.OP.MPA – amendments

Aerodrome operating minima CAT.OP.MPA.110 / 3.225, 3.430, Appendix 1 to 3.430 Part-CAT contains the operator requirement to establish aerodrome operating minima The associated AMC material contains the detailed rules for take-off (except LVTO), NPA, APVs, CAT I and circling

  • perations

All rules below related to LVTO and operations below CAT I minima are prescribed in SPA.LVO System minima tables have been amended with operations using GNSS facilities Airborne radar approaches (ARAs) for overwater

  • perations do not need a prior authorisation

20.09.2012 EHA Information Day 60

slide-61
SLIDE 61

CAT.OP.MPA – amendments

Fuel policy CAT.OP.MPA.150 / 3.255 The fuel policy and any change to it require a prior approval by the competent authority Carriage of special categories of passengers (SCPs) CAT.OP.MPA.155 / 3.260, 3.265 Redrafted taking into account Regulation (EC) No 1107/2006 concerning the rights of disabled persons and persons with reduced mobility when travelling by air

20.09.2012 EHA Information Day 61

slide-62
SLIDE 62

CAT.OP.MPA – amendments

Ground proximity detection TERRAIN AWARENESS WARNING SYSTEM (TAWS) FLIGHT CREW TRAINING PROGRAMMES CAT.OP.MPA.290 Transposes with minor amendments TGL 27 Use of airborne collision avoidance system (ACAS) CAT.OP.MPA.295 / 3.398 The operator shall establish operational procedures and training programmes; the IR links to AUR.ACAS, Commission Regulation (EU) No 1332/2011

20.09.2012 EHA Information Day 62

slide-63
SLIDE 63

CAT.OP.MPA – amendments

Commencement and continuation of approach CAT.OP.MPA.305 / 3.405 The outermarker is replaced by 1 000 ft; additional rule for approaches where the DH/MDH is above 1 000 ft of the aerodrome height. A new AMC summaries the specifications for visual references for different approach operations. The rule sources for this AMC are the specifications for visual references contained in Appendix 1 OPS 3.430. The text for EVS has been amended to align with SPA.LVO.110(c)

20.09.2012 EHA Information Day 63

slide-64
SLIDE 64

CAT.POL.H

20.09.2012 EHA Information Day 64

Scope of CAT.POL.H Performance and operating limitations (POL) for CAT

  • perations with helicopters (H)

Containing all performance requirements, including specific approvals (except HEMS and HHO) CAT.POL.H consists of 4 Chapters following JAR-OPS 3 structure Chapter 1 – General requirements Chapter 2 – Performance class 1

Appendix 1 to JAR-OPS 3.005(i) – Public Interest Site

Chapter 3 – Performance class 2

Appendix 1 to JAR-OPS 3.517(a) – Operations without an assured safe forced landing capability

Chapter 4 – Performance class 3

Appendix 1 to JAR-OPS 3.005(e) – Mountain and remote areas in Performance class 3

slide-65
SLIDE 65

CAT.POL.H

20.09.2012 EHA Information Day 65

Appendix 1 to JAR-OPS 3.005(c) not transposed - contradicting the Essential Requirements (4.a.) This issue is currently being addressed by RMT.0132

Agency task foreseen to be concluded by 2016

Operations without an assured safe forced landing capability For legal clarity reason, the ‘set of conditions’ to be implemented to operate without an assured safe forced landing capability is spelled out and no longer explained in an AMC There will be a new GM to explain under which circumstances FADEC can be considered as a recording device for the purpose of recording the required engine parameters

slide-66
SLIDE 66

CAT.POL.H

20.09.2012 EHA Information Day 66

Specific approvals CAT.POL.H.225 – Helicopter operations to/from a Public Interest Site CAT.POL.H.420 – Helicopter operations over a hostile environment located outside a congested area The obligation for obtaining a prior approval of the authority of the State in which it is intended to conduct these operations has been changed into the obligation to obtain an endorsement. In cases where that authority is not the same as the authority issuing the AOC.

slide-67
SLIDE 67

CAT.POL.H

20.09.2012 EHA Information Day 67

Specific approvals CAT.POL.H.225 – Helicopter operations to/from a Public Interest Site Changes have been made to reflect EASA competence

Aerodromes, including equipment, located in the territory subject to the provisions of the Treaty, open to public use and which serve commercial air transport and where operations using instrument approach or departure procedures are provided, and: (a) have a paved runway of 800 m or above; or (b) exclusively serve helicopters; shall comply with this Regulation. Personnel and organisations involved in the operation of these aerodromes shall comply with this Regulation.

EASA can therefore not mandate a site improvement programme for hospital sites

EASA will endeavour to make Member States aware of this necessity by promoting its inclusion in the SSP of the Member States and investigate the inclusion in the EASP/EASp.

slide-68
SLIDE 68

CAT.POL.H

20.09.2012 EHA Information Day 68

Chapter 1 – General requirements Small changes, to better differentiate between the

  • bjective and method of compliance

Definitions aligned with CS definitions, and updated since EASA is the authority responsible for the TC Several are deleted, as they have become obsolete as a result of definitions used in the Basic Regulation CAT.POL.H.110 – obstacle accountability

slide-69
SLIDE 69

CAT.POL.H

20.09.2012 EHA Information Day 69

Chapter 2 – Performance class 1 Small changes, to delete duplication Chapter 3 – Performance class 2 Already mentioned before the ‘set of conditions’ to be implemented to operate without an assured safe forced landing capability is spelled out and no longer explained in an AMC New GM addressing FADEC for the purpose of recording the required engine parameters

slide-70
SLIDE 70

CAT.POL.H

20.09.2012 EHA Information Day 70

Chapter 4 – Performance class 3 CAT.POL.H.420 – helicopter operations over a hostile environment located outside a congested area Redrafted following the outcome of discussions in the EASA committee Approval can only be given following a safety risk assessment by the operator Elements to be considered in this safety risk assessment are now included in a new AMC An example of a safety risk assessment is provided in new GM Current text agreed with the Commission

slide-71
SLIDE 71

20.09.2012 71

CAT.POL.MAB

Scope and content of CAT.POL.MAB Implementing Essential Requirements for air operations referred to in Article 8 of Reg. (EC) No 216/2008 Annex IV:

  • 2. Flight preparation

2.a.3. (iv) Mass and balance 2.a.3. (v) Loading

while preserving as much as possible existing standards (JAR-OPS 3 subpart J & related Section 2 material) CAT.POL.MAB consists of two chapters:

Chapter 1 – motor-powered aircraft Chapter 2 – other-than motor-powered aircraft

EHA Information Day

slide-72
SLIDE 72

72

CAT.POL.MAB

Scope and content of CAT.POL.MAB (cont.) Unlike the rest of Subpart POL, where the performance requirements are broken down into aircraft-specific sections, mass and balance requirements were kept together, since only a few differences exist between aeroplanes and helicopters. Only two implementing rules in the final version:

CAT.POL.MAB.100 Mass and balance, loading CAT.POL.MAB.105 Mass and balance data and documentation

Appendices are transposed at AMC level Some further changes have been introduced after the public consultation of the NPA and the CRD

20.09.2012 EHA Information Day

slide-73
SLIDE 73

73

CAT.POL.MAB

Differences to JAR-OPS 3 Appendix 1 to OPS 3.605 and related IEM:

Text on CG limits, operational CG envelope and in-flight CG has been merged and clarified at AMC level (AMC1 CAT.POL.MAB.100(b)).

OPS 3.607 - Terminology

Definitions have been moved to Annex I – Definitions and its AMC.

OPS 3.620 and Appendices:

Approval for alternative standard masses are no longer required. The approval process is replaced by the alternative means of compliance

  • procedure. A similar change has been made for pooled weighing

surveys performed by different operators. (AMC1 CAT.POL.MAB.100(e)) Additional criteria for the approval of standard masses for load items

  • ther than passengers and baggage is added.

(CAT.POL.MAB.100 (f))

20.09.2012 EHA Information Day

slide-74
SLIDE 74

74

CAT.POL.MAB

Differences to JAR-OPS 3 (cont.) OPS 3.625 and Appendixes:

Flexibility for managing tolerances when using fleet CGs has been allowed for, provided a proper risk assessment is completed by the

  • perator. (AMC1 CAT.POL.MAB.100(b))

Mass and balance computer systems (CAT.POL.MAB.105(e) / GM1 & GM2 CAT.POL.MAB.105(e))

Mass and balance documentation provisions expanded to cover the use

  • f different types of mass and balance systems.

A GM has been added to provide definitions on “on-board integrated mass and balance computer system” and “stand alone computerised mass and balance system”.

Electronic signature (AMC1 CAT.POL.MAB.105(c))

AMC added to clarify what can be considered equivalent to a signature.

20.09.2012 EHA Information Day

slide-75
SLIDE 75

CAT.IDE.H

Scope and content of CAT.IDE.H Implementing Essential Requirements for air operations referred to in Article 8 of EC 216/2008 Annex IV:

  • 5. Instruments, data and equipment

5.a Equipment necessary for the intended flight 5.b Safety, medical, evacuation and survival equipment 5.c Data necessary for the execution of the flight

while preserving as much as possible existing standards (JAR-OPS 3 subpart K, L & related Section 2 material), ensuring compliance with ICAO SARPs and taking into account certain JAA NPAs. Subpart IDE consists of four sections addressing different aircraft categories. Helicopters are covered in Section 2.

20.09.2012 EHA Information Day 75

slide-76
SLIDE 76

CAT.IDE.H

Scope and content of CAT.IDE.H (cont.) The rule sequence is aligned as much as possible with JAR- OPS 3 Subparts K and L respectively. Equipment and instruments specifications are, as far as possible, given at AMC level, being performance objectives set at IR level. This approach, while ensuring flexibility, will also facilitate the development of alternative AMCs in the future. Proportionality is ensured using criteria of Mass, Passenger seating configuration (MOPSC) or date of first issue of the CofA in order to define the applicability of certain requirements. Further changes have been introduced after the public consultation of the NPA and the CRD.

20.09.2012 EHA Information Day 76

slide-77
SLIDE 77

CAT.IDE.H

20.09.2012 77

Differences to JAR-OPS 3 Approval of instruments and equipment

The approval requirements on the instruments and equipment required by CAT.IDE.H.100 have been drafted with regard to Part-

  • 21. Additional provisions have been added to ensure that

instruments and equipment not required by Part-CAT, that do not need to be approved in accordance with Part-21, are not used for safety functions and do not affect airworthiness.

MEL

The former content of OPS 3.030 is transposed in Subpart IDE (CAT.IDE.H.105)

EHA Information Day

slide-78
SLIDE 78

CAT.IDE

20.09.2012 78

Differences to JAR-OPS 3 (cont.) Cockpit voice & flight data recorders

These requirements (CAT.IDE.H.185/190) have been revised in accordance with the latest developments of ICAO Annex 6 and EUROCAE standards taking into account certain JAA NPAs. Relevant AMCs and GMs have been developed

Data link recording

A requirement for recording of data link communications (CAT.IDE.H.195) is added in accordance with ICAO Annex 6 The date for mandating data link communication recording ideally should be as soon as data link is used for essential VHF communications, but many comments requested sufficient notice to avoid costly retrofit. It is proposed to mandate two years after the OPS Regulation enters into force, i.e. 2014. Relevant AMCs and GMs have been developed

EHA Information Day

slide-79
SLIDE 79

CAT.IDE.H

20.09.2012 79

Restraint systems

The requirements on upper torso restraint (UTR) systems (CAT.IDE.H.205) have been updated.

Oxygen

The alleviation for oxygen requirements for pilots (CAT.IDE.H.240) is kept, as originally given in JAR-OPS 3, for other-than-complex helicopters operated between 10 000 ft and 13 000 ft for a period up to 30 minutes, after comments to the CRD. Further exemptions for short incursions between 13 000 ft and 16 000ft, originally foreseen by JAR-OPS 3 under a specific approval of the authority will have to be handled through Article 14 of the Basic Regulation. These further exemptions are not in line with ICAO SARPs and to be approved should be based on specific mitigating measures (e.g. operator’s experience, pilot’s physiological adaptation to certain altitudes. Furthermore, they would usually be achievable only in certain regions (i.e. mountainous areas).

EHA Information Day

slide-80
SLIDE 80

CAT.IDE.H

20.09.2012 80

Differences to JAR-OPS3 (cont.) Fire extinguishers

The JAR provision mandating the use of Halon have been removed to comply with Regulation (EC) No 1005/2009 that forbids its use. The new rule (CAT.IDE.H.250) contains a general safety objective on the efficiency of the fire extinguishing agent. In order to allow a smooth transition from Halon to new extinguishing agents.

First-aid kits

This requirement (CAT.IDE.H.220) has been updated with regards to maintenance and replenishment of the kit after use and especially with regards to the content to comply with the latest ICAO developments and to take into account a JAA NPA.

Emergency lighting and marking

Requirements on emergency exit markings visibility are clarified and regrouped in the same rule (CAT.IDE.H.275) for large helicopters and helicopters operated overwater under certain conditions.

EHA Information Day

slide-81
SLIDE 81

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO Part-CAT

Part-SPA

Willy Sigl, EASA Bas van der Weide, EASA

FTL On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations Overview to Regulation Air crew Final remarks 20.09.2012 EHA Information Day 81

slide-82
SLIDE 82

Annex IV: Part-SPA

Applicability: To all operators conducting an operation requiring a specific approval

20.09.2012

‘Cover’ Regulation Air operations Annex I Definitions Annex II Part-ARO Part-III Part-ORO Annex IV Part-CAT Annex V Part-SPA Annex VI Part-NCC Annex VII Part-NCO Annex VIII Part-SPO

EHA Information Day 82

slide-83
SLIDE 83

Annex V: Part-SPA

Part-SPA .GEN .PBN .MNPS .RVSM .LVO .ETOPS .DG .NVIS .HHO .HEMS .GEN – general requirements .PBN – performance based navigation .MNPS – minimum navigation performance specifications .RVSM – reduced vertical separation minima .LVO – low visibility operations .ETOPS – extended range operations with two- engined aeroplanes .DG – dangerous goods .NVIS – night vision imaging systems .HHO – helicopter hoist operations .HEMS – helicopter emergency medical services 20.09.2012 EHA Information Day 83

slide-84
SLIDE 84

SPA.GEN

SPA.GEN.100 Competent authority Competent authority for commercial operations:

  • perator’s principal place of business

Competent authority for non-commercial operations: place where the operator is established or residing For non-commercial operators using aircraft registered in a third country, the approvals for PBN should be issued by the third country State of Registry.

84 20.09.2012 EHA Information Day

slide-85
SLIDE 85

SPA.GEN

SPA.GEN.110 Documentation of specific approvals for commercial operations: “operations specifications” (OPSPECS) for non-commercial operations: “list of specific approvals” The corresponding authority requirements are specified in Part-ARO including the forms for OPSPECS and list of specific approvals

EHA Information Day 85 20.09.2012

slide-86
SLIDE 86

SPA.PBN

Overview of operations and reference documents

86 EASA AMC Other documents RNAV 10 AMC 20-12 FAA order 8400.12a RNAV 5 (B-RNAV) (approval not required) AMC 20-4 TGL 2 RNAV2 (non-European) To be developed RNAV 1 (~P-RNAV) To be developed TGL10 RNP 4 To be developed ICAO DOC 9613 BASIC-RNP 1 To be developed ICAO DOC 9613 RNP APCH (LNAV) AMC 20-27 ICAO DOC 9613 RNP APCH (LNAV/VNAV) AMC 20-27 ICAO DOC 9613 RNP APCH (LPV) AMC 20-28 RNP AR APCH AMC 20-26 20.09.2012 EHA Information Day

slide-87
SLIDE 87

SPA.LVO

Sources: OPS 3.430 Appendix 1 to OPS 3.430 Related Section 2 material Containing: LVTO LTS CAT I CAT II OTS CAT II CAT III approach operation utilising EVS for which an operational credit on RVR minima is applied

87 20.09.2012 EHA Information Day

slide-88
SLIDE 88

SPA.LVO

Key issues Operating minima Lowest minima are defined in Annex I – Definitions LVO-related rules transposed in Part-SPA Non-LVO related rules transposed in CAT.OP.110 Relevant provisions of Appendix 1 to OPS 3.430 moved to AMC Harmonisation with FAA provisions For LVTO: RVR minima depending on aerodrome lighting facilities For failed or downgraded equipment: effect on

  • perating minima

20.09.2012 88 EHA Information Day

slide-89
SLIDE 89

SPA.LVO

Key issues (cont.) LVTO Approval required for take-off with an RVR <400m For LVTO with RVR 150m<x<400m training programme required For LVTO with RVR <150m additional conditions EVS / OTS CAT II Amendments with safety justifications Operations with call-outs below 200ft the terrain ahead

  • f the runway threshold should be surveyed

20.09.2012 89 EHA Information Day

slide-90
SLIDE 90

SPA.LVO

Key issues (cont.) LVP Required for all LVO New subparagraph added to clarify the application of the requirement where the term LVP is not used

20.09.2012 90 EHA Information Day

slide-91
SLIDE 91

SPA.DG

Changes to JAR-OPS 3 Dynamic reference to the ICAO Technical Instructions (T.I.) SPA.DG is shorter than Subpart R Extracts from the T.I. are not repeated Remind: CAT.GEN address the circumstances under which DG might be carried without holding an SPA.DG approval

20.09.2012 91 EHA Information Day

slide-92
SLIDE 92

SPA.NVIS

92 20.09.2012 EHA Information Day

Transposition of: JAR-OPS 3.005 (j) Inclusion of: JAA TGL-34 Changes: Deletion of all reference to covert operations

References to IR lights/capability

Only applicable to CAT(H) EASA (and rulemaking group) has no knowledge of NVIS

  • perations outside CAT (within the remit)

Therefore no expertise for determining what proportionate rules may be for other than CAT operations

slide-93
SLIDE 93

SPA.HHO

Transposition of: JAR-OPS 3.005 (h) Appendix 1 to JAR-OPS 3.005(h) All related AMC, ACJ and IEM Inclusion of: JAA NPA-OPS 69, as AMC Changes: Based on comments received

Communication requirements

To better differentiate between the objective and method of compliance:

Training objectives, versus methods of compliance with respect to detailed items to be included in the training programme

93 20.09.2012 EHA Information Day

slide-94
SLIDE 94

SPA.HEMS

Transposition of: JAR-OPS 3.005 (d) Appendix 1 to JAR-OPS 3.005(d) All related AMC, ACJ and IEM Inclusion of: JAA HSST Working Paper HSST-WP-07-03.4 New rule on fuel policy New/amended AMC and GM material to better explain the rule, based on comments received, e.g.:

Explain ‘to afford every assistance’ in training ground emergency service personnel Possibility to train a Medical Passenger, rather then briefing before every flight Provide guidance in determining when 2 pilots should be required

94 20.09.2012 EHA Information Day

slide-95
SLIDE 95

SPA.HEMS

Changes: To better differentiate between the objective and method

  • f compliance:

Training objectives, versus methods of compliance with respect to detailed items to be included in the training programme Primary and secondary task of a HEMS technical crew member To address the remit of EASA Reference to SAR deleted

95 20.09.2012 EHA Information Day

slide-96
SLIDE 96

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO Part-CAT Part-SPA

FTL

Daniel Coutelier, EASA

On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations Overview to Regulation Air crew Final remarks 20.09.2012 EHA Information Day 96

slide-97
SLIDE 97

FTL

State of play FTL for CAT operations with aeroplanes Other FTL tasks

20.09.2012 EHA Information Day 97

slide-98
SLIDE 98

Update FTL CAT aeroplanes

20.09.2012 EHA Information Day 98

Opinion 3rd quarter 2012 Core FTL elements as in Subpart Q in IR

  • Art. 8 provisions in CS
slide-99
SLIDE 99

New elements

20.09.2012 EHA Information Day 99

New:

  • Delayed reporting
  • Standby: airport / short-call / long-call
  • Disruptive schedules

Refined:

  • Acclimatisation
  • Accommodation
  • In-flight rest facility
slide-100
SLIDE 100

Core element (1) – Flight Duty Period

20.09.2012 EHA Information Day 100

Maximum at night – 11 hours Sector reduction beyond 6th sector ‘Minimum’ maximum 9 hours

slide-101
SLIDE 101

Core element (2) – Rest

20.09.2012 EHA Information Day 101

Reduced rest 12 hrs at home base; 10 hrs

  • ut of base

Extended recovery rest increased: 2 days twice a month Extended recovery rest 60 hrs to compensate for disruptive schedules Rest to compensate for time zone crossing mirrors acclimatisation

slide-102
SLIDE 102

Core element (3) – Cumulative limits

20.09.2012 EHA Information Day 102

110 hours of duty in any 14 consecutive days 1 000 hours of flight in any 12 consecutive calendar months

2 Additional limits

slide-103
SLIDE 103

Other FTL tasks

20.09.2012 EHA Information Day 103

Publication Dates

(indicative)

TOR NPA CRD Opinion

(or Decision if only CS)

Decision after Opinion A & H EMS RMT.0346 2012 18 April 2013 Quarter 3 2014 Quarter 1 2015 Quarter 1 One year later A Air Taxi RMT.0429 2012 21 August 2014 Quarter 1 2014 Quarter 3 2015 Quarter 3 One year later H Other CAT

  • ps by H

RMT.0430 2013 Quarter 3 2015 Quarter 1 2015 Quarter 3 2016 Quarter 3 One year later

slide-104
SLIDE 104

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO Part-CAT Part-SPA FTL

On-going/future rulemaking tasks – introduction

Daniela Defossar, EASA

HEMS, PIS Offshore operations Overview to Regulation Air crew Final remarks 20.09.2012 EHA Information Day 104

slide-105
SLIDE 105

105

2012 On-going rulemaking tasks

Carriage of special categories of passengers (RMT.0269, 0270) NPA planned for 1q 2013 Sterile flight deck procedures (RMT.0416, 0417) NPA open for comments until 11 October 2012 Guidance material for development of a safety risk assessment for flight operations with known or forecast volcanic cloud contamination (RMT.0460) transposition of the related ICAO Document and work as requested by stakeholders in response to A-NPA 2011-06 leads to AMC/GM NPA open for comments until 19 October 2012

20.09.2012 EHA Information Day

slide-106
SLIDE 106

106

2012 On-going rulemaking tasks

Electronic Flight Bags (RMT.0001) NPA 2012-02 closed for comments on 18 June Comment review on-going SAFA/SACA (RMT.0385, 0435, 0441) Rule material dealing with the qualification of ramp inspectors, the approval of training organisations and the ramp inspection procedures Objective: harmonisation and standardisation of ramp inspections NPA under preparation and publication expected this year

20.09.2012 EHA Information Day

slide-107
SLIDE 107

107

2012 On-going rulemaking tasks

CRM training (RMT.0411) Review and update of material inherited from EU-OPS / JAR-OPS 3 / TGL 44 RM group has first meeting beginning of October Flights related to design and production activities (RMT.0348/0349) Terms of Reference were published and rulemaking group created Development of OPS requirements for such flights

20.09.2012 EHA Information Day

slide-108
SLIDE 108

108

2012 On-going rulemaking tasks

Updating of existing recorder installations and equipment I (RMT.0400/0401) Terms of Reference under preparation ICAO alignments CVR recording duration 2 hours; discontinuation of magnetic tape recorders Universal Locator Beacons: transmission for 90-days; carriage of low-frequency, long-range ULBs

20.09.2012 EHA Information Day

slide-109
SLIDE 109

109

2012 On-going rulemaking tasks

Helicopter HV diagram (RMT.0132, 0515) Terms of Reference under preparation To address temporary flight through the height velocity diagram

20.09.2012 EHA Information Day

slide-110
SLIDE 110

110

2012 On-going rulemaking tasks

PBN operational approvals (RMT.0256, 0257) Terms of Reference under consultation with RAG/TAG/SSCC Remove operational approvals for some PBN operations as they became common; enhance pilot training requirements instead

20.09.2012 EHA Information Day

slide-111
SLIDE 111

111

2012 On-going rulemaking tasks

MDM.097 (a) & (b) Airworthiness and operational aspects for maintenance check flights Rulemaking group concluded activity NPA open for comments until 30 October 2012

20.09.2012 EHA Information Day

slide-112
SLIDE 112

112

2012 On-going rulemaking tasks

CS supporting OSD: CS-MMEL complex, CS-Cabin crew, CS-Flight crew CRD for CS-MMEL complex open for reactions until 10 November 2012 NPA for CS-Flight crew open for comments until 8 October 2012 Decision CS-Cabin crew under preparation

20.09.2012 EHA Information Day

slide-113
SLIDE 113

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO Part-CAT Part-SPA FTL On-going/future rulemaking tasks – introduction

HEMS and PIS

Darko Vucic, EASA

Offshore operations Overview to Regulation Air crew Final remarks 20.09.2012 EHA Information Day 113

slide-114
SLIDE 114

HEMS and PIS

RMT.0325 & .0326 (OPS.057a&b) HEMS performances and public interest site Revision of the draft IR for Air Operations, Annexes I-V, and AMC/GM related to performance requirements for HEMS

  • perations in general and to performance requirements for
  • perations to and from a public interest site(s) (PIS)

ToR RMT.0325 & .0326 “HEMS performances and public interest site” with GC will be published within next few days NPA 2014/Q1, FCD 2014/Q4, Opinion with CRD 2015/Q3 HEMS – high altitude performance, mountainous area PIS – climb gradient 8%, derogation within Cover Regulation to Air Operations related to PIS

20.09.2012 EHA Information Day 114

slide-115
SLIDE 115

HEMS and PIS

Public Interest Site means a site used exclusively for operations in the public interest.

  • Art. 6.6 of drafted Regulation on Air

Operations allows Member States to derogate from the requirements for HEMS Operational base

20.09.2012 EHA Information Day 115

slide-116
SLIDE 116

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO Part-CAT Part-SPA FTL On-going/future rulemaking tasks – introduction Operations to public interest sites

Offshore operations Oyvind Friis-Ottessen, EASA

Overview to Regulation Air crew Final remarks 20.09.2012 EHA Information Day 116

slide-117
SLIDE 117

Helicopter offshore operations

20.09.2012 EHA Information Day 117

slide-118
SLIDE 118

Helicopter offshore operations

20.09.2012 EHA Information Day 118

EASA received proposal for Rulemaking regarding Offshore Helicopter Operation. A Rulemaking Task was initiated in 2011 to ensure harmonised rules at EU level for helicopter offshore operations whilst ensuring that necessary levels of safety are maintained.

slide-119
SLIDE 119

Helicopter offshore operations

Offshore

  • perations

are included in “Air Operations - OPS”

Annex I Definitions Annex IV Part-CAT Annex VI Part-NCC Annex VII Part-NCO Annex VIII Part-SPO

20.09.2012 EHA Information Day 119

slide-120
SLIDE 120

Helicopter offshore operations

20.09.2012 EHA Information Day 120

Assess which CAT IRs need amending and complementing taking into account the situation in Member States. Assess if all offshore-related provisions should be included in a new subpart of Part-SPA; thus, becoming a specific approval. Assess the risk and mitigating measures for non-commercial and specialised operations and, as appropriate, propose suitable requirements. Assess if new technology, either available or in use by some Member States, should be mandatory.

slide-121
SLIDE 121

Helicopter offshore operations

Authority oversight. Level playing field. Proportionality.

20.09.2012 EHA Information Day 121

slide-122
SLIDE 122

Helicopter offshore operations

A Notice of Proposed Amendments (NPA) shall be expected this year.

20.09.2012 EHA Information Day 122

slide-123
SLIDE 123

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO Part-CAT Part-SPA FTL On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations

Overview to Regulation Air crew

Gerda Pardatscher, EASA

Final remarks 20.09.2012 EHA Information Day 123

slide-124
SLIDE 124

Regulation aircrew

1178/2011 published 3 November 2011 Entry into force 23 November 2011 Applicable 8 April 2012 Opt-outs following Regulation 290/2012: Horizontal opt-out for all annexes till 8 April 2013 PL, As, B and Sailplanes till 8 April 2015 LAPL till 8 April 2015 Additional ratings 8 April 2015 Helicopters Section 8 Subpart J (MCCI) till 8 April 2015 Sections 10 and 11 of subpart J (MI and FTI) till 8 April 2015

20.09.2012 EHA Information Day 124

slide-125
SLIDE 125

Regulation aircrew

Opt-outs following regulation 290/2012: Point CC.GEN-030 of Annex V till 8 April 2015 ORA and ARA for ATOs for LAPL, PPL, BPL or SPL and Flight test ratings till 8 April 2015 Annex V in commercial operations by helicopters until 8 April 2015 ORA.GEN.200(a)(3) FSTD qualification no ATO and no AOC till 8 April 2014

20.09.2012 EHA Information Day 125

slide-126
SLIDE 126

Regulation aircrew

Opt-outs following regulation 290/2012: ORA and ARA to non JAR ATOs till 8 April 2014 Non JAR licences (A) and (H) till 8 April 2014 3rd country licences and medicals for non commercial till 8 April 2014 Specific medical requirements for LAPL till 8 April 2015 Medical fitness CC till 8 April 2014 Grandfather rights for JAR licences, reissued till 8 April 2018 Training to be finished before 8 April 2016

20.09.2012 EHA Information Day 126

slide-127
SLIDE 127

Regulation aircrew - ATOs

Grandfather rights for JAR-FCL ATOs Till 8 April 2014 compliance with Annex VII, (ORA) JAR RF – may continue to provide training for JAR PPL

20.09.2012 EHA Information Day 127

slide-128
SLIDE 128

Regulation aircrew - derogations

20.09.2012 EHA Information Day 128

Information to the Commission and to the Agency Implementation plan Derogation-table

www.easa.europa.eu

slide-129
SLIDE 129

Regulation aircrew – future projects

EASA - Rulemaking programme 2013-2016

20.09.2012 EHA Information Day 129

slide-130
SLIDE 130

Regulation aircrew – next steps

FCL.002 (a) and (b) Updating Annex I-III to Commission regulation laying down detailed rules for civil aviation personnel Objectives in the ToRs: To amend the Implementing Rules, their AMCs and GM of the extended Basic Regulation as regards pilot licensing: the learning objectives for the theoretical knowledge training for aeroplane and helicopter pilots the Flight Examiners Manual (aeroplanes, helicopters) validity period of theoretical knowledge examinations for IR theoretical knowledge syllabus for ATPL, CPL and IR review of prerequisites for ATPL(H)

20.09.2012 EHA Information Day 130

slide-131
SLIDE 131

Regulation aircrew – next steps

Objectives in the TORs: harmonisation of night rating requirements for aeroplanes and helicopters development of a night rating syllabus for PPL(A) content of the training flight for revalidation of class ratings to be defined review of the tables containing the requirements for skill tests and proficiency checks Instrument Rating Instructor (H) syllabus to be harmonised with the syllabus for the aeroplanes and airship category; flight time credit on Annex II aircraft class and type rating list and endorsement list

20.09.2012 EHA Information Day 131

slide-132
SLIDE 132

Regulation aircrew – next steps

Objectives in the TORs: review of Annex III to Part-FCL; editorial and clarification changes; solve implementation and transitional problems. 2011-2015

20.09.2012 EHA Information Day 132

slide-133
SLIDE 133

Regulation aircrew – future projects

FCL.006 (a) and (b) 2014-2017

20.09.2012 EHA Information Day 133

Extension of competency-based training to all licences and ratings and extension of TEM principle to all licences and ratings

slide-134
SLIDE 134

Regulation aircrew – future projects

FCL.007 (a) and (b) FSTDs 2012-2016

20.09.2012 EHA Information Day 134

Review of CS/AMC/GM to assure alignment with the new ICAO Doc. 9625, 3rd edition as a new technical basis for all international standards for new fidelity levels of Flight Simulation Training Devices (FSTDs) required to support each of the required training tasks. Also addresses SR SPAN- 2011-020.

slide-135
SLIDE 135

Regulation aircrew – future projects

FCL.008 (a) and (b) 2008-2013 (2014)

20.09.2012 EHA Information Day 135

Review of the transposed JAR- FCL requirements for the Instrument Rating in line with the wider scope of EASA compared to JARs.

slide-136
SLIDE 136

Regulation aircrew – future projects

FCL.013 ARA - ORA 2012-2014

20.09.2012 EHA Information Day 136

Updating the authority and organisations requirements pertaining to Part-FCL

slide-137
SLIDE 137

Regulation aircrew – future projects

FCL.015 (a) and (b) 2015-2017

20.09.2012 EHA Information Day 137

Review of Part-FCL and development

  • f licensing requirements for

gyroplane pilots

slide-138
SLIDE 138

Regulation aircrew – future projects

FCL.016 Additional ratings for Part-FCL licence holders 2013-2015

20.09.2012 EHA Information Day 138

Development of IR, AMC and GM for a mountain rating for helicopter pilots and a seaplane extension for LAPL(A) holders

slide-139
SLIDE 139

Outline

Introduction Overview of Regulation on Air Operations Cover Regulation OPS Part-ORO Part-CAT Part-SPA FTL On-going/future rulemaking tasks – introduction HEMS, PIS Offshore operations Overview to Regulation Air crew

Final remarks Vittorio Morassi, EHA Elisabetta Dalla Benetta, EHA Daniela Defossar, EASA

20.09.2012 EHA Information Day 139

slide-140
SLIDE 140

Summary

  • EASA supports NAAs and helicopter operators to

transition to the new harmonised European aviation safety rules
