SLIDE 1
Efficient Top-K Query Processing on Massively Parallel Hardware
ANIL SHANBHAG, HOLGER PIRK, SAM MADDEN
1
CPU
16-24 Cores Main Mem
128-256GB
GPU Mem
12-32GB
GPU
~5000 Cores
250-900 GB/s 60 GB/s 16-40 GB/s
2
Efficient Top-K Query Processing on Massively Parallel Hardware - - PowerPoint PPT Presentation
Efficient Top-K Query Processing on Massively Parallel Hardware - - PowerPoint PPT Presentation
Efficient Top-K Query Processing on Massively Parallel Hardware ANIL SHANBHAG, HOLGER PIRK, SAM MADDEN 1 CPU GPU 16-24 Cores ~5000 Cores 60 GB/s 250-900 GB/s Main Mem GPU Mem 128-256GB 12-32GB 16-40 GB/s 2 Top-K SELECT id FROM tweets
SLIDE 2
SLIDE 3
Top-K
SELECT id FROM tweets WHERE tweet_time ∈ [X,Y] ORDER BY retweet_count + 0.5*likes_count DESC LIMIT K Typical K is 5-100
3
SLIDE 4
Top-K
Classic Sequential Algorithm: Use a min-heap of size k to maintain the top-k items 7
15 20 21 50 40 32
4
SLIDE 5
Partition and Merge
Core Core Core
On Multi-core CPU: Partition data
5
Merge Results
SLIDE 6
On GPU
Does not work well on GPU execution model PROBLEMS !
- Significant thread divergence
ce
……
Warp of Threads
6
- Ma
Maintaini ning ng he heap o p of s size k k pe per t r thr hread l d limits performance ce
SLIDE 7
7
Intuition
Sort + Top-K Heap Per-Thread Radix-Select Bucket-Select
Priority Queue ??? Heap Sort Bitonic Sort
Parallel Sequential Top-K Sort
Bitonic Top-K
SLIDE 8
Bitonic Top-K
8
SLIDE 9
Bitonic Sequence
Sequence S = <a0, a1, a2 … an-1> such that
- a0 ≤ a1 ≤ .. ≤ ak
- ak+1 ≥ ak+2 ≥ ... ≥ an-1
9
Two monotonic sequences
SLIDE 10
10
S1 and S2 are both bitonic S1 < S2 : Every element in S1 is smaller than any element of S2
Bitonic Merge
Sor Sort Entire Sequenc equence e -> > log(n) r ) rounds.
S1 = <min(a0, an/2), min(a1, an/2+1), ... min(an/2-1, an-1)> S2 = <max(a0, an/2), max(a1,an/2+1), ... max(an/2-1, an-1)>
Apply recursively on S1 and S2 =>
From S1 From S2
< < <
SLIDE 11
Bitonic Sort
Phase Step
1 1 2 1 2 3 4 2 1 1 2 3 4 5 6 7
Complexity: O(n(logn)2)
11
SLIDE 12
Unsorted Sequence Finding Top-4 in 16 elements Sorted Sequences of length k Merge neighboring sorted sequences of length k To select largest k elements (bitonic sequence) Sort bitonic sequence of length k Result top-k
When list size = k
12
Phase 1 : Local Sort Phase 2: Merge Phase 3: Rebuild
Len Inc 1 1 2 1 2 2 1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
v
2 1 P2: Merge P3:Rebuild
v
P1: Local Sort P3: Rebuild
v
P2:Merge 2 2
Bitonic Top-K
Complexity: O(n(logk)2)
SLIDE 13
On the GPU
Simplest way to partition into kernels: Each column has a kernel invocation Each thread does 1 comparison n/2 comparisons needed => n/2 threads launched
Naive Sort 521ms 130ms Time to find top-32 in sequence of size 229 Final 14.5ms One Pass 10ms
13
SLIDE 14
Optimizations
14
SLIDE 15
15
Optimizations
Global Memory Shared Memory Registers
260 GBps Upto 3.5 TBps SM-1 Registers L1 SMEM SM-2 Registers L1 SMEM SM-N Registers L1 SMEM L2 Cache Global Memory Off chip On chip
SLIDE 16
Optimization 1: Using Shared Memory
- Time to find top-32 in
sequence of size 229 For thread block with T threads, load 2T elements into shared memory
16
Shared memory access Global memory access
SLIDE 17
Instead of loading 2T, lets load 8T elements and combine the 5 phases
Optimization 2: Combining Phases
- 17
Shared Memory Bandwidth Bound
Shared memory access Global memory access
SLIDE 18
Optimization 3: Combining Steps
4 2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
One step at a time Three steps at a time
- 4
2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Shared memory access
18
SLIDE 19
Optimization 4: Padding
- 1
2 3 4 5 6 7
Memory Bank Address 1 X 2 3 X 4 5 X 6 7
1 2 3 4 5 6 7
Memory Bank Address
Thread Access Unused Cell
Before Padding After Padding
2 1 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
1 3 5 7 2 4 6
19
SLIDE 20
1 2 3 4 5 6 7 Padded Cell 1 2 3 4 5 6 7
Optimization 5: Chunk Permutation
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 4
20
Step
1 2 1 4 2 1 1 2 3 4 5 6 7
Before After 17.8ms 16ms
SLIDE 21
Evaluation
21
SLIDE 22
Setup
Intel i7
16 Cores Main Mem 64GB GPU Mem 12 GB
Titan X
60 GB/s
16 GB/s
260 GB/s
22
SLIDE 23
For 2^29 (1/2 billion) floats from U(0,1)
Varying K
23
SLIDE 24
Varying Distributions
24
SLIDE 25
SELECT id FROM tweets WHERE tweet_time < X ORDER BY retweet_count DESC LIMIT 50
Integration
Dataset: 250 million tweets May 2017
4.5 x Faster
25
SLIDE 26
Conclusion
Data analytics on GPUs increasingly common and Top-K on GPU non-trivial Bitonic Top-k: Novel Top-K algorithm for GPU
- Distribution Independent
- Best performing for K <= 256
Integrated into a real database - >4x performance improvement
26
