SLIDE 1

CS4224/CS5424 Lecture 9 Distributed Query Processing

SLIDE 2

Query Processing

Translates query into a query plan that

minimizes some cost function

◮ Minimize total cost ⋆ CPU cost, I/O cost, & communication cost ◮ Minimize response time ⋆ Time elapsed for query execution CS4224/CS5424: Sem 1, 2019/20 Distributed Query Processing 2

SLIDE 3

Example

Site A: Relations R(a, c, · · · ) & S(a, · · · )
Site B: Relations T(b, c, · · · ) & U(b, · · · )
Query at Site B:

SELECT * FROM R, S, T, U WHERE R.a = S.a AND T.b = U.b AND R.c = T.c

Query Plans:

⊲ ⊳ ⊲ ⊳ R S ⊲ ⊳ T U

Site B

⊲ ⊳ ⊲ ⊳ ⊲ ⊳ R S T U

Site B

Plan 1 Plan 2

CS4224/CS5424: Sem 1, 2019/20 Distributed Query Processing 3

SLIDE 4

Example (cont.)

Cost model:

◮ JC(X,Y) = CPU & I/O cost of joining relations X & Y ◮ CC(X) = Communication cost of sending relation X from one

site to another site

◮ JC(R, S) = 2000,

JC(T, U) = 2000

◮ JC(R ⊲

⊳ S, T) = 1000, JC(R ⊲ ⊳ S ⊲ ⊳ T, U) = 600

◮ JC(R ⊲

⊳ S, T ⊲ ⊳ U) = 100, CC(R ⊲ ⊳ S) = 200

⊲ ⊳ ⊲ ⊳ R S ⊲ ⊳ T U

Site B

⊲ ⊳ ⊲ ⊳ ⊲ ⊳ R S T U

Site B

Plan 1 Plan 2

CS4224/CS5424: Sem 1, 2019/20 Distributed Query Processing 4

SLIDE 5

Example (cont.)

Cost model:

◮ JC(X,Y) = CPU & I/O cost of joining relations X & Y ◮ CC(X) = Communication cost of sending relation X from one

site to another site

◮ JC(R, S) = 2000,

JC(T, U) = 2000

◮ JC(R ⊲

⊳ S, T) = 1000, JC(R ⊲ ⊳ S ⊲ ⊳ T, U) = 600

◮ JC(R ⊲

⊳ S, T ⊲ ⊳ U) = 100, CC(R ⊲ ⊳ S) = 200

100 2000

R S

2000

T U

200

600 1000 2000

R S T U

200

Plan 1: Total Cost = 4300 Plan 2: Total Cost = 3800

CS4224/CS5424: Sem 1, 2019/20 Distributed Query Processing 5

SLIDE 6

Example (cont.)

Cost model:

◮ JC(X,Y) = CPU & I/O cost of joining relations X & Y ◮ CC(X) = Communication cost of sending relation X from one

site to another site

◮ JC(R, S) = 2000,

JC(T, U) = 2000

◮ JC(R ⊲

⊳ S, T) = 1000, JC(R ⊲ ⊳ S ⊲ ⊳ T, U) = 600

◮ JC(R ⊲

⊳ S, T ⊲ ⊳ U) = 100, CC(R ⊲ ⊳ S) = 200

100 2000

R S

2000

T U

200

600 1000 2000

R S T U

200

Plan 1: Response Time = 2300 Plan 2: Response Time = 3800

CS4224/CS5424: Sem 1, 2019/20 Distributed Query Processing 6

SLIDE 7

Query Processing Steps

Query rewriting

◮ Query decomposition ⋆ Translates query into relational algebra query ◮ Data localization ⋆ Rewrites distributed query into a fragment query

Global query optimization

◮ Finds an optimal execution plan for query

Distributed query execution

◮ Executes query plan to compute query result CS4224/CS5424: Sem 1, 2019/20 Distributed Query Processing 7

SLIDE 8

Query Decomposition

SELECT * FROM R, S WHERE R.a = S.a AND R.b = 20

− →

⊲ ⊳R.a=S.a σb=20 R S

Normalization

◮ Rewrites query into some normal form

Semantic Analysis

◮ Checks that query is semantically correct

Simplification & Restructuring

◮ Rewrites query into simpler form (e.g., eliminates redundancy) CS4224/CS5424: Sem 1, 2019/20 Query Decomposition 8

SLIDE 9

Normalization

A simple predicate defined on a relation R is of

the form “Ai op v” where Ai is an attribute of R,

p ∈ {=, =, <, ≤, >, ≥} and v ∈ Domain(Ai)
Conjunctive Normal Form (CNF)

(p11 ∨p12 · · ·∨p1n1) ∧ · · ·∧ (pm1 ∨pm2 · · ·∨pmnm)

Disjunctive Normal Form (DNF)

(p11 ∧p12 · · ·∧p1n1) ∨ · · ·∨ (pm1 ∧pm2 · · ·∧pmnm)

Each pij is a simple predicate

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Normalization 9

SLIDE 10

Review of RA Equivalence Rules

attributes(R) = Set of attributes in schema of relation R attributes(p) = Set of attributes in predicate p

1. Commutativity of binary operators

1.1 R × S ≡ S × R 1.2 R ⊲ ⊳ S ≡ S ⊲ ⊳ R

2. Associativity of binary operators

2.1 (R × S) × T ≡ R × (S × T) 2.2 (R ⊲ ⊳ S) ⊲ ⊳ T ≡ R ⊲ ⊳ (S ⊲ ⊳ T)

3. Idempotence of unary operators

3.1 πL′(πL(R)) ≡ πL′(R) if L′ ⊆ L ⊆ attributes(R) 3.2 σp1(σp2(R)) ≡ σp1∧p2(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 10

SLIDE 11

Review of RA Equivalence Rules (cont.)

4. Commutating selection with projection

4.1 πL(σp(R)) ≡ πL(σp(πL∪attributes(p)(R)))

5. Commutating selection with binary
perators

5.1 σp(R × S) ≡ σp(R) × S if attributes(p) ⊆ attributes(R) 5.2 σp(R ⊲ ⊳p′ S) ≡ σp(R) ⊲ ⊳p′ S if attributes(p) ⊆ attributes(R) 5.3 σp(R ∪ S) ≡ σp(R) ∪ σp(S)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 11

SLIDE 12

Review of RA Equivalence Rules (cont.)

6. Commutating projection with binary
perators

Let L = LR ∪ LS, where LR ⊆ attributes(R) and LS ⊆ attributes(S)

6.1 πL(R × S) ≡ πLR(R) × πLS(S) 6.2 πL(R ⊲ ⊳p S) ≡ πLR(R) ⊲ ⊳p πLS(S) if attributes(p) ∩ attributes(R) ⊆ LR and attributes(p) ∩ attributes(S) ⊆ LS 6.3 πL(R ∪ S) ≡ πL(R) ∪ πL(S)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 12

SLIDE 13

Example

Student (sid, sname, major) Course (cid, cname, area) Enrol (sid,cid, grade)

SELECT sname, cname FROM Student S, Course C, Enrol E WHERE E.sid = S.sid AND E.cid = C.cid AND major = "CS" AND area = "DB" AND grade = "F"

− →

πsname, cname σ(major=”CS”)∧(area=”DB”)∧(grade=”F”) ⊲ ⊳C.cid=E.cid Course C ⊲ ⊳E.sid=S.sid Enrol E Student S

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 13

SLIDE 14

Example (cont.)

πsname, cname σ(major=”CS”)∧(area=”DB”)∧(grade=”F”) ⊲ ⊳C.cid=E.cid Course C ⊲ ⊳E.sid=S.sid Enrol E Student S

3.2

− →

πsname, cname σmajor=”CS” σarea=”DB” σgrade=”F” ⊲ ⊳C.cid=E.cid Course C ⊲ ⊳E.sid=S.sid Enrol E Student S

σp1(σp2(R)) ≡ σp1∧p2(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 15

Example (cont.)

πsname, cname σmajor=”CS” σarea=”DB” ⊲ ⊳C.cid=E.cid Course C σgrade=”F” ⊲ ⊳E.sid=S.sid Enrol E Student S

5.2

← −

πsname, cname σmajor=”CS” σarea=”DB” σgrade=”F” ⊲ ⊳C.cid=E.cid Course C ⊲ ⊳E.sid=S.sid Enrol E Student S

σp(R ⊲ ⊳p′ S) ≡ σp(R) ⊲ ⊳p′ S if attributes(p) ⊆ attributes(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 16

Example (cont.)

πsname, cname σmajor=”CS” σarea=”DB” ⊲ ⊳C.cid=E.cid Course C σgrade=”F” ⊲ ⊳E.sid=S.sid Enrol E Student S

5.2

− →

πsname, cname σmajor=”CS” σarea=”DB” ⊲ ⊳C.cid=E.cid Course C ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E Student S

σp(R ⊲ ⊳p′ S) ≡ σp(R) ⊲ ⊳p′ S if attributes(p) ⊆ attributes(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 17

Example (cont.)

πsname, cname σmajor=”CS” ⊲ ⊳C.cid=E.cid σarea=”DB” Course C ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E Student S

5.2

← −

πsname, cname σmajor=”CS” σarea=”DB” ⊲ ⊳C.cid=E.cid Course C ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E Student S

σp(R ⊲ ⊳p′ S) ≡ σp(R) ⊲ ⊳p′ S if attributes(p) ⊆ attributes(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 18

Example (cont.)

πsname, cname σmajor=”CS” ⊲ ⊳C.cid=E.cid σarea=”DB” Course C ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E Student S

5.2

− →

πsname, cname ⊲ ⊳C.cid=E.cid σarea=”DB” Course C σmajor=”CS” ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E Student

σp(R ⊲ ⊳p′ S) ≡ σp(R) ⊲ ⊳p′ S if attributes(p) ⊆ attributes(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 19

Example (cont.)

πsname, cname ⊲ ⊳C.cid=E.cid σarea=”DB” Course C ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E σmajor=”CS” Student S

5.2

← −

πsname, cname ⊲ ⊳C.cid=E.cid σarea=”DB” Course C σmajor=”CS” ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E Student

σp(R ⊲ ⊳p′ S) ≡ σp(R) ⊲ ⊳p′ S if attributes(p) ⊆ attributes(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 20

Example (cont.)

πsname, cname ⊲ ⊳C.cid=E.cid σarea=”DB” Course C ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E σmajor=”CS” Student S

3.1

− →

πsname, cname πsname, cname, cid ⊲ ⊳C.cid=E.cid σarea=”DB” Course C ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E σmajor=” Student

πL′(πL(R)) ≡ πL′(R) if L′ ⊆ L ⊆ attributes(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 21

Example (cont.)

πsname, cname ⊲ ⊳C.cid=E.cid πcname, cid σarea=”DB” Course C πsname, cid ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E σmajor=”CS” Student S

6.2

← −

πsname, cname πsname, cname, cid ⊲ ⊳C.cid=E.cid σarea=”DB” Course C ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E σmajor=” Student

πL(R ⊲ ⊳p S) ≡ πLR(R) ⊲ ⊳p πLS(S)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 22

Example (cont.)

πsname, cname ⊲ ⊳C.cid=E.cid πcname, cid σarea=”DB” Course C πsname, cid ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E σmajor=”CS” Student S

3.1

− →

πsname, cname ⊲ ⊳C.cid=E.cid πcname, cid σarea=”DB” Course C πsname, cid πsname, cid, sid ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E σmajor=” Student

πL′(πL(R)) ≡ πL′(R) if L′ ⊆ L ⊆ attributes(R)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 23

Example (cont.)

πsname, cname ⊲ ⊳C.cid=E.cid πcname, cid σarea=”DB” Course C πsname, cid ⊲ ⊳E.sid=S.sid πcid, sid σgrade=”F” Enrol E πsname, sid σmajor=”CS” Student S

6.2

← −

πsname, cname ⊲ ⊳C.cid=E.cid πcname, cid σarea=”DB” Course C πsname, cid πsname, cid, sid ⊲ ⊳E.sid=S.sid σgrade=”F” Enrol E σmajor=” Student

πL(R ⊲ ⊳p S) ≡ πLR(R) ⊲ ⊳p πLS(S)

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 14

SLIDE 24

Example (cont.)

πsname, cname σ(major=”CS”)∧(area=”DB”)∧(grade=”F”) ⊲ ⊳C.cid=E.cid Course C ⊲ ⊳E.sid=S.sid Enrol E Student S πsname, cname ⊲ ⊳C.cid=E.cid πcname, cid σarea=”DB” Course C πsname, cid ⊲ ⊳E.sid=S.sid πcid, sid σgrade=”F” Enrol E πsname, sid σmajor=”CS” Student S

Original Query Final Query

CS4224/CS5424: Sem 1, 2019/20 Query Decomposition: Restructuring 15

SLIDE 25

Query Localization

Rewrites distributed query into a fragment query
Uses data distribution information to determine

which fragments are involved

⊲ ⊳R.a=S.a σb=20 R S

− →

∪ ⊲ ⊳ S1 σb=20 R1 ⊲ ⊳ S2 σb=20 R2

Distributed Query Fragment Query

CS4224/CS5424: Sem 1, 2019/20 Query Localization 16

SLIDE 26

Localization Program

A localization program for a fragmented relation

R is a reconstruction rule for R in terms of its fragments

Example:

◮ Let {R1, · · · , Rn} be a complete & disjoint partitioning of R ◮ If each Ri = σFi(R), then localization program for R is

R1 ∪ · · · ∪ Rn

◮ If each Ri = πLi(R) & key(R) ∈ Li, then localization program for

R is R1 ⊲ ⊳ · · · ⊲ ⊳ Rn

CS4224/CS5424: Sem 1, 2019/20 Query Localization 17

SLIDE 27

Localized Query

Localized query = query with each fragmented

relation replaced by its localization program

R1 = σa≤10(R), R2 = σa>10(R) S1 = σa≤10(S), S2 = σa>10(S) ⊲ ⊳R.a=S.a σb=20 R S

− →

⊲ ⊳R.a=S.a σb=20 ∪ R1 R2 ∪ S1 S2

Distributed Query Localized Query

CS4224/CS5424: Sem 1, 2019/20 Query Localization 18

SLIDE 28

Reduction Techniques

Reduction techniques = rewriting techniques to

simplify localized queries

Identify & eliminate query expressions on

fragments that do not contribute to query results

Techniques:

◮ Reduction for primary horizontal fragmentation ⋆ Reduction with selection ⋆ Reduction with join ◮ Reduction for derived horizontal fragmentation ◮ Reduction for vertical fragmentation ◮ Reduction for hybrid fragmentation CS4224/CS5424: Sem 1, 2019/20 Query Localization 19

SLIDE 29

Reduction with Selection

Rule 1: σp(Ri) = ∅ if Ri = σFi(R) and Fi ∧ p = false

R = R1 ∪ R2 ∪ R3 R1 = σa<10(R) R2 = σa∈[10,70](R) R3 = σa>70(R) Q1 = σa=12(R) = σa=12(R1 ∪ R2 ∪ R3) = σa=12(R1) ∪ σa=12(R2) ∪ σa=12(R3) = σa=12(R2)

CS4224/CS5424: Sem 1, 2019/20 Query Localization 20

SLIDE 30

Reduction with Join

Rule 2: Ri ⊲ ⊳a Sj = ∅ if Ri = σFa∧F(R), Sj = σF ′

a∧F ′(S),

Fa&F ′

a are predicates on attribute a, and

Fa ∧ F ′

a = false

R = R1 ∪ R2 ∪ R3 R1 = σa<10(R) R2 = σa∈[10,70](R) R3 = σa>70(R) S = S1 ∪ S2 S1 = σa<10(S) S2 = σa≥10(S)

Q = R ⊲ ⊳a S = (R1 ∪ R2 ∪ R3) ⊲ ⊳a (S1 ∪ S2) = (R1 ⊲ ⊳a S1) ∪ (R1 ⊲ ⊳a S2) ∪ (R2 ⊲ ⊳a S1) ∪ (R2 ⊲ ⊳a S2) ∪ (R3 ⊲ ⊳a S1) ∪ (R3 ⊲ ⊳a S2) = (R1 ⊲ ⊳a S1) ∪ (R2 ⊲ ⊳a S2) ∪ (R3 ⊲ ⊳a S2)

CS4224/CS5424: Sem 1, 2019/20 Query Localization 21

SLIDE 31

Reduction for Derived Fragmentation

Rule 3: Si ⊲ ⊳a Rj = ∅ if Si = S ⋉a Ri is a derived horizontal fragmentation of S wrt R, and i = j Consider R(a, b, c), S(x, y, a) where S.a is a foreign key of R

R1 = σb=10(R),

R2 = σb=10(R)

S1 = S ⋉a R1,

S2 = S ⋉a R2 Q = σb=20(R) ⊲ ⊳a S = σb=20(R1 ∪ R2) ⊲ ⊳a (S1 ∪ S2) = σb=20(R2) ⊲ ⊳a (S1 ∪ S2) = (σb=20(R2) ⊲ ⊳a S1) ∪ (σb=20(R2) ⊲ ⊳a S2) = σb=20(R2) ⊲ ⊳a S2

CS4224/CS5424: Sem 1, 2019/20 Query Localization 22

SLIDE 32

Reduction for Vertical Fragmentation

Rule 4: πL(R1 ⊲ ⊳ R2 ⊲ ⊳ · · · ⊲ ⊳ Rn) = πL(R2 ⊲ ⊳ · · · ⊲ ⊳ Rn) if R1, · · · , Rn are vertical fragments of R and (attributes(R1) − key(R)) ∩ L = ∅ Consider R(a,b,c) where R = R1 ⊲ ⊳a R2 R1 = πa,b(R) R2 = πa,c(R) Q = πc(R) = πc(R1 ⊲ ⊳a R2) = πc(R2)

CS4224/CS5424: Sem 1, 2019/20 Query Localization 23

SLIDE 33

Reduction for Hybrid Fragmentation

R = (R1 ∪ R2) ⊲ ⊳a R3 R1 = πa,b(σa<10(R)) R2 = πa,b(σa≥10(R)) R3 = πa,c(R) Q = πb(σa=20(R)) = πb(σa=20((R1 ∪ R2) ⊲ ⊳a R3) = πb(σa=20(R1 ∪ R2)) = πb(σa=20(R1) ∪ σa=20(R2)) = πb(σa=20(R2))

CS4224/CS5424: Sem 1, 2019/20 Query Localization 24

SLIDE 34

Distributed Join Strategies for R ⊲ ⊳A S

Assume that both R & S have been partitioned
ver all the nodes
Collocated/Local join Both R and S have been

partitioned on join key.

Directed join Only table R has been partitioned
n join key. Dynamically repartition S on join

key.

Broadcast join Replicate table S to all nodes.
Repartitioned join Neither of the tables has been

partitioned on join key. Repartition both tables

ver all the nodes using the join key as

partitioning key.

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 25

SLIDE 35

Join Strategies: Example

Customers (cust#, cname, city)
Orders (order#, cust#, odate)
Suppliers (supp#, sname, city)

Customers cust# cname city 1 Alice Singapore 2 Bob Penang 3 Carol Bangkok 4 Dave Singapore 5 Eve Singapore 6 Fred Penang 7 George Bangkok Orders

rder#

cust#

date

302 1 June 2013 304 2 May 2013 307 3 Nov 2013 308 1 April 2013 309 5 May 2013 311 6 Dec 2013 312 3 July 2013 Suppliers supp# sname city 32 A Bangkok 33 B Singapore 34 C Singapore 36 D Bangkok 37 E Penang 38 F Penang 39 G Singapore CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 26

SLIDE 36

Collocated Join: Example

Customers hash partitioned on cust# using hcust
Orders hash partitioned on cust# using hcust
hcust(c) = (c mod 3) + 1

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Orders1

rder#

cust#

date

307 3 Nov 2013 311 6 Dec 2013 312 3 July 2013 Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Orders2

rder#

cust#

date

302 1 June 2013 308 1 April 2013 Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Orders3

rder#

cust#

date

304 2 May 2013 309 5 May 2013 CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 27

SLIDE 37

Collocated Join: Example (cont.)

Query 1: Customers ⊲

⊳cust# Orders

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Orders1

rder#

cust#

date

307 3 Nov 2013 311 6 Dec 2013 312 3 July 2013 Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Orders2

rder#

cust#

date

302 1 June 2013 308 1 April 2013 Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Orders3

rder#

cust#

date

304 2 May 2013 309 5 May 2013

3

i=1

(Customersi ⊲ ⊳ Ordersi)

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 28

SLIDE 38

Directed Join: Example

Customers hash partitioned on cust# using hcust
Orders hash partitioned on order# using horder
hcust(c) = (c mod 3) + 1
horder(o) = (o mod 3) + 1

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Orders1

rder#

cust#

date

309 5 May 2013 312 3 July 2013 Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Orders2

rder#

cust#

date

304 2 May 2013 307 3 Nov 2013 Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Orders3

rder#

cust#

date

302 1 June 2013 308 1 April 2013 311 6 Dec 2013 CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 29

SLIDE 39

Directed Join: Example (cont.)

Query 1: Customers ⊲

⊳cust# Orders

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Orders1

rder#

cust#

date

309 5 May 2013 312 3 July 2013 Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Orders2

rder#

cust#

date

304 2 May 2013 307 3 Nov 2013 Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Orders3

rder#

cust#

date

302 1 June 2013 308 1 April 2013 311 6 Dec 2013 CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 30

SLIDE 40

Directed Join: Example (cont.)

Query 1: Customers ⊲

⊳cust# Orders

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Orders1

rder#

cust#

date

309 5 May 2013 312 3 July 2013 Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Orders2

rder#

cust#

date

304 2 May 2013 307 3 Nov 2013 Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Orders3

rder#

cust#

date

302 1 June 2013 308 1 April 2013 311 6 Dec 2013

Repartition Orders on cust# : Orders′

i = σhcust(cust#)=i(Orders)

3

i=1

(Customersi ⊲ ⊳ Orders′

i )

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 31

SLIDE 41

Broadcast Join: Example

Customers hash partitioned on cust# using hcust
Suppliers hash partitioned on supp# using hsupp
hcust(c) = (c mod 3) + 1
hsupp(s) = (s mod 3) + 1

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Suppliers1 supp# sname city 33 B Singapore 36 D Bangkok 39 G Singapore Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Suppliers2 supp# sname city 34 C Singapore 37 E Penang Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Suppliers3 supp# sname city 32 A Bangkok 38 F Penang CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 32

SLIDE 42

Broadcast Join: Example (cont.)

Query 2: Customers ⊲

⊳city Suppliers

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Suppliers1 supp# sname city 33 B Singapore 36 D Bangkok 39 G Singapore Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Suppliers2 supp# sname city 34 C Singapore 37 E Penang Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Suppliers3 supp# sname city 32 A Bangkok 38 F Penang CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 33

SLIDE 43

Broadcast Join: Example (cont.)

Query 2: Customers ⊲ ⊳city Suppliers

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Suppliers1 supp# sname city 33 B Singapore 36 D Bangkok 39 G Singapore Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Suppliers2 supp# sname city 34 C Singapore 37 E Penang Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Suppliers3 supp# sname city 32 A Bangkok 38 F Penang

Option 1: Broadcast Suppliers

3

i=1

(Customersi ⊲ ⊳ Suppliers)

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 34

SLIDE 44

Broadcast Join: Example (cont.)

Query 2: Customers ⊲

⊳city Suppliers

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Suppliers1 supp# sname city 33 B Singapore 36 D Bangkok 39 G Singapore Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Suppliers2 supp# sname city 34 C Singapore 37 E Penang Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Suppliers3 supp# sname city 32 A Bangkok 38 F Penang

Option 2: Broadcast Customers

3

i=1

(Customers ⊲ ⊳ Suppliersi)

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 35

SLIDE 45

Repartitioned Join: Example

Customers hash partitioned on cust# using hcust
Suppliers hash partitioned on supp# using hsupp
hcust(c) = (c mod 3) + 1
hsupp(s) = (s mod 3) + 1

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Suppliers1 supp# sname city 33 B Singapore 36 D Bangkok 39 G Singapore Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Suppliers2 supp# sname city 34 C Singapore 37 E Penang Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Suppliers3 supp# sname city 32 A Bangkok 38 F Penang CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 36

SLIDE 46

Repartitioned Join: Example (cont.)

Query 2: Customers ⊲

⊳city Suppliers

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Suppliers1 supp# sname city 33 B Singapore 36 D Bangkok 39 G Singapore Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Suppliers2 supp# sname city 34 C Singapore 37 E Penang Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Suppliers3 supp# sname city 32 A Bangkok 38 F Penang CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 37

SLIDE 47

Repartitioned Join: Example (cont.)

Query 2: Customers ⊲

⊳city Suppliers

Repartition both tables using hcity

c hcity(c) Singapore 1 Penang 2 Bangkok 3

Customers′

i = σhcity(city)=i(Customers)

Suppliers′

i = σhcity(city)=i(Suppliers)

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 38

SLIDE 48

Repartitioned Join: Example (cont.)

Query 2: Customers ⊲ ⊳city Suppliers

Site 1 Customers1 cust# cname city 3 Carol Bangkok 6 Fred Penang Suppliers1 supp# sname city 33 B Singapore 36 D Bangkok 39 G Singapore Site 2 Customers2 cust# cname city 1 Alice Singapore 4 Dave Singapore 7 George Bangkok Suppliers2 supp# sname city 34 C Singapore 37 E Penang Site 3 Customers3 cust# cname city 2 Bob Penang 5 Eve Singapore Suppliers3 supp# sname city 32 A Bangkok 38 F Penang

3

i=1

(Customers′

i ⊲

⊳ Suppliers′

i )

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 39

SLIDE 49

Comparison of join strategies for R ⊲ ⊳ S

Let the relations be partitioned over n nodes Join Strategy Communication Cost Collocated Directed size(R) if R is being repartitioned Broadcast (n − 1) × size(R) if R is being broadcast Repartitioned size(R) + size(S)

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies 40

SLIDE 50

Query Processing in Google’s F1

Google’s early NewSQL system

◮ Distributed relational database system ◮ Hybrid of NoSQL & RDBMS ◮ NoSQL: High availability, scalability ◮ RDBMS: Consistency, usability

Used by Google’s AdWords system since 2012

◮ 100s of applications & 1000s of users ◮ Database is over 100 TB, 105 requests/sec CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies: Google’s F1 41

SLIDE 51

Query Processing in Google’s F1

SELECT agc.CampaignId, ac.Region, c.Language, SUM(ac.Clicks) FROM AdClick ac JOIN AdGroupCreative agc USING (AdGroupId, CreativeId) JOIN Creative c USING (CustomerId, CreativeId) WHERE c.Date = ’2013-02-23’ GROUP BY agc.CampaignId, ac.Region, c.Language

Creative (CreativeId, CustomerId, Language, ...) AdgroupCreative (AdGroupId, CreativeId, CampaignId, CustomerId, ...) Adclick (AdGroupId, CreativeId, Region, Date, Clicks, ...)

(Shute, et al., 2013)

CS4224/CS5424: Sem 1, 2019/20 Distributed Join Strategies: Google’s F1 42

SLIDE 52

References

T. Özsu & P

. Valdureiz, Overview of Query Processing, Chapter 6, Principles of Distributed Database Systems, 3rd Edition, 2011

T. Özsu & P

. Valdureiz, Query Decomposition and Data Localization, Chapter 7, Principles of Distributed Database Systems, 3rd Edition, 2011

C. Baru, et al. DB2 Parallel Edition, IBM Systems Journal,

34(2), 1995.

Google goes back to the future with SQL F1 database,

The Register, August 2013, https://www.theregister.co.uk/2013/08/30/google_f1_deepdive/

F1: A Distributed SQL Database That Scales, VLDB

2013, https://research.google.com/pubs/pub41344.html

CS4224/CS5424: Sem 1, 2019/20 Distributed Query Processing 43
